Desa LMFP33NR Quick start guide

Save this manual for future reference.
For more information, visit www.desatech.com
WARNING: If the information in this manual is not
followedexactly,afireorexplosionmayresultcausing
property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vaporsandliquidsinthevicinityofthisoranyother
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediatelycallyourgassupplierfromaneighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installationandservicemustbeperformedbyaquali-
fied installer, service agency, or the gas supplier.
UNVENTED (VENT-FREE) GAS FIREPLACE
OWNER’S OPERATION AND INSTALLATION MANUAL
LMFP33NR/LMFP33PR REMOTE CONTROL
GAS FIREPLACE SYSTEMS
Shown with optional cabinet mantel and hearth base accessories.
Patent Pending

www.desatech.com 111604-01E
2
WARNING: Improper installation, adjustment, altera-
tion, service, or maintenance can cause injury or prop-
ertydamage.Refertothismanualforcorrectinstallation
and operational procedures. For assistance or addi-
tional information consult a qualified installer, service
agency, or the gas supplier.
WARNING: This is an unvented gas-fired heater. It uses
air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air
must be provided. Refer to Air for Combustion and
Ventilation section on page 5 of this manual.
This appliance may be installed in an aftermarket,*
permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the
manufacturer
TABLE OF CONTENTS
Safety Information ............................................... 3
Product identification........................................... 4
Local Codes ........................................................ 5
Unpacking ........................................................... 5
Product Features ................................................ 5
Air for Combustion and Ventilation...................... 5
Installation ........................................................... 8
Operating Heater .............................................. 19
Inspecting Burners ............................................ 22
Cleaning and Maintenance ............................... 23
Troubleshooting ................................................ 24
Specifications .................................................... 28
Wiring Diagram ................................................. 28
Technical Service .............................................. 28
Service Hints ..................................................... 28
Replacement Parts ........................................... 28
Accessories....................................................... 29
Illustrated Parts Breakdown and Parts List ....... 30
Warranty Information.......................... Back Cover

www.desatech.com
111604-01E 3
SAFETY INFORMATION
WARNING:Thisproductcon-
tainsand/orgenerateschemicals
known to the State of California
to cause cancer or birth defects,
or other reproductive harm.
IMPORTANT:Readthisowner’s
manualcarefullyandcompletely
beforetryingtoassemble,oper-
ate, or service this heater. Im-
proper use of this heater can
cause serious injury or death
fromburns,fire,explosion,elec-
trical shock, and carbon mon-
oxide poisoning.
DANGER:Carbonmonoxide
poisoning may lead to death!
Carbon Monoxide Poisoning: Early signs of car-
bon monoxide poisoning resemble the flu, with
headaches, dizziness, or nausea. If you have these
signs, the heater may not be working properly. Get
fresh air at once! Have heater serviced. Some
people are more affected by carbon monoxide than
others.Theseinclude pregnantwomen,people with
heart or lung disease or anemia, those under the
influence of alcohol, and those at high altitudes.
Naturaland Propane/LPGas:Natural andpropane/
LP gases are odorless. An odor-making agent is
added to the gas. The odor helps you detect a gas
leak. However, the odor added to the gas can fade.
Gas may be present even though no odor exists.
Make certain you read and understand all warn-
ings. Keep this manual for reference. It is your
guide to safe and proper operation of this heater.
WARNING: Any change to
thisheateroritscontrolscanbe
dangerous.
WARNING: Do not use a
blower insert, heat exchanger
insert, or other accessory not
approvedforusewiththisheater.
WARNING:Donotallowfans
toblowdirectlyintothefireplace.
Avoidanydraftsthatalterburner
flame patterns. Ceiling fans can
create drafts that alter burner
flame patterns. Altered burner
patterns can cause sooting.
Due to high temperatures, the
applianceshouldbelocatedout
of traffic and away from furni-
ture and draperies.
Do not place clothing or other
flammable material on or near
the appliance. Never place any
objects on the heater.
Fireplace and screen become
veryhotwhenrunningfireplace.
Keep children and adults away
fromhotsurfacestoavoidburns
or clothing ignition. Fireplace
will remain hot for a time after
shutdown. Allow surfaces to
cool before touching.
Carefully supervise young chil-
dren when they are in the room
with fireplace. When using the
optional hand-held remote ac-
cessory,keepselectorswitchin
theOFFpositiontopreventchil-
dren from turning on burners
with remote.
You must operate this fireplace
with the fireplace screen and
hood in place. Make sure fire-
place screen and hood are in
place before running heater.
Keep the appliance area clear
and free from combustible ma-
terials,gasoline,andotherflam-
mable vapors and liquids.

www.desatech.com 111604-01E
4
SAFETY INFORMATION
Continued
1. This appliance is only for use with the type of
gas indicated on the rating plate. This appli-
anceis notconvertible foruse withother gases.
2. Do not place propane/LP supply tank(s) in-
side any structure. Locate propane/LP supply
tank(s) outdoors (propane/LP units only).
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not
use any phone in your building
• immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions
• if you cannot reach your gas supplier, call
the fire department
4. This fireplace shall not be installed in a bed-
room or bathroom.
5. Do not use this fireplace as a wood-burning
fireplace. Use only the logs provided with the
fireplace.
6. Do not add extra logs or ornaments such as
pine cones, vermiculite, or rock wool. Using
these added items can cause sooting. Do not
add lava rock around base. Rock and debris
could fall into the control area of fireplace.
7. To prevent the creation of soot, follow the
instructions in Cleaning and Maintenance,
page 23.
8. Before using furniture polish, wax, carpet
cleaner, or similar products, turn heater off. If
heated, the vapors from these products may
create a white powder residue within burner
box or on adjacent walls or furniture.
9. This fireplace needs fresh air ventilation to run
properly. This fireplace has an Oxygen Deple-
tion Sensing (ODS) safety shutoff system. The
ODS shuts down the fireplace if enough fresh
airis notavailable.SeeAirforCombustionand
Ventilation,pages 5through7.If fireplacekeeps
shutting off, see Troubleshooting, pages 24
through 27.
10. Do not run fireplace
• where flammable liquids or vapors are used
or stored
• under dusty conditions
11. Do not use this fireplace to cook food or burn
paper or other objects.
12. Donotusefireplaceif anyparthasbeenexposed
to or under water. Immediately call a qualified
service technician to inspect the fireplace and to
replace any part of the control system and any
gas control which has been under water.
13. Do not operate fireplace if any log is broken.
Do not operate fireplace if a log is chipped
(dime-sized or larger).
14. Turn fireplace off and let cool before servic-
ing. Only a qualified service person should
service and repair fireplace.
15. Operating fireplace above elevations of 4,500
feet could cause pilot outage.
16. Topreventperformanceproblemsinpropane/LP
units, do not use propane/LP fuel tanks of less
than 100 lbs. capacity (propane/LP units only).
17. Provideadequateclearancesaroundairopenings.
PRODUCT
IDENTIFICATION
Figure 2 - Fireplace
(VYGF33PRA Shown)
Figure 1 - Log Base Assembly
O
F
F
P
I
L
O
T
O
N
5-Piece
Log Set
Remote
Receiver
Piezo
Ignitor
Remote Control
Control
Knob
Top Louver
Assembly
Firebox
Hood
Bottom Louver
Assembly
Screen
Assembly
Top Outer Casing
Firebox
Support
Blower
Assembly
(Optional)

www.desatech.com
111604-01E 5
LOCAL CODES
Install and use fireplace with care. Follow all lo-
cal codes. In the absence of local codes, use the
latest edition of TheNational Fuel GasCodeANSI
Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
Note: Where listed vented decorative logs are re-
quired, thermostat operation is not permitted.
UNPACKING
CAUTION: Do not remove
the data plates attached to the
heater base assembly. The data
plates contain important war-
ranty and safety information.
1. With utility knife, cut the carton all the way
around above the staples on the bottom tray.
Lift the carton off the heater. Remove pack-
ing. Note: The hood is located in the packing
on the right hand side of the heater front. Lift
the heater off the bottom tray.
2. Locate two screws above top corners of the
fireplace screen. Remove and discard these
screws. Lift fireplace screen up and pull out
to remove.
3. Remove protective packaging applied to logs,
log base assembly, and fireplace.
4. Remove fireplace hood from carton insert.
5. Check all items for any shipping damage. If
damaged, promptly inform dealer where you
bought fireplace.
PRODUCT FEATURES
OPERATION
Thisvent-free fireplaceis cleanburning. Itrequires
no outside venting. There is no heat loss out a vent
or up a chimney. Heat is generated by both realis-
tic flames. When used without the blower, the fire-
place requires no electricity making it ideal for
emergency backup heat. This heater is designed
for vent-free operation. It has been tested and ap-
proved to ANSI Z21.11.2 standard for unvented
heaters. State and local codes in some areas pro-
hibit the use of vent-free heaters.
SAFETY DEVICE
This fireplace has a pilot with an Oxygen Deple-
tion Sensing (ODS) safety shutoff system. The
ODS/pilot is a required feature for vent-free room
heaters. The ODS/pilot system shuts off the fire-
place if there is not enough fresh air.
PIEZO IGNITION SYSTEM
This fireplace has a piezo ignitor. This system re-
quires no matches, batteries, or other sources to
light fireplace.
OPTIONAL BLOWER ASSEMBLY
(GA3700 SERIES & GA3700TA
SERIES)
This fireplace accepts an optional blower assem-
bly (not included). The GA3700TASeries blower
operates thermostatically and features a variable
speed control. The GA3700 Series blower oper-
ates manually and also features a variable speed
control. The blower circulates heated air from the
fireplace into the room. See Accessories, page 29.
AIR FOR COMBUSTION
AND VENTILATION
WARNING: This heater shall
notbeinstalledinaconfinedspace
or unusually tight construction
unless provisions are provided
foradequatecombustionandven-
tilation air. Read the following in-
structions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
Today’s homes are built more energy efficient than
ever. New materials, increased insulation, and new
construction methods help reduce heat loss in
homes. Home owners weather strip and caulk
around windows and doors to keep the cold air out
and the warm air in. During heating months, home
owners want their homes as airtight as possible.
While it is good to make your home energy effi-
cient, your home needs to breathe. Fresh air must
enter your home.All fuel-burning appliances need
fresh air for proper combustion and ventilation.
Exhaust fans, fireplaces, clothes dryers, and fuel
burning appliances draw air from the house to
operate. You must provide adequate fresh air for
these appliances. This will insure proper venting
of vented fuel-burning appliances.

www.desatech.com 111604-01E
6
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Section 5.3,Air
for Combustion and Ventilation.
All spaces in homes fall into one of the three fol-
lowing ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 5 through 7 will help
you classify your space and provide adequate
ventilation.
Unusually Tight Construction
The air that leaks around doors and windows may
provide enough fresh air for combustion and ven-
tilation. However, in buildings of unusually tight
construction,you must provideadditional freshair.
Unusually tight construction is defined as
construction where:
a. walls and ceilings exposed to the out-
side atmosphere have a continuous
water vapor retarder with a rating of one
perm (6 x 10-11 kg per pa-sec-m2) or less
with openings gasketed or sealed and
b. weather stripping has been added on
openable windows and doors and
c. caulking or sealants are applied to ar-
eas such as joints around window and
door frames, between sole plates and
floors, between wall-ceiling joints, be-
tween wall panels, at penetrations for
plumbing, electrical, and gas lines, and
at other openings.
If your home meets all of the three criteria
above, you must provide additional fresh
air. See Ventilation Air From Outdoors ,
page 7.
If your home does not meet all of the three
criteria above, proceed to Determining
Fresh-Air Flow For Heater Location .
Confined and Unconfined Space
The National Fuel Gas Code, ANSI Z223.1/
NFPA 54 defines a confined space as a space
whose volume is less than 50 cubic feet per 1,000
Btu per hour (4.8 m3per kw) of the aggregate in-
put rating of all appliances installed in that space
and an unconfined space as a space whose vol-
ume is not less than 50 cubic feet per 1,000 Btu
per hour (4.8 m3per kw) of the aggregate input
rating of all appliances installed in that space.
Rooms communicating directly with the space in
which the appliances are installed*, through open-
ings not furnished with doors, are considered a
part of the unconfined space.
*Adjoiningroomsare communicatingonly ifthere
are doorless passageways or ventilation grills be-
tween them.
DETERMINING FRESH-AIR FLOW
FOR FIREPLACE LOCATION
Determining if You Have a Confined or
Unconfined Space
Use this work sheet to determine if you have a
confined or unconfined space.
Space: Includes the room in which you will install
fireplace plus any adjoining rooms with doorless pas-
sageways or ventilation grills between the rooms.
1. Determine the volume of the space (length x
width x height).
Length x Width x Height =__________cu. ft.
(volume of space)
Example: Space size 20 ft. (length) x 16 ft.
(width)x 8ft. (ceiling height)= 2,560 cu.ft. (vol-
ume of space)
If additional ventilation to adjoining room is sup-
plied with grills or openings, add the volume of
these rooms to the total volume of the space.
2. Multiply the space volume by 20 to determine
the maximum Btu/Hr the space can support.
__________ (volume of space) x 20 = (Maxi-
mum Btu/Hr the space can support)
Example: 2,560 cu. ft. (volume of space) x 20 =
51,200 (maximum Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in
the space.
Vent-free fireplace _________ Btu/Hr
Gas water heater* _________ Btu/Hr
Gas furnace _________ Btu/Hr
Vented gas heater _________ Btu/Hr
Gas fireplace logs _________ Btu/Hr
Other gas appliances* + ________ Btu/Hr
Total = ________ Btu/Hr
* Do not include direct-vent gas appliances. Di-
rect-ventdraws combustion airfrom the outdoors
and vents to the outdoors.
AIR FOR COMBUSTION
AND VENTILATION
Continued

www.desatech.com
111604-01E 7
Example:
Gas water heater _____________ Btu/Hr
Vent-free fireplace _____________ Btu/Hr
Total _____________ Btu/Hr
4. Compare the maximum Btu/Hr the space can
support with the actual amount of Btu/Hr used.
________
Btu/Hr(maximum thespacecansupport)
________ Btu/Hr(actualamount of Btu/Hr used)
Example: 51,200 Btu/Hr (maximum the space
can support)
73,000 Btu/Hr (actual amount of
Btu/Hr used)
The space in the example is a confined space because
the actual Btu/Hr used is more than the maximum
Btu/Hr the space can support. You must provide ad-
ditional fresh air. Your options are as follows:
A. Rework worksheet, addingthespace of an adjoin-
ing room. If the extra space provides an uncon-
finedspace,removedoor to adjoining roomoradd
ventilation grills between rooms. See Ventilation
Air From Inside Building.
B. Vent room directly to the outdoors. See Ventila-
tion Air From Outdoors.
C. Install a lower Btu/Hr fireplace, if lower Btu/Hr
size makes room unconfined.
If the actual Btu/Hr used is less than the maximum
Btu/Hr the space can support, the space is an un-
confined space. You will need no additional fresh
air ventilation.
WARNING: If the area in
which the heater may be oper-
atedissmallerthanthatdefined
asan unconfinedspaceorifthe
building is of unusually tight
construction, provide adequate
combustion and ventilation air
byoneofthemethodsdescribed
in the National Fuel Gas Code,
ANSI Z223.1/NFPA 54 Section
5.3 or applicable local codes .
40,000
33,000
73,000
AIR FOR COMBUSTION
AND VENTILATION
Continued
Figure 4 - Ventilation Air from Outdoors
Figure 3 - Ventilation Air from Inside
Building
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining un-
confined space. When ventilating to an adjoining
unconfined space, you must provide two perma-
nent openings: one within 12" of the ceiling and
one within 12" of the floor on the wall connecting
the two spaces (see options 1 and 2, Figure 3).
You canalso removedoor into adjoiningroom (see
option 3, Figure 3). Follow the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, Section 5.3,Air for
Combustion and Ventilation for required size of
ventilation grills or ducts.
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation grills
or ducts. You must provide two permanent open-
ings: one within 12" of the ceiling and one within
12" of the floor. Connect these items directly to
the outdoors or spaces open to the outdoors. These
spaces include attics and crawl spaces. Follow the
National Fuel Gas Code, ANSI Z223.1/NFPA 54,
Section 5.3, Air for Combustion and Ventilation
for required size of ventilation grills or ducts.
IMPORTANT: Do not provide openings for inlet
or outlet air into attic if attic has a thermostat-con-
trolled power vent. Heated air entering the attic
will activate the power vent.

www.desatech.com 111604-01E
8
INSTALLATION
NOTICE:Thisheaterisintended
for use as supplemental heat.
Use this heater along with your
primary heating system. Do not
install this heater as your pri-
mary heat source. If you have a
centralheatingsystem,youmay
run system’s circulating blower
whileusingheater.Thiswillhelp
circulatetheheatthroughoutthe
house. In the event of a power
outage, you can use this heater
as your primary heat source.
WARNING: A qualified ser-
vice person must install fire-
place. Follow all local codes.
WARNING: Never install the
fireplace
•in a bedroom or bathroom
•in a recreational vehicle
•where curtains, furniture,
clothing or other flammable
objectsarelessthan42inches
from the front, top or sides of
the heater
•in high traffic areas
•in windy or drafty areas
CAUTION:Thisfireplacecre-
ates warm air currents. These
currents move heat to wall sur-
faces next to fireplace. Install-
ingfireplacenexttovinylorcloth
wall coverings or operating
heater where impurities (such
as, but not limited to, tobacco
smoke,aromaticcandles,clean-
ingfluids,oilorkerosenelamps,
etc.) in the air exist, may dis-
color walls or cause odors.
Note: Your fireplace is designed to be used in zero
clearance installations. Wall or framing material
can be placed directly against any exterior surface
on the rear, sides, or top of your fireplace, except
where standoff spacers are integrally attached. If
standoff spacers are attached to your fireplace,
these spacers can be placed directly against wall
or framing materials.
Use the dimensions shown for rough openings to
create the easiest installation. See Built-In Fire-
place Installation, pages 11 through 13.
IMPORTANT: Vent-free heaters add moisture to
the air.Although this is beneficial, installing fire-
place in rooms without enough ventilation air may
cause mildew to form from too much moisture.
See Air for Combustion and Ventilation, pages 5
through 7. IMPORTANT: Make sure the fireplace
is level. If fireplace is not level, log set will not
work properly.
CHECK GAS TYPE
Use the correct gas type (natural or propane/LP)
for your fireplace. If your gas supply is not cor-
rect, do not install fireplace. Call dealer where you
bought fireplace for proper type fireplace.
ELECTRICAL HOOKUP
(Models GA3700 Series and GA3700T
Series Blower Accessories, and GA3555
Internal Duplex Kit)
This fireplace accepts a blower assembly with an
electrical cord. The electrical cord is five feet in
length. You must locate fireplace within reach of
a 120 volt grounded electrical outlet. If not, you
mustinstall an electricaloutlet withinreach offire-
place power cord. The GA3555 outlet accessory
is used for built-in applications with blower ac-
cessory installed.
INSTALLING HOOD
Install hood to top of firebox as shown in Figure 5.
Use 3 Phillips screws provided
Figure 5 - Installing Hood to Firebox

www.desatech.com
111604-01E 9
Figure 6 - Assembling Brass Trim
Side Brass
Trim
Slot
Mitered
Edge
Slot Shim
Set Screws
Adjusting
Plate
Trim
Hanging
Screws
Assembled
Brass Trim
Hanging
Notches
on Trim
ASSEMBLING AND ATTACHING
OPTIONAL BRASS TRIM
(Included with Mantel Accessory)
IMPORTANT: If you are recessing the firebox in a
wall,donotattachbrasstrimatthistime.Seepage10.
Note :The instructions below show assembling
and attaching brass trim to fireplace.
1. Removepackagingfromthreepiecesofbrasstrim.
2. Locatefourbrassscrews,twoadjustingplateswith
setscrews,andtwoshimsinthehardwarepacket.
3. Align shim under adjusting plate as shown in
Figure 6.
4. Slide oneend of adjustingplate/shim in sloton
mitered edge of top brass trim (see Figure 6).
5. Slide other end of adjusting plate/shim in slot on
mitered edge of side brass trim (see Figure 6).
6. While firmly holding edges of brass trim to-
gether, tighten both set screws on the adjust-
ing plate with slotted screwdriver.
7. Repeat steps 1 through 6 for other side.
8. Tighten trim hanging screws (#10 x 6.25 shoul-
der) into holes in cabinets. Place the assembled
trimontofireplacecabinet.Alignhangingnotches
on trim with hanging screws on side of fireplace
(see Figure 7). Push trim firmly into place, slid-
ing hanging notches over hanging screws.
Top Brass
Trim
INSTALLATION
Continued
Figure 7 - Attaching Brass Trim to
Fireplace
INSTALLATION CLEARANCES
WARNING: Maintain the
minimumclearances.Ifyoucan,
providegreaterclearancesfrom
floor,ceiling,andadjoiningwall.
Carefully follow the instructions below. This will
ensure safe installation.
Minimum Clearances For Side
Combustible Material, Side Wall, and
Ceiling
A. Clearances from the side of the fireplace cabi-
net to any combustible material and wall
should follow diagram in Figure 8.
Example:The faceof a mantel,bookshelf, etc.
ismade of combustiblematerial and protrudes
3 1/2" from the wall. This combustible mate-
rial must be 4" from the side of the fireplace
opening (see Figure 8).
B. Clearancesfromthetop ofthe fireplaceopening
to the ceiling should not be less than 42 inches.
*
Example
MINIMUM CLEARANCE TO
COMBUSTIBLE MATERIALS
Top Left and Bottom
Right Sides and Rear
42" 16" 0"
Figure 8 - Minimum Clearance for
Combustible to Wall
*Minimum 16 inches from Side Wall

www.desatech.com 111604-01E
10
CONVENTIONAL FIREPLACE
INSTALLATION
Conventionalinstallation of thisfireplace involves
installing fireplace along with the corner, face, or
cabinetmantel withhearth baseaccessories against
a wall in your home. Follow the instructions be-
low to install the fireplace in this manner.
Note: The instructions in this section show instal-
lation using the cabinet mantel and hearth base
accessories. The hearth base accessory shown is
optional for this installation. You can install fire-
place and cabinet mantel directly on the floor.
1. Assemble cabinet mantel, hearth base, and
trimaccessories.Assembly instructionsare in-
cluded with each accessory.
2. When installing blower, install a properly
grounded, 120 volt three-prong electrical out-
let at fireplace location if an outlet is not there.
Ifpossible, locate outletso cabinet mantelwill
cover it when installed (see Figure 9).
3. Install gas piping to fireplace location. This
installation includes an approved flexible gas
line(if allowed bylocal codes)after the equip-
ment shutoff valve. The flexible gas line must
be the last item installed on the gas piping.
See Installing Gas Piping to Fireplace Loca-
tion, pages 13 and 14.
4. Place hearth base accessory against wall at
installation location. Cut an access hole in
hearth top to run flexible gas line to fireplace
(seeFigure 9). Makesure to locateaccess hole
so cabinet mantel will cover it when installed.
Note: You can secure base to floor using wood
screws.Countersinkscrewheadsandputty over.
5. Route flexible gas line through access hole in
hearth base.
6. Center cabinet mantel on hearth base (see Fig-
ure10). Makesure mantelis flushagainst wall.
7. Break off nailing flanges (see Figure 11) with
hammer or pliers.
INSTALLATION
Continued
8. Place cardboard or other protective material
on top of hearth base. Carefully set fireplace
on protective material, with back of fireplace
inside mantel opening.
9. Attach flexible gas line from fireplace gas
regulator to gas supply. See Connecting Fire-
place to Gas Supply, page 13.
10. If blower is installed, route blower electrical
cord through access holes in either side of fire-
place.
Note: Bushing may be moved if neces-
sary. Plug electrical cord into electrical outlet.
11. Carefully insert fireplace into cabinet mantel.
Becarefulnot toscratchor damagehearthbase,
cabinet mantel, or any laminate trim on hearth
base. Remove protective material from top of
hearthbase andfrom frontof fireplace (ifany).
Note: You can secure fireplace to hearth or
floor. Open lower louver. Locate screw holes
inbottomofbase.Tightenwoodscrews through
these holes and into hearth or floor.
12. Check all gas connections for leaks. See
Checking Gas Connections, pages 16 and 17.
Figure 10 - Installing Cabinet Mantel
Cabinet
Mantel
Figure 11 - Location of Nailing Flanges
Nailing
Flanges
Electrical Outlet
Rigid Gas Line Gas Line
Access
Hole
Figure 9 - Placing Hearth Base
Accessory Against Wall
Hearth
Base
