NATURAL GAS BURNER SYSTEM MODEL (F)SDVBNC
PROPANE/LP GAS BURNER SYSTEM MODEL (F)SDVBPC
REMOTE READY
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediatelycallyourgassupplierfromaneighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire
department.
WARNING: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Refer to this
manual for correct installation and
operational procedures. For assis-
tanceoradditionalinformationcon-
sult a qualified installer, service
agency, or the gas supplier.
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
FOR YOUR SAFETY
Donotstoreorusegasolineorotherflammablevapors
andliquidsinthe vicinity of this or any other appliance.
— Installation and service must be
performed by a qualified installer,
serviceagency,orthegas supplier.
IMPORTANT: This direct-vent burner system must be installed into approved cast iron stove
bodies, models SCIVFC/PSCIVFC series and PFC series ONLY.
This appliance may be installed in an aftermarket*, permanently located manufactured (mo-
bile) home, where not prohibited by state or local codes.
— This appliance is only for use with
the type of gas indicated on the rating
plate.Thisapplianceisnotconvertible
for use with other gases, unless a
certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
TM
CAST IRON STOVE AND DIRECT-VENT
(FREESTANDING FIREPLACE HEATER)
BURNER SYSTEM
OWNER’S OPERATION AND INSTALLATION MANUAL
Save this manual for future reference.
Save this manual for future reference.
For more information, visit www.desatech.com
For more information, visit www.desatech.com
SCIVFC/PSCIVFC
SERIES STOVE PFC SERIES STOVE

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
2
SAFETY INFORMATION
IMPORTANT: Read this owner’s manual carefully
andcompletelybeforetryingtoassemble,operate,or
service this stove and burner system. Improper use
of this stove and burner system can cause serious
injuryordeathfromburns,fire,explosions,electrical
shock, and carbon monoxide poisoning.
WARNINGS
1. This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases unless a certified kit is used.
2. For propane/LP burner system, do notplace propane/LP supply
tank(s) inside any structure. Locate propane/LP supply tank(s)
outdoors. To prevent performance problems, do not use pro-
pane/LP fuel tank of less than 100 lbs. capacity.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not use any phone in
your building
• immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions
• if you cannot reach you gas supplier, call the fire department.
4. Never install the stove
• in a recreational vehicle
• where curtains, furniture, clothing, or other flammable ob-
jects are less than 42" from the front, top, or sides of the stove
• in high traffic areas
• in windy or drafty areas
5. This stove reaches high temperatures. Keep children and adults
awayfrom hotsurfaces toavoid burnsorclothingignition.Stove
will remain hot for a time after shut-down. Allow surfaces to
cool before touching.
6. Carefully supervise young children when they are in the room
with stove.
WARNING: Any change to this stove or burner
system or its controls can be dangerous.
DANGER: Carbon monoxide poisoning may lead
to death!
Thisappliancecomplies withthe current ANSI Z21.88and CSA 2.33
as a Vented Gas Fireplace Heater and is listed and tested by the
CanadianStandardsAssociationtotheaboveteststandards.Thisstove
with burner system is a vented product. This stove with burner system
will not produce any gas leakage into your home if properly installed.
Thisstovewithburnersystemmust beproperlyinstalledbyaqualified
serviceperson.Theglassdoormustbeproperlyseatedandsealed.Ifthis
unit is not properly installed by a qualified service person with glass
door properly seated and sealed, gas leakage can occur.
CarbonMonoxidePoisoning:Earlysignsofcarbonmonoxidepoison-
ing resemble the flu, with headaches, dizziness, or nausea. If you have
thesesigns,thestovemaynothavebeeninstalledproperly.Getfreshair
atonce!Havestoveinspectedandservicedbyaqualifiedserviceperson.
Some people are more affected by carbon monoxide than others. These
include pregnant women, people with heart or lung disease or anemia,
those under the influence of alcohol, and those at high altitudes.
Propane/LP gas and natural gas are both odorless. An odor-making
agentisaddedtoeachofthesegases.Theodorhelpsyoudetectagas
leak. However, the odor added to these gases can fade. Gas may be
present even though no odor exists.
TABLE OF CONTENTS
SAFETY INFORMATION
TABLE OF CONTENTS
SAFETY INFORMATION ........................................................... 2
PRODUCT IDENTIFICATION ..................................................... 3
LOCAL CODES........................................................................... 4
PRODUCT FEATURES .............................................................. 4
GLOSSARY OF TERMS............................................................. 4
PRE-INSTALLATION PREPARATION ........................................ 4
CAST IRON STOVE AND DIRECT-VENT
BURNER SYSTEM ASSEMBLY ................................................. 5
GENERAL VENTING ................................................................ 10
VENTING INSTALLATION ........................................................ 12
STOVEAND DIRECT-VENT BURNER SYSTEM
INSTALLATION ......................................................................... 20
OPERATING STOVE WITH BURNER SYSTEM...................... 26
INSPECTING BURNERS.......................................................... 28
CLEANING AND MAINTENANCE ............................................ 29
TROUBLESHOOTING .............................................................. 30
REPLACEMENT PARTS .......................................................... 33
TECHNICAL SERVICE ............................................................. 33
WIRING DIAGRAM ................................................................... 33
SERVICE HINTS....................................................................... 33
SPECIFICATIONS .................................................................... 34
ACCESSORIES ........................................................................ 35
ILLUSTRATED PARTS BREAKDOWN AND PARTS LIST ....... 36
WARRANTY INFORMATION....................................... Back Page
Make certain you read and understand all warnings. Keep this
manual for reference. It is your guide to safe and proper operation
of this stove and burner system.

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
3
3
P
I
L
O
T
L
O
H
I
OFF
ON
SAFETY INFORMATION
Continued
PRODUCT IDENTIFICATION
Figure 1 - DESA Direct-Vent Burner System Shown Installed in
Approved Cast Iron Stove Body (Vanguard Models SCIVFC/
PSCIVFC Series Shown)
7. Do not modify the burner or stove under any circumstances.Any
parts removed for servicing must be replaced prior to operating
stove or burner system.
8. Turn burner system off and let cool before servicing, installing, or
repairing. Only a qualified service person should install, service, or
repair the stove or burner system. Have burner system inspected
annually by a qualified service person.
9. You must keep control compartments, burners, and circulat-
ing air passages clean. More frequent cleaning may be needed
due to excessive lint and dust from carpeting, bedding mate-
rial, pet hair, etc. Turn off the gas valve and pilot light before
cleaning stove or burner system.
10. Have venting system inspected annually by a qualified service
person. If needed, have venting system cleaned or repaired.
See Cleaning and Maintenance, page 29.
11. Keep the area around your stove clear of combustible materi-
als, gasoline, and other flammable vapor and liquids. Do not
run burner system where these are used or stored. Do not place
items such as clothing or decorations on or around stove.
12. Do not use this stove to cook food or burn paper or other objects.
13. Never place anything on top of stove.
14. Do not use any solid fuels (wood, coal, paper, cardboard, etc.)
in this stove. Use only the gas type indicated on burner system
nameplate.
15. This appliance, when installed, must be electrically grounded
inaccordancewith local codesor,in theabsenceof local codes,
with the National Electrical Code, ANSI/NFPA 70, or the Ca-
nadian Electrical Code, CSA C22.1.
16. Do not obstruct the flow of combustion and ventilation air in
any way. Provide adequate clearances around air openings into
the combustion chamber along with adequate accessibility
clearance for servicing and proper operation.
17. Do not install stove directly on carpeting, vinyl tile, or any com-
bustiblematerialother thanwood.Thestove mustset onametal
or wood panel extending the full width and depth of the stove.
18. Do not use stove or burner system if any part has been ex-
posed to or under water. Immediately call a qualified service
person to arrange for replacement of the unit.
19. Do not operate burner system if any log is broken.
20. Do not use a blower insert, heat exchanger insert, or other ac-
cessory not approved for use with this stove.
21. Donot operateburnersystemwithglass doorremoved, cracked,
or broken.
22. Provide adequate clearances to air openings.
SAFETY INFORMATION
PRODUCT IDENTIFICATION
Cast Iron
Stove Body
Piezo Ignitor Control Valve
Log Set
Blower with
Adjustment
Knob (Optional
Installation)
Lava Rock
Pilot
Assy
Burner
Vent
Opening
Glass
Door Assy
Glowing
Embers
Grate Assembly
Rear
Cover
Cast Iron
Stove Body
ON/OFF
Switch
(Other
Side)

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
4
LOCATION AND SPACE REQUIREMENTS
Determine the safest and most efficient location for your cast iron
stove. Make sure that rafters and wall studs are not in the way of the
venting system. Choose a location where the heat output is not
affected by drafts, air conditioning ducts, windows, or doors. Figure
2showssomecommonlocations.Readallventinginformationinthis
manual. Be aware of all restrictions and precautions before deciding
the exact location for your stove.
When deciding the location of your stove, follow these rules:
1. Do not connect this stove and burner system to a chimney flue
serving a separate solid-fuel burning fireplace or appliance.
2. Due to high temperatures, do not locate this stove in high traf-
fic areas or near furniture or draperies.
PRE-INSTALLATION
PREPARATION
On Wall with
Horizontal Termination
On Wall with Vertical
Termination Through Ceiling Corner Installation
Figure 2 - Common Stove Locations
WARNING: A qualified service person must in-
stallstoveand burnersystem.Followalllocal codes.
CAUTION: This stove creates warm air currents.
These currents move heat to wall surfaces next to
stove. Installing stove next to vinyl or cloth wall
coverings or operating stove where impurities (such
as, but not limited to, tobacco smoke, aromatic
candles, cleaning fluids, oil or kerosene lamps, etc.)
in the air exist, may discolor walls or cause odors.
LOCAL CODES
Install and use stove and burner system with care. Follow all local
codes. In the absence to local codes, use the current National Fuel
Gas Code ANS Z223.1/NFPA 54* (USA) or the current CSA-
B149[.1 or .2] Installation Codes (Canada).
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
PRODUCT FEATURES
OPERATION
This cast iron stove with burner system is clean burning and vents
easily through outside walls or vertically using outside air for
combustion.Heatis generatedby bothrealistic flamesandglowing
embers. When used without the blower accessory, the stove with
burnersystemrequires noelectricitymaking itidealfor emergency
backup heat.
PIEZO IGNITOR
This burner system has a piezo ignitor. This system requires no
matches, batteries, or other sources to light burner system.
GLOSSARY OF TERMS
Chase - A box-like enclosure to protect venting from the elements
when the venting run is on the outside of a structure.
Mastic - A pliable sealant for use around the vent terminal.
Snorkel Termination -A box thatraises the horizontaltermination
above ground level clearances.
Vent Termination - Mounted on an outside wall or roof to separate
the inlet and outlet of the vent system and protect it from weather.
VinylSidingStandoff-Ametalboxthatseparatestheventcapfrom
vinyl siding.
Wall Thimble/Firestop - A metal plate used to secure the vent pipe
when it passes through a wall or ceiling.
LOCAL CODES
PRODUCT FEATURES
Operation
Piezo Ignitor
GLOSSARY OF TERMS
PRE-INSTALLATION PREPARATION
Location and Space Requirements

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
5
5
6 "
4 "
Front
4"
36"
from
Front
42"
Ceiling
Floor
from
Back
Wall
29"
4"
4"
Figure 3 - Clearances for Standard Installation
Figure4-ClearanceforCornerInstallation
Figure 5 - Stove With Burner System Bottom Dimensions
26 1/4"
19 1/2"
Front
3. Proper clearances must be maintained, see Figures 3 and 4.
4. This stove is a freestanding unit designed to set directly on the
floor. If your stove is to be installed directly on carpeting, vi-
nyl tile, or any combustible material other than wood, it must
be installed on a metal or wood panel extending the full width
and depth of the stove. See Figure 5.
PRE-INSTALLATION
PREPARATION
Continued
STOVE BODY ASSEMBLY
1. Lift off corrugated box enclosing stove body crating.
2. Remove allscrews fastening thewood frame enclosure.Spread
woodframeopen andlift away fromplastic-bagged stovebody.
The bottom pieces of pallet wood will remain bolted to the
stove body.
3. Remove plastic bag from stove body.
4. Locate the product identification label on the back panel (see
figure 6) and record the model number and 7 digit serial num-
ber in the space provided in the back of this owner’s manual.
Retain this operation and installation manual for future refer-
ence and warranty.
5. Remove the six (6) bolts on the back stove panel with an ad-
justable wrench or a 10 mm socket. Discard the back panel
and retain the bolts and washers to attach the rear cover pro-
vided with the burner system.
Figure 6 - Removing Back Panel
Bolt
Product
Identification
Label
Back Stove
Panel
CAST IRON STOVE AND
DIRECT-VENT BURNER
SYSTEM ASSEMBLY
PRE-INSTALLATION PREPARATION
Location and Space Requirements (Cont.)
CAST IRON STOVE AND DIRECT-VENT BURNER SYSTEM ASSEMBLY
Stove Body Assembly (Cont.)
27"

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
6
Figure 10 - Attaching Stove Legs
Bottom Of
Stove Unit
Leg
Bolt
Washers
6. Remove allcontents from insidestove cavity.Contents include:
(1) - Stove bottom (Discard - Not used with this application)
(4) - Legs with leg leveler bolts
(1) - Bottom door
(3) - Top grates
(1) - Hardware kit bag with fasteners
7. Carefully lay stove body on back to attach bottom components to
stove body (see Figure 7). Rest stove on drop cloth or blanket to
avoid scratching stove edges.
8. Remove remaining pallet wood attached to bottom of stove
body (see Figure 8). Use an adjustable wrench to remove bolts.
9. Fasten each leg to stove with four (4) M8 x 1.25 - 20mm bolts.
Use a flat washer and lock washer with each bolt. Tighten bolts
into threaded holes on stove body (see Figures 9 and 10). Use
an adjustable wrench or a 12mm and 6mm socket.
10. Attachstove doorby insertingstep boltthrough doorhinge pivot
hole and into threaded hole in stove body (Figure 11 on page 7
and Figure 9). Use an adjustable wrench or a 12mm socket to
fasten step bolt. Tighten step bolt until snug. Make sure door
moves freely.
11. Installdoor catch bolt(M8 x 1.25-55mmwithtwo M8hexnuts)
into threaded hole on stove body (see Figure 9). Use an adjust-
able wrench or a 12mm socket. The catch bolt has two hex nuts
attached to it (see Figure 12, page 7). The top nut is a bolt stop
and the bottom nut is for door leveling adjustment.
12. Check general catch bolt alignment with door claw. Make
final adjustment and door leveling after stove is in normal
standing position.
13. Carefully lift stove back up on its four attached legs.
14. Remove 2 bolts from bottom of stove and discard. Remove
bolt from the top of the stove to remove the front panel assem-
bly (see Figure 13, page 7).
CAST IRON STOVE AND
DIRECT-VENT BURNER
SYSTEM ASSEMBLY
Continued
Figure 7 - Laying Down Stove On Side
Figure8-RemovingPalletWoodFromTheBottomofTheStove
Pallet
Wood
Bolt Pallet
Wood
Bottom Of
Stove Unit
Front
Pallet
Wood
Bolted to
Bottom of
Stove Body
Front of
Stove
Unit
Top of Stove Unit
Front of
Stove Unit Top of
Stove
Unit
Drop
Cloth/
Blanket
Figure9-LocatingThreadedHolesforLegsandDoorAttachment
Door Hinge Step
Bolt Hole
Door Catch Bolt
With Adjustable
Hex Nuts Hole
Leg Hole
Leg Hole
Leg Hole
Front
Bottom of
Stove Unit
CAST IRON STOVE AND DIRECT-VENT BURNER SYSTEM ASSEMBLY
Stove Body Assembly (Cont.)

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
7
7
CAST IRON STOVE AND
DIRECT-VENT BURNER
SYSTEM ASSEMBLY
Continued
Adjusting Nut
Bolt Stop
Catch Bolt
Door Claw
Door
Figure 12 - Catch Bolt and Door Claw Orientation
14. Lay the front panel assembly face down on a protected sur-
face. Remove the two screws that hold the front plate onto the
front surround plate (see Figure 14). Save these screws.
15. Optional: Remove the seven screws and washers that hold the
screenonto thefront surroundplate. Discardthese screws,wash-
ers, and screen. They are for vent-free use only (see Figure 14).
16. Replace the two screws from step 14 to reassemble the front
plate and the front surround plate. Set this assembly aside un-
til burner system has been installed, logs have been placed
inside of burner system, and glass door to burner system insert
has been replaced.
Figure 11 - Attaching Lower Stove Door Panel
Stove Door
Panel
Door Hinge
Step Bolt
Threaded
Hole
Bolt
Shoulder
Figure 13 - Removing Front Assembly
Front
Assembly
Bolt
Stove
Body
Figure 14 - Removing Screen from Front Assembly
Screws
Front Surround
Plate
Front Plate
Screen
Screw with
Washer
CAST IRON STOVE AND DIRECT-VENT BURNER SYSTEM ASSEMBLY
Stove Body Assembly (Cont.)

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
8
NOTICE: If installing blower in an existing stove
burner system with gas connections, shut off gas
supply and disconnect heater from gas supply. Con-
tact a qualified service person to do this.
INSTALLING OPTIONAL BLOWER
ACCESSORY
INSTALLING THE BLOWER
1. Remove 4 hex screws securing rear cover to back of stove body
(see Figure 16).
2. Separate bottom cover from rear cover by loosening the 8
mounting screws (see Figure 16).
3. Align the holes in the top mounting tabs of blower with the
holes in wall of rear cover. Using the 4 screws provided, mount
blower and tighten screws securely (see Figure 17).
Figure 17 - Blower Assembly, Speed Control, and Thermal
Switch Locations
Figure16-RemovingRearCoverandBottomCoverfromStove
Body
Speed
Control
Blower
Control
Knob Locknut
Blower
Assembly
Thermal
Switch and
Bracket
Control
Shaft TOP VIEW
Stove Body
Rear Cover
Bottom Cover
Hex
Screws
Mounting
Screws
Mounting
Screws
Hex Screws Mounting
Screws
Mounting Holes
Screws
Mounting
Holes
INSTALLING DIRECT-VENT BURNER
SYSTEM INTO STOVE BODY
1. Carefully lift burner system and place into stove body from
the rear of stove.
2. Place the left and right grate tops into the top of stove body. Dis-
card center grate top of stove and replace with center grate top
provided with burner system.
Figure 15 - Installing Burner System Into Cast Iron Stove Body
L
O
H
I
P
I
L
O
T
OFF
ON
Cast Iron
Stove Body
Burner
System
Right Top
Grate
Center Top Grate
(Included with
Burner System)
Left Top
Grate
CAST IRON STOVE AND
DIRECT-VENT BURNER
SYSTEM ASSEMBLY
Continued
CAST IRON STOVE AND DIRECT-VENT BURNER SYSTEM ASSEMBLY
Installing Direct-Vent Burner System Into Stove Body
Installing Optional Blower Accessory

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
9
9
CAST IRON STOVE AND
DIRECT-VENT BURNER
SYSTEM ASSEMBLY
Continued
4. Thermostat Blower Only: Attach thermal switch and bracket
to inside rear cover wall with two hex head screws provided as
showninFigure 17,page 8.After securingbracket torearcover,
carefully bend along existing bend line on bracket to almost a
90°angle(see Figure17, page8).This willallow thermalswitch
to be positioned against stove rear wall and sense temperature
when in operating mode.
5. Place speed control on left inside of rear cover and push the
plastic control shaft through opening (see Figure 17, page 8).
6. While supporting speed control, secure control shaft with lock nut
by pushing and turning lock nut with pliers clockwise until tight
againstthesideofrearcover.Placecontrolknobprovidedontoshaft.
7. Place the green ground wire between the bottom hole on the
blower assembly and the hex screw and tighten (see Figure 18).
8. Connect the blue wire on the blower assembly to one side of
the thermal switch (see Figure 18).
9. Connect the black wire to the other side of the thermal switch
(see Figure 18).
10. Connect the white wire to the other terminal on the blower mo-
tor assembly (see Figure 18). Make sure the thermal switch has
been properly installed to fit against back of fireplace insert af-
ter the rear cover assembly has been reinstalled.
11. Make sure all wire connections to terminals on blower motor
and thermal switch are securely attached and that the screw
retaining the green ground wire is tight.
Green Ground Wire
Wiring
Diagram
Decal
Speed
Control
Black
Wire
White
Wire
Blue Wire
Power Cord (Route Through
Plastic Bushing in Bottom
Cover When Assembled)
Screw
Thermal
Switch
WARNING: Nevertouchtheblowerwheelwhilein
operation.
WARNING: Failure to position the parts in accor-
dance with supplied diagrams or failure to use only
partsspecificallyapprovedwiththisheatermayresult
in damage or personal injury.
Figure 18 - Blower Wiring Layout (Thermostat Blower Shown)
12. Check to make sure that the power cord is completely clear of the
blowerwheelandthat therearenoforeignobjects inblowerwheel.
13. Peel off the backing paper and stick the supplied wiring dia-
gram decal on the inside of rear cover as shown (see Figure 18).
14. Reattach bottom cover to rear cover with 8 screws (see Figure
16, page 8). Make sure that you don’t pinch any wires during
reassembly. Route power cord through plastic bushing in bot-
tom of rear cover.
CAST IRON STOVE AND DIRECT-VENT BURNER SYSTEM ASSEMBLY
Installing Optional Blower Accessory (Cont.)
Installing Rear Cover
INSTALLING REAR COVER
1. Place rear cover behind stove body. Rear cover will rest on the
bottom ledge of the stove body.
2. Place wire harness from ON/OFF switch under the cast of
stove body.
3. Using hex screws provided, attach rear cover to back of stove
body. See Figure 19. IMPORTANT: This rear cover must be
securely in place before venting pipes are installed.
Rear Cover
(Shown with
Optional
Blower)
Hex Screws
Blower
Power
Cord
ON/OFF
Switch Wire
Harness
ON/OFF Switch
Figure 19 - Installing Rear Cover (Shown with Optional Blower
Accessory)

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
10
LOCATION OF VENT TERMINATION
When locating vent termination, it is important to observe the
minimum clearances shown in Figure 21, page 11.
*Check with local codes or with the current CAN/CSA B149[.1 or
.2] Installation Codes for Canada or the USA Installations follow
the current National Fuel Gas Code, ANSI Z223.1/NFPA 54.
Your stove with burner system is approved to be vented either
through the side wall, or vertically using the following guidelines:
• Use only venting components or kits specifically approved for
use with this stove and burner system (see Parts Lists for Vent-
ing Kits and Components, page 19).
IMPORTANT: Do not mix venting components made by differ-
ent manufacturers.
• Minimum clearance between vent pipes and combustible mate-
rials is 1" (25 mm), except where stated otherwise.
• Do not recess venting terminations into a wall or siding.
• Install horizontal venting with a 1/4" rise for every 12" of
run toward the termination.
• You may paint the vent termination with 450ºF (232ºC) heat-
resistant paint to coordinate with the exterior finish.
• There must not be any obstruction such as bushes, garden sheds,
fences, decks, or utility buildings within 24" from the front of
the termination cap.
• Do not locate termination cap where excessive snow or ice build
up may occur. Be sure to clear vent termination area after snow
falls to prevent accidental blockage of venting system. When
using snow blowers, do not direct snow towards vent termina-
tion area.
• You must maintain minimum wall and ceiling clearances shown
in Figures 3 and 4, page 5.
• If installing horizontal vent termination cap on an exterior wall
with siding, you must us a vinyl siding standoff (see Figure 27,
page 14).
GENERAL VENTING
Figure 20 - Control Valve Terminals
To Control
Switch
CAST IRON STOVE AND
DIRECT-VENT BURNER
SYSTEM ASSEMBLY
Continued
CAST IRON STOVE AND DIRECT-VENT BURNER SYSTEM ASSEMBLY
Installing Rear Cover (Cont.)
GENERAL VENTING
Location of Vent Termination
4. Open lower door panel. The valve is attached to the underside
of the burner system assembly.
5. Connect one terminal of the wire from ON/OFF switch to the
THTP terminal on the valve. Connect remaining wire terminal to
the TH terminal on the valve. Make sure that the wire terminals
are in the positions on the unit as pictured in Figure 20. If wires
are not connected as shown, the ON/OFF switch will not work.
14. Connect or reconnect gas supply, see Connecting Stove/Burner
System to Gas Supply on page 21.
WARNING: A qualified installer or service per-
sonmustconnectfireplace togassupply.Followall
local codes.

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
11
11
Fixed
Closed Openable Fixed
Closed
Openable
V
V
V
V
VV
V
V
X
X
VX
G
G
J
F
B
B
K
N
H
I
A
N
E
L
D
B
M
A
C
B
V
V
A
G
G
B
TERMINATION CAP AIR SUPPLY INLET GAS METER RESTRICTED AREA
(TERMINATION PROHIBITED)
A = clearance above grade, veranda, porch, deck, or balcony
[*12 inches (305mm) minimum]
B = clearance to window or door that may be opened
[12 inches (305mm) minimum]
C = clearance to permanently closed window [minimum 12 inches
(305mm) recommended to prevent condensation on window]
D = vertical clearance to ventilated soffit located above the terminal
within a horizontal distance of 24 inches (610mm) from the
center-line of the terminal [18 inches (457mm) minimum]
E = clearance to unventilated soffit [12 inches (305mm) minimum]
F = clearance to outside corner (see below)
G = clearance to inside corner (see below)
H = *not to be installed above a meter/regulator assembly within
36 inches (914mm) horizontally from the center-line of the regulator
I = clearance to service regulator vent outlet [*72 inches (1829mm)
minimum]
J = clearance to non-mechanical air supply inlet to building or the
combustion air inlet to any other fireplace [*12 inches (305mm)
minimum]
K = clearance to a mechanical air supply inlet [*72 inches (1829mm)
minimum]
L = † clearance above paved side-walk or a paved driveway located on
public property [*84 inches (2133mm) minimum]
M = clearance under veranda, porch, deck [*12 inches (305mm) minimum ‡]
N = clearance above a roof shall extend a minimum of 24 inches (610mm)
above the highest point when it passes through the roof surface and
any other obstruction within a horizontal distance of 18 inches (457mm)
† vent shall not terminate directly above a side-walk or paved driveway which is located between two
single family dwellings and serves both dwellings*
‡ only permitted if veranda, porch, deck or balconey is fully open on a minimum of 2 sides beneath the floor*
* as specified in CAN/CSA B149 (.1 or .2) Installation Codes (1991) for Canada and U.S.A.
Note : Local codes or regulations may require different clearances
A = 6" (152mm)
Inside Corner
V
B
E
V
B = 6" (152mm)
C = Maximum depth of 48" (1219mm) for
recessed location
D = Minimum width for back wall of
recessed location -
Combustible - 38" (965mm)
Noncombustible - 24" (610mm)
E = Clearance from corner in
recessed location-
Combustible - 6" (152mm)
Noncombustible - 2" (51mm)
Outside Corner Recessed Location
G
H
G = 12" (305mm) minimum clearance
Balcony with No SideWall
V
J
Combustible &
Noncombustible
H = 24" (610mm)
J = 20" (508mm)
Balcony with Perpendicular Side Wall
CDC
Termination Clearances for Buildings with Combustible and Noncombustible Exteriors
Figure 21 - Minimum Clearances for Vent Terminations
GENERAL VENTING Continued
GENERAL VENTING

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
12
WARNING: Read all instructions completely and
thoroughly before attempting installation. Failure to
dosocould resultinserious injury,propertydamage
or loss of life. Operation of improperly installed and
maintained venting system could result in serious
injury, property damage or loss of life.
WARNING: Seal all vent connections. Seal only
the outer pipe connections with high temperature
silicone (600°F/316°C). Before joining elbows and
pipes, apply a bead of high temperature silicone
sealant (GE RTV 106/Loctite RTV 81585) to the male
end of the elbow or pipe. High temperature silicone
must also be used to re-seal any connections after
maintenance to venting system.
NOTICE: Failure to follow these instructions will void
the warranty.
INSTALLATION PRECAUTIONS
Consult local building codes before beginning the installation. The
installer must make sure to select the proper vent system for installa-
tion. Before installing vent kit, the installer must read this stove and
burner system manual and vent kit instructions.
Only a qualified service person should install venting system. The
installer must follow these safety rules:
• Wear gloves and safety glasses for protection
• Use extreme caution when using ladders or when on roof tops
• Be aware of electrical wiring locations in walls and ceilings
Thefollowingactionswillvoidthewarrantyonyourventingsystem:
• Installation of any damaged venting component
• Unauthorized modification of the venting system
• Installationofany componentpartnot manufacturedorapproved
by DESA International
• Installation other than as instructed by these instructions
VENTING INSTALLATION
WARNING:Thisstovewithburnersystemandvent
assembly must be vented directly to the outside. The
ventingsystemmustNEVERbeattachedtoachimney
serving a separate solid fuel burning appliance. Each
gasappliancemustuseaseparateventsystem.Donot
use common vent systems.
WARNING: Horizontal sections of this vent system
require a minimum clearance of 2" from the top of the
pipe and 1" minimum to the sides and bottom. Vertical
sections of this system require a minimum of 1" clear-
ance to combustible materials on all sides of the pipe.
INSTALLATION PLANNING
There are two basic types of direct-vent installation:
• Horizontal Termination
• Vertical Termination
It is important to select the proper length of vent pipe for the type of
terminationyouchoose.Itisalsoimportanttonotethewallthickness.
For Horizontal Termination: Select the amount of vertical rise
desired. The horizontal run of venting must have 1/4" rise for every
12" of run towards the termination.
You may use up to two 90°elbows on any single horizontal run of
vent pipe in this confuguration. See Horizontal Termination Con-
figurations on page 15.
For Vertical Termination: Measure the distance from the burner
systemflueoutlettotheceiling.Addtheceilingthickness,thevertical
rise in an attic or second story, and allow for sufficient vent height
above the roofline. You may use one or two 90°elbows in this vent
configuration. See Vertical Termination Configurations on pages 17
and 19.
Note: You may use two 45°elbows in place of a 90°elbow. You
must follow rise to run ratios when using 45°elbows.
Fortwo-storyapplications,firestopsarerequiredateachfloorlevel(see
Figure33,page16).Ifanoffsetisneededintheattic,additionalpipeand
elbows will be required.
Youmayuse a chasewith a venttermination with exposedpipeon the
exterior of the house. See Installing Vent System in a Chase, page 13.
Your stove with direct-vent burner system has been tested for a
maximumhorizontal runof 20'with8'verticalrise (seeInstallation
for Horizontal Termination, pages 13 through 15). The maximum
vertical run is 40' (see Installation for Vertical Termination, pages
16 through 19).
It is very important that the venting system maintain its balance
between the combustion air intake and the flue gas exhaust. Certain
limitationsapplytoventconfigurationsandmustbestrictlyfollowed.
WARNING:Neverrunthevent pipedownwardas
this may cause excessive temperatures which could
cause a fire.
VENTING INSTALLATION
Installation Precautions
Installation Planning

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
13
13
INSTALLATION FOR HORIZONTAL
TERMINATION
1. Determine the route your horizontal venting will take. Note:
The location of the horizontal vent termination on the exterior
wall must meet all local and national building codes and must
not be easily blocked or obstructed.
Snorkel terminations are available for terminations requiring a
vertical rise on the exterior of the building (see Figures 22 and
23). Snorkel kit VKS-47-K is also available (see page 19). Fol-
low the same installation procedures used for standard horizon-
tal termination with the exception of the external wall firestop.
The snorkel termination does not require the use of the exter-
nal wall firestop. If installing the snorkel termination below
grade (basement applications), you must provide proper drain-
age to prevent water from entering the snorkel termination (see
Figure 23). Do not back fill around the snorkel termination.
2. Vent pipes and fittings have special twist-lock connections.As-
semble the desired combination of pipe and elbows to the appli-
ance adaptor with pipe seams oriented towards the wall or floor.
Twist-lock Procedure: The female ends of the pipes and fit-
tings have four locking lugs (indentations). These lugs will
slide straight into matching slots on the male ends of adjacent
pipes and fittings. (All connections must be sealed with high
temperature silicone sealant as specified in the second warn-
ing statement on page 12.) Push the pipe sections together and
twist one section clockwise approximately one-quarter turn
until the sections are fully locked. See Figure 24. Note: Hori-
zontal runs of vent must be supported every three feet. Use
wall straps for this purpose.
VENTING INSTALLATION
Continued
WARNING:Donotrecessventterminalintoawall
or siding.
Figure 22 - Snorkel Termination
Snorkel
Figure 23 - Snorkel Termination with Drainage Pipe
12" Minimum
(305mm)
NOTICE: Treatment of firestops and construction of
the chase may vary from building type to building
type. These instructions are not substitutes for the
requirements of local building codes. You must fol-
low all local building codes.
Note: When installing in a chase, you should insulate the chase as
you would the outside walls of your home. This is especially
important in cold climates. Minimum air space clearance between
vent pipes and combustible materials and/or insulation is 1".
Installing Vent System in a Chase
Achaseisaverticalbox-likestructurebuilttoencloseventingthatruns
alongtheoutsideofabuilding.Achaseisnotrequiredforsuchventing.
Snorkel
Adequate
drainage
12" Minimum
(305mm)
Figure 24 - Vent Pipe Connections
Female
Locking Lugs
Male
Slots
Vent Pipe
VENTING INSTALLATION
Installation Planning (Cont.)
Installation for Horizontal Termination

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
14
VENTING INSTALLATION
Continued
Figure 26 - Installing Horizontal Vent Cap with Exterior Wall
Firestop (Combustible Exterior)
WARNING: Do not recess vent termination in to
any wall. This will cause a fire hazard.
Figure 27 - Installing Vinyl Siding Standoff
Cut Vinyl Siding
Away to Fit
Standoff
Vinyl Siding Standoff
(Apply Mastic to All
Four Sides)
7
1
/ 2 "
(190mm)
Vent Opening
Noncombustible Wall
(Framing
Detail)
10"
(254mm)
10"
(254mm)
Vent Opening
Combustible Wall
Vent O
p
ening
Figure 28 - Interior Wall Firestop
Interior Wall
Firestop
Exterior Wall Firestop
(Apply Mastic to All
Four Sides)
Vent
Termination
Vent
Termination
Interior Wall
Firestop
Interior Wall
Firestop
Vent
Termination Horizontal
Vent Pipe
3. Attach vent pipe assembly to the burner system. Set stove in
front of it’s permanent location to insure minimum clearances.
Mark the wall for a 10" square hole (for noncombustible ma-
terial such as masonry block or concrete, a 7 1/2" diameter hole
is acceptable). See Figure 25. The center of the hole should
line up with the center-line of the horizontal vent pipe. Cut a
10"x10" (254mm x 254mm) square hole through combustible
exterior wall (7 1/2"[190mm] diameterhole if noncombustible).
Frame as necessary (see Figure 25).
4. ForCombustibleExterior:Apply abeadof non-hardeningmas-
tic around the outside edge of the exterior wall firestop. Posi-
tion the external wall firestop withinthe 10" square opening on
the exterior wall with firestop flanges inside the opening. At-
tach using screws provided as shown in Figure 26. Position
the vent termination in the center of exterior wall firestop with
arrow on termination pointing up.
For Noncombustible Exterior: Apply a bead of non-harden-
ing mastic around the outside edge of the vent termination.
The exterior wall firestop will not be necessary for this appli-
cation. Position the termination cap in the center of the 7 1/2"
hole on exterior wall with arrow on termination pointing up.
Attach the vent termination with four wood screws supplied
(see Figure 26). Note : Replace the wood screws with appropri-
ate fasteners for stucco, brick, concrete, or other types of siding.
5. Use of a vinyl siding standoff is required when vinyl siding,
cedar shake, or other painted wood surfaces could melt, peel,
or discolor from trapped or wind driven flue exhaust (exces-
sive heat) near vent termination. The vinyl siding standoff re-
places the outer firestop between the vent termination and the
exterior wall to protect these exterior wall treatments. Bolt the
vent cap to the standoff. Apply non-hardening mastic around
outside edge of the standoff. Position standoff within the 10"
square opening on theexterior wall. Use wood screws provided
to attach the standoff. See Figure 27.
6. Slide the interior wall firestop over the vent pipe before con-
necting the horizontal run to the vent cap (see Figure 28).
7. Carefully move the stove with vent assembly attached toward
the wall and insert the vent pipe into the horizontal termina-
tion. The pipe overlap should be a minimum of 1 1/4". Apply
silicone to the outer pipe connection. Fasten all vent connec-
tions with screws provided.
8. Slide the interior wall firestop against the interior wall surface
and attach with screws provided (see Figure 28).
Figure 25 - Vent Opening Requirements
VENTING INSTALLATION
Installation for Horizontal Termination (Cont.)

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
15
15
Venting withTwo 90°Elbows
Vertical (V) Horizontal (H1) +
Horizontal (H2)
6' min. 4' max.
7' min. 6' max.
8' min. 10' max.
20' max. 12' max.
Figure 31 - Horizontal Termination Configuration for Venting
Using Two 90 ° Elbows with Termination at 90 ° with Stove
Figure29-HorizontalTerminationConfiguration
for Venting Using One 90
° Elbow
Horizontal Venting
Vertical (V) Horizontal (H)
52" min. 26" max.
63" min. 49" max.
86" min. 96" max.
91" min. 20' max.
.
Horizontal Termination Configurations
Figures 29 through 31 show different configurations for venting
with horizontal termination. Each figure includes a chart with
vertical minimum/maximum and horizontal maximum dimensions
which must be met. Seal all connections with high temperature
siliconesealant (outerpipeonly) asspecifiedinthesecondwarning
statementonpage12.Allhorizontalpipingrunsrequire1/4"riseper
12" of horizontal run.
Venting withTwo 90°Elbows
Vertical (V) Horizontal (H1) Horizontal (H1) +
Horizontal (H2)
6' min. 4' max. 8' max.
7' min. 6' max. 12' max.
8' min. 8' min. 20' max.
20' max. 8' max. 20' max.
Figure 30 - Horizontal Termination Configuration for Venting Using Two 90 ° Elbows
VENTING INSTALLATION
Continued
P47-12
P47-12
VENTING INSTALLATION
Installation for Horizontal Termination (Cont.)

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
16
1. Determine the route your vertical venting will take. If ceiling
joists, roof rafters, or other framing will obstruct the venting
system, consider an offset (see Figure 32) to avoid cutting
loadbearing members. Note: Pay special attention to these in-
stallationinstructions forrequiredclearances (airspace) tocom-
bustibleswhen passingthroughceilings,walls,roofs, enclosures,
attic rafters, etc. Do not pack air spaces with insulation. Also
notemaximum vertical riseof theventing systemandany maxi-
mum horizontal offset limitations. Offsets must fall within the
parameters shown in Figures 36 through 38, pages 17 and 18.
2. Set the stove in desired location. Drop a plumb line down from
the ceiling to the position of the burner system exit flue. Mark
the center point where the vent will penetrate the ceiling. Drill
a small locating hole at this point.
Drop a plumb line from the inside of the roof to the locating
hole in the ceiling. Mark the center point where the vent will
penetrate the roof. Drill a small locating hole at this point.
Flat Ceiling Installation
1. Cut a 10" square hole in the ceiling using the locating hole as a
centerpoint.The openingshouldbe framedto 10"x10"(254mm
x 254mm) inside dimensions, as shown in Figure 25 on page
14 using framing lumber the same size as the ceiling joists. If
the area above the ceiling is an insulated ceiling or a room, nail
firestop from the top side. This prevents loose insulation from
falling into the required clearance space. Otherwise, install
firestopbelow theframedhole.The firestopshould beinstalled
with no less than three nails per side (see Figure 33).
2. Assemble the desired lengths of pipe and elbows necessary
to reach from the burner system flue up through the firestop.
All connections must be sealed with high temperature sili-
cone sealant as specified in the second warning statement on
page 12. Be sure all pipe and elbow connections are fully
twist-locked (see Figure 24, page 13).
3. Cut a hole in the roof using the locating hole as a center point.
(Coverany exposedopenvent pipesbefore cuttingholein roof.)
The 10"x10" hole must be measured on the horizontal; actual
length may be larger depending on the pitch of the roof. There
mustbea 1"clearancefrom thevent pipe tocombustible mate-
rials. Frame the opening as shown in Figure 25 on page 14.
4. Connect a section of pipe and extend up through the hole.
Note: If an offset is needed to avoid obstructions, you must
support the vent pipe every 3 feet. Use wall straps for this
purpose (see Figure 32). Whenever possible, use 45°elbows
instead of 90°elbows. The 45°elbow offers less restriction
to the flow of the flue gases and intake air.
5. Place the flashing over the pipe section(s) extending through
the roof. Secure the base of the flashing to the roof and fram-
ing with roofing nails. Be sure roofing material overlaps the
top edge of the flashing as shown in Figure 32. There must be
a 1" clearance from the vent pipe to combustible materials.
6. Continue to add pipe sections until the height of the vent cap
meets the minimum building code requirements described in
Figure 21 on page 11. Note : You must increase vent height
for steep roof pitches. Nearby trees, adjoining rooflines, steep
pitched roofs, and other similar factors may cause poor draft
or down-drafting in high winds. Increasing the vent height
may solve this problem.
Figure 32 - Offset with Wall Strap and 45 ° Elbows
INSTALLATION FOR VERTICAL
TERMINATION
NOTICE:Userigidpipeonly.Flexventingisnot to be
used with a vertical termination.
VENTING INSTALLATION
Continued
Figure 33 - Installing Firestop
If area above is not a
room, install firestop below
framed hole.
If area above is a room, install
firestop above framed hole.
45°Elbow
Wall Strap
Roof
Flashing
Ceiling Firestop
VENTING INSTALLATION
Installation for Vertical Termination

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
17
17
Vertical Termination Configurations
Figure36through39showfourdifferentconfigurationsforvertical
termination. All connections must be sealed with high temperature
silicone sealant as specified in the second warning statement on
page 12.
Venting with One 90°Elbow
Vertical (V) Horizontal (H)
5' min. 2' max.
6' min. 4' max.
7' min. 6' max.
8' min. 8' max.
20' max. 8' max.
Figure36 -Vertical VentingConfiguration UsingOne 90 ° Elbow
Note: Install restrictor
into 4" collar of burner
system as shown.
VENTING INSTALLATION
Continued
Figure 34 - Cathedral Ceiling Support Box Installation
Non-hardening Mastic
under all edges of support
box before nailing
Figure 35 - Installed Cathedral Ceiling Support Box
Cut hole 1/8" larger than support
box when projected onto roofline
2" minimum below
finished ceiling
Cathedral ceiling
support box
Level
7. Twist-lock the vent cap onto the last section of vent pipe and
seal outer pipe connection with high temperature silicone seal-
ant as specified in the second warning statement on page 12.
Note: Iftheventpipepassesthroughanyoccupiedareasabovethefirst
floor,includingstoragespacesandclosets,youmustenclosepipe.You
may frame and sheetrock the enclosure with standard construction
material. Make sure and meet the minimum allowable clearances to
combustibles.Do notfillany oftherequired airspaceswith insulation.
Cathedral Ceiling Installation
1. Remove shingles or other roof covering as necessary to cut the
rectangular hole for the support box. Mark the outline of the
cathedral ceiling support box on the roof sheathing using the
locating hole as a center point.
2. Cut the hole 1/8" larger than the support box outline (see
Figure 34).
3. Lower the support box through the hole in the roof until the
bottom of the box extends at least 2" below the ceiling (see
Figure 34). Align the support box vertically and horizontally
usingalevel.Temporarilytackthe supportbox in placethrough
the inside walls and into the roof sheathing.
4. Using tin snips, cut the support box from the top corners down
to the roofline and fold the resulting flaps over the roof sheath-
ing(seeFigure35).Apply abeadof non-hardeningmasticaround
the top edges of the support box to make a seal between the box
and the roof. Nail in place with roofing nails. Remove any com-
bustible material that might be inside of the support box.
5. Complete thecathedralceilinginstallationby followingthe same
procedures outlined in steps 2 through 7 for Flat Ceiling Instal-
lation, page 16 .
VENTING INSTALLATION
Installation for Vertical Termination (Cont.)
PA-47

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
18
Venting withTwo 90°Elbows
Vertical (V1) Horizontal (H)
5' min. 6' max.
6' min. 12' max.
7' min. 18' max.
8' min. 20' max.
Note: Vertical (V1) +
Vertical (V2) = 20' max.
Figure38-VerticalVentingConfigurationUsingTwo90 ° Elbows
VENTING INSTALLATION
Continued
Venting withTwo 90°Elbows
Vertical (V) Horizontal (H1) +
Horizontal (H2)
5' min. 2' max.
6' min. 4' max.
7' min. 6' max.
8' min. 8' max.
20' max. 8' max.
Figure37-VerticalVentingConfigurationUsingTwo90 ° Elbows
with Two Horizontal Runs
Note: Install
restrictor into 4"
collar of burner
system as shown.
Note: Install
restrictor into 4"
collar of burner
system as shown.
PA-47
VENTING INSTALLATION
Installation for Vertical Termination (Cont.)
PA-47

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
19
19
VENTING INSTALLATION
Continued
HIGH ALTITUDE INSTALLATION
Your cast iron stove and direct-vent burner system has been AGA
tested and approved for elevations from 0-2000 feet and CSA
certified for elevations from 0-4500 feet.
When installing this stove at an elevation above 2000 feet (in the
USA), you may need to decrease the input rating by changing the
existing burner orifice to a smaller size. Reduce input 4% for each
1000 feet above sea level. Check with your local gas company for
proper orifice size identification.
When installing this stove at an elevation above 4500 feet (in
Canada), check with local authorities.
Figure 39 - Vertical Venting Configuration With No
Horizontal Run
Vertical Venting
V = 40' max.
Note: Install restrictor
into 4" collar of burner
system as shown.
PARTS LISTS FOR VENTING KITS AND
COMPONENTS
Number Description
VKG-47-K Ground Floor Vent Kit, Black
Includes:Horizontal SquareTermination,90°Elbow, 7"-
12" Adjustable Coaxial Pipe, 6" Pipe Adaptor, 2' Coaxial
Pipe,WallFirestop, DecorativeTrimPlateand18Screws
VKB-47-K Basement Vent Kit
Includes:Horizontal SquareTermination,90°Elbow, 7"-
12" Adjustable Coaxial Pipe, 6" Pipe Adaptor, 4' Coaxial
Pipe,WallFirestop, DecorativeTrimPlateand18Screws
VKS-47-K Snorkel Vent Kit
Includes: 36" Snorkel Termination, 90°Elbow, 7"-12"
Adjustable Coaxial Pipe, 6" Pipe Adaptor, 4' Coaxial
Pipe,WallFirestop,DecorativeTrimPlateand18Screws
VKR-47-K Roof Vent Kit
Includes:VerticalHighWindTermination,FlueRestrictor,
7"-12" Adjustable Coaxial Pipe, 6" Pipe Adaptor, 12"
Coaxial Pipe, 4' Coaxial Pipe, Firestop Decorative Trim
Plate, Roof Flashing, Storm Collar and 18 Screws
P-47-12-K 12" Black Coaxial Pipe (1 pk)
P-47-24-K 24" Black Coaxial Pipe (1 pk)
P-47-48-K 48" Black Coaxial Pipe (1 pk)
PA47-712-K 7"-12" Black Coaxial Pipe (1 pk)
P-47-6-K 6" Black Coaxial Pipe (1 pk)
E47-90-K 90°Elbow (1 pk)
E47-45-K 45°Elbow (1 pk)
PA-47-6-K 6" Adaptor Collar, Black (1 pk)
WS-47 Wall Strap (1 pk)
SC-47 Storm Collar (1 pk)
VT-47 Vertical Round Termination (1 pk)
WF-47 Wall Firestop (1 pk)
VR-47 Vertical Restrictor (1 pk)
FP-47 Firestop Plate (1 pk)
HTS-47 Horizontal Square Termination (1 pk)
CS-47 Cathedral Ceiling Support Box (1 pk)
RF-47-6 Roof Flashing 0 to 6/12 Pitch (1 pk)
RF-47-12 Roof Flashing 6/12 to 12/12 Pitch (1 pk)
S-47 Vinyl Siding Standoff (1 pk)
TP-47 Trim Plate, Black (1 pk)
HT-47 Horizontal Round Termination (1 pk)
ST-47-14 14" Snorkel Termination (1 pk)
ST-47-36 36" Snorkel Termination (1 pk)
Consult your local gas company to help determine the proper orifice
for your location.
For assistance with any high altitude installation contact DESA
International’s Technical Service Department at 1-866-672-6040
PA-47
VENTING INSTALLATION
Installation for Vertical Termination (Cont.)
High Altitude Installation
Parts List for Venting Kits and Components

107304
For more information, visit www.desatech.com
For more information, visit www.desatech.com
20
CAUTION: Use only new, black iron or steel pipe.
Internally-tinned copper tubing may be used in cer-
tain areas. Check your local codes. Use pipe of 1/2"
diameter or greater to allow proper gas volume to
burner system. If pipe is too small, undue loss of
volume will occur.
Installation must include an equipment shutoff valve, union, and
plugged1/8"NPTtap.LocateNPTtapwithinreachfortestgaugehook
up. NPT tap must be upstream from burner system (see Figure 41).
IMPORTANT: Installmain gas valve(equipment shutoff valve)in
an accessible location. The main gas valve is for turning on and
shutting off the gas to the appliance.
Checkyourbuildingcodesforanyspecialrequirementsforlocating
equipment shutoff valve to stoves.
STOVE AND DIRECT-VENT
BURNER SYSTEM
INSTALLATION
INSTALLING GAS PIPING TO STOVE/
BURNER SYSTEM LOCATION
Installation Items Needed
Before installing stove and burner system, make sure you have the
items listed below.
• external regulator (supplied by installer)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
• approved flexible gas line with gas connector (if allowed by lo-
cal codes) (not provided)
* ACSAdesign-certifiedequipmentshutoffvalvewith1/8"NPTtap
is an acceptable alternative to test gauge connection. Purchase the
CSA design-certified equipment shutoff valve from your dealer.
For propane/LP connections only, the installer must supply an
external regulator. The external regulator will reduce incoming gas
pressure.Youmustreduceincominggaspressuretobetween11and
14 inches of water. If you do not reduce incoming gas pressure,
burner system regulator damage could occur. Install external regu-
lator with the vent pointing down as shown in Figure 40. Pointing
the vent down protects it from freezing rain or sleet.
WARNING:Aqualifiedinstallerorserviceperson
mustconnectburnersystemtogassupply.Followall
local codes.
CAUTION: For propane/LP units, never connect
burnersystemdirectlytothepropane/LPsupply.This
burner system requires an external regulator (not
supplied). Install the external regulator between the
burner system and propane/LP supply.
Figure 40 - External Regulator with Vent Pointing Down
(Propane/LP Only)
Propane/LP
Supply Tank
External
Regulator
Vent Pointing
Down
CHECK GAS TYPE
Use proper gas type for the burner system unit you are installing. If
you have conflicting gas types, do not install burner system. See
dealer where you purchased the stove and burner system for proper
burner system according to your gas type. Conversion kits are also
available for these models, see Accessories on page 35.
Figure 41 - Gas Connection
* The CSA design-certified equipment shutoff valve may be sup-
plied with the appliance or you can purchase it from your dealer.
CSA Design-Certified
Equipment Shutoff Valve with
1/8" NPT Tap*
3" Minimum
Approved Flexible
Gas Line
Pipe Nipple Cap Tee Joint
Sediment Trap/Drip Leg
Propane/LP - From
External Regulator
(11" W.C. to 14"
W.C. Pressure)
Natural - From
Gas Meter (5"
W.C. to 10.5"
W.C. Pressure )
STOVE AND DIRECT-VENT BURNER SYSTEM INSTALLATION
Check Gas Type
Installing Gas Piping to Stove/Burner System Location
