Vacuum Cleaner and Blower
Installation, Operation and Maintenance
Description
Compact lightweight blower / vacuum cleaner designed
for precise removal and collection of dry dust particles
and debris from electrostatic static sensitive devices
(ESDS). The conductive nozzles drain-off any static
build-up to earth. The 231710 features a speed control
dial allowing for complete adjustment of suction levels.
In order to comply with EN61340-5 recommendations
for working in an ESD protected area (EPA), the
appliance housing, nozzles, hose, shoulder strap,
cable and accessories are fully conductive. The
vacuum cleaner can retain dust and fine dry particles
as small as 0.3 micron, the vacuum cleaner is fitted
with a double-layer paper filter bag and an electrostatic
charged micromotor filter.
The appliance can also be converted in seconds into
a powerful blower for dust removal in areas otherwise
not accessible - the blower’s air-current is CFC-free and
contains no oil or water residue.
July 2018
TECHNICAL BULLETIN TB-7510
The appliance is constructed to safety class II: Double
insulated design in compliance with CE standards.
- Durable and compact design
- Motor has thermal protection with RFI / EMC filter
- Hose assembly extends to 130 cm
- Includes hard crevice and soft rubber nozzle
- 1.2 l filter bag
- Advanced 5 stage filtration system
- 3 m long power cord
- Conductive carry strap
- Input power supply voltage: 220-240 volts
- Made in the Netherlands
The Vacuum Cleaner is available in the following
models:
Item# Description
231700 ESD Vacuum Cleaner
231710 ESD Vacuum Cleaner with Speed Control
Packaging
Remove the vacuum cleaner from the carton and
inspect for shipping damages.
Each unit includes the following:
1 Vacuum Cleaner (231700 or 231710)
1 1.3 m Hose
2 Nozzles
1 Carrying Strap
Optional Accessories:
- 231725: Replacement Bags, Pack of 10
- 231705: Carry Bag
- 231726: Long Soft Rubber Nozzle with Mini Crevice
Tool
- 231728: Long Soft Rubber Nozzle with Brush Head
- 231729: Replacement Micromotor Filter
Operating Instructions
1. Push hose end into suction opening.
2. Press the suction nozzle onto the free suction
hose-end.
3. Place rocker switch in off position.
4. Insert the plug into the electrical supply and start
appliance, pressing on-off switch to “on” position.
5. 231710 only: Move dial clockwise to increase
suction. Blow power and noise level will intensify.
Move dial anti-clockwise to reduce suction, blow
power and noise level.
EUROPE
Figure 1. 231700 ESD Vacuum Cleaner
Figure 2. 231710 ESD Vacuum Cleaner with Speed Control

TB-7510 Page 2 of 2
DESCO EUROPE - 2A DUNHAMS LANE, LETCHWORTH, HERTFORDSHIRE, SG6 1BE, UK
Phone: [phone] • E-mail: [email protected], Website: DescoEurope.com
© 2018 DESCO INDUSTRIES INC
Employee Owned
If there is substantial loss of vacuum or blow-pressure,
take the following steps:
6. Remove appliance from the EPA.
7. Check whether nozzle or suction hose have become
blocked.
8. Switch off appliance and disconnect plug from
electrical supply.
9. Lift metal bottom lock and remove housing’s front
cover.
10. Remove and replace the spent paper filter bag.
11. Replace electrostatic micromotor filter.
Note: This appliance is equipped with a thermal
protection device. To protect the motor from
overheating, it will switch off automatically if there is an
inadequate air supply. To enable a restart, check filters,
bags, nozzle and hose for blockages. Reduce the power
setting. When the motor has cooled down, the appliance
should restart after 15-20 minutes.
Safety Points
When cleaning this equipment, ensure it is switched-off
and no longer connected to the power supply.
Ensure any object to be cleaned, is itself
connected to earth in accordance with EN 61340-5
recommendations. Always use the on-off rocker switch
to turn the appliance on or off.
This appliance is made for indoor use only, it must be
stored in a dry place and should not be operated under
wet conditions such as wet floors or wet surfaces. Never
touch the appliance or the plug with wet hands.
This appliance is not designed, nor suitable, to collect
liquids, nor health endangering dust such as asbestos
or tropical wood sawdust.
Do not pull the cord to unplug it, do not use the cord to
carry or pull the appliance. Keep the cord away from hot
surfaces. Never use the appliance if the cord or plug
are damaged. Never use the appliance if the suction is
blocked or with completely restricted vacuum flow or air
exit.
Do not operate the vacuum cleaner near flammable or
combustible liquids or fumes. Do not collect anything
that is hot, smoking or burning with the cleaner. Do not
pick-up burning cigarettes, hot ashes or matches.
Use safety glasses when the application is in blow
mode. Never blow in corners or in the direction of sharp
objects such as staples, paperclips, drawing-pins,
needles, pins and glass fragments. Never use the
appliance without the filter bag and motor filter in place.
Never re-use spent filter bags.
Limited Warranty, Warranty Exclusions, Limit
of Liability and RMA Request Instructions
See the Desco Europe Warranty -
DescoEurope.com/Limited-Warranty.aspx
