Design Dynamics VTD-18N-JHB Quick start guide
For more information, visit www.desatech.com
WARNING: If the information in this manual is not
— WHAT TO DO IF YOU SMELL GAS
• Do not touch any electrical switch; do not use any
-
VENTED DECORATIVE NATURAL GAS LOG HEATER
OWNER’S OPERATION AND INSTALLATION MANUAL
MODELS VTD-18N-JHB,
VTD-24N-JHB AND VTD-30N-JHB
TESTED AND
LISTED BY
RGA 2-72
APPROVED
-
www.desatech.com 114370-01E2
SAFETy
TABLE OF CONTENTS
Safety .................................................................. 2
Local Codes......................................................... 4
Unpacking............................................................ 4
Product Identication........................................... 5
Installation ........................................................... 5
Operation........................................................... 10
Cleaning and Maintenance................................ 10
Troubleshooting..................................................11
Replacement Parts............................................ 13
Service Hints ..................................................... 13
Technical Service............................................... 13
Accessory.......................................................... 13
Parts .................................................................. 14
Warranty ..............................................Back Cover
-
service or maintenance can
Refer to this manual for correct
additional information consult
is for installation only in a
material and connected to a
from the room in which it is in-
National Fuel Gas Codes, ANSI
Z233.1/NFPA54,Air for Combus-
tion and Ventilation.
chemicals known to the State
of California to cause cancer or
-
State of Massachusetts: The
www.desatech.com
114370-01E 3
-
Early signs
of carbon monoxide poisoning resemble the
u, with headaches, dizziness or nausea. If
you have these signs, the log set may not be
working properly. Have
log set serviced. Some people are more af-
fected by carbon monoxide than others. These
include pregnant women, people with heart or
lung disease or anemia, those under the in-
uence of alcohol and those at high altitudes.
Natural Gas: Natural gas is odorless. An
odor-making agent is added to the gas. The
odor helps you detect a gas leak. However,
the odor added to the gas can fade. Gas may
be present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this log set.
-
WARNING: Do not allow fans
adults away from hot surface to
-
dren when they are in the room
-
1. This appliance, as supplied, is for use with
NATURAL GAS ONLY. This appliance is
NOT convertible for use with other gases.
SAFETy
Continued
www.desatech.com 114370-01E4
2. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not
use any phone in your building
• immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions
• if you cannot reach your gas supplier,
call the re department
3. Never install the log set
• in a recreational vehicle
• where curtains, furniture, clothing or other
ammable objects are less than 42" from
the front, top or sides of the log set.
• in high trafc areas
• in windy or drafty areas
4. Before installing in a solid fuel burning
replace, the chimney ue and rebox
must be cleaned of soot, creosote, ashes
and loose paint by a qualied chimney
cleaner. Creosote will ignite if highly
heated. Inspect chimney ue for damage.
If damaged, repair ue before operating
appliance.
5. You must operate this log set with replace
screen in place and fully closed.
6. This log set is designed to be smokeless.
If logs ever appear to smoke, turn off appli-
ance and call a qualied service person.
Note: During initial operation, slight smok-
ing could occur due to log curing and
the burning of manufacturing residues.
SAFETy
Continued
LOCAL CODES
Install and use log set with care. Follow all local
codes. In the absence of local codes, use the
latest edition of the National Fuel Gas Code
ANSI Z223.1/NFPA 54*
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Battery March Park
Quincy, MA 02269
You may wish to add more ventilation by
opening a window.
7. To reduce the creation of soot, follow the
instructions in Cleaning and Maintenance,
page 10.
8. The installation and provisions for com-
bustion and ventilation air must conform
with the National Fuel Gas Codes, ANSI
Z233.1/NFPA 54, Air for Combustion and
Ventilation.
9. Do not run log set
• where ammable liquids or vapors are
used or stored
• under dusty conditions
10. Do not burn solid fuel in the replace after
installing the log set. Do not use this log
set to cook food or burn paper or other
objects.
11. To help prevent breakage, new logs must
be broken-in (see Curing Logs, page 10).
12. Do not use heater if any part has been ex-
posed to or under water. Immediately call
a qualied service technician to inspect
the room heater and to replace any part
of the control system and any gas control
which has been under water.
13. Turn log set off and let cool before servic-
ing, installing or repairing. Only a qualied
service person should install, service or
repair log set.
14. Provide adequate clearances around air
openings.
UNPACkING
CAUTION: Do not remove the
-
1. Remove logs, hearth kit, pan materials and
hardware from carton.
2. Remove all protective packaging applied to
logs and base for shipment.
3. Check all items for any shipping damage.
If damaged call DESA Heating, LLC at
1-866-672-6040 for replacement parts
before returning to dealer.
www.desatech.com
114370-01E 5
PRODUCT IDENTIFICATION
Figure 1 - Product Identication (Ramp
Pan Burner)
Log Set
Assembly
Grate
Chassis
INSTALLATION
-
-
NOTICE: Installation, service and
listed in these instructions may
manufacturer's instructions and
accessory items will void the
Ceramic
Burner
-
CHECK GAS TYPE
Use only natural gas. If your gas supply is not
natural gas, DO NOT install this gas log set.
If the replace does not have a gas supply
shutoff valve, one must be installed.
FLUE OPENING SPECIFICATIONS
Note: This vented appliance must be installed
only in a solid-fuel burning replace con-
structed of noncombustible material.
The charts in Figure 2, page 6 indicate tech-
nical information regarding the installation of
your gas log set. Please make sure that all of
the specications shown are applicable before
installation is attempted.
The replace must include a ue and venting
system with the minimum openings shown in
Figure 2, page 6.
www.desatech.com 114370-01E6
Figure 3 - Attaching Damper Clamp
Manufactured
Fireplace
Masonry
Fireplace
Damper
Damper
Clamp
Damper
Damper
Clamp Damper
VENTING SPECIFICATIONS FOR
INSTALLATION
The replace chimney ue and vent must be
drafting properly. To check the vent for proper
drafting: Light a tightly rolled newspaper on
one end and place it at the inside front edge
of the replace. Observe the smoke and be
sure the vent is properly drawing it up the
chimney. If the smoke spills out into the room,
extinguish the ame and remove any obstruc-
tion until proper venting is achieved.
The chimney ue must remain open a mini-
mum of 3" at all times during the operation of
this log set.
MODEL
BURNER
DESCRIPTION
BTU
INPUT
MINIMUM VENT
OPENING
VTD-18N-JHB 18" Ramp 59,000 8" dia.
VTD-24N-JHB 24" Ramp 69,000 8" dia.
VTD-30N-JHB 30" Ramp 74,000 8" dia.
INSTALLATION
Continued
MINIMUM FIREBOX SIZES
MODEL FRONT WIDTH BACK WIDTH* DEPTH HEIGHT
VTD-18N-JHB 28" 16" 14" 18"
VTD-24N-JHB 29 3/4" 17" 15 1/2" 18"
VTD-30N-JHB 36" 27" 18" 18"
*At depth indicated
BURNER ORIFICE
LOG SIZE
NATURAL
INCHES NUMBER
18" 0.1495 25
24" 0.1570 22
30" 0.1660 19
FUEL INLET PRESSURE
MIN. MAX.
NG 5.5" 10.5"
Figure 2 - Technical Information Charts
INSTALLING DAMPER CLAMP
Secure the damper stop clamp to the edge of
the damper as shown in Figure 3. If for any
reason this clamp doesn't work on your re-
place, another suitable clamp or permanent
stop must be installed, or the damper blade
must be cut or removed.
www.desatech.com
114370-01E 7
INSTALLATION
Continued
CONNECTING TO GAS SUPPLY
-
WARNING: Never connect
Installation Items Needed
Before installing log set, make sure you have
the items listed below.
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve*
• test gauge connection*
• adjustable (crescent) wrench or pliers
• sediment trap
• tee joint
• pipe wrench
* A CSA design-certied equipment shutoff
valve with 1/8" NPT tap is an acceptable al-
ternative to test gauge connection. Purchase
the optional CSA design-certied equipment
shutoff valve from your dealer.
CAUTION: Use only new,
-
Installation must include an equipment shutoff
valve, union and plugged 1/8" NPT tap. Locate
NPT tap within reach for test gauge hook up.
NPT tap must be upstream from log set (see
Figure 4).
IMPORTANT: Install equipment shutoff valve
in an accessible location. The equipment
shutoff valve is for turning on or shutting off
the gas to the appliance.
Apply pipe joint sealant lightly to male NPT
threads. This will prevent excess sealant from
going into pipe. Excess sealant in pipe could
result in clogged heater valves.
We recommend that you install a sediment
trap in supply line as shown in Figure 4.
Locate sediment trap where it is within reach
for cleaning. Install in piping system between
fuel supply and appliance. Locate sediment
trap where trapped matter is not likely to
freeze. A sediment trap traps moisture and
contaminants. This keeps them from going
into heater controls. If sediment trap is not
installed or is installed wrong, heater may
not run properly.
Figure 4 - Gas Connection
* Purchase the optional CSA design-certied
shutoff valve from your dealer.
** Minimum inlet pressure for purpose of input
adjustment.
Approved Flexible
Gas Hose (If
allowed by local
codes)
CSA Design-Certied
Equipment Shutoff
Valve with 1/8" NPT
Tap*
From Gas
Meter (5" W.C.**
to 10.5" W.C.
Pressure)
3" Min.
Pipe Cap Tee
Nipple Joint
Sediment Trap
www.desatech.com 114370-01E8
INSTALLATION
Continued
CHECKING GAS CONNECTIONS
and connections, internal and
external to unit, for leaks after
WARNING: Never use an
-
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
Test Pressures In Excess Of 1/2 PSIG
1. Disconnect log set with its individual
equipment shutoff valve from gas supply
piping system.
2. Cap off open end of gas pipe where equip-
ment shutoff valve was connected.
3. Pressurize supply piping system by either
using compressed air or opening main gas
valve located on or near gas meter.
4. Check all joints of gas supply piping sys-
tem. Apply noncorrosive leak detection
uid to gas joints. Bubbles forming show
a leak.
5. Correct all leaks at once.
6. Reconnect log set and equipment shutoff
valve to gas supply. Check reconnected
ttings for leaks.
1. Close equipment shutoff valve (see Fig-
ure 5).
2. Pressurize supply piping system by either
using compressed air or opening main gas
valve located on or near gas meter.
Figure 6 - Checking Gas Joints
HEARTH KIT ASSEMBLY AND
INSTALLATION
1. Determine which side the gas line will be
coming into the replace.
NOTICE: Unit comes preassembled with
gas inlet on right side. If your replace gas
supply is on the left, gas inlet should be
repositioned to left side of unit.
2. If gas supply line in your replace is on the
right side, continue to step 3. If not, see
Repositioning the Gas Inlet to the Left Side
of Unit, page 9.
3. Install adapter tting that comes with log
set into replace gas supply pipe (see
Figure 7). Seal using thread sealant.
Figure 7 - Connecting Adapter to Gas
Supply
Gas
Connector
Tube
Adapter
Fitting
Gas Inlet
Fitting
Equipment Shutoff Valve
Gas Meter
Figure 5 - Equipment Shutoff Valve
Equipment
Shutoff
Valve
Open
Closed
3. Check all joints from gas meter to equip-
ment shutoff valve (see Figure 6). Apply
noncorrosive leak detection uid to all
joints. Bubbles forming show a leak.
4. Correct all leaks at once.
www.desatech.com
114370-01E 9
INSTALLATION
Continued
4. Place log set assembly in center of
fireplace floor. Make sure front faces
forward.
5. Install gas connector tube into gas supply
tting. Carefully shape tube to attach to
adapter tting being careful not to kink
tube.
6. Install provided gas connector tube
into the gas inlet fitting (see Figure 7,
page 8).
7. Test for leaks following instructions under
Testing Burner for Leaks.
Unit
1. Remove venturi and gasket by unscrew-
ing two screws under chassis (see
Figure 8).
2. Unthread elbow tting from orice (see
Figure 8).
3. Remove orice and brackets by unscrew-
ing two screws on right side of unit (see
Figure 8).
4. Install orice and brackets into left side of
unit using screws removed in step 1.
5. Install venturi and gasket under bottom
burner and into repositioned orice and
brackets (see Figure 8).
6. Thread elbow tting back into orice. Ap-
ply thread sealant to orice threads (see
Figure 8).
7. Install gas connector tube that comes
with log set into gas inlet tting (see
Figure 8).
8. Install supplied brass adapter tting that
comes with log set into replace gas
supply pipe. Use thread sealant (see
Figure 8).
9. Place log set assembly in center of
fireplace floor. Make sure front faces
forward.
10. Install gas connector tube into gas supply
tting. Carefully shape tube to attach to
adapter tting. Be careful not to cause
kinks in tube.
11. Test for leaks following instructions under
Testing Burner for Leaks.
TESTING BURNER FOR LEAKS
1. Generously apply noncorrosive leak de-
tection uid to all connections.
WARNING: Never check for
2. Light burner with shutoff valve no more
than half open and holding a match
slightly in front of the pan (see Lighting
Instructions, page 10).
3. Inspect all connections for bubbles, raw
gas odors, or ame from any area other
than burner. If leaks are detected, shut
off gas valve immediately. Tighten or
reassemble the loose connections using
pipe joint compound until burner system
is leak free.
4. When nished testing, turn gas shutoff
valve OFF to extinguish all ames.
Figure 8 - Repositioning Gas Inlet to Left
Side of Unit
Outer
Bracket
Gasket
Venturi
Screws Inner
Brackets Orice
Elbow
Fitting
Elbow
Fitting
Inner Brackets
Orice
Gasket
Venturi
Screws
Chassis
Chassis
www.desatech.com 114370-01E10
OPERATION
3. Wait ve (5) minutes to clear out any gas.
If you then smell gas, STOP! Follow "A"
in the safety information, column 1. If you
don't smell gas, go on the next step.
4. Light a match and lay it on top of pan
material about 2" from end of supply side
of pan.
5. Slowly turn gas shutoff valve ON until the
burner ignites. If burner does not ignite
within 10 seconds with the match burning,
turn shutoff valve OFF and repeat steps 1
through 4 again.
GAS SHUTOFF
VALVE OPERATION
Adjust ame ON/OFF by turning gas shutoff
valve counterclockwise to open and
clockwise to close as necessary.
Turn gas shutoff valve clockwise to
OFF position (see Figure 5, page 8).
CURING
LOGS
During the 2-3 hour appliance break in period,
you may detect an odor from appliance as
the various paints and compounds used in
the manufacturing of this log set cure. This is
a normal and temporary situation that is not
cause for alarm. However, you may want to
provide extra ventilation to the room during
this time.
To ensure proper curing of logs:
• Ignite a 2" ame and maintain for 1 hour
• Burn logs in consecutive 1 hour periods
raising ame an additional 2" to full height
for a total of 3 hours.
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: If you do not fol-
low these instructions exactly,
-
WHAT TO DO IF YOU SMELL GAS
• Do not touch any electric switch; do
LIGHTING
INSTRUCTIONS
1. STOP! Read the safety information,
above.
2. Turn gas shutoff valve to OFF.
CLEANING AND MAINTENANCE
• Keep area around log set clean and clear
of debris.
• Occasionally use a soft bristle brush to
clean logs.
• Once every year a qualied agency or certi-
ed chimney sweep should examine and
clean the venting system of the replace.
www.desatech.com
114370-01E 11
TROUBLESHOOTING
Note: All troubleshooting items are listed in order of operation.
POSSIBLE CAUSE REMEDY
OBSERVED PROBLEM
1. Poor fuel quality
2. Fireplace venting system
not drafting properly
3. Improper fuel/air mix
4. Excessive gas supply or
pressure
1. Passage of air or gas
across irregular surfaces
1. Incorrect gas supply or
pressure
2. Blocked burner orice or
burner manifold
3. Improper burner orifice
size
Log set is smoking/sooting
excessively
(Note: It is natural and un-
avoidable for vented gas log
sets to produce moderate
levels of carbon (soot) where
ames contact logs.
Burner is excessively noisy
(Note: The movement and
combustion of gas will cre-
ate low, unavoidable levels
of noise.)
Burner ame is too low or
too high
1. Contact local gas supplier
2. Adjust damper wide open
and/or have replace and
venting professionally
cleaned and checked
3. Remove any foreign items
from ame pattern and/or
check for proper orifice
sizing
4. Preheat ue in very cold
weather.
1. Relieve any tight bends or
kinks in gas supply line
1. Check for proper gas sup-
ply pressure
2. Free burner orifice and
manifold ports of any burrs,
paint or other blockage
3. Verify proper burner ori-
fice sizing (see Figure 2,
page 6)
www.desatech.com 114370-01E12
OBSERVED PROBLEM
Log set produces a clicking/
ticking noise just after burners
are lit or shut off
Log set produces unwanted
odors
Gas odor even when control
knob is in OFF position
Gas odor during combustion
REMEDY
1. This is normal with most
appliances. If noise is
excessive, contact qualied
service person
1. Open window to ventilate
room. Stop using odor
causing products while
appliance is running
2. Locate and correct all leaks
(see Checking Gas Con-
nections, page 8)
1. Locate and correct all leaks
(see Checking Gas Con-
nections, page 8)
2. Replace control valve or
gas control
1. Locate and correct all leaks
(see Checking Gas Con-
nections, page 8)
POSSIBLE CAUSE
1. Metal expanding while
heating or contracting
while cooling
1. Log set burning vapors
from paint, hair spray,
glues, cleaners, chemicals,
new carpet, etc. (See
IMPORTANT statement
above)
2. Gas leak.
1. Gas leak. See Warn-
2. Control valve or gas con-
trol defective
1. Gas leak. See Warn-
TROUBLESHOOTING
Continued
-
IMPORTANT: Operating log set where impurities in air exist may create odors. Cleaning sup-
plies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc.,
create fumes. These fumes may mix with combustion air and create odors. These odors will
disappear over time.
www.desatech.com
114370-01E 13
SERVICE HINTS
When Gas Pressure is Too Low
• pilot will not stay lit
• burners will have delayed ignition
• heater will not produce specied heat
You may feel your gas pressure is too low. If
so, contact your local natural gas supplier.
TECHNICAL SERVICE
You may have further questions about installa-
tion, operation, or troubleshooting. If so, con-
tact DESA Heating, LLC at 1-866-672-6040.
When calling please have your model and
serial numbers of your heater ready.
You can also visit DESA Heating, LLC’s web
site at .
ACCESSORy
Purchase this accessory from your local
dealer. If they can not supply this accessory,
call DESA Heating, LLC at 1-866-672-6040 for
information. You can also write to the address
listed on the back page of this manual.
Order when additional rock is desired (1.8 lb.
bag).
REPLACEMENT PARTS
Note: Use only original replacement parts.
This will protect your warranty coverage for
parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product. If
they can’t supply original replacement part(s),
call DESA Heating, LLC at 1-866-672-6040.
When calling DESA Heating, LLC, have
ready:
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• purchase date
Usually, we will ask you to return the part to
the factory.
PARTS NOT UNDER WARRANTY
Contact authorized dealers of this product. If
they can’t supply original replacement part(s),
call DESA Heating, LLC at 1-866-672-6040 for
referral information. A list of authorized dealers
can be found by visiting
When calling DESA Heating, LLC, have
ready:
• model and serial numbers of your heater
• the replacement part number
www.desatech.com 114370-01E14
PARTS
www.desatech.com
114370-01E 15
PARTS
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 13 of this manual.
KEY
DESCRIPTION
1112801-01 Chassis • 1
112801-02 Chassis • 1
112801-03 Chassis • 1
2 ** Grate • • • 1
3 112372-07 Venturi/Shutter • 1
112372-08 Venturi/Shutter • 1
112372-09 Venturi/Shutter • 1
4112804-03 Bracket • • • 1
5112804-04 Plate • • • 1
6 901057-01 Brass Elbow • • • 1
7 112371-09 Orice • 1
112371-10 Orice • 1
112371-11 Orice • 1
8112370-01 Gasket • • • 1
9 901232-01 Flexible Connector • • • 1
10 112832-01 Ceramic Burner • 1
112832-02 Ceramic Burner • 1
112832-03 Ceramic Burner • 1
11 112833-01 Log Assembly • 1
112833-02 Log Assembly • 1
112833-03 Log Assembly • 1
12 14325 Brass Elbow • • • 1
13 111800-01 Screw, #10 Self THD • • • 6
PARTS AVAILABLE - NOT SHOWN
112363-01 Log Scrap Kit #1 • • • 1
112364-01 Log Scrap Kit #2 • • • 1
GA6060 Lava Rock • • • 1
901242-01 Damper Clamp • • • 1
114371-01 Warning Plate • • • 1
114366-02 Rating Plate • 1
114366-05 Rating Plate • 1
114366-08 Rating Plate • 1
112799-01 Ember Flakes Kit • • • 1
26839 Rock Wool • • • 1
**Not a eld replaceable part
VTD-18N-JHB
VTD-24N-JHB
114370-01
Rev. E
05/08
114370 01
NOT A UPC
DESA Heating, LLC
2701 Industrial Drive
Bowling Green, KY 42101
www.desatech.com
1-866-672-6040
WARRANTy
kEEP THIS WARRANTy
DESA HEATING, LLC LIMITED WARRANTIES
New Products
Standard Warranty: DESA Heating, LLC warrants this new product and any parts thereof to be free from
defects in material and workmanship for a period of four (4) years from the date of rst purchase from an
authorized dealer provided the product has been installed, maintained and operated in accordance with
DESA Heating, LLC’s warnings and instructions. When installed in a listed outdoor solid fuel burning re-
place, the warranty is limited to one (1) year for the burner system and logs.
For products purchased for commercial, industrial or rental usage, this warranty is limited to 90 days from
the date of rst purchase.
Factory Reconditioned Products
Limited Warranty: DESA Heating, LLC warrants factory reconditioned products and any parts thereof
to be free from defects in material and workmanship for 30 days from the date of rst purchase from an
authorized dealer provided the product has been installed, maintained and operated in accordance with
DESA Heating, LLC’s warnings and instructions.
Terms Common to All Warranties
The following terms apply to all of the above warranties:
Always specify model number and serial number when contacting the manufacturer. To make a claim under
this warranty the bill of sale or other proof of purchase must be presented.
This warranty is extended only to the original retail purchaser when purchased from an authorized dealer,
and only when installed by a qualied installer in accordance with all local codes and instructions furnished
with this product.
This warranty covers the cost of part(s) required to restore this product to proper operating condition and
an allowance for labor when provided by a DESA Heating, LLC Authorized Service Center or a provider
approved by DESA Heating, LLC. Warranty parts must be obtained through authorized dealers of this prod-
uct and/or DESA Heating, LLC who will provide original factory replacement parts. Failure to use original
factory replacement parts voids this warranty.
Travel, handling, transportation, diagnostic, material, labor and incidental costs associated with warranty
repairs, unless expressly covered by this warranty, are not reimbursable under this warranty and are the
responsibility of the owner.
Excluded from this warranty are products or parts that fail or become damaged due to misuse, accidents,
improper installation, lack of proper maintenance, tampering, or alteration(s).
This is DESA Heating, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty
excludes any and all other warranties, express or implied, written or verbal and limits the duration of any
and all implied warranties, including warranties of merchantability and tness for a particular purpose to four
(4) years on new products and 30 days on factory reconditioned products from the date of rst purchase.
DESA Heating, LLC makes no other warranties regarding this product.
DESA Heating, LLC’s liability is limited to the purchase price of the product, and DESA Heating, LLC shall
not be liable for any other damages whatsoever under any circumstances including indirect, incidental, or
consequential damages.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
For information about this warranty contact:
Model (
located on product or identication tag
)_____________________________
Serial No. (
located on product or identication tag
)__________________________
Date Purchased __________________________
Keep receipt for warranty verication.
This manual suits for next models
2
Table of contents
Other Design Dynamics Gas Heater manuals
Design Dynamics
Design Dynamics VTD-18ND-TKA Operation manual
Design Dynamics
Design Dynamics VF-24N-PJD Quick start guide
Design Dynamics
Design Dynamics VF-18N-PJD Operation manual
Design Dynamics
Design Dynamics HCA-18-RFN Quick start guide
Design Dynamics
Design Dynamics VF-18N-BTB Quick start guide
Design Dynamics
Design Dynamics PFS VF-18N-MHD User manual
Design Dynamics
Design Dynamics VTD-18N-PDG Quick start guide
Design Dynamics
Design Dynamics VF-18N-EMU Quick start guide
Design Dynamics
Design Dynamics VTD-18NV-JHB Quick start guide
Design Dynamics
Design Dynamics VF-18P-PDG Quick start guide
Popular Gas Heater manuals by other brands
Vanguard
Vanguard VP5D OWNER'S OPERATION AND INSTALLATION MANUAL
Ambirad
Ambirad TORNADO instruction manual
ENERCORP
ENERCORP HEATSTAR HS125KT Operating instructions and owner's manual
MrHeater
MrHeater MHBF10LP Installation instructions and owner's manual
ENERCORP
ENERCORP HeatStar HS60CLP Operating instructions and owner's manual
Vanguard
Vanguard VYD18NRB Owner's operation
Focal Point
Focal Point F500079 installation instructions
Ambirad
Ambirad AR13 U Installation and Servicing Manual
SunStar
SunStar CK6M-4-NG Installation and owner's guide
Comfortflame
Comfortflame River Canyon 24FMN Installation and operation instructions
MrHeater
MrHeater MH24T Operating instructions and owner's manual
Procom
Procom MN060HBA OWNER'S OPERATION AND INSTALLATION MANUAL
US Stove Company
US Stove Company NEWMAC PRO NMTT15 manual
BuckMaster
BuckMaster CVFB200 TOWNSEND II OWNER'S OPERATION AND INSTALLATION MANUAL
Desa
Desa VGL24NR OWNER'S OPERATION AND INSTALLATION MANUAL
Brigantia Fireplaces
Brigantia Fireplaces 24-DVRS25N-2 User's installation, operation and maintenance manual
FMI
FMI EMC18NR/PR OWNER'S OPERATION AND INSTALLATION MANUAL
Desa
Desa NY108 Safety information and installation manual
