Desoutter KA3 Series User manual

www.desouttertools.com
Part no 6159949980
Issue no 07
Series C
Date 08/2015
Page 1 / 40
WARNING
To reduce the risk of injury, before using or servicing tool, read and understand the
following information as well as separately provided safety instructions
(Item number: 6159943570).

12
AVERTISSEMENT
Avant toute utilisation ou intervention sur l’outil, veillez à ce que les informations
suivantes ainsi que les instructions fournies dans le guide de sécurité
(Code article : 6159943570) aient été lues, comprises et respectées.

14
ADVERTENCIA
Antes de utilizar la herramienta o intervenir sobre ella, asegúrense de que la
información que gura a continuación, así como las instrucciones que aparecen en
la guía de seguridad (Código artículo: 6159943570) han sido leídas, entendidas y
respetadas.

16
WARNUNG
Werkzeuge erst benutzen, wenn die nachstehenden Hinweise und die Regeln des
Sicherheitsleitfaden (Artikel-Nr. 6159943570) gelesen und verstanden wurden.

18
KA3 Series
KA3.135-7 6151705150
KA3.36-7 6151705160
KA3.21-7 6151705170
KA3.36A 6151705180

6159949980_07
Series: C
2 / 40 08/2015
WARNING
AVVISO
Prima di qualsiasi utilizzazione o intervento sull’attrezzo, vericate che le informazioni
che seguono e le istruzioni contenute nella guida di sicurezza
(Codice articolo: 6159943570) siano state lette, comprese e rispettate.

20
AVISO
Antes de utilizar ou intervir na ferramenta, leia atentamente e respeite as informações
seguintes assim como as instruções fornecidas no manual de segurança
(Código artigo: 6159943570).

22
VAROITUS
Lue huolellisesti seuraavat ohjeet samoin kuin turvallisuusohjeet
(Tuotekoodi : 6159943570) ennen työkalun käyttöönottoa.

24
VARNING
Läs noga igenom dessa säkerhetsinstruktioner liksom anvisningarna i
säkerhetsguiden (Artikelkod: 6159943570) innan du börjar använda verktyget.

26
ADVARSEL
Før enhver bruk eller reparasjon av verktøyet skal de følgende instruksjonene og
forskriftene i sikkerhetsheftet (artikkelnummer: 6159943570) leses nøye.

28
VARELSE
Læs omhyggeligt, forstå og overhold disse instruktioner samt sikkerhedsforskrifterne
(Varenummer: 6159943570), inden værktøjet tages i brug eller repareres.

30
WAARSCHUWING
Voor gebruik of demontage van het gereedschap altijd eerst zekerstellen dat de
navolgende informatie evenals de geleverde veiligheidsinstructies
(Code artikel: 6159943570) gelezen, begrepen en in acht genomen zijn.

32
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
Πριν από οποιαδήποτε χρήση ή επέμβαση στο εργαλείο, διαβάστε προσεκτικά,
κατανοήστε και τηρήστε τις παρακάτω πληροφορίες, καθώς και τις οδηγίες που
περιλαμβάνονται στο εγχειρίδιο ασφαλείας (Κωδικός προϊόντος: 6159943570).

34
Find more information and your Desoutter contacts on:
Software and documentation available at:
www.desouttertools.com
http://resource-center.desouttertools.com
No login/password required.

6159949980_07
Series: C
3 / 4008/2015
TECHNICAL DATA
Fig. 1
Models Tool ref. Weight Working pressure
(bar)
Rated
Speed
(rpm)
Max. power
(Kg) (lb) (W) (hp)
KA3.135-7 6151705150 0.6 1.3
6.3
13500 300 0.4
KA3.36-7 6151705160 0.65 1.4 3500 300 0.4
KA3.21-7 6151705170 0.65 1.4 3500 300 0.4
KA3.36A 6151705180 0.65 1.4 2000 300 0.4
IDENTIFICATION
Fig .2
Part no 8888888888
Issue no 01
Series C
Date 02/2088
Page 1 / 100
www.desouttertools.com
Toreduce the risk of injury, before using or servicing tool, read and understand the following
informationas well as separately provided safety instructions (Item number: 6159930690).
Thefeatures and descriptions of our products are subject to change without prior notice.
 10
Avanttoute utilisation ou intervention sur l’outil, veillez à ce que les informations suivantes
ainsique les instructions fournies dans le guide de sécurité (Code article : 6159930690) aient
étélues, comprises et respectées. Les caractéristiques et descriptifs de nos produits sont
susceptiblesd’évolution sans préavis de notre part.
 14
Antesde utilizar la herramienta o intervenir sobre ella, asegúrense de que la información
(Códigoartículo: 6159930690) han sido leídas, entendidas y respetadas. Las carasterísticas
ydescripción de nuestros productos son suceptibles de evolución sin previo aviso por parte
nuestra.
 18
Werkzeugeerst benutzen, wenn die nachstehenden Hinweise und die Regeln des
Sicherheitsleitfaden(Artikel-Nr. 6159930690) gelesen und verstanden wurden. Die
Eigenschaftenund Beschreibungen unserer Produkte sind der Weiterentwicklung unterworfen
undbedürfen keiner vorherigen Benachrichtigung unsererseits.
 22
seguonoe le istruzioni contenute nella guida di sicurezza (Codice articolo: 6159930690) siano
statelette, comprese e rispettate. Le caratteristiche e le descrizioni dei nostri prodotti sono
soggettea cambiamenti senza preavviso da parte nostra.
 26
Antesde utilizar ou intervir na ferramenta, leia atentamente e respeite as informações
seguintesassim como as instruções fornecidas no manual de segurança (Código artigo:
6159930690).As características e descrições dos nossos produtos estão sujeitas a evoluções
semaviso prévio.
 30
Luehuolellisesti seuraavat ohjeet samoin kuin turvallisuusohjeet (Tuotekoodi : 6159930690)
ennentyökalun käyttöönottoa. Tämän laitteen ominaisuudet ja selostus voivat muuttua ilman
erillistähuomautusta.
 34
XXXXXXXXXXXX XXX
WARNING
Ser. No.:XXCXXXX-XXXX
Model
Year of
manufacture
Serial n°
Week n°
Serial n°
Speed
Ser. No.: XXXXXXX-XXXX
KA3XXX XX
XXXXX RPM
Part no
61599
Issue no
10
Series
C
Date
02/201
Page
1 / 10
7m max.
Ø6mm (1/4") Pmax 6.3 bar Ø12.5 mm (1/2")
ISO VG15

6159949980_07
Series: C
4 / 40 08/2015
COMPLETE TOOL ASSEMBLY
6
75
4
3
2
1
15Nm
A
15Nm
ALoctite 243

6159949980_07
Series: C
5 / 4008/2015
COMPLETE TOOL ASSEMBLY
Item Description Part no. Qty Used on
1S-GRIP ASSEMBLY 2050552063 1
2 GASKET 2050504523 1
3 MOTOR (12T) 2050500753 1 KA3.135-7
3 MOTOR (7T) 2050500743 1 KA3.36-7 , KA3.21-7 , KA3.36A
4 GEARBOX 20000rpm 2050497593 1 KA3.135-7
4 GEARBOX 5500rpm 2050505463 1 KA3.36-7 , KA3.36A
4 GEARBOX 3000rpm 2050505453 1 KA3.21-7
5 SPACER 2050560173 1 KA3.135-7
5 SPACER 2050560183 1 KA3.36-7 , KA3.21-7 , KA3.36A
7 NUT 2050560193 1
6ANGLE HEAD ASSY 2050560133 1 KA3.135-7
6ANGLE HEAD ASSY 2050560143 1 KA3.36-7 , KA3.21-7
6ANGLE HEAD ASSY 2050560623 1 KA3.36A

6159949980_07
Series: C
6 / 40 08/2015
ANGLE HEAD ASSEMBLY
Item Description Part No Used on
1 ANGLE HEAD HOUSING -
2 BEVEL GEAR SET 399.373
3 BEARING 64368
4 BEARING 758.49
5 NEEDLE BEARING 785.30
6 SPINDLE COLLET 501.59 KA3.135-7 , KA3.36-7 , KA3.21-7
7 SPINDLE M14 6155011420 KA3.36A
8 LOCK NUT 672102
9 COUPLING 2050560153 KA3.135-7
10 COUPLING 2050560163 KA3.36-7 , KA3.21-7 , KA3.36A
11 CAP - SLEEVE 570.390
4
5
11
6
8
7
3
9
10
2
1
A
B
5 Nm
ALoctite 243
BGrease Molykote BR2Plus
10Nm
10Nm

6159949980_07
Series: C
7 / 4008/2015
GEARBOX - MODULE ASSEMBLY
Grease Molykote G68
A1
8
9
10
11
12
2
3
4
5
6
7
A
Gearbox (3000 rpm) 2050505453 Gearbox (5500 rpm) 2050505463
Item Description Part No
1 Pinion sleeve 7T to 15T 2050491103 1
2 O-Ring 22x1.5 455653 1 1
3 Plate back dia. 22.0x1.5 2050491093 1 1
4 Gearcase - M28 2050491013 1 1
5 Needle 2.5x15.8 6157900480 3 3
6 Needle roller 298893 3 3
7 Wheel planet, 17T 2050491073 3
7 Wheel planet, 14T 2050491083 3
7 Wheel planet, 16T 2050493833
8 Shield 2050505863 1 1
9 Cage, output 3000 rpm 2050505823 1
9 Cage, output 5500 rpm 2050505833 1
10 Washer plain 2050505993 1 1
11 Bearing 15x24x5 758.49 1 1
12 Ring internal 2050505423 1 1

6159949980_07
Series: C
8 / 40 08/2015
STRAIGHT GRIP
B
Grease Molykote PG75 Plastislip
A
8 Nm
8 Nm
8 Nm
A
Loctite 480
B
64
5
3
1
2
7
8
9
10
11
12
13
16
15
14
Item Description Part No Qty
1 Kit adaptor 1/4" BSP 472633 1
2 Kit adaptor 1/4" NPT 472623 1
3 Air feed bolt DR300 2050545283 1
4 Filter 252183 1
5 Inlet O-Ring 450803 1
6 Exhaust grid 2050506083 1
7 O-Ring 27x1.5 6156582960 1
8 Sintered bronze silencer 2050505793 1
9Air deector 2050505803 1
10 Straight case valve spring 466453 1
11 Valve sub-assembly 349403 1
12 Seat valve 472673 1
13 Needle 2.5x23.8 6157901450 1
14 O-Ring 3x1 280163 1
15 Plunger 2050504563 1
16 Safety lever 2050502883 1

6159949980_07
Series: C
9 / 4008/2015
MOTOR
Grease Molykote G68
A
27652 ISO VG15
B
0.040
0.025
8
2
7
6
5
3
4
1
A B A
Kit motor 7T 2050500743
Item Description Part No Qty
1 Bearing 4x13x5 216663 1
2 Pin 2.0 x 8 222423 1
3 Housing, bearing rear 2050503723 1
4 Rotor 2050490983 1
5 Blade 2050491113 5
6 Cylinder 2050503713 1
7 Housing, bearing front 2050549363 1
8 Bearing 7x22x7 282123 1
Kit, motor 12T 2050500753
Item Description Part No Qty
1 Bearing 4x13x5 216663 1
2 Pin 2.0 x 8 222423 1
3 Housing, bearing rear 2050503723 1
4 Rotor 2050497763 1
5 Blade, rotor radial 2050491113 5
6 Cylinder 2050503713 1
7 Housing, bearing front 2050549363 1
8 Bearing 7x22x7 282123 1

6159949980_07
Series: C
10 / 40 08/2015
2
3
4
5
1
Item Description Part no. Qty
1 Collet Ø6mm (KA3.135-7, KA3.136-7, KA3.21-7) 6155260790 1
2 1/4” air hose nipple for 6mm ID hose 6157050090 1
3 Flat wrench 25/64” (10mm) 6158010020 1
4 Flat wrench 14mm 6158010050 1
5 Exhaust Hose 2050512593 1
ACCESSORIES INCLUDED
