Detecto GH Series User manual

GH SERIES
FULL FRAME
GLOVE BOX HOLDER
MOUNTING INSTRUCTIONS
IMPORTANT!
PLEASE READ THROUGH INSTRUCTIONS
CAREFULLY BEFORE STARTING INSTALLATION.
Unpacking
Open the carton containing the glove box holder and the mounting hardware. Remove all
packing material. You should have the following components:
QTY PART NO. DESCRIPTION
1 GH SERIES FULL FRAME GLOVE BOX HOLDER
2 6021-1511 SCW PAN HEAD, SHEET METAL #10x1.5, PHILIP DR,
ZINC PLATE, FASTENAL #31366
2 6030-0500 ANCHOR, WALL PLUG FOR #10x1-1/2" SCREW, SOLID
WALL ANCHOR AF6-1/4, FASTENAL #50945
Tools Required
Drill 1/4 Drill Bit #1 Philip Screwdriver
Installation
1. Determine the desired location and height of
where the glove box holder is to be mounted.
2. Place the holder against the wall. Insure it is
level and mark the holes to use to mount the
holder.
3. Remove the holder and drill two 1/4” diameter
holes for the mounting wall anchors.
4. Insert the wall anchors in the wall until they are
flush with the wall.
5. Insert the screws into the anchors and then
tighten the screws until about a 1/8’ gap is
between the screw head and the anchor.
6. Align the large end of the slotted holes in the
holder over the screw heads and pull down to
secure the holder to the wall.
7. The glove box holder is now ready for use.
1 Box Mounting Dimensions
8”
SNAP-ON CLIP

MOUNTING INSTRUCTIONS, Cont.
2 Box Mounting Dimensions
3 Box Mounting Dimensions
0903-M104-O1 Rev A 203 E. Daugherty, Webb City, MO 64870 USA Printed in USA
05/05 Ph: 417-673-4631

Fax: [phone]
www.detecto.com
6 1/2”
9 3/16”
6 1/2”
15 3/16”
Technical Support: Ph: 866-254-8261

[email protected]
