DeWalt DCMASBC1N-XJ User manual

DCMASBC1

B
Copyright DeWALT
English (original instructions) 3

1
Fig. A
XXXX XX XX
1
2
4
Fig. B
3
5
8
9
6
17

2
610 mm
Fig. F Fig.G
Fig.C Fig. D
3
4
18
19
17
3
16
12
10
11
Fig.E
13
14

ENGLISH
3
aWARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
EC‑Declaration of Conformity
Machinery Directive
o
Brush Cutter
DCMASBC1
DeWALT declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN 62841‑1:2015, EN ISO 11806‑1:2011.
2000/14/EC, Brush Cutter, Annex V
DEKRA Certification B.V.
Meander 1051/ P.O. box 5185
6525MJ ARNHEM / 6802ED
ARNHEM, Netherlands
Notified Body ID No.: 0344
Level of accoustic power according to 2000/14/EC
(Article 12, Annex III, L ≤ 50cm):
LPA (measured sound pressure) 88dB(A)
uncertainty (K) = 2.5 dB (A)
LWA (guaranteed sound power) 102dB(A)
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice‑President Engineering, PTE‑Europe
DeWALT, Richard‑Klinger‑Straße 11,
65510, Idstein, Germany
31.12.2020
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in EN62841
and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm
(relevant for vibration), organisation of workpatterns.
DCMASBC1
Voltage VDC 54
Low speed /min 3700
High speed /min 4600
Blade Diameter mm 200
Weight kg 1.9
Noise values and vibration values (triax vector sum) according to EN62841-1
LPA (emission sound pressure level) dB(A) 88
K (uncertainty of sound pressure level) dB(A) 2.5
LWA (sound power level) dB(A) 100
K (uncertainty for the given sound level) dB(A) 1.6
Vibration emission value a
h
=
m/s23.9
Uncertainty K =
m/s21.5
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
English (original instructions)
BRUSH CUTTER
DCMASBC1

4
ENGLISH
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non‑skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off‑position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.

5
ENGLISH
ADDITIONAL SAFETY INSTRUCTIONS FOR
BRUSH CUTTERS
WARNING: Cutting elements continue to rotate after the
motor is switchedoff.
• Wear long trousers and boots to protect your legs andfeet.
• Always wear eye protection to protect from thrown objects
and ricochets. The metal blade may throw debris or small
objects that it comes in contactwith.
• Do not wear loose clothing, jewelry, short pants, sandals, or
gobarefoot.
• Before using the appliance, check that your cutting path is free
from sticks, stones, wire and any otherobstacles.
• Make sure the cutting attachment, blade and any guards are
properlysecured.
• Only use the appliance in the upright position, with the cutting
blade near the ground. Never switch the appliance on in any
otherposition.
• Move slowly when using the appliance. Be aware that freshly
cut grass is damp andslippery.
• Do not work on steep slopes. Work across the face of slopes,
not up anddown.
• Never cross gravel paths or roads while the appliance
isrunning.
• Never touch the cutting blade while the appliance isrunning.
• Do not put the appliance down until the cutting blade has
come to a completestandstill.
• Be aware of blade thrust. The appliance could suddenly move
sideways, forward or backwards when the cutting accessory
jams or cataches on an object such as a sapling or treestump.
• Keep hands and feet away from the cutting blade at all times,
especially when switching on themotor.
• Before using the appliance and after any impact, check for
signs of wear or damage and repair asnecessary.
• Close supervision is necessary when the appliance is used
nearchildren.
• This appliance is not intended for use by young or infirm
persons withoutsupervision.
• This appliance is not to be used as atoy.
• Use in a dry location only. Do not allow the appliance to
becomewet.
• Do not immerse the appliance inwater.
• Do not open the body casing. There are not user‑serviceable
parts inside
• Do not operate the appliance in explosive atmospheres, such
as in the presence of flammable liquids, gases ordust.
• Do not use toothed blades, such as saw blades, with
thisproduct.
Safety of Others
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
ofinjury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may causeexplosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk offire.
6) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized serviceproviders.

6
ENGLISH
Description (Fig. A)
WARNING: Never modify the tool. Damage or personal
injury couldresult.
1 Brush cutter pole
2 Guard
3 Brush cutter housing
4 Brush cutter blade
Intended Use
Your brush cutter attachment has been designed to be used
with your DCMAS5713 powerhead. This brush cutter has been
designed for household trimmingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT let children come into contact with the tool. Supervision
is required when inexperienced operators use thistool.
Date Code Position (Fig.A)
The date code 5, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020XX XX
Year and week of Manufacture
Wear eyeprotection.
Wear earprotection.
Do not expose the tool to rain or high
humidity or leave outdoors while it israining.
Switch the tool off. Before performing any
maintenance on the tool, remove the battery
from thetool.
Keep bystandersaway.
Wear slip‑resistantfootwear.
Wear slip‑resistantgloves.
Do not use circular metalblades.
No hands
Beware of bladethrust.
Directive 2000/14/EC guaranteed
soundpower.
Package Contents
The package contains:
1 Brush cutter
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Residual Risks
To ensure you have good footing on slopes, do not overreach.
Keep your balance at all times. Always walk, do notrun.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged useetc.
Even with the application of the relevant safety regulations and
the implementation of safety devices, certain residual risks can
not be avoided. These include:
• Injuries caused by touching any rotating/movingparts.
• Injuries caused when changing any parts, blades
oraccessories.
• Injuries caused by prolonged use of a tool. When using any
tool for prolonged periods ensure you take regularbreaks.
• Impairment ofhearing.
• Health hazards caused by breathing dust developed when
using your tool (example: working with wood, especially oak,
beech and MDF.)
• Risk of burns due to accessories becoming hot
duringoperation.
SAVE THESE INSTRUCTIONS
been given supervision or instruction concerning use of the
appliance by a person responsible for theirsafety.
• Do not use this product near bystanders. The metal blade
could throw or richochet small objects that it may come
in contact with, such as small rocks, causing serious injury
tobystandars.
• Children must be supervised to ensure that they do not play
with theappliance.
• When the appliance is stored or transported in a vehicle
it should be placed in the boot or restrained to prevent
movement following sudden changes in speed ordirection.
• When not in use, the battery should be removed. The
appliance should be stored in a dry , well ventilated place out
of reach ofchildren.
• Children should not have access to storedappliances.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.

7
ENGLISH
Brush Cutting (Fig. F, G)
With the brush cutter on, angle it and swing side to side as
shown in Fig.F.
Maintain a minimum distance of 24" (610mm) between the
guard and your feet as shown in Fig.G.
WARNING: Keep the rotating blade roughly parallel with
the ground (tilted no more than 30°). This trimmer is not
an edger. DO NOT TILT the brush cutter so that the blade
is spinning near a right angle to the ground. Flying debris
can cause seriousinjury.
Helpful Cutting Tips
• Use the tip of the blade to do the cutting; do not force tool
head into uncutgrass.
WARNING: Hold the tool using only the designated
gripping surfaces: The powerhead handle and the
auxiliary handle.
WARNING: Do not use the pole as a grippingsurface.
Proper hand position requires one hand on the powerhead
handle13 and one hand on the auxiliary handle14.
Proper Hand Position (Fig. A, E)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Attaching and Adjusting the Shoulder Strap
(Fig. E)
WARNING: The shoulder strap should only be slung over
one shoulder and not across thebody.
WARNING: Use of a shoulder strap10is required while
using thistool.
Attach the strap to the tool as shown in Fig. E and adjust for
proper balance and support.
1. Attach the strap mount.
2. Snap the shoulder strap latch 12 onto the strap
mount
11
located on the unit, just in front of the ON/OFF
trigger as shown in Fig.E. Adjust the strap so it fits over
yourshoulder and provides proper balance andsupport.
Assembling the Brush Cutter Attachment to
the Powerhead (Fig. A, B)
1. When installing the brush cutter attachment1 into the
upper powerhead pole7, align the latching button8 with
the main hole9 as shown in Fig. B.
2. Lock the knob6.
3. When properly assembled, it should look like Fig. B.
Powerhead (Fig. B)
(DCMAS5713 sold separately)
WARNING: To reduce risk of injury:
• Before any use, be sure everyone using this unit
reads and understands all manufacturer's safety
instructions and other information contained in
manufacturer'smanual.
• Never apply power without an attachment being
properly mounted to thepowerhead.
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories, or prior to
cleaning.An accidental start‑up can causeinjury.
Your attachment is designed such that the powerhead can
separate from the brush cutter attachment by releasing the
knob6 and gently pulling them apart by their poles1,7.
This should only be done with the power switch off and the
battery pack removed. Inside the upper powerhead pole7 is a
mechanical coupling that will spin if the powerhead is turned
on. This coupling can cause severe injury if contacted while the
powerhead isoperating.
NOTE: DO NOT operate the brush cutter attachment WITHOUT
the barrier properly assembled to the powerhead pole.
NOTE: A double shoulder harness is required if the mass of the
tool and battery pack exceed 7.5kg.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
WARNING: Use only DeWALT battery packs andchargers.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.

8
ENGLISH
Replacing the Cutting Blade (Fig. A, C, D)
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories, or prior to
cleaning. An accidental start‑up can causeinjury.
When replacing the blade, use 8" (203 mm) diameter blades.
Use DeWALT replacement blade Model No. DT20680. Other
sizes may degrade performance or cause damage to thebrush
cutterattachment. DO NOT use toothed blades, such as saw
blades, with thisproduct.
1. Removebattery.
2. Remove brush cutter attachment from thepowerhead.
Reverse the steps under Assembling the Brush Cutter
Attachment to thePowerhead.
WARNING: Use gloves and proper eye protection. Turn the
brush cutter on its side. Be careful of sharp edges of blade.
Removing the Cutting Blade
1. Align the shaft bushing hole16with the locking rod slot17
and insert a screwdriver (not supplied) into the bushinghole.
Hold the screwdriver inposition.
2. While holding the screwdriver, remove the flange nut 18
by turning it counterclockwise with a 13mm wrench (not
supplied) as shown in Fig.C.
3. Remove the blade spacer 19 and the blade 4 as shown
in Fig. C. Examine all pieces for damage and replace
ifnecessary.
Installing the New Cutting Blade
1. Install new blade4 on shoulder of the blade cutter shaft
bushing15 as shown in Fig.C.
2. Align the shaft bushing hole16with the locking rod slot17
and insert a screwdriver into the bushinghole.
3. Hold the screwdriver inposition.
4. Install the blade spacer 19 on the blade so that the wide
flat side faces theblade.
5. Install flange nut18with the flange against the blade
spacer19and securely tighten with a13mm wrench
(notsupplied).
6. Tighten nut counterclockwise against the blade while
holding the locking rod:
‑If using a torque wrench and an 13mm socket tighten
to: 325‑335 in lb, 27‑ 28ft. lb, 37‑ 38Nm.
‑Without a torque wrench, use a 13mm closed‑end or
socket wrench, turning the nut until the blade retainer is
snug against the shaft bushing. Ensure that the blade is
installed correctly, then rotate the nut an additional 1/4
to 1/2 turncounterclockwise.
7. Remove the screwdriver from the locking rod slot17.
Use a transport cover on the metal blades when transporting
and storing the brush cutterattachment.
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
D
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
C
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
• Wire and picket fences cause extra blade wear, even
breakage. Stone and brick walls, curbs, and wood may wear
stringrapidly.
• In long growth, cut from the top down and do not exceed
12" (305mm)high.
• Keep brush cutter head tilted toward the area being cut; this
is the best cuttingarea.
• The brush cutter cuts best when passing the unit from the
left to right. This will avoid throwing debris at theoperator.
• Avoid trees and shrubs. Tree bark, wood moldings, siding,
and fence posts can easily be damaged by theblade.

9
ENGLISH
Protecting the Environment
wSeparate collection. Products and batteries marked
with this symbol must not be disposed of with
normal householdwaste.
Products and batteries contain materials that
can be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
ourenvironment:
• Run the battery pack down completely, then remove it from
thetool.
• Li‑Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.

Belgique et
Luxembourg België en Luxemburg
DeWALT - Belgium BVBA
Egide Walschaertsstraat 16
2800 Mechelen
Tel: NL 32 15 47 37 63
Tel: FR 32 15 47 37 64
Fax: [phone]
www.dewalt.be
[email protected]
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620 Albertslund
Tel: [phone]
Fax: [phone]
www.dewalt.dk
[email protected]
Deutschland DeWALT
Richard Klinger Str. 11
65510 Idstein
Tel: [phone]
Fax: [phone]
www.dewalt.de
[email protected]
Ελλάς DeWALT (Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα
SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
[email protected]
España DeWALT Ibérica, S.C.A.
Parc de Negocios “Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
Tel: [phone]
Fax: [phone]
www.dewalt.es
[email protected]
France DeWALT (Stanley Black & Decker France SAS)
62 Chemin de la Bruyère
CS 60105,
69574 DARDILLY Cedex
Tel: [phone]
Fax: [phone]
www.dewalt.fr
[email protected]
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902 Urdorf
Tel: 044 - 755 60 70
Fax: 044 - 730 70 67
www.dewalt.ch
[email protected]
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: [phone]
Fax: [phone]
www.dewalt.ie
[email protected]
Italia DeWALT
via Energypark 6
20871 Vimercate (MB), IT
Tel: [phone]
39 039-9590200
Fax: [phone]
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120 AB BORN
Tel: [phone]
Fax: [phone]
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405 Oslo, Norge
Tel: [phone]
Fax: [phone]
www.dewalt.no
[email protected]
Österreich DeWALT
Werkzeug Vertriebsges m.b.H
Oberlaaerstrasse 248, A-1230 Wien
Tel: 01 - 66116 - 0
Fax: 01 - 66116 - 614
www.dewalt.at
[email protected]
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2º Esq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770 071 Paço de Arcos
Tel: [phone]
Fax: [phone]
www.dewalt.pt
[email protected]
Suomi DeWALT
PL47
00521 Helsinki, Suomi
Puh: 010 400 4333
Faksi: 0800 411 340
www.dewalt.fi
[email protected]
Sverige DeWALT
BOX 94
43122 Mölndal
Sverige
Tel: [phone]
Fax: [phone]
www.dewalt.se
[email protected]
Türkiye Sanayi ve Ticareet Bakanlığı tebliğince kullanim ömrü 7 yıldır.
Stanley Black & Decker Turkey Alet Üretim San. Tic. Ltd.Şti.
AND Kozyataği - İçerenköy Mah. Umut Sok. AND Ofis Sit. No: 10-12 / 82-83-84
Ataşehir/İstanbul, Türkiye
Tel: [phone]
Faks: [phone]
www.dewalt.com.tr
[email protected]
United Kingdom DeWALT, 270 Bath Road;
Slough, Berks SL1 4DX
Tel: [phone]
Fax: [phone]
www.dewalt.co.uk
[email protected]
Australia DeWALT
810 Whitehorse Road Box Hill
VIC 3128 Australia
Tel: Aust 1800 338 002
Tel: NZ 0800 339 258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: [phone]
Fax: [phone]
www.dewalt.ae
[email protected]
N833480 12/20
