DGF Fabrications Renaissance 16" User guide

NJL/GTECH- 3/10/06 Revision No.3 0
User, Installation & ervicing Instructions
for the following range of fires:
RENAI ANCE CLA I HOT BOXE
(16c, 18″ & 22″ VARIANT ),
IN ET FIRE (16″&18″)
AND RENAI ANCE CLA II MULTI-FLUE
HOTBOX
These appliances are for use on
NATURAL GA (G20) at a supply pressure of 20mbar
Or
LPG PROPANE (G31) at a supply pressure of 37 mbar
They are supplied as, CAT I
2H
in case of NG and CAT I
3P
in case of LPG, designated
category of appliances.
This leaflet has been prepared to help you install and service your gas fire.
This leaflet has been prepared to help you
install and service your gas fire.
Please read the instructions carefully before you
begin installing this fire, and once complete hand to
user to keep handy for future reference.
DGF Fabrications

NJL/GTECH- 3/10/06 Revision No.3 1
GENERAL
The Renaissance range of fuel effect gas fires are intended for decorative purposes. They are, not designed to
be converted or used on any other fuel, other than that specified on the appliance data plate.
TYPE OF FLUE UITABLE
16” & 18” Insets and 16”, 18” & 22” Hotboxes
Appliances are suita le for Class 1 flue systems only, and can e hearth mounted to a non-
com usti le wall or suita le fire surround.
The flue or chimney should have no dimension across its axis of less than 175mm (7in), and a
minimum height of not less than 3m (10ft) from the hearth to the termination point of the flue.
The chimney must have any damper or register plate removed or fixed permanently in the fully
open position.
16” Renaissance Class II Hotbox
Appliance is suita le for oth Class I & II application. Class II using either metal ox and
minimum 5” diameter flue or pre-cast flue provided the starter locks are of sufficient size to
accommodate. In either case a minimum height of not less than 3m (10ft) is required.
Note: The Dunbrik Mini Clearflow flue block system employing “M set” starter bricks are ideal (see diag.)
16” & 18” Insets
The 16” & 18” Inset fires are only suita le for installation into either: Hot oxes supplied y DGF Fa rications
or into existing solid fuel urning fireplaces where components to BS 1251 “Open fireplace Components” are
used.
See diagram for typical chair rick design.
APPROVAL /RECOMMENDATION
The appliances have een designed to meet the requirements of EN509, and other relevant
safety standards, ut during use parts of the Hot ox casing may ecome HOT. It is therefore
recommended that a suita le fireguard to BS6539 “Fireguards for use with solid fuel appliances”
e used where the very young or infirm are concerned.
TATUTORY REQUIREMENT :
A CORGI REGISTERED INSTALLER must carry out the installation of this appliance in
accordance with the current issue and relevant requirements of:-
 This installation ooklet.
 The gas safety (installation and use) regulations.
 The uilding regulations.
 The uilding standards (Scotland) regulations.
 The health and safety at work act.
 The control of su stances hazardous to health.
 Any applica le local regulations.
Typical pre-cast
starter bricks.
Typical metal
flue-box.
Typical solid-fuel
chairbrick
Fig 1

NJL/GTECH- 3/10/06 Revision No.3 2
Detailed recommendations are contained in the current issue of the following British Standards
and Codes of Practice:-
BS 5440 Part 1 Specifications for installation of flues.
BS 5440 Part 2 Specification for installation of ventilation for gas appliances.
BS 6461 Part 1 Codes of practice for masonry chimneys and flue pipes.
BS 5871 Part 3 Decorative fuel effect gas appliances of heat input not exceeding 15kW
(2
nd
& 3
rd
family gases).
BS 6891 Specification for installation of low pressure gas pipe work of up to
28mm (R1) in domestic premises (2
nd
family gases).
BS 8303 Installation of domestic heating and cooking appliances urning solid
mineral fuels.
BS 1251 Specification for open-fireplace components.
This installation ooklet must not e taken as overriding statutory requirements.
FRONT AND FRET UITABLE FOR ALL FIRE :
The
Renaiss
ance
range of
applianc
es can e used with a variety of fire fronts, ut only if they meet the minimum ventilation
requirements shown a ove.
PECIFICATION :
DIMEN ION HOTBOX FIRE :
For full dimensions see Fig No.1 and ta le elow.
D
E
C
F
G
H
H
B
A
Fig 3
Total free area in
ash pan cover
should add up to a
minimum of 4000mm2
Fig 2

NJL/GTECH- 3/10/06 Revision No.3 3
Overall Dimensions (Fig 3) :
Model 16” (Class I) 18” (Class I) 22” (Class I) 16” (Class II)
Overall width (A) 505 555 655 470
Overall height (B) 585 585 585 585
Overall depth (E) 215 215 215 140
pecific Dimensions (Fig 3) :
Model C D E F G H
16” Hotbox 405 555 215 100 285 60
18” Hotbox 455 555 215 100 335 60
22” Hotbox 555 555 215 100 555 60
16” Multiflue 330 555 140 100 265 -

NJL/GTECH- 3/10/06 Revision No.3 4
HEAT INPUT/INJECTOR MARKING /BURNER PRE URE ETTING
:
Model
Gross heat
input kW
Natural gas
injector:
Natural gas
setting
pressure
(mbar):
LPG gas
injector:
LPG gas setting
pressure (mbar):
Max Min Marking Max Min Marking Max Min
16”
7.0 3.5 510 15.0 4.0 220 33.0 9.0
16" (N.V.)
6.75 2.5 460 16.0 2.5 190 30.2 4.6
16" (Class II
Multi-flue)
5.5 3.0 460 10.7 3.4
16" (Class II
Multi-flue)
6.8 3.2 190 30.7 7.6
18”
8.8 4.5 650 13.0 4.0 240 32.0 8.0
22"
10.5 5.5 700 * 18.0 5.0 340 30.0 8.5
INJECTOR :
All injectors are marked (on the side of the ody) as ta le a ove.
Note: Injector marked 700 * is manufactured y Stereomatic; all other injectors are Bray Cat 82
type.
MAIN GA CONNECTION :
8mm O.D. X M14 compression nut on R.H. side of gas control.
Anglo Nordic type:
APPLIANCE ERIAL NO. LOCATION :
Data plate affixed under urner assem ly on appliance ase.
PECIFIC REQUIREMENT :
The fire must e installed in either
a) A specially prepared non-com usti le uilders opening with a chimney free from
o struction and conforming to Fig no. 2.
Or
) A non-com usti le fire resistant fireplace with chimney free from o struction and
conforming to the current Building Regulations. Make good as appropriate to leave and
opening with dimensions conforming to Fig no. 2. This may mean that the fire ack (or
chair rick) will have to e removed.
They must NOT e mounted on a com usti le floor or carpet
The fireplace or uilders opening should only have two openings, an entrance through the
fireplace for the appliance, and an exit for the flue gas, all other openings must e sealed off.
A flue test in accordance with national regulations must be carried out to prove that there is a
positive up draught.
In the case of a Class I installation the chimney must e swept prior to installation.
The ase of the uilders opening must e flat, level and square with the fireplace.

NJL/GTECH- 3/10/06 Revision No.3 5
D
E
B
C
A
H
F
J
G F
A minimum flat level area around
the opening must be provided to
seal the appliance to the
fireplace opening.
Fig 4
The fires are not suita le for wall mounting. A non-com usti le hearth conforming to the
dimensions shown in Fig no. 2 must e fitted in front of the fire.
VENTILATION :
Ventilation required for these appliances must e in accordance with the rules in force and
checked regularly for o structions:-
All 18” inset, 18”Hotboxes and 22” Hotboxes must have a permanent air vent of an effective
area of at least 100cm
2
(15.5in
2
) in the room. The vent must e either to outside air or to an
adjacent room having permanent vent to outside of the same area.
16” NV & 16” Class II Hotbox do not normally (spillage test to determine) require any additional
ventilation into the room into which they are to e installed when installed in Great Britain.
If the appliance is installed in IRELAND, a minimal cross sectional area of 100mm
2
is required.
IN TALLING THE APPLIANCE (Hearth clearances) :
A non-com usti le
hearth with a minimum
thickness of 12.5mm
and having a perimeter
of 50mm a ove floor level is required to discourage placing carpets or com usti le materials
close to the hearth. The width must e a minimum of 150mm either side of the fireplace opening
and a depth of 300mm from the front face of the fire opening. (Fig. 4).
Note: - If this appliance is to e fitted not less than 9” up the Wall, then no hearth need e fitted.
But extra care must e taken to ensure that loose fret cannot e knocked from position
Model A Min B Min C Min D Min E Min F Min G Min H Min I Min K Min
16” 415 560 265 520 600 150 715 300 50 20
18” 465 560 265 570 600 150 765 300 50 20
22” 565 560 265 670 600 150 865 300 50 20
Clearance to sides and shelves :
150
Fig 5
150mm or more a ove the top point of the
appliance, provided it does not project

NJL/GTECH- 3/10/06 Revision No.3 6
IN TALLATION :
Prepare the fireplace and chimney as previously descri ed.
Unpack the fire. For ease of installation remove the urner assem ly. Unscrewing the two
retaining screws at the ase of the front support legs can do this. Remove the complete urner
assem ly and rear ase oard.
Within the ase of the ox, there are three mounting holes. Place the ox centrally into the
fireplace opening; making sure the ox is square and level. Mark through the three mounting
holes and remove the ox. Using a 6mm masonry drill, drill and plug the fixing holes.
Lay the gas supply pipe in the fireplace opening. A means of isolating the gas supply other than
the appliance control valve should e fitted in the gas supply line. The inlet pipe to the appliance
should e 8mm O.D rigid or semi-rigid tu ing. If the supply pipe is more that 1.5 meters in length
then the gas supply pipe diameter should e increased to a minimum of 1.5mm from that point.
Access through the outer casing of the appliance is through the rear or side access holes. The
gas supply pipe should e positioned within the fireplace as shown in fig No 21. A separate hole
is made through the fi re and the tu e passed through. The tu e must e sealed around the
hole using suita le silicon mastic, flexi le fire cement or other approved method.
The ox is repositioned within the fireplace, sealed to the opening, and secured to the hearth y
means of fixing screws. Check seal around the edges.
Replace the urner assem ly, rear ase oard and make good the final gas connection into the
main control valve. Finally check the whole system for gas soundness.
Using spacer frame :
The 16” Hotboxes Class I and Class II and NV version (no vent) can e installed into various
flue situations with a minimum of preparation provided the following o servations are made in
assessing suita ility of fit.
Class II fire will fit into a 16” opening complete with chair- rick in place provided spacer frame is
used. See diagram.
Gap should be
no less than 50mm
Renaissance Class II fitted
with 50mm spacer frame.
16" chairbrick to
BS 1251in builders
opening fireplace.
Plan view
Fig 6

NJL/GTECH- 3/10/06 Revision No.3 7
Pre-cast starter blocks :
The class II Renaissance Hot ox will fit most pre-cast starter locks: The lock size will dictate
whether or not a spacer frame will e required. Shown are some typical starter rick sizes in
common use:
IN TRUCTION pecific to Class II Hotbox only (pages 8-12)
Overall dimensions:-
CLA I APPLICATION Tapered openings fitted with chairbrick
These are tapered fire ricks, which were originally designed for solid fuel, and may require the
spacer ox to e fitted if the depth of the opening is not sufficient.
Dunbrik "M set" starter brick.
450
220
Dunbrik "M set" starter brick.
450
220
Fig 7
The Rena
issance
Class I Hotbox will
fit only the larger
starter block such
as Dunbrik “M set”
315
115
Dunbrik "Standard set"
Dunbrik "Red set"
410
115
Fig 8
470.0
586 550.0
30
100.0
140.0
50.0
370.0
90
180.0

NJL/GTECH- 3/10/06 Revision No.3 8
Note: It is important that enough space is allowed for ehind the fire for any falling de ris to
collect without locking up the flue-way. The following recommendations should e adhered to.
Class II Applications
Opening Requirements :
The following requirements are for dry lined walled pre-cast flues conforming to BS1289 Part 1:
A pre-cast flue conforming to the current issue of BS 1289 and BS 1289 Part 1 including properly
constructed pre-cast flues with a cross sectional area of 13000mm
2
.
210
With the chair rick in position
then the minimum depth of the
fire opening must e not less
than 210 mm for the appliance to
e fitted without the spacer ox.
Fig 9
210-160
If the depth of the fire opening
with the chair rick in position is
etween 210 mm and 160 mm
then the spacer ox must e
fitted, or the chair rick
removed.
Fig 10
Min 190
With the chair rick removed
then the minimum depth of
the fireplace opening must e
not less than 190 mm for the
appliance to e fitted without
the spacer ox.
Fig 11
190-140
If the depth of the fireplace
opening with the chair rick
removed is less than 190 mm
ut more than 140 mm, then
the spacer ox must e fitted.
Less than 140 mm on a Class
I flue, then the appliance is
unsuita le for this application.
Fig 12
Check that the plaster oard or
plaster is sealed to the edge of the
opening as shown.
Min 325
Sealant
Starter
block Plaster or
plasterboard
Fig 13

NJL/GTECH- 3/10/06 Revision No.3 9
Rebated urrounds :
The re ate is the distance from the front of the non-com usti le surface, i.e. mar le to the plaster or wall
surface. Check the overall depth of the fireplace opening.
If the depth of the starter lock plus the re ate adds up to less than 140mm, then the spacer ox must e
fitted. Note this dimension should not e less than 90mm.
The minimum depth of the starter lock
including the plaster must not e less
than 140 mm if no spacer frame is to e
used and 90mm if the spacer frame is
used.
Class II without spacer frame.
Minimum:
325 mm
Minimum 140
Fig 14
Opening width
min 406
max 450
Min depth 140
Opening height:
min 560
max 575
The height of the starter lock
opening must e not less than
560 mm, and not more than 575
mm from the top of the hearth, to
the underside of the opening.
Fig 15
Minimum width
of starter brick:300mm
Class II fitted with spacer frame.
mm
Minimum depth
including
plaster/marble:90 mm
The minimum width of the
starter lock opening must e
not less than 325 mm without
spacer frame and 300mm
when spacer frame used.
Fig 16

NJL/GTECH- 3/10/06 Revision No.3 10
Note: If using a re ate surround with a flue previously used for solid fuel urning then an additional 50mm
should e added to the a ove dimensions for de ris accommodation.
If the depth of the starter lock plus the re ate when added up together is more than the 140mm then the
appliance can e fitted without the spacer ox.
FITTING THE PACER BOX :
Class 1 Application :
Class 2 Applications :
Flue Box Application :
90 Min
140 Min
Without spacer frame. With spacer frame
Fig 17
Position the spacer ox central to the fireplace opening.
Using the four angle rackets provided, position the rackets
so as to clamp the spacer ox to the fireplace surround. Mark
through the hole in the racket into the side of the fireplace
opening. Drill and plug the four holes. Remove the spacer
ox and run suita le sealant over the face, which is to e
clamped to the fireplace surround, reposition ox, f it clamps
in position and screw to wall. Fig. No. 18.
Fig 18
Position the spacer ox central to the fireplace opening.
Using the four angle rackets provided, position the
rackets so as to clamp the spacer ox to the fireplace
surround. Mark through the hole in the racket into the
inner skin of the flue ox and drill for self-tapping screws.
Remove the spacer ox and run suita le sealant over the
spacer ox face, which is to e clamped to the fire
surround, and screw to inside of flue ox. Fig. No. 19.
Fig 19
Position the spacer ox central to the fireplace opening.
Using the four angle supplied, end the long end of the
racket form a “ “ shape, the depth of the racket is to e
the same depth of the re ated surround.
Position the four angle rackets so as to clamp the ox to the
fireplace surround. Mark through the hole in the front face of
the starter lock, drill and plug the four holes.
Remove the spacer ox and run a suita le sealant over the face,
which is to e clamped to the fire surround. Reposition spacer
ox
fit
clamps in
position and screw to wall. Fig. No. 20.
Fig 20

NJL/GTECH- 3/10/06 Revision No.3 11
pacer Box
On completing and positioning of the gas supply pipe, slide the Hot Box into position, then using the four
countersunk screws provided, place the screws through the four holes outer trim of the Hot Box, and into
the corresponding screwed holes of the spacer.
Screw and seal the Hot Box to the spacer ox, ensuring that the heads of the screws are not protruding
a ove the countersunk holes.
Fitting the Fire without pacer Box
Slide the appliance fully into the fireplace opening. Ensure that the appliance is level, square, and central,
mark the position of four holes in the outer trim, and remove the appliance. Using a pilot drill, carefully drill into
the fireplace surround at the positions marked. Then using a 6mm drill, carefully drill out the pilot holes
and plug.
On completing and positioning of the gas supply pipe, slide the Hot Box into position. Seal and screw the
Hot Box to the fireplace surround, ensuring that the heads of the screws are not protruding a ove the
countersunk holes.
Fitting the Brass Trim
After the appliance has een commissioned and spillage tested, the final operation is to clip the decorative
rass trim onto the outer trim of the Hot ox.
Gently slide the two sidepieces into position. Using the inner return edge of the rass trim to clip over the
inner edge of the Hot ox trim. The top piece is then placed in position in the same manner. Finally the
plastic protective cover is carefully removed.
Gas upply :
Connection
A means of isolating the gas supply other than the appliance control valve should e fitted in the gas supply
line to the fire.
The inlet pipe to the appliance should e 8 mm O.D. rigid or semi-rigid tu ing. If the supply pipe is more
than 1.5 metres in length then the gas supply pipe diameter should e increased to a minimum of 15 mm
from that point.
110 Restrictor elbow
Concealed Connection
There is access through the outer casing of the appliance,
via, the rear and side access holes. The gas supply pipe
should e positioned within the fireplace hearth as detailed
Fig. No. 21. A hole is made through the fi re, and the tu e
push through it, the fi re acting as a seal around the tu e.
Fig 21

NJL/GTECH- 3/10/06 Revision No.3 12
LAYING THE COAL (ALL FIRE )
The coal uild is made up of 4 rows.
Detailed in the ta le elow is the num er of coals required per model.
COAL BUILD DATA :
MODEL Row 1 Row 2 Row 3 Row 4
16”/NV 6 5 4 5
18” 7 6 5 6
22” 9 8 7 8
Multiflue 6 5 4 5
The coals supplied are rectangular in shape with rough torn edges. It is important to use only that num er
of coals stated in these instructions and supplied. DO NOT pack THE COAL in tight ut leave air gaps
etween the coals to allow flames to pass through the coal uild.
Note:
Coal laying procedure is shown for the 16” Renaissance Hot ox/Inset. All other models should e laid in a
similar fashion ut allowing for the extra coals in each row to e accommodated on the wider models. (See
ta le a ove)
The coals should e laid as detailed in Fig nos.22-25, ensure that no coals are in such a position that they
ecome unsta le and fall off the fire ed.
Hands should e washed after handling coals.
COAL GUARDS
BURNER
PILOT
GUARD
DETAILS OF BURNER ASSEMBLY
FIRE FRONT NOT SHOWN
COAL GUARDS
BURNER
PILOT GUARD
Fig 22

NJL/GTECH- 3/10/06 Revision No.3 13
WITH FRONT AND FRET IN POSITION
The second row of coals is placed in the
vie created y the first row. The coals are
placed so as to rest on the rear of the front
row and the coal supports. The coals
should e angled the opposite way to the
front row in order to maintain a random
coal effect.
2nd ROW
Fig 23
The third row of coals is placed ehind
the 2
nd
row eing supported y the
ase- oard and resting in the “v” formed y
the 2
nd
row of coals. Again the coals are
laid at an angle to the previous row with
the edges angled up as shown.
3RD ROW
Fig 24
The 4
th
row of coals is placed in the “v”
ehind the 3
rd
row of coals and in front
of the ack wall. The coals are
4TH ROW
Fig 25

NJL/GTECH- 3/10/06 Revision No.3 14
COMMI IONING THE FIRE :
Remove the control valve cover y pulling it forward. Fig. No. 9. Slacken the pressure test point
sealing screw and connect a suita le pressure gauge.
The gas control valve is fitted with a piezo spark ignitor, maximum and minimum flow adjusting screws, and
a pressure test point. If the main urner or pilot goes out for any reason DO NOT attempt to relight the pilot
for three minutes .
Remove the control valve cover y pulling it forward (fig no 26). Slacken and remove the pressure test point
sealing screw and connect a suita le gauge.
PILOT
OFF
Remove control
cover by pulling
forward.
Fig 26
Pressure
test point.
Fig 27
Control with cover removed.
High rate
adjustment
screw
Low rate
adjustment
screw
Fig 28

NJL/GTECH- 3/10/06 Revision No.3 15
Fig 29
The appliance is cali rated at the factory, and any adjustment should not e necessary, confirm the gas inlet
pressure corresponds with specifications and data plate.
If any large discrepancies occur check meter and pipe work pressure.
Place a compati le front & fret at the front (see fig 2) of the urner, light the fire. When 10-15mins has passed
initiate spillage test using e.g. smoke match. Instruct user in the use and operation of the fire through
demonstration/instructions.
Turn the control kno anti-clockwise from the pilot position to the maximum position, check that the setting
pressure is as stated in the Gas Data.
Turn the control kno clockwise to the minimum position; again check that the setting pressure is as stated in
Gas Data.
Turn the control kno ack to the pilot position remove the pressure gauge from the pressure test point, and
refit the test point sealing screw.
Turn the kno to maximum position to relight the fire and check for gas soundness. Refit the control valve
cover .
CHECK FOR CLEARANCE OF COMBU TION PRODUCT :
It is IMPORTANT that, efore the appliance is handed
over to the user, a full check for clearance of com ustion
products is carried out with the appliance running at the
full on position,
Ensure that all doors and windows of the room are
closed. Remove the ash pan cover and light the fire as
previously descri ed. Replace the ash-pan cover and
leave the fire on maximum gas rate for ten minutes.
Hotboxes:
Insert a smoke match as shown in Fig No.29. Ensure
that the smoke is eing drawn into the opening, along its
full width, particularly the corners of the opening. If in
dou t repeat the procedure after a further ten minutes.
If there is a fan in a near y room then the test must e
repeated with the fan turned on, any interconnecting
doors etween the fire and the fan location must e left
open.
If spillage is detected the chimney or flue may e faulty. The fault must e corrected efore leaving the fire
installed. If the fault cannot e corrected turn off the appliance and disconnect the gas supply to the fire, and
seek expert advice.
Inset Fires:
For inset fires insert smoke match in
position shown and ensure all smoke
is drawn up into chimney. See Fig 30
Smoke match
to e positioned
100mm down
and 10mm in
from this point
Smoke match
Fig 30

NJL/GTECH- 3/10/06 Revision No.3 16
PILLAGE MONITORING Y TEM :
The appliance is fitted with an oxygen depletion pilot In the event of flue lockage or non-evacuation of
com ustion products, the appliance will automatically shut down.
The pilot assem ly is none-adjusta le and is pre-set. It is IMPORTANT that this is not altered, adjusted or y-
passed in any way. If replacement is required, only original manufacturer’s parts should e used.
If the appliance does shutdown automatically leave for 3 minutes efore relighting. If however automatic
shutdown still occurs switch the fire OFF, disconnect the gas supply to the fire and seek expert advice.
IN TRUCT THE U ER :
Leave these instructions with the user, and explain how to light and operate the appliance, including how to
light the appliance using a long lighted spill.
Impress on the user, that the coals must e located in accordance with the instructions, and a CORGI
registered engineer to ensure safe operation should service the appliance at regular intervals.
Advise the user that any smell coming from the fire on initial lighting will quickly disappear after a few hours.
ERVICING :
It is recommended that the fire is inspected/serviced on an annual asis y a CORGI registered engineer. The
service engineer should replace any damaged or roken coals as necessary.
Before commencing any work isolate the gas supply to the fire. After any work ALWAY TE T FOR GA
OUNDNE .
ERVICING PROCEDURE :
Ensure that the fire is switched OFF and is cold efore servicing commences. Isolate the gas supply to the
appliance. Carefully remove all coals from the fire and inspect for damage, remove the fire front and coal
guard.
Using a soft rush remove all soot and de ris deposits from the main urner and pilot. Check condition of the
main urner gauze.
If parts require replacing then removal of the urner assem ly is carried out as follows:-
Disconnect the gas at the inlet to the appliance. Remove the 2 screws at the ase of the urner front support
legs and remove complete urner assem ly. Remove the rear ase oard, check for damage and replace as
necessary.
Check the condition of the thermocouple and spark ignitor.
Clean or replace the main urner injector. The injector should e cleaned y lowing out de ris or wiping it with
a soft rag. Do not use any hard instruments or wire as this may cause damage to it.
Re-assem le the parts and carefully position the completed urner assem ly within the ox and secure the
urner to the ox via the 2 locating screws at the ase of the support legs.
Re-connect the gas supply and test for gas soundness.
Replace any damaged coals as necessary. Check the setting pressures as descri ed in COMMI IONING
THE FIRE.
REPLACEMENT PART :

NJL/GTECH- 3/10/06 Revision No.3 17
Part Numbers :
The following component parts can e purchased from DGF Fa rications quoting following part num ers:
Description 16” Model 18” Model 22” Model
Burner RMB – 16 RMB – 18 RMB – 22
Burner injector RBI – 16 RBI – 18 RBI – 22
Base oard RBB – 16 RBB – 18 RBB – 22
Coal pack RCP – 16 RCP – 18 RCP – 22
Ancillary Components (All models) :
Description Part number
Pilot urner assem ly RPB – 01
Control valve RCV – 01
Control valve kno RCK – 01
Control valve cover RCC – 01
Burner insulating strip RIS – 01
Users manual RUM – 01
Installation manual RIM – 01

NJL/GTECH- 3/10/06 Revision No.3 18
Users Instructions (All fires)
This leaflet has een prepared to help you use and
understand your gas fire.
Please read the instructions carefully before you begin
using this fire and keep the leaflet handy for future
reference.
OPERATION OF THE FIRE
To o tain access to the controls remove the ash-pan cover. The gas control valve cover is marked with the
following positions, Off, Pilot and a graduated section for Minimum and Maximum gas rates Fig.31. The
control kno point should e placed next to the position required.
TO LIGHT THE FIRE :
Ensure that the control kno is in the OFF position. Fully depress the control kno and keep in, turn
anticlockwise, you should feel some resistance to the kno turning; this is the piezo spark generator eing
activated. Upon reaching the pilot position you will here a click, as the piezo spark igniter operates, the pilot
should light. If the pilot fails to light repeat the operation.
Once the pilot has lit, hold the kno in for a further 10-15 seconds to esta lish the pilot. When the kno is
released the pilot should remain alight. If the pilot fails to remain alight repeat the procedure ut hold the kno
in longer to allow the pilot to esta lish.
If however you are experiencing difficulty in lighting the pilot, then the pilot can e lit manually y the use of a
long lighted spill. Place the lighted spill in the area of the pilot, turn the kno to the pilot position and hold in,
the pilot will then light off the lighted spill.
The gas control valve is fitted with a piezo spark generator, which when activated creates a spark at the pilot
head. If the main urner or pilot urners are extinguished for any reason, DO NOT ATTEMPT TO RELIGHT
THE PILOT FOR THREE MINUTE .
TO ALTER THE HEAT ETTING
With the main urner lit the heat setting is varia le etween high and low, and at any required setting etween.
See fig 31.
TO TURN THE FIRE OFF :
To turn the fire off, turn the control kno to the minimum position, slightly depress the kno and continue
turning clockwise until the pilot position is reached. The fire will go out and the pilot light will remain lit, and
may, if required e left on for intermittent use.
OFF
PILOT
OFF
PILOT
OFF
PILOT
OFF
PILOT
Off Pilot only Burner minimum Burner maximum.
Fig 31

NJL/GTECH- 3/10/06 Revision No.3 19
To turn the fire off completely keep the control kno depressed and continue turning clockwise until the off
position is reached. (See fig 31).
INITIAL OPERATION
Due to newness the fire may give off a slight smell for a short period after commissioning, this will disappear
after a few hours operation.
IMPORTANT NOTE
Whilst the fire meets the required safety standards additional guarding is recommended to give protection to
the young, elderly, and the infirm. Fitting a fireguard, which complies, with current regulations can provide
extra security.
The appliances have een designed to meet the requirements of EN509, and other relevant safety standards,
ut during use parts of the Hot ox casing may ecome HOT. It is therefore recommended that a suita le
fireguard to BS6539 “Fireguards for use with solid fuel appliances” e used where the very young or infirm are
concerned.
Never allow ru ish to e thrown on to the coal ed of the appliance, or otherwise distur the fuel ed. Any
hearth at the front of the fire should never e covered with com usti le flooring or materials.
The chimney should e checked annually to ensure continued clearance of com ustion products, and that
there is no excessive uild up of soot. It is recommended that the fire also e inspected/checked on an annual
asis y a CORGI registered engineer.
CLEANING
Cleaning should e carried out only when the fire is turned off and Cold. If the fire has a ack ox, the
rassware on the fire may e cleaned using an appropriate metal polish, care should e taken not to let the
metal polish come into contact with the paintwork, as metal polished, steel wool, solvent and vitreous enamel
cleaners will harm the paintwork.
The flame effect of the fire may deposit some soot onto the coals, whilst light powdery deposits are accepta le,
large deposits will need to e removed, along with any de ris, which may have collected. This can e done
using a soft rush. Remove the coals for cleaning. Dust down using soft rush. Check the urner and
remove any deposits, which may have collected, again y using a soft rush.
It is advised that a vacuum cleaner should not e used
.
REMOVING AND REPLACING COAL
Ensure that the fire and pilot are turned OFF and that the fire is cold.
In time due to expansion and contraction, the "coals" may settle. It is suggested that the coals unless
satisfactory e re-arranged. The settlement of the coals may cause minor a rasions and expose some white
spots. These spots usually add realism to the fire when in operation.
If coals are to e replaced or re-arranged then remove the existing coals and replace as descri ed in
Installation Instructions (pages 12-14).
Note: - coals can e rotated a out their positions as an aid to alancing the flame picture. This should only e
done y using a pair of long handled tongues.
Ensure that NO coals are in such a position that they could ecome unsta le and fall off the fire ed.
It is important to use only that num er of coals stated in these instructions.
Hands should e washed after handling coals. -
MAINTENANCE
