DHP 4415449 User manual

Platform bed with storage drawers
DO NOT RETURN TO THE STORE !
I f parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Thank you for purchasing
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
King
Gray Linen
Weight Limit: Bed: 500 Lb / 227 Kg
Drawer: 40 Lb / 18 Kg

Read Before Beginning Assembly
2
Caution
● Call our toll free number if you need assistance.
● Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use a piece of the cardboard packaging to protect your floor and product.
● Recommended # of people needed for assembly: 2 (however it is always better t
o have an extra hand). Estimated assembly time is 1.5h.
● Make sure all parts are included. Most parts are labeled or stamped on the raw
edge.
● Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in sequence,
assembly difficulties will occur.
● This product is designed for home use and not intended for commercial use.
● This product contains small components. Please ensure that they are kept away
from small children.
● Do not use power tools to assemble your furniture. Power tools may strip or
damage the parts.
●You will need a phillips headed screwdriver to assemble this product.

3
Parts
This item is packed in 2 boxes!
All parts listed on this page are in Box A.
If Box B is missing please contact your Retailer.
Before you throw the package, please use the
Check Box to identify the parts and ensure that
you have all the parts needed for the assembly.
There are inner box(es) that include components
required to complete this assembly.
N
L
KS
S
N
L
K
Drawer Back Panel
T946400
X 2
Drawer Side Panel
T946410
X 4
Drawer Bottom Panel
T946390
X 2
Drawer Front Panel
T946420
X 2

4
Parts
This item is packed in 2 boxes!
All parts listed on this page are in Box B.
If Box A is missing please contact your Retailer.
Before you throw the package, please use the
Check Box to identify the parts and ensure that
you have all the parts needed for the assembly.
There are inner box(es) that include components
required to complete this assembly.
E
D
B
FG
H
I
Y
X
P1
M
Headboard
T978460
X 1
Footboard
T978470
X 1
Side Panel
T978480
X 2
Side Rail
T978450
X 2
Side Support Leg
T962150
X 2
Side Tube
T960430
X 2
Cross Rail
T962140
X 1
Center Rail
T935850
X 2
Support Leg
T935880
X 4
Wooden Slats
T956330
X 39
Single Slat Cap
T926370
X 26
Double Slat Cap
T926380
X 26
Q
Caster
T946430
X 8
C
Side Panel
T947010
X 2
A
A
B
D
E
F
P1
G
I
C
H
Q

5
Hardware Pack
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
67
4
3
2
1/4" X 3/4"
X 28
1/4" X 3/4"
X 2
4mm
X 1
1/4''
X 8
8
5
9
1/4" X 1 9/16"
X 16
1
1/4" X 1/2"
X 2
1/4" X 1 3/16"
X 6
4# X 1 3/16"
X 40
8# X 1/2"
X 16

6
Step 1
E
E
I
Attach I X 2 to E X 2 with ❶ and ❷.
To make sure the completion of the next
installation, please assemble the parts as
shown in the diagram!
X 4
2
1
X 2
E
EI
I
I
E
1
2

7
Step 2
Attach G to I X 2 with ❷.
2
X 4
E
EG
I
I
I
G

8
Step 3
X 8
Attach D X 2 to E X 2 with ❺.
5
D
D
E
E
E
D

9
Step 4
X 4
2
Attach H X 2 to B with ❷.
B
H
H

10
Step 5
Attach A and B to E X 2 with ❺.
Don't completely tighten the bolts until
STEP 7 is complete.
X 8
5
E
E
A
B Part H is located on lower side!
Holes are
located on top side!
A
E

11
Step 6
X 8
2
F
M
M
Attach M X 2 to F with ❷.
Repeat the same procedure for remaining
parts M X 2 and F.
X 2

12
Step 7
Attach F X 2 to A and B with ❷.
Then properly tighten all the bolts.
A
B
F
2
X 8
A
F

13
Step 8
8.1 8.2
SLAT WARNING
Incorrect: Slat curve
facing downwards.
Correct: Slat curve should
be facing upwards.
8.1 Insert P1 into X;
8.2 Press X into E, repeat the same
procedure for the opposite side of the
bed with a new P1 and X into E.
Follow the same procedures going
backwards for every row of slats.
P1
P1
X
X
E
P1
P1
X
E
E

14
Step 9
9.1 Insert Y x 2 onto the free end of both
P1 assembled in previous step, Take a
new P1 and insert each end into the other
free end of Y x 2;
9.2 Press Y x 2 SIMULTANEOUSLY into
F x 2 as illustrated.
Follow the same procedure going
backwards for every row of slats.
9.1 9.2
Correct : Slat curve should
be facing upwards.
Incorrect : Slat curve
facing downwards.
SLAT WARNING
P1
P1
Y
F
P1
Y
Y
F
P1
Y
Y
Y
F
P1

15
Step 10
X 16
L
SN
N
7
Attach N X 2 to S & L with ❼.
Repeat the same procedure for remaining
N x 2 and S, L.
X 2
N
Make sure that these holes are all
located on the top side before assembling!

16
Step 11
N
L
K
7
Attach K to S , L & N with ❼.
Repeat the same procedure to complete
the other subassembly.
X 2
X 24
Make sure that these holes are all
located on the top side before assembling!
S
N

17
Step 12
X 16
X 2
K
Q
K
Q
6
Attach Q X 4 to K with ❻.
Repeat the same procedure to complete
the other subassembly.
Q
Q
Q

18
Step 13
Attach ❸ and ❽ to C,
Attach S to C with ❹ and ❽.
Repeat the same procedure to complete
the other subassembly.
X 6
X 8
X 2
S
C
38
4
C
83
84
C
S
X 2

19
Step 14
Align Drawers with the bed frame and push
them into the bed.
Lock drawers by slightly lifting drawer and
inserting the Pin into the Slot.
Slot Pin
Slot
Pin

20
Helpful Hints
● Move your new furniture carefully, with two
people lifting and carrying the unit to its new
location.
● Your furniture can be disassembled and
reassembled to move.
● Some parts have been pre-assembled for this
item. They are illustrated on this page and available
for replacement.
WARNINGS:
For safety reasons and to prevent injuries:
● This bed is not intended for use by children under 4
years old.
● Prohibit jumping and horseplay on this bed.
● Only use a mattress which is 79" - 80" long and
75" - 76" wide.
● Do not stand on drawers.
● Do not use risers under this bed.
Helpful Hints
Weight Limit:
To unlock the drawers:
Lift and pull the drawers toward outside.
Bed: 500 Lb / 227 Kg
Drawer: 40 Lb / 18 Kg
End Cap
T392520
X 4
End Cap
T392530
X 6
