Diamond Antenna CP-5HS User manual

●ワンサイド形ラジアル

CP-5HS
（図−9 ）
●規 格
周波数/7,14,21,28〜29,50MHz
インピーダンス/50Ω
VSWR/1.5以下（共振周波数にて）
耐入力/200WＳＳＢ(7MHz)
400WＳＳＢ(14/21MHz)
500WＳＳＢ(28/29/50MHz)
FM/CWではSSBの約1/3程度に
なります
耐風速/45m/sec.
全長/3.6m
ラジアル長/約1.8m
重量/約3.4Kg
適合マスト径/30〜62φ
接栓/M-J型
形式/5バンドグランドプレーン
空中線形式/中間部負荷型
（表−Ａ）
14 -50 f0+50
7 -14 f0+14
21 -100 f0+100
28-29 -125 f0+125
50 -1500 f0+1500
MHz KHz KHz
1.5
1.4
1.3
1.2
1.1
●VSWR表
2007年11月 第1版発行
C2007第一電波工業株式会社

40m,20m,15m,10mand6m(7/14/21/28-29and50MHz)Five-bandVerticalAntenna
#0(3
・Description
①TheCP-5HSisafive-bandvertical
antennaforHFband.
②Compact,lightweightedandveryeasy
toassemble.
③Itiscompletelyself-supportedand
doesnotneedanyguywires.
④Trapradialscouldbeconcentratedon
onedirectioninsteadofspreading
themaroundtheantenna.Thisis
especiallyconvenientiftheantennais
installedonbalconyrailingorwindow
sideofcondominiumsandurban
apartments.
⑤SincetheantennaisdirectDCground
atthefeedpoint,coaxialcableand
transceiverarebeingprotectedfrom
thehighvoltagecausedbylighting.
⑥Centerfrequenciesoftheantennaare
adjustableineachbandsimplybychange
thelengthofeachradialelement.
⑦Toploadingstructureutilizingcapacitive
hatenablestheantennatocomplete
withfullquarterwavelengthantennas
initsperformance.
⑧Itisrigidandruggedenoughtowithstand
thewindpressureover100MPH.
⑨Mastbracketsareaadjustabletoaccept
11/5”to21/3”diametermast.
⑩Feedpointsectioniskeptwaterproof
bycoveringitwithsupportpipe.
⑪10mFMbandcompatible.
・PartsDescription
OperationInstructions
（Fig1）
PipeNo.1φ15
M39006
InternaltoothlockwasherM4
M39021
TappingscrewM4x8
M39020
Doubleelement
trapcoilassembly
M39007
InternaltoothlockwasherM4
M39021
TappingscrewM4x8
M39020
PipeNo.230φ
M39008
SpringwasherM6
M39019
Hexheadscrew
M6x8 
M39018
15m(21MHz)radialelement
trapcoilassembly
M39012
Mastbracketset
M39001
Gripnut
M39017
40m(7MHz)radialelement
trapcoilassembly
M39014
Mastsupportpipe
M39002
Radialring3holes
M39003
6m(50MHz)radialelement
trapcoilassembly
M39010
10m(28-29MHz)radial
elementtrapcoilassembly
M39011
Radialelement
M39015
Feedpoint
assembly
M39005
Hexheadscrew
M6x8
M39018
SpringwasherM6
M39019
Capacityhatassembly
M39009
Capacityhat
fastenerring
M39022
Radialelementfastenerring
M39016
V-boltwithnut
M27021
8cm
・PartsDescription
Parts#Description  Qty
M39001Mastbracketset  2
M39002Mastsupportpipe  1
M39003Radialring3holes  1
M39004Radialring2holes  1
M39005Feedpointassembly  1
M39006PipeNo.1φ15  1
M39007
Doubleelementtrapcoilassembly 1
M39008PipeNo.230φ  1
M39009Capacityhatassembly 4
M390106m(50MHz)radialelement
 trapcoilassembly  1
M3901110m(28-29MHz)radial
 elementtrapcoilassembly 1
M3901215m(21MHz)radialelement
 trapcoilassembly  1
M3901320m(14MHz)radialelement
 trapcoilassembly  1
M3901440m(7MHz)radialelement
 trapcoilassembly  1
M39015Radialelement  5
M39016Radialelementfastenerring 5
M39017Gripnut   5
M39018HexheadscrewM6x8 3
M39019SpringwasherM6  3
M39020TappingscrewM4x84
M39021I
nternaltoothlockwasherM4 4
M39022Capacityhatfastenerring 1
M39023V-boltwithnut  2
Nutwithradial
elementfastenerring
Screwwithradial
elementfastenerring
Screwwithradial
elementholder
※Radiatorhasawaterdrainhole.
Leaveitopened.
Radialring2holes
M39004

(Fig-4)
(Fig-5)
Radialelement
trapcoil
Gripnut
Radialelementfastenerring
Adjustlengthofradialelement
14MHz
7MHz
(Fig-3)
2cm
・Antennalocation
ResonatefrequencyofHFantenna
canchangebasedonlocation.
Antennashouldbemountedaway
fromtree,buildingandotherantennas.
①IftheCP-5HSislocatedonthe
roofofahouseortopofabuilding,
lookaroundtherooftoseeifthere
areanyobstaclessuchasTV
antennaorwaterreservationtank.
TheCP-5HShastobelocatedas
farawayaspossiblefromthose
thingstoobtainitsmaximum
performance.
②IftheCP-5HSisinstalledona
balconyrailing,installingtheantenna
tooclosetothebuildingwallmay
causebadeffectforelectrical
characteristicsoftheantenna.Locate
atleast2mto5m(7ʼto16ʼ)away
fromthebuildingwalldependingon
structureofthebuilding.
<<Note>>
・Fasteningtheradialelementtrap
coilassemblytightlymaybe
damaged.
・Inthecaseofspreadaroundstyle
radialelements,theturntofixthe
radialsisrestricted.However,the
radialsofthelowerfrequencies
aremoreinfluencedbythe
surroundingcondition.Setthe
radialsfor40masfarawayas
possiblefromthebuildings.
<<RumblingThunder>>
①Thethunderseemstorumblein
thevicinity,donʼttouchthe
antennaandcoaxial.Whenyou
donʼtusetheradio,takeoffthe
cablefromtheradio.
<<Ifthereissomethingwrong,stop
transmittingimmediately.>>
①KeepingtransmittingwithhighVSWR
maycausetheradiotobedamaged.
Stoptransmittingimmediatelyand
checkthefollowingmatters.Ifit
doesnʼtsolvetheproblem,please
askthedealerorDiamondAntenna
Corporation.
[Condition:Iftheantennadoesnʼtseem
toreceivewellorpropagatewell]
Check1:Istheantennatoocloseto
thebuildingwall?Iftheobstaclesare
tooclosetoantenna,VSWRishigher
andtheradiationpatternisdisturbed.
Pleaseinstalltheantennafromthe
buildingasfarawayaspossible.
Check2:Didyouassembletheantenna
correctly?Pleasereadtheinstruction
againandreconfirmtheassembly.
Check3:Isthecoaxialcablesomething
wrong?Pleasecheckifsolderingthe
connectorisokayandthewirebreaks
bythevolt-ohmmeter.
・Inthecaseoftheonedirection
styleradialelements,setthe
radialfor40mandonethe
radialfor20matthebothend.
Pullonepieceoftheradial
elementholderdown2cmandfixit.
・Incaseofusingthemetallicstay
wire,setthewireonthelower
mastbracketsetandattachthe
insulatorsatwithin1mfromthe
mastbracketsetinorderto
insulate.
・Itispossibletoremovetheradials
youdonítusethebandfor.
（Fig2）
(Fig-6)
Onedirectionstyleradialelements
Spreadaroundstyleradialelements
-Note-------------------------------------------
《Installingtheantenna》
①Donʼtinstallonarainyorwindyday
sinceitisdangerous.
②Donʼtattempttoinstalltheantenna
onlybyyourself.Installingtheantenna
aloneontheroofmayleadyou
dangerousaccident.Alwaysaskyour
friendsforhelpinstallingtheantenna.
③Donʼtdroptheantenna,toolsand
attachmentwheninstallingtheantenna
intheheight.Installtheantennabefore
assemblingitontheground.
《Antennalocation》
①IftheCP-5HSislocatedonthe
roofofahouseortopofabuilding,
lookaroundtherooftoseeifthere
areanyobstaclessuchasanelectronic
wireorTVantenna.TheCP-5HS
hastobelocatedasfarawayas
possiblefromthosethingstoobtain
itsmaximumperformance.Installing
theantennatooclosetothebuilding
wallmaycausebadeffectforelectrical
characteristicsoftheantenna.
②Donʼtinstalltheantennawhereis
easilyreachablebypeople.
③Installtheantennafirmlynottofall
downduetothestrongwind.Even
iffallingdowntheantenna,locate
theantennaatthesafeplacewhere
peopleandbuildingarenotinflicted
injures.
《Beforetransmitting》
①Transmitafterconfirmingifthe
antennaworksnormallybyanSWR
meter.IfVSWRislessthan1.5,itis
noproblem.IfVSWRishigher,stop
transmittingandcheckiftheparts
oftheantennaandcoaxialcableare
connected.Iftherearetallbuildings
orobstaclesorthedistancebetween
theantennaandthegroundisshort,
VSWRmaynotbelowered.
※DiamondAntennaSWR/POWERmeter
isaninsertiontypebeingconnected
betweenatransmitterandanantenna.
TransmittingpowerandSWRcanbe
measuredwithverysimpleoperations.
Inadditionwiththoseconventional
measurement,PEP(peakenvelope
power)onSSBmodecanbemeasured
withaPEPmonitorfunction.Withour
Diamondʼswidebandandlowinsertion
lossdirectionalcouplerthose
measurementscanbeperformedwith
minimumeffectintransmissionline.
<<Duringtransmitting>>
①Touchingtheantennaduring
transmissionmaycausetoelectrify.
Payattentionnottotouchtheantenna
especiallyforchildrenifinstalling
onabalconyrailing.
・AssemblyInstruction
①Putradialelementineachradial
elementtrapcoilassemblyby
referringtothetypicalelement
lengthlistedinTableAandfasten
itwithelementfastenerring.
(Figure-6)
②Setgripnutrightlytotreadedpart
ofeachradialelementtrapcoil
assembly.
③ConnectpipeNo.1,doubleelement
trapcoilassembly,andpipeNo.2
intheverticalelementsectionand
fastenthemwithtappingscrews
andinnertoothwashersbyaligning
holesineachjointsection.
④Attachfourcapacityhatassemblies
toeachcapacityhatholdersection.
Capacityhatholdersaresetatthe
specifiedsectionsinthefactory.
Locationsforthosecapacityhat
holdersarefixedatabout8cm(3.1”)
belowthetopendofdoubleelement
trapcoilassemblyforlowercapacity
hatrespectively.

  I 
  I 
 I 
  I 
0+] .+] .+]
CP-5HS





(Fig-7)
(Fig-8)
(Fig-9)
(TableA)
Mastbracket
V-bolt
Springwasher
Mast Support
pipe
Nut
Supportpipe
Mast
Applox.12cm(4.7")
Coaxialcable
Trappinghole
thisside
Radiator
Screw
(2pcs/upper
&lower)
Hexheadscrew
Hexheadscrew
Feedpointassembly
Gripnut
Mastsupportpipe
Radialelementholder
(2pcs/upper&lower)
Alignwaterdrainhole
downwardwhenattach
Radialelement
Tranceiver VSWR
meter
Band Spread One Length/
 radials direction Frequency
  radials
40m Applox. Applox. 10mm/
(7MHz) 570mm 530mm 10KHz
20m Applox. Applox. 15mm/
(14MHz) 620mm 600mm 20KHz
15m Applox. Applox. 32mm/
(21MHz) 680mm 620mm 50KHz
10m Applox. Applox. 27mm/
(
28-29MHz ) 600mm 590mm 50KHz
6m Applox.Applox. 50mm/
(50MHz) 550mm 550mm 1MHz
  I 
⑤Attachmastsupportpipetomast
withmastbrackets.Mastsupport
pipeʼstappingholehastobeplaced
abovethebracketsandithastobe
pointedoutsideagainstthemast.
Upperendofmastsupportpipe
hastobeplacedmorethan12cm
(4.7”)abovethetopendofthemast.
⑥Placethetworadialelementholder
fromupperendofthesupportpipe
andfastentemporarywithscrewdriver.
Donotfastentootightlyatthisstage,
otherwisefeedpointassembliesmight
notbeputintothesupportmastlater.
⑦Connectacoaxialcabletofeedpoint
assemblethroughthesupportpipe.
Thenaligntheholeinthelowerpart
offeedpointassemblywiththehole
inthesupportpipeandsecurethem
withhexheadscrewandspringwasher.
⑧Placeverticalelementonfeedpoint
assemblyandfixwithtwohexhead
screwsandspringwashers.
⑨Turneachradialelementintoradial
elementholders.Thenalignwater
drainholeineachradialelementtrap
coilassemblydownwardbyturning
backwardandfasteneachelement
withgripnut,Notethat6mradial
elementdoesnothavetrapcoil
assembly.
<<Note>>
Toavoidbreakingeachradial
elementtrapcoilassembly,turnit
intoaholderlightlytillitstopsand
turnbackwardtoalignwaterdrain
holedownwardandsecurewitha
screw.
・Adjustment
<<Noteforfrequencyadjustment>>
Practicethefollowingadjustment
procedureattheplacewherethe
antennaisactuallyinstalled.Test
transmissionfortheadjustmenthas
tobeperformedforasshorttimeas
possibleandwithaslowRFpoweras
possible.MaximumRFpowerratingof
continuouswave(FM/CW)isabout
1/3ofitinSSBmode.Iftheantenna
isinstalledonalongbalconyrailing,
therailingitselfmayworkasaradial
elementandVSWRoftheantennamay
notbechangedwiththeadjustment
ofattachedradialelementlength.If
resonantfrequencyoftheantennais
withinadesiredrange,theantennacan
beusednormallyinthiscase.If
resonantfrequencyisoutofdesired
frequencyrangeandadjustmentis
required,theantennahastobeisolated
fromtherailing,movedtoadifferent
placeorinstalledonamast,whichis
atleast1mto2m(3.3ʼto6.6ʼ)long.
①PreparesuitableVSWRmeterfor
operatingfrequenciesandoutput
RFpower.Thenconnectitasshown
inbelow.
②Adjustmentprocedurecanbestarted
fromanyfrequencyyoulike.Transmit
atdesiredfrequencyandtrim
adjustmentlengthofradialelement
tohavelowerVSWRatthefrequency.
・Adjustmentlengthofradialelement
①Adjustmentlengthofeachradial
elementisshowninthefollowingtable.
IfyoudonothaveaVSWRmeter,
adjustittoatypicaladjustmentlength.
※Iftheradialelementofabandismade
longer,resonantfrequencyoftheband
ismadelowerproportionally.
※Thoughtypicaladjustmentlengthof
eachradialelementissetatcenter
frequencyofeachband,itvariesmore
orlessdependingontheplacethe
antennaisinstalled.
Adjustmentexample:
Ifcenterfrequencyof40mbandisset
at7.050MHzandrealcenterfrequency
whentheantennaisinstalledisat
7.010MHz,thenfrequencydifference
betweenis:
7.050MHz(desiredcenterfrequency)
‒7.010MHz(realcenterfrequency)
=40KHz
・Specifications
Frequencyrange 40,20,15,10,6m
  (7,14,21,28-29,50MHz)
FeedpointImpedance 50Ω
VSWR Lessthan1.5
Maximumpowerrating
 200WSSB(7MHz)
 400WSSB(14/21MHz)
 500WSSB(28/29/50MHz)
MaximumRFpowerratingof
continuouswave(FM/CW)isabout
1/3ofitinSSBmode.
Maximumwindresistance 100MPH
   (45m/sec)
Verticalelementlength 142”(3.6m)
Radialelementlength 71”(1.8m)
Weight   7.5lbs(3.4Kg)
Mastdiameteraccepted 11/5”‒21/3”
   (30-62φ)
Design 5bandtrapverticalantenna
 withtrapradials
Thoughtheseproductspurchased
aremanufacturedunderstrictquality
control,ifdamageiscausedby
transporting,askyourdealerpromptly.
Designandspecificationsofthese
productswillbechangedforfuture
improvementwithoutadvancenotice.
FromTableA,adjustmentlengthat
40mbandisabout10mmper10KHz,
therefore:10mmx40KHz/10KHz=
40mm,Sincerealcenterfrequencyis
lowerthandesiredcenterfrequency,
radialelementhastobemade40mm
shortertohave7.050MHzcenter
frequency.
・VSWR
DIAMONDANTENNACORPORATION
MiyataBuilding,No.15-1,1-chomeSugamo,ToshimakuTokyo,Japan170-0002TEL.[phone]FAX.[phone]
HomePagehttp://www.diamond-ant.co.jp
E-mail[email protected]
