Directive Systems & Engineering DSE3347LYA User manual

DSE3347LYA Rev 4/21
Directive Systems & Engineering
2702 Rodgers Terrace
Haymarket, VA 20169-1628
www.directivesystems.com
703-754-3876
33cm Loop Yagi, Model DSE3347LYA (w/sub-boom)
SPECIFICATIONS
Frequency range: 910-930 MHz Gain: 20.5 dBi
Number of elements: 47 3 dB Beamwidth
Boom length: 216 inches (E plane): 14.4º
Boom diameter: 1 inch F/B ratio: >20 dB
Mast diameter: 2 inch max Maximum Power: 550 W average
Weight: (assembled) 13 pounds Stacking distance: 38 inches’vertical
Connector: Type N female 41 inches’ horizontal
Note: All hardware is Stainless Steel unless otherwise noted.
Anti-Seize Compound - Apply a small amount of the supplied Anti-Seize Compound to the aluminum joints and
to the threads of the U-Bolts to prevent galling.
BEFORE INSTALLING YOUR NEW ANTENNA, PLEASE BE SURE
TO READ THE ENCLOSED WARNING PAMPHLET.
ASSEMBLY INSTRUCTIONS
1) Unpack antenna and locate the two preassembled antenna sections and the hardware
package. The antenna is shipped in three boom sections. There are alignment marks to assure
proper assembly. The mid boom has a long rectangular bracket attached. This is the midpoint of
the antenna at D21. The front and rear sections have shorter 3-3/4" brackets attached at D13 &
D33. Assemble the three sections together so that the alignment marks match. You will have to
remove D17 & D31 and insert the boom sections into one another, then reinstall the two loops and
retighten the 4-40 hardware. A1/4" nut driver is required for this.
2) Straighten any misaligned elements and tighten hardware if necessary. But do not
touch R1, DE or D1, as these have been factory set for minimum SWR.
3) Attach the boom to mast plate to the boom with the hardware provided. Install the U-bolts
so that the mast comes up directly under the boom. Note that the bracket can be installed for
either vertical or horizontal polarization. (See drawings below)

P a g e | 2
DSE3347LYA Rev 4/21
(Can be up or down) (Can be left or right)
4) Attach the feed line, and tape it to the bottom of the boom. The connector should be sealed
with electronic grade RTV or equivalent.
5) As shipped, the antenna SWR will be less than 1.5:1. Additional tweaking can be
accomplished by adjusting the distance between the driven element and R1 and D1, or by
adjusting the shape of the driven element. NOTE: Do not attempt this adjustment unless the
proper equipment and qualified personnel are available.
6) If antennas are to be stacked, see "Instructions for Stacking Loop Yagis".
Refer to photos in the next few steps for clarification on the Sub Boom:
7) Mount the boom to mast bracket (square tubing piece) to the center boom section,
using 8-32 X 2" screws, lock washers and nuts. Mount the boom to mast plate to this bracket
using 8-32 x 1 ¼” screws, lock washers and nuts. Note: There may be extra holes in the plate that
may be used for different applications.
8) There are two sub-boom brackets consisting of ½” aluminum angle and sub-boom
plates. Mount the angle brackets on the front and rear boom sections using 8-32 x 1 3/8”
screws, lock washers and nuts. Mount the sub-boom plates to these brackets using 8-32 x ½”
screws, lock washers and nuts.
9) Mount the sub-boom (3/4” thick wall aluminum square tubing) to the sub-boom brackets
and boom to mast plate using 8-32 x 1 ¼” screws, lock washers and nuts. NOTE: Do not
tighten any of this hardware until sub-boom assembly is complete.
DO NOT, UNDER ANY CIRCUMSTANCES, APPLY ANY TYPE OF SEALANT OR COATING TO THE
DRIVEN ELEMENT, T-ARMS OR CONNECTOR ASSEMBLY, OTHER THAN KRYLON®
CLEAR COAT. ANY OTHER COATING WILL ADVERSELY AFFECT THE SWR AND VOID YOUR
WARRANTY.

P a g e | 3
DSE3347LYA Rev 4/21
Boom to Mast Bracket
Boom to Mast Plate
Sub Boom
Sub Boom
Sub Boom Plate
Sub Boom
Bracket

P a g e | 4
DSE3347LYA Rev 4/21
