Diamond View 1995SL User manual

DIAMOND VIEW
1995SL
Colour Monitor
19” (48cm) CRT Size
18” (45.7cm) Viewable Area
User’s Manual

U
G/MO1995SL/0102/2

i
Table of Contents
1Important Safety Instructions...........................................1
2Features .............................................................................2
3Unpacking the Monitor......................................................3
4Installation .........................................................................3
Drivers for Windows 95, 98, 2000 and Millennium Edition.............4
5Adjusting the Monitor .......................................................5
Selecting Functions and Making Adjustments...............................6
Contrast Hotkey............................................................................6
Brightness Hotkey.........................................................................6
The Main Menu ................................................................................6
Make adjustments.........................................................................7
Timing and Refresh Rate Setting..................................................11
Factory Preset Timings.................................................................12
6Troubleshooting..............................................................13
7Specifications..................................................................15
8Service Contacts .............................................................17
Australian Service Contacts .........................................................17
New Zealand Service Contacts.....................................................18

i
i
Copyright Notice
Copyright 2000, Mitsubishi Electric Australia Pty. Ltd. All rights reserved. No
part of this publication may be reproduced, transmitted, transcribed, stored in
a retrieval system or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission.
Disclaimer
Mitsubishi Electric Australia Pty. Ltd. makes no representations or
warranties, either expressed or implied, with respect to the contents hereof
and specifically disclaims any warranties, merchantability or fitness for any
particular purpose. Further, Mitsubishi Electric Australia reserves the right to
revise this publication and to make changes from time to time in the contents
hereof without obligation to notify any person of such revision or changes.
Diamond View is a registered trademark of Mitsubishi Electric Australia Pty. Ltd.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks remain the property of their respective owners.
Reference Information
For future reference, write the following information about your
monitor in the space below. The serial number is on the back of
the product or on the bottom of its stand.
Monitor Information
Product Name: Diamond View 1995SL
Serial Number:
Date of Purchase:
Dealer Information
Dealer:
Telephone
Number:
Address:

1
1Important Safety Instructions
Please read the following safety instructions before installing or cleaning your
Diamond View monitor:
1. This monitor must be operated from the type of power source indicated
on the rating label. If you are not sure of the type of power available in
your area, consult your dealer or local electricity supply company.
2. This monitor must be operated with a 3 wire electrical cable that has a
plug with a third (grounding) pin. The plug must only be connected to a
grounded power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician to make the
necessary outlet changes. Australian and New Zealand customers
should use the power cable supplied with the monitor.
3. Make sure that the power outlet that you plug the monitor into is easily
accessible.
4. Unplug the monitor’s power cable from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a soft cloth to clean the
monitor housing and screen.
5. Slots and openings on the back or top of the cabinet are provided for
ventilation. They must not be blocked or covered. This product should
never be placed near or over a radiator or other heat source, or in a
built-in installation unless proper ventilation is provided.
6. Never push objects of any kind, or spill liquid of any kind into the
monitor.
7. Do not attempt to service the monitor yourself as opening or removing
covers may expose you to dangerous voltages or other risks. Removing
the cover of the monitor may void warranty.
8. If any abnormal operation or an accident (such as dropping the unit)
occurs, disconnect the monitor from the wall power outlet and contact
qualified service personnel.

2
2Features
Your Diamond View 1995SL Monitor has the following features:
♦Plug’n Play Compatibility
With DDC1and DDC2B, the 1995SL is compatible with Plug and
Play feature of MicrosoftWindows95, 98, 2000 and Millennium
Edition.
♦Flicker-free Image
The monitor supports VESA standard graphics signals with flicker-free
refresh rates at resolutions up to 1280 x 1024 pixels at 85Hz.
♦Larger Viewable Size
With its 45.7 cm (18”) viewable size, the 1995SL offers a larger
viewable screen area than many other 19”monitors.
♦Easy to Use On Screen Display
The On-Screen Display (OSD) allows you to adjust all settings simply
with on-screen menus.
♦Power Saving Function
The power management complies with VESA DPMS standard. When
the system is idle (off mode), the monitor automatically cuts its power
consumption up to 95%.
♦Green Commitment
No CFCs are used in the manufacturing process of your monitor. It
complies with the US government’s Energy Star standards and the
rigorous standards of Scandinavian countries.

3
3Unpacking the Monitor
Please check that the following items are included with your monitor. If they
are missing or damaged, please contact your place of purchase immediately.
♦Monitor with attached signal cable
♦Power cord
♦User’s manual
Locate the model name and the serial number label on the back of your
monitor and write the details of the monitor and your place of purchase in the
space on page (ii) of this manual for future reference.
4Installation
Your monitor is equipped with an automatic power supply with a voltage
range from 100 to 240 Volts AC at a frequency of 50 to 60 Hz.
To install your Diamond View 1995SL monitor:
1. Make sure that the computer
system’s power is turned off.
2. Connect the power cord to the
monitor and attach it to a power
socket.

4
3. Connect the computer end of the D-
SUB cable to the 15-pin output
connector on the video board of your
computer.
4. Turn the monitor and the computer
on.
If you wish to connect the monitor to an older-type Apple Macintosh, you
need to use a Macintosh cable adapter to connect the video signal cable of
your monitor to the video port of the computer. Your computer dealer should
be able to supply you with a suitable adaptor.
Drivers for Windows 95, 98, 2000 and Millennium Edition
Windows will detect the Diamond View 1995SL monitor the first time you turn
the computer on after installing it. The Add New Hardware wizard will prompt
for drivers. Install the standard Windows Plug & Play Monitor driver. This
driver will work correctly and allow you to use the monitor with its optimal
resolutions and refresh rates.
A specific driver that includes the Windows ICC/ICM colour profile for the
Diamond View 1995SL is available from Mitsubishi Electric Australia’s web
site at
http://www.mitsubishi-electric.com.au
Follow the link to the File Downloads/Monitors section of the site to download
the drivers. Installation instructions are also available from at the monitor
driver page.

5
5Adjusting the Monitor
E
nter
Exit
1
2 3 4 5
You can adjust the monitor using its On-Screen Display (OSD) menu system.
There are 5 buttons that control the monitor:
1. Exit Returns to the last menu page, saves changes or
quits the menu system.
2. and Move to another menu item or decrease the selected
parameter. Hotkey for contrast adjustment.
3. and Move to another menu item or increase the selected
parameter. Hotkey for brightness adjustment.
4. Enter Open a sub-menu or selects a menu item.
5. Power Switch Turn the monitor on or off.
3
4

6
Selecting Functions and Making Adjustments
Contrast Hotkey
1. Press to open the contrast adjustment display.
2. Press
or to adjust the contrast level.
3. Press the Exit button to save your changes.
Brightness Hotkey
1. Press to open the brightness adjustment display.
2. Press
or to adjust the contrast level.
1. Press the Exit button to save your changes.
The Main Menu
The Diamond View 1995SL’s OSD has a in Main Menu organised into 6
groups of functions: Luminance, Geometry, Colour Adjustment, Recall,
Degaussing and Miscellaneous. The remainder of this chapter describes the
use of each function and the way that you can make adjustments to the
image displayed on the monitor’s screen.

7
Make adjustments
1. In Main Menu: Pressor to select the function group with the item
that you wish to change.
2. Press Enter to open the Sub Menu.
3. Pressor to select the item to be changed and press Enter.
4. Press
or again to make the adjustment.

8
Hor. Position
Enter:Save
Exit : Exit
Enter:Save
Exit : Exit
etc
Sub menu
F
unction name
Scale
75
5. Press Exit to save the setting.
6. Press Exit to return to main menu.
1. Luminance
Contrast changes the difference between the light and dark
areas of the displayed image.
Brightness adjusts the brightness of the displayed image.
2. Geometry
Hor. Position adjusts the horizontal position of the image.
Hor. Size adjusts the image width.
Ver. Position adjusts the vertical position of the image.
Ver. Size adjusts the image height.
Rotation corrects any tilting of the image.
Pincushion: corrects curves in the vertical edges of the image.

9
Unbalance adjusts the pincushion balance if both sides of the
image are bowed toward either the left or the
right.
Trapezoid makes the vertical edges of the image parallel.
Parallelogram aligns the top and bottom edges of the image.
Top corner adjusts the edge curvature at the top corners of
the image.
Bottom corner adjusts the edge curvature at the bottom corners
of the image.
3.Colour Adjustment
Colour mode Colour Temperature
(Preset Mode) Colour Temperature (User Mode)
C1 (9300K) 9300K User Mode 1
C2 (6500K) 6500K User Mode 2
Colour Preset Mode: In this mode, C1 and C2 are two memory areas where
the factory-preset colour settings are stored. These settings are fixed and
can not be modified.
Colour User Mode: Pressor to locate the colour mode and Enter to
choose a colour. Pressor again to make the adjustment. If you want
to reset to preset modes, please locate to recall the preset colour
settings

10
4. Recall/Reset and Image Status
Select and press Enter to recall the factory settings for the current
graphics signal. The word “Recall”will blink on the screen in the process of
recall.
This page is also a status display that shows the horizontal and vertical
frequencies of the current graphics signal. Please note that the resolution is
only displayed if you are using a graphics signal that corresponds with one of
the monitor’s presets.
5. Manual degaussing function
To eliminate colour shading or impurity induced by magnetism. Press Enter
to degauss the monitor. Use this function after moving the monitor or
changing the direction that it is facing.
6. Miscellaneous
Hor. Moire adjusts horizontal Moiré.
Ver. Moire adjusts vertical Moiré.
If the picture is unstable when you adjust the Moiréreduction
setting, over-adjustment has occurred. Please lower the Moiré
reduction setting level.
OSD position changes the OSD’s position.
OSD Language:
De : Deutsch En :English Es : Español
Fr : Français It : Italiano

11
Note:
The setting of each parameter is represented by a numeric value and
corresponding scale.
The on-screen menu will automatically disappear after 20-second’s of
inactivity. If changes have been made, the monitor will automatically
save them.
Timing and Refresh Rate Setting
By making adjustments of your video card settings, you can set the timing
and the refresh rate to match your requirements. Please consult your
operating system’s and graphics adaptor’s documentation for details about
how this may be done.
The monitor will automatically save the changes that you make and use the
new settings whenever you turn it on. The Diamond View 1995SL monitor
can accept horizontal scanning frequencies ranging from 30 KHz to 95 kHz
and vertical frequencies from 50 Hz to 160 Hz. However, due to the
requirements of signals with different resolutions, and to avoid possible
damage to your monitor, do not exceed the following maximum vertical
refresh rates.
Resolution Maximum Vertical
Refresh Rate (Hz)
800 x 600 150
1024 x 768 118
1280 x 1024 88
1600 x 1200 76

12
Factory Preset Timings
Mode Resolution Vertical
Frequency (Hz) Horizontal Frequency (KHz)
Industry 640 x 400 70 31.47
Industry 640 x 480 60 31.47
VESA 800 x 600 75 46.88
VESA 800 x 600 85 53.67
VESA 1024 x 768 75 60.02
VESA 1024 x 768 85 68.68
VESA 1280 x 1024 75 79.98
VESA 1280 x 1024 85 91.15
VESA 1600 x 1200 65 81.25

13
6Troubleshooting
If you encounter any trouble using the Diamond View 1995SL monitor, make
sure that your monitor is properly installed. (For hardware installation, see
Chapter 4 of this manual.) If the problems persist, please check this chapter
for possible solutions before calling Mitsubishi Electric or one of our
Authorised Service Centres.
No image is displayed
-Check that the light (LED) next to the monitor’s power button is lit and
is green in colour.
-If the LED is orange there is no signal from the computer and the
monitor is in power saving mode. Check that the computer is switched
on. Press a button on the computer keyboard or move the mouse to
wake the computer. If that does not help, check that the VGA cable is
securely plugged into the computer. Also check the pins of the VGA
cable’s connector. If any pins are bent or broken off, then contact your
dealer.
-If the LED is not lit at all, check that the monitor is plugged into the
power socket and that the power switch is turned on at the wall. Check
that the monitor’s power switch is also turned on.
-Video sync signal. The video sync signal from the graphics card must
be as specified for the monitor.
The picture is scrolling or unstable.
-The most common cause of this problem is a loose VGA signal cable
or connector. Check that the cable is securely connected to the
computer.
-Check the VGA signal cable for damage. If any pins are bent or
broken off, contact your dealer or an authorised Mitsubishi Electric
service agent.
-Make sure that the graphics card settings are correct and within the
monitor’s specifications. Change the settings of your graphics card to
values within the monitor’s range.

14
-Remove any magnetic objects that are near the monitor. These
include speakers and power supplies ( AC adaptors ).
Colours are impure.
-Check that the cable is securely connected to the computer.
-Check the VGA signal cable for damage. If any pins are bent or
broken off, contact your dealer or an authorised Mitsubishi Electric
service agent (see Chapter 11 for details).
-Check the monitor’s colour settings. Press the Enter button and select
the Color Settings menu. Select the Recall menu item to return to the
factory preset colours and press Enter.
-Degauss the monitor using the degauss function of the monitor’s On
Screen Display.
-Remove any objects that can create a magnetic field that may be
near the monitor. These include speakers and power supplies (AC
adaptors ).
The image is blurred or there is visible ghosting
-Have you used a VGA extension cable? If so, remove the extension
cable and check the displayed image. Is the image quality improved?
Depending on the characteristics and type of the extension cable,
some blurring or distortion may occur due to conduction the extension
cable. You can minimise these losses by using an extension cable
with better conduction quality.
-Have you used a VGA splitter or a video amplifier? Depending on the
characteristics and type of the splitter or amplifier some blurring or
distortion may occur due to the limitations of the device’s bandwidth.
Problems caused by a limited bandwidth will increase as the signal’s
resolution and refresh rate increased. If you need to use a splitter or
amplifier with you monitor, make sure that it is a good quality device
that has sufficient bandwidth for the graphics resolution that you need
to use.

15
7Specifications
Model Diamond View 1995SL
Display Characteristics
Display Type 19”(48 cm) diagonal short-length
cathode ray tube
Maximum Viewable Size 18”(45.7cm) diagonal
Dot pitch 0.26 mm
Surface coating Anti-Glare, Anti-Reflective, Anti-
Static coating
Graphics Signals
Maximum Resolution 1600 x 1200 pixels (at 75 Hz)
Recommended Resolution 1280 x 1024 pixels (at 85 Hz)
Horizontal Frequency 30 –95 kHz
Vertical Frequency 50 - 160 Hz
Video Bandwidth 176 MHz
Microprocessor Controlled Graphics 9 factory preset timings
15 user modes
Signal Connection 15-pin mini D-sub cable
Video Input VGA-type (15 pin mini D-sub
connector)
Video Signal RGB analog (Positive polarity)
0.7 Vpp/75 Ohm
Synchronisation TTL separate, composite TTL
Plug & PLay DDC-1, DDC-2B

16
User Interface
Controls Mains power switch, On-Screen
Display with 4 control buttons
On-Screen Display Functions:
Contrast; Brightness; Vert. & Hor. Image Position and Size; Pincushion
Amplitude, Phase and Balance; Top and Bottom Corner Pincushion; Color
Balance; Degauss; Horiz. and Vert. Moire; Choice of language (6 language
OSD); OSD Position; Status Indicator
Physical Characteristics
Power Management VESA DPMS, Energy Star
Maximum Power Consumption 120 Watts
Consumption in Power Saving Mode < 15 Watts
< 5 Watts
Operating Voltage Automatic switched mode power
supply, 100 - 240 V, 50 - 60 Hz
Dimensions (W x H x D) 455 x 476 x 416 mm
Weight 19 kg
Temperature (Operating/Storage) 5 °C ~ 40 °C / -20 °C ~ 60 °C
Air Humidity (Operating/Storage) 20% ~ 90% / 10% ~ 90%
Regulatory Certification
Safety IEC 950, EN 60950 (TÜV/GS)
AS/NZS 3260, UL1950, PTB
EMI/EMC CSA, FCC Class B, AS/NZS 3548,
VCCI
Other TÜV/Ergonomics, FTZ Class B,
DSNF, ISO 9241-3 -7 –8, CE Mark
