Diamond FRP 30 User manual

Mod: CR-18P/B-N
Production code: FRP 30
11/2017

DRINKING FOUNTAIN
FRP 30 / FRP 35
Congratulations for the acquisition of this upmarket appliance made in France. You
chose an appliance which alloys the best technical qualities with a big user-
friendliness. We wish you the biggest contentment
1. SECURITY INSTRUCTIONS
Please respect these instructions scrupulously to avoid any risk of fire, electric shock,
scald or other wounds and damage. During the use of this appliance, fundamental
circumspection of security must always be noticed, such as:
-Take into account the instructions to be systematically kept with the appliance.
-Install the appliance always in instructions respect.
-Protect the appliance from direct light of the sun, frost and humidity.
-Never leave the appliance within the reach of children or disabled persons
without surveillance.
-Never move the appliance when it is working.
-Check that the appliance is definitely off before connecting it up or disconnect-
ing it.
-Do not use the appliance for other functions than determined use.
-Do not leave the electrical cord in contact of hot surfaces.
-The appliance should not be used close to combustible materials.
-To avoid any electric shock, never plunge the cord or plug in water or quite
other liquid.
-If the cord is harmed, it must be replaced by the producer, its after sale service
or persons of similar skills to avoid any risk.
-Entrust repairs only to a skilled person.
-Use only spare parts of origin.
-Before cleaning the appliance, do not forget to disconnect it.
2. CONTENTS OF CARDBOARD PACKAGING
Device: a drinking fountain
Accessories: the present note
3

4
3. CONFORMITY OS USE
Use the machine only for an unlimited supply of cold, fresh and pure water ... for of-
fices, workshops, canteens, hospitals, schools, stadiums, leisure parks and other
public places!
4. WAY OF FUNCTIONING
The drinking fountain is composed of two subsets :
*Cold: hermetic compressor, ventilated condenser, evaporator regulated through
a thermostat.
*Hydraulics: a water jet tap equipped with an integrated regulator, a filler glass , a
flow limiter.
Directly connected to the main water supply, this drinking fountain provide a constant
supply of chilled water (+8 to +10°C).
Glass filler Water jet tap
1
2
1 2

5
5. FUNCTIONING / MANIPULATION
a) Installation / assembly:
-Unpack carefully the appliance from its packaging
-Place the equipment on a stable surface.
-Install the machine in a clean, ventilated place, far away from heating sources
(radiators, sun lights…)
-Never place the device near a wall or near a partition makes of combustible ma-
terials even if it is very well isolated.
-A distance of 10 cm from the partition or the wall is considered enough.
-Remove the protective film from the appliance.
b) First starting :
First cleaning
Clean the machine before its first use (see 6. Cleaning)
Connection to the main water supply
-Connect the drinking fountain on a stop valve with a male thread 15/21.
Minimal pressure : 0.6 bar. Maximal pressure : 6 bars
-The water evacuation circuit must be conceived to avoid any return of liquid
waste.
Starting
-Open the stop valve and purge the drinking fountain by pressing on the control
lever of the filler glass. Adjust the flow thanks to the visible adjusting screw on the
back part of the fountain.
-Adjust the flow of the water jet tap to have a suitable trajectory.
-Switch on when there is no more air in the circuit.
Connection of the device
-Check that the tension and the frequency of the electricity network suit to the val-
ues indicated on the descriptive plate.
-Check that neither the cord nor the plug are damaged
-Make sure that every control knob is positioned on 0.
-Unwind completely the electric power cable and connect it in a normalised plug
with the earth.
-The device is connected.
NB: in case of connection of the device in a plug without earth protection or directly on
the electricity network, confide its connection to a qualified person .

6
d) Breakdown / repair:
In case of breakdown or of damaged part, please call your after-sales service and
confide any technical operation to qualified person.
When you contact the after-sales service of your distributor or your store, give him the
complete reference of your device (commercial name, type and serial number). This
information appears on the visible descriptive plate behind the device.
6. CLEANING AND MAINTENANCE
Disconnect the device.
-Clean regularly the metallic parts after each use by using only use non-abrasive
products, warm water and wash liquid: avoid the abrasive towelling. Rinse your de-
vice with a wet sponge and dry it with a soft cloth.
-Never clean the device under a water jet, the infiltrations would risk to damage it in a
irreparable way.
-Never immerse the cord or the plug in the water or quite other liquid to avoid any
electric shock.
-Never use abrasive product to clean the stainless steel basin
-Proceed to a regular maintenance of the machine (see 11. Maintenance recommen-
dations)
7. TECHNICAL SPECIFICATIONS
Wires colours correspondence Phase Brown / Black / Grey
Neutral Blue
Earth Yellow-Green
8. NORMS AND LEGALS DISPOSALS
The device is conform to :
IEC/EN 60335-1
IEC/EN 60335-2-89
EN 55014-1 + 55014-2
EN 61000-3-2 + 61000-3-3
Model FRP 30 FRP 35
Outside dimensions 300 x 340 x 1010 mm 400 x 440 x 1250 mm
Weight 30 Kg 35 Kg
Compressor 280 W 280 W
Gas R 134 A R 134 A
Water temperature +8° à +10° C+8° à +10° C
Current 2.5 A2.5 A
Voltage 220-240 V ~ 220-240 V ~

7
9. ELIMINATION OF THE ELECTRIC AND ELECTRONIC WASTE
The device respects the directives:
2002/96/CE (DEEE) N°34270064800021
2002/95/CE (ROHS)
2066/95 CE
2004/108 CE
Reach rule
Never put the device among household waste.
The device must be put down in a centre of recycling for the electric equipments.
The materials of the device are indeed reusable. By eliminating correctly the electric
and electronic wastes, the recycling and quite other shape of re-use of worn equip-
ments, you participate in a significant way in the environmental protection.
For any information about the collection of electric and electronic waste, please contact
your distributor.
10. GUARANTEE
Conditions of guarantee
The guarantee applicable to any device is the commercial guarantee of the distributor
or the retailer. Please contact the store where you bought your device to know the pre-
cise conditions.
The guarantee grants no right for damages.
The dispositions which follow are not exclusive of the profit of the legal guarantee
planned by articles 1641 and following ones of the Civil code relative to the defects and
the latent defects.
Exclusion clauses of the guarantee
Bad installation and bad maintenance, in particular if they do not respect current
regulations or instructions appearing in this user guide.

8
Cannot benefit from the guarantee the repairs required as a result of false operations,
of inappropriate use, of carelessness or of excess loads of the device, as well as
those resulting from variations of the power supply, over tension or from defective in-
stallations.
The damage due to shocks, bad weather is not flatware by the guarantee. The mate-
rial travels at the risks of the user; in case of delivery by carrier, the consignee has to
have reservations towards the carrier before any delivery of the device.
The guarantee comes to an end in case of intervention, of repair, of modification by no
qualified persons, or of use in inappropriate purposes.
11. MAINTENACE RECOMMENDATIONS
These data are extracted from the guide for the control of water quality in hospital
complexes (RHC October 2000)
Technical maintenance (Machine unplugged)
Method Frequency Observations
Visual inspection
and verification
of the good work-
ing Once a year at
least
Dusting of the
motor and the
protection grid
Changing the
filter (if the ma-
chine has one)
According the
manufacturer
recommenda-
tions
If the manufacturer recommends to change the filter
according to the water volume, it is essential to install a
water meter
Replacement of
parts (filter,
pipes…)
In case of
wear or ac-
cording to the
manufacturer
recommenda-
tions*
~ Multiplication of the bio film inside the connection
pipe of the drinking fountain to the main water supply.
~ Install opaque pipes and the shortest possible .
~ Cleaning and disinfection of the new parts (see be-
low)

9
Cleaning, des-
caling and
disinfection of
the parts of the
drinking foun-
tain
At least once a
year and in
case of abnor-
mal results
when control
Disassemble the drinking fountain
Descaling:
~ Make the descaling product circulate inside the evapora-
tor ~ Take off the parts that can be dismantled and immerse
them in the descaling agent (time of contact according to
the recommendations of the product manufacturer)
~ Rinse the circuit during 5 minutes after reassembly of
the fountain
Disinfect:
~ Inject in the circuit the disinfecting product (possibly by
means of a pump), until flow at the other end
~ Time of contact according to the recommendations of the
product manufacturer
~ Inject again the disinfecting product in the circuit until
flow at the other end
~ Rinse abundantly
Control sampling before starting up again.
*Plan a change of filter after each stop of more than 8 days
Technical maintenance (Machine on)
Method Frequency Observations
Verification
of the good
working Everyday ~ Check that the water is cold
~ If the water has an abnormal colour, do not use it and con-
tact technical services.
External surfaces, grid and basin
Cleaning Everyday
External surfaces :
~ Clean with a soft detergent
~ Rinse
~ Avoid using abrasive products
Grid and basin :
~ Clean with a soft detergent
~ Rinse
~ Clean with a soft clothe and a bit of scouring powder
~ Rinse to eliminate all trace of product
Purge Everyday
~ In the morning, before filling it the first jug
~ After a non-used exceeding 24 h
~ Purge time depends on the pipe length on which the water
is staying in during night. The purge is ok when the water is
at the right temperature

Preventive cleaning (Machine on)
Method Frequency Observations
Stainless steel surfaces, glass filler and basin
Cleaning and dis-
infection Cleaning and disinfection
2 methods can be used
*1st method:
~ Cleaning with a detergent
~ Rinse
~ Disinfection with chlorinated water at 6° chl, time
of contact 15 min
~ Rinse
*2nd method:
~ Cleaning and disinfection with a “detergent and
dissection” solution; time of contact according the
recommendations of the product manufacturer.
~ Rinse
Pipes and siphon
Cleaning and dis-
infection without
disassembling
Cleaning and
disinfection
~ Pour chlorinated water at 12° chl. Inside the si-
phon
~ Contact 15 min
~ Rinse by opening the tap
~ Never mix chlorinated water with a descaling
agent (risk of chlorine gas emanation).
Descaling Trimestral
~ Use a descaling agent
~ For the little scaly zones, apply the product with a
moistened and soaked soft clothe.
~ For the very scaly surfaces, apply directly the
product to walls to be treated.
~ Let act the product according to the recommenda-
tions of the manufacturer.
~ Rinse to eliminate any trace of product
10
