Dietz Rehab TAIMA m User manual

EN
User manual Version 3.2.0 EN
Lightweight rollator

2
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
NOTE
For better visibility nd our user
manual also online under
www.dietz-rehab.de
as PDF le with zoom function.
USER MANUAL
Thank you for purchasing a
TAiMA rollator from DIETZ.
The TAiMA rollator is exceptionally light,
strong and can easily be folde to stow
away. It provides ideal support during all
your daily ventures as well a seat to rest.
Before using the rollator for the rst time
please read this ma nual carefully and
make sure to be familiar with all features
of the product.
In addition, you will receive information
that will aid operational and trafc safety
and the preservation of your investment in
your rollator.
If you have any questions or require additional
information, please contact the specialist
retailer which supplied the wheelchair to you.
You can always nd the latest information
about your product on our website.
For information or queries concerning product
safety and on recalls, please contact DIETZ
in writing or by telephone. You will nd our
contact information on the back of this user
manual.

3
EN
USER MANUAL CONTENT
01 Important information
Intended use. . . . . . . . . . . . . . . . . . . . . . . . . .4
Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Contraindication . . . . . . . . . . . . . . . . . . . . . . .4
Signs and symbols . . . . . . . . . . . . . . . . . . . . .4
02 Product description
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . .4
Optional accessories . . . . . . . . . . . . . . . . . . . .5
Set up TAiMA . . . . . . . . . . . . . . . . . . . . . . . . .5
03 Build up the rollator
Setting up/unfolding the rollator . . . . . . . . . . .6
Grip handle adjustment . . . . . . . . . . . . . . . . .6
04 Using the rollator
Walking with your rollator . . . . . . . . . . . . . . . .7
Curb climber . . . . . . . . . . . . . . . . . . . . . . . . . .7
Braking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Parking brakes . . . . . . . . . . . . . . . . . . . . . . . .8
Brake adjustment . . . . . . . . . . . . . . . . . . . . . .8
Folding your rollator . . . . . . . . . . . . . . . . . . . .9
05 Accessories
Attaching and using accessories . . . . . . . . . . .9
Shopping bag (tted as standard) . . . . . . . . . .9
Shopping bag (optional) . . . . . . . . . . . . . . . .10
Backrest (optional) . . . . . . . . . . . . . . . . . . . .10
Cane holder (tted as standard) . . . . . . . . . .10
Tray (optional) . . . . . . . . . . . . . . . . . . . . . . .11
One hand brake system (optional) . . . . . . . . .11
Extended push handles (optional) . . . . . . . . .11
Umbrella (optional) . . . . . . . . . . . . . . . . . . . .12
Accessories and add-ons
from external suppliers . . . . . . . . . . . . . . . . .12
06 Safety instructions
Safety instructions. . . . . . . . . . . . . . . . . . . . .13
07 Instructions for general use
Servicing / maintenance. . . . . . . . . . . . . . . . .15
Maintainance schedule . . . . . . . . . . . . . . . . .14
Fault-nding and rectication . . . . . . . . . . . .17
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Desinfection . . . . . . . . . . . . . . . . . . . . . . . . .18
Forwarding/reusing . . . . . . . . . . . . . . . . . . . .18
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Product labelling . . . . . . . . . . . . . . . . . . . . . .20
08 Manufacturer declarations
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Lifetime. . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
09 Technical documentation
Specications . . . . . . . . . . . . . . . . . . . . . . . .22
Product tests. . . . . . . . . . . . . . . . . . . . . . . . .23
Environmental conditions . . . . . . . . . . . . . . .23
Capture identication data . . . . . . . . . . . . . .23

4
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
01 IMPORTANT INFORMATION 02 PRODUCT DESCRIPTION
INTENDED USE
The TAiMA rollator is designed for persons
with restricted mobility with a maximum body
weight of 150 kg for use as a walking aid and,
to a limited extent, as a seating device for
temporary rest.
It is used both indoors as well outdoors and is
designed exclusively for use on solid and level
surfaces.
The intended purpose may differ for products
which were manufactured as custom models
and which have been labelled as such. In
this case, please refer to the documentation
supplied with the product.
INDICATION
The use of the TAiMA is indicated for:
c Restricted mobility due to a restriction of
the active or passive musculoskeletal
system
c Coordination problems when walking
c Reduced load-bearing capacity
CONTRAINDICATIONS
The use of the TAiMA is not indicated for
c False sensations,
c Severe disequilibrium
c User weights of above 150 kg
The rollator is not suitable for children.
The TAiMA must not be used as a climbing
aid, transport aid for large loads/persons or for
similar purposes.
SIGNS AND SYMBOLS
These symbols indicate passages of text that
are helpful for using and operating the product
in every day life.
WARNING
Safety hazard! It is mandatory to observe
and comply with warnings.
They inform you of circumstances that could
result in injury and/or damage to the wheelchair
or surroundings if the warnings are not
observed.
NOTE
Tips and advice to simplify using the functions.
SCOPE OF DELIVERY
The scope of delivery of the TAiMA includes the
following components and accessories:
c TAiMA rollator
c User manual
c Standard bag
c Cane holder (left/right mount)
c Curb climber
On receipt of the rollator, please immediately
check to make sure that the contents are complete
and undamaged. If the contents are noticeably
damaged, inform the freight company
immediately.

5
EN
02 PRODUCT DESCRIPTION
ACCESSORIES (OPTIONAL)
The following optional accessories
are available for your TAiMA rollator:
c Shopping bag for rollator
Art. 290101
c Backrest „Standard“
Art. 290007
c Backrest „Comfort“ soft, extra wide
Art. 290038
c One hand brake system
Art. 290105 (left)
Art. 290104 (right)
c Extended push handles
Art. 290106
c Umbrella to protect from sun or rain
Art. 601270 (rot)
Art. 601271 (macchiato)
c Tray
Art. 280009
SET UP TAIMA
1
2
3
4
6
5
1. Ergonomic handgrips
2. Brake lever
3. Cane holder
4. Height adjustment screw
5. Locking pin
6. Brake
7. Curb climber
7

6
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
03 BUILD UP THE ROLLATOR
SETTING UP THE ROLLATOR
The TAiMA rollator is fully assembled at
the factory. The following chapters describe
how to set up the rollator, adjust it to suit
your requirements and enable you to use it
comfortably.
SETTING UP/UNFOLDING THE
ROLLATOR
1. Position the rollator in front of you with
the handles pointing towards you.
Push the side tubes of the seat apart and
down until the rollator has unfolded
completely A. The folding lock (red
button) B must audibly click into place.
WARNING
Safety hazard! Only use the rollator if the
folding lock is correctly engaged.
WARNING
Risk of trapping! Take care not to trap your
hands, ngers or clothing when operating the
folding lock and when unfolding/folding the
rollator!
ADJUSTING THE HANDLE HEIGHT
1. Loosen screw B and remove it completely.
2. Adjust the grip handles to the height
desired.
3. Place screw B back in it´s hole and tighten
it firmly.
NOTE
To use TAiMA correctly, it must be adjusted to
your individual size. You should have an
employee of your medical supply store or
another trained person do this.
CLICK!

7
EN
04 USING THE ROLLATOR
USING THE ROLLATOR
Familiarise yourself thoroughly with your TAiMA
rollator before using it for the rst time so
that you feel safe and condent handling the
rollator. It is advisable to be accompanied by a
second person.
Check that the rollator has been correctly
assembled before using it:
c Are all attached parts firmly fixed in
place?
c Have all screws been firmly tightened?
c Do the brakes work?
c Does the rollator rest on all four wheels?
c Is the folding lock properly engaged?
WALKING WITH YOUR ROLLATOR
Position yourself inside the rollator. Grab the
handgrips with both hands.
As soon as you stand safely, you can loosen the
parking brakes.
WARNING
Safety hazard! The following points are im-
portant for your safety!
c Do not push the rollator too far in front
of you. In order to give good support,
the rollator should be kept close to your
body.
c Control your speed by gently applying
both brakes evenly.
c Walk upright and look forwards to be
able to avoid any upcoming obstacles
early. Walking backwards with your
rollator is difficult, and not
recommended.
c Use the brake (pull the brake lever
upwards) on sloping paths and do not
use paths that are excessively steep.
c It is inadvisable to walk backwards using
the rollator.
CURB CLIMBER
It is easier to overcome curbs and other
obstacles by tipping the rollator.
1. Ensure that you have a firm footing.
2. Gently press the toe cap with your toe.
This slightly lifts the front wheels of the
rollator.
3. Push the rollator onto the obstacle and
take your foot back off the toe cap.
WARNING
Tipping danger! Keep in mind that pressing
the curb climber can impair your balance.

8
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
04 USING THE ROLLATOR
BRAKE ADJUSTMENT
Check that the brakes are correctly adjusted as
follows:
c The brake lever and the Bowden cable
must not be loose (they must not have
any play).
c When you release the brake lever, the
wheels must turn without making any
scraping noises.
c If necessary, the braking effect can be
adjusted using the adjusting screw C of
the Bowden cable on the brake pads of
the rear wheels.
WARNING
Safety hazard! If problems occur when ad-
justing the brakes, please contact an autho-
rised specialist retailer! This is the only way of
ensuring the safe use of the rollator.
Safety hazard! Never fully unscrew the
screw, otherwise the brake will no longer
work.
BRAKING
To reduce speed while walking just pull both
levers evenly and gently upwards. Always apply
the same amount of power on both brake
levers A.
PARKING BRAKE
1. To block the brakes (parking brake), press
the brake levers downwards B. They will
click into place audibly and automatically.
2. To release the brakes, press the levers back
upwards A (See drawing above).
CLICK!

9
EN
05 ACCESSORIES
ATTACHING AND USING ACCESSORIES
Your TAiMA rollator is equipped with a
shopping bag and cane holder as standard.
Optional additional accessories can be
purchased (see chapter “Optional accessories“).
SHOPPING BAG (FITTED AS STANDARD)
The standard bag is approved for transporting
objects up to a maximum weight of 5 kg.
1. To attach the bag, take hold of the two
side loops A and hang them over the two
holding rods.
2. To remove the bag, take hold of the two
loops again and pull the bag forwards
and off the rods.
3. To pick up the shopping bag using the
carrying straps B, place the bag briefly on
the ground and then take hold of the
straps on both sides.
FOLDING UP YOUR ROLLATOR
It is easy to fold up the TAiMA rollator. It can
stand freely when folded, which has the great
advantage of saving storage space.
1. To fold the rollator, release the folding
lock A by pulling the red button towards
yourself.
2. At the same time, pull the seat upwards
using strap B.
3. The rollator will fold up automatically.
WARNING
Risk of trapping! Take care not to trap your
hands, ngers or clothing when operating the
folding lock and when unfolding/folding the
rollator!

10
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
05 ACCESSORIES
SHOPPING BAG (OPTIONAL)
Your TAiMA rollator can optionally be equipped
with a shopping bag that is approved for
carrying up to 15 kg in weight.
These bags are attached, removed and carried in
exactly the same way as the standard shopping
bag (see description in previous chapter).
The shopping bag can also be closed using a zip.
BACKREST (OPTIONAL)
If you wish to have the optional backrest
"Standard" A or „Comfort“ (soft & extra
wide) on your TAiMA, please contact your
medical supply store to install the backrest.
The backrest allows you to seat yourself safely
and helps you to nd the correct position on
the seat of the TAiMA.
WARNING
Tipping danger! Make sure that the brakes
are locked before you sit down, and be aware
that leaning against the backstrap will reduce
the tilt stability.
WARNING
Tipping danger! Before you sit down, make
sure that the backrest is not turned upwards or
downwards. You could otherwise lose your bal-
ance and fall.
NOTE
The seat is only designed to be used for short
periods, such as when taking a short break
when walking. For longer breaks, use
conventional seating!
CANE HOLDER (FITTET AS STANDARD)
The cane holder is already tted on the right-
hand side of your rollator on delivery.
1. To insert your walking stick, first position
the rubber base of the walking stick in the
lower section of the cane holder A.
2. Then use slight pressure to click the stick
into the upper clip of the cane holder B.

11
EN
05 ACCESSORIES
If having the cane holder positioned on the left-
hand side would be more practical for you, the
upper and lower sections of the cane holder
can be released and attached to the left-hand
side. Please contact your authorised specialist
retailer to have this installed.
TRAY (OPTIONAL)
The tray is designed for transporting small
items up to a maximum of 5 kg but only for
use indoors.
Place the tray on the seat cover. There are four
pins on the bottom of the tray. Position the pins
in the four holes in the seat cover.
When transporting objects on the tray, always
push the rollator with extra care. If you make
jerky movements, the objects could tip over or
fall off.
WARNING
Risk of burns! Do not use the tray to trans-
port hot items or hot drinks. You could burn
yourself if the transported items tip over
ONE HAND BRAKE SYSTEM (OPTIONAL)
If one of your hands is not sufciently strong to
operate the brake safely, the TAiMA M can be
equipped with a one-hand brake. This must be
mounted on the rollator by an authorised spe-
cialist retailer.
c Your rollator must only be fitted with a
one-hand brake if the hand with which
the brake will be operated is sufficiently
strong to guarantee safe handling.
c The same usage and maintenance
instructions apply as for the version with
brakes on both handlebars.
EXTENDED PUSH HANDLES (OPTIONAL)
The TAiMA M can be equipped with extended
push handles. This is advisable if you are not
able to walk upright when pushing the rollator
due to your size.
WARNING
Safety hazard! Please contact your
authorised specialist retailer to have extended
push handles installed.
Setting the precise handle height, using the
brakes and adjusting the brakes are performed
in exactly the same way as for conventional
push handles. For information on these tasks,
read the chapters “Adjusting the handle
height“, “Brakes“, “Parking brakes“ and
“Adjusting the brakes“.

12
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
05 ACCESSORIES
UMBRELLA (OPTIONAL)
Your TAiMA rollator can be equipped with an
umbrella, which can also be used as a sunshade.
The installation of this optional accessory is
described in a separate user manual supplied
with the product. Have the umbrella tted by
an authorised specialist retailer, who will hand
over the user manual to you. Please observe
all of the usage and safety instructions in the
separate user manual for the umbrella!
WARNING
Tipping danger! Fitting an umbrella may af-
fect the tilt stability of your rollator inuence
negatively!
Safety hazard! Please observe all usage and
safety instructions stated in the separate user
manual for the umbrella!
ACCESSORIES AND ADD-ONS FROM
EXTERNAL SUPPLIERS
As a general principle, only original accessories
from DIETZ GmbH are to be used. If third-
party products are installed on the rollator,
responsibility for the safety of the product
passes to the person who installs the
accessories or carries out the installation. The
compliance of the combination of accessories
or add-on and product is then new, and must
be declared by the person who attaches it. The
compliance declared by DIETZ according to
MDR 2017/745, Annex II expires.
WARNING
Product safety! Should add-ons or accesso-
ries that are not sold by DIETZ be used, the
safety of the product cannot be guaranteed.
Product safety! If accessories or add-ons are
added to the rollator, the safety instructions in
the user manual for the accessories or add-ons
must be observed.

13
EN
06 SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
By observing the intended use and following
the safety instructions, there is no danger of
using the TAiMA rollator.
WARNING
Follow all safety instructions, otherwise there
may be a risk of injury!
c The rollator may only be on level, firm
ground.
c Use the service brake on sloping paths
(pull the brake lever upwards).
c If your TAiMA is equipped with
pneumatic tyres, check regularly that
the tyre pressure is correct.
c The rollator must be securely upright
on all four wheels.
c Before each use of the rollator, check
that all attached parts are properly
fastened, that the brakes are working
and that the folding mechanism is
locked.
c Always lock both brakes before sitting
on the rollator's seat.
c The rollator’s seat is only designed to
be used for short periods, such as
when taking a break when walking!
c Attention: Please note that a shift of
balance due to body movements may
increase the risk of the rollator tipping
over. Always make sure the load on
the rollator is evenly!
c Do not hang any bags on the handles
or other parts of the rollator, as this
will increase the risk of it tipping over!
c Take care not to trap your hands,
fingers or clothing when operating the
folding lock and when unfolding/
folding the rollator! Risk of crushing!
c Never exceed the maximum combined
load of 150 kg for user and load!
c Avoid exposing the wheelchair to
direct sunlight, heat sources or low
temperatures for long periods of time
as parts of the product (e.g. frames,
footrests, brakes and side panels) may
b come very hot (> 41°C) or very cold
(<0°C) and this may cause skin
injuries.
c Ensure that the rollator is not parked
in direct vicinity of emergency exits
and escape routes and blocks them.
c Never use the rollator under the
influence of alcohol or other
substances that can negatively affect
your attention and reaction ability!
c Only ever use the rollator in
accordance with its intended use!
When using the rollator, never
approach obstacles such as steps or
curbs without applying the brakes.
c The rollator must not be left to
children to play and must not be
subjected to improper use!
c When sitting on the rollator, you must
not walk with your feet or be pushed
by other persons! This is an injury risk
and may cause damage to the product!
c Observe the road traffic regulations on
public road traffic.
c Wherever possible, wear light, eye-
catching clothing. This will allow you
to be seen more easily by other road
users.

14
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
06 SAFETY INSTRUCTIONS
c Never use the rollator as a seat in a
vehicle or on public transport. This
poses an increased risk of falling!
c Never use escalators. The risk of falling
and injury is very high!
c Stairs must only be negotiated with the
help of accompanying persons if no
elevators or ramps are present.
c The wheel bearings can be damaged by
sand, seawater and road salt. Clean
the rollator thoroughly if it has been
exposed to conditions such as these.
c I f they cannot be bypassed, ruts, rails
or similar obstacles must always be
crossed at right angles (90°).
c The rollator must not be used to
transport heavy loads. Items must only
be transported using the rack, basket
or tray, as described in the
“Accessories” section.
c Serious incidents that occur in relation
to the rollator must be reported to the
manufacturer and the responsible
authorities!
c If you notice any limitations in the
functioning of your rollator, please take
it to your authorised specialist retailer
for repair immediately.
c If stored for over one year, all
mandatory inspections stipulated in
the maintenance plan must be
performed before putting the rollator
back into service.

15
EN
06 SAFETY INSTRUCTIONS 07 INSTRUCTIONS FOR GENERAL USE
MAINTENANCE SCHEDULE TAIMA
What Description
Brakes/parking
brakes:
Function
If the brake handles are pushed down/locked (parking brake) or the
brake handles are actuated (service brake), the rear wheels must not
turn.
The brakes must be recongured after replacing the Bowden
cables or rear wheels. This must only be performed by the
authorised specialist retailer.
x
Push handles:
stability
1. It must be possible to rmly lock the star screws
on the push handles.
2. The push handles must not wobble.
x
Before use
Monthly
SERVICING/MAINTENANCE
We recommend performing the inspections listed in the maintenance schedule at regular intervals
to ensure that the rollator is always safe to use.
Defective or neglected care and maintenance of the rollator limits liability. The maintenance schedule
does not give any information concerning the amount of work actually required on the rollator.
WARNING
Safety hazard! Repairs on the rollator must
only be performed by specialist shops using
DIETZ original spare parts to maintain the
operational safety of the rollator. The relevant
spare parts catalogue can be found on our
website in the information of the product in
question.
NOTE
The inspections and measures stipulated in the
maintenance schedule must be performed by
the user or assistant if not otherwise stated.
NOTE
As the user, you will be the rst to notice
possible damage. If you notice a fault as
described in the maintenance schedule or
further defects and functional impairments,
contact an authorised specialist dealer
immediately.
NOTE FOR SPECIALIST DEALERS
If the user indicates abnormalities on the
rollator, check all the inspection points listed in
the maintenance schedule on the rollator. The
checks must also be performed before putting
the rollator back into operation and after longer
storage periods (> 4 months).
before use
monthly

16
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
07 INSTRUCTIONS FOR GENERAL USE
What Description
Folding lock and
folding mechanism:
Function & safety
1. It must be easy to pull out the folding lock (red button) and
engage it again.
2. It must be easy to push the two parts of the frame
together and apart.
x
Screw connections:
securely fastened
All screw connections must be securely fastened.
Repeated loosening and re-tightening causes self-locking nuts
and screws to lose their effectiveness. These must therefore be
replaced by an authorised specialist retailer if they become loose.
x
Steering and
running wheels:
Mobility, function &
damage
1. The wheels must run in a straight line and must not wobble.
2. The wheels must move easily and quietly during travel.
3. The wheels must not be damaged.
x
Steering and
running wheels:
Mobility, function &
damage
1. The wheels must not be damaged and must run quietly, in a straight
line and without wobbling.
2. Please clean the wheel hub if it is dirty or if uff has accumulated.
x
Push handles:
Stability &
damage
1. The handles and brake handles must be rmly secured.
2. The push handles must not have any external damage/distortion
and must not wobble.
3. It must be possible to rmly lock the star screws.
x
Seat:
dirt & damage
1. The seat cover must be rmly positioned in the side rails.
2. If the seat is dirty, clean it according to the
cleaning instructions.
2. If damaged, have the seat replaced.
x
Frame, entire:
Function &
damage
1. The two frame parts and cross struts must not be damaged or cracked.
2. Functional damage or surface damage must be rectied. x
Visual inspection:
loose parts, fractures,
corrosion or other
damage
If this type of damage is detected, the rollator must
no longer be used, as safe operation is no
longer guaranteed!
x
Dirt:
entire rollator
The entire rollator must be cleaned depending on how dirty it is, but at
least once a month (see chapter “Cleaning”). x
before use
monthly

17
EN
07 INSTRUCTIONS FOR GENERAL USE
FAULT-FINDING AND RECTIFICATION
What Possible causes Measures
The front wheels do not
run in a straight line.
The wheel bearings are defective or
the wheel suspension is no longer
correctly attached.
Consult an authorised specialist
retailer.
The rollator is hard to
push.
The wheel axles/wheel hubs are dirty. Remove the dirt.
The brakes are incorrectly adjusted.
Consult an authorised specialist
retailer.
The wheel bearings are defective or
the wheel suspension is no longer
correctly attached.
The brake function is
insufcient or uneven.
The brakes are incorrectly adjusted or
the brake pad has worn out.
Consult an authorised specialist
retailer.
The seat cover is not taut
or not rmly connected to
the rollator.
The rollator is not fully unfolded. Fully unfold the rollator and engage
the folding lock.
The seat cover is not correctly xed in
the side rails or is defective. Consult an authorised specialist
retailer.
The cross struts or folding mechanism
are defective.
Squeaking or grinding
noises Various causes Consult an authorised specialist
retailer.
The rollator does not
provide secure support or
does not stand reliably.
The push handles are not xed in
place properly or have been incorrectly
adjusted for the user.
Check the position of the push
handles.
Check whether the clamping levers
on the push handles are securely
tightened.
The rollator has not been fully
unfolded and the folding lock has not
been engaged.
Fully unfold the rollator and engage
the folding lock.
The rollator frame or the push handles
are damaged.
Consult an authorised specialist
retailer.

18
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
07 INSTRUCTIONS FOR GENERAL USE
CLEANING
WARNING
Material damage! Do not use high-pressure
cleaners, strong, corrosive chemicals or scouring
agents for cleaning purposes.
Material damage! After cleaning, ensure
that all materials are completely dried in order
to preserve their quality.
c Clean the rollator by regularly wiping the
frame parts with a damp cloth. If the
rollator is very dirty, you can use a mild
detergent and warm water.
c The seat cover and shopping bag can be
hand-washed in mild soapy water of up
to 40°C.
c The wheels can be cleaned using a damp
brush with soft plastic bristles.
c Remove dirt and fluff from the wheel
hubs.
c Only ever use standard mild cleaning and
disinfection products to clean the
rollator. Detailed information on
disinfection can be found in the
following section.
DESINFECTION
WARNING
Material damage! Observe the use and
processing instructions issued by the cleaning
agent/ disinfectant manufacturer.
When manually reconditioning a used aid for
reuse, all of the aid’s components must be
thoroughly treated/wiped with a disinfectant.
Take particular care to disinfect surfaces that
come into frequent contact with hands/skin,
such as handles.
Please only use the following disinfectants; use
of other chemicals might damage the rollator:
c Aldehyde-free disinfectants based on
alcohol (max. 70% propylalcohol)
FORWARDING / REUSING
The number of times the rollator can be reused
depends on the material wear conditions and
the functional capabilities of the respective
product. If the rollator is passed on to a new
user or specialist dealer for reuse, please
remember to hand over all technical documents
that are necessary for safe usage. The rollator
must be cleaned and disinfected, and must
be checked for damage and approved by the
specialist retailer. To do so, please check all
the inspection points listed in the maintenance
schedule on the rollator.

19
EN
07 INSTRUCTIONS FOR GENERAL USE
STORAGE
WARNING
Material damage! Do not store the rollator
near a heat source or store objects on
it.
To store the rollator, ensure that it is stored
in a dry place protected against direct, strong
sunlight and at a temperature of 0°C to +45°C.
Secure the rollator against unintentional rolling
away. Do not use the parking brakes for this, as
these can damage the tires over a long period
of time when they are activated.
After longer periods of storage (> 4 months),
please check all the inspection points on the
rollator listed in the maintenance schedule
before reusing/redeploying it.
DISPOSAL
If you no longer need the rollator, please contact
your specialist dealer. They will then pick up the
rollator and either dispose it properly or make
further use of it. If this is not possible, please
take the wheelchair to your local recycling
facility.

20
DIETZ / User manual rollator TAiMA M / Version 3.2.0 EN
07 INSTRUCTIONS FOR GENERAL USE
PRODUCT LABELLING
The type plate must always remain legible. On
the TAiMA model it is located on the left cross
strut.
Please have any illegible or missing signs/
stickers replaced by your specialist retailer
immediately. This includes the reector stickers.
The following section explains the symbols and
information on the type plate in detail. (The
type plate shown here is only an example.) The
type plate also contains the serial number of
your rollator.
2019-08
(01)04260241684407
(10)1900XXX
(21)371022XXX
200059
TAiMA M
630 mm
790 mm-
950 mm 150 kg
Trademark
TYPE/Modell
REF = Item number
UDI = Unique Device
Identier
(01) UDI-DI
(10) Order number
(21) Serial number
Manufacturer/manufacturer's
trademark/contact address
Maximum load capacity/load
incl. payload
Date of manufacture
Total width of rollator
Total hight of rollator
(min.- max.)
The rollator can be used in-
and outside
Follow the user manual
Caution - note the safety
information in the user
manual
Medical Device
The product is compliant with
Regulation (EU)2017/745
on medical devices
Products with the following designation are
custom-made devices:
Custom-made devices are products which are
customised for a particular user. The type plate,
warnings and, where applicable, the intended
use differ in this case. Please pay attention to
the additional documentation!
