Schuchmann MALTE User manual

malte. & malte outdoor.
Instructions for use.
malte. & malte outdoor.
The compact and versatile posterior walking aids.

Our promise.
Dear Customer,
at this point we would like to thank you for placing your trust in our company and for
purchasing our product. We ask you to read through the Instructions for use carefully
prior to initial commissioning of the product, and to observe them. Please note that gui-
delines and representations in these Instructions for use may deviate from your product
due to diering equipment.
We reserve the right to make technical modifications.
Important information!
Ensure that these Instructions for use remain with the product..
Your schuchmann-Team

03 Contents.
1. Preparation. ...................................................................................05
1.1 Delivery....................................................................................................................... 05
1.2 Safety measures prior to use.......................................................................... 05
1.3 Safe disposal.......................................................................................................... 05
1.3.1 Verpackung............................................................................................ 05
1.3.2 Product.................................................................................................... 05
1.4 Where to store the Instructions for use..................................................... 05
2. Product description. .......................................................................06
2.1 Material information............................................................................................ 06
2.2 Handling / transport.......................................................................................... 06
2.3 Application areas, use according to the intended purpose......... 06
2.4 Use not in accordance with the intended
purpose / warning guidelines...............................................................................07
2.5 Equipment for basic model.............................................................................07
2.6 List of accessories ................................................................................................07
2.7 Product overview ................................................................................................. 08
3. Settings. ........................................................................................09
3.1 Closing / folding up the frame...................................................................... 09
3.2 Handles...................................................................................................................... 10
3.2.1 Handle height adjustment............................................................. 10
3.2.2 Setting the handle width ............................................................... 10
3.3 Direction locks..........................................................................................................11
3.4 Combined pelvis and buttocks pelotte pads ........................................11
3.5 Storage basket.......................................................................................................12
3.6 Tip protector ...........................................................................................................13
3.7 Bench ..........................................................................................................................13
3.8 Lower armrests .......................................................................................................14
3.9 Handle / grip ball for lower armrests ..........................................................15
3.10 Friction brake.........................................................................................................15
3.11 Parking brake ..........................................................................................................15
3.12 Bar ...............................................................................................................................16
3.13 Deflector................................................................................................................... 17
3.14 Backwards stop....................................................................................................17
4. Repairs and cleaning. .....................................................................18
4.1 Cleaning .....................................................................................................................18
4.2 Repairs........................................................................................................................18
4.3 Spare parts...............................................................................................................18
4.4 Duration of use and re-use..............................................................................18
5. Technical data. ...............................................................................19
6. Guarantee. .....................................................................................21
7. Identication. ................................................................................22
7.1 EC declaration of conformity...........................................................................22

0404 Contents.
7.2 Serial number / date of manufacture ........................................................23
7.3 Product version.......................................................................................................23
7.4 Issue of the document........................................................................................23
7.5 Name and address of the manufacturer,
specialist dealer supplying the product..........................................................23

05 1. Preparation.
1.1 Delivery
On receiving the product, please check it for completeness, lack of faults
and check it for any transport damage. Inspect the goods in the presence
of your forwarder Should transport damage have occurred, please arrange
for an inventory (determination of the faults) to be made in the presence of
the forwarder. Please send a complaint in writing to the specialist dealer
responsible.
1.2 Safety measures prior to use
Correct usage of the respective posterior walker requires precise and
careful instruction of the accompanying person. We ask you to read through
the Instructions for use carefully prior to first use of the posterior walker, and
to observe them. Cushioned parts may become warm when exposed to di-
rect sunlight. Cover these parts or protect the equipment from direct sun-
light.
1.3 Safe disposal
In order to preserve and protect the environment, to prevent environmental
pollution, and to improve the recycling of raw materials, please note the
disposal instructions (1.3.1 and 1.3.2).
1.3.1 Verpackung
The product packaging should be stored in case the product needs to be
transported again. Should you have to return the product for repairs or in
case of a guarantee claim, please if possible use the original box so that
the product is optimally packaged. Separate the packaging materials for
recycling according to their classification. Do not leave packaging materials
unattended, as they are a possible source of danger.
1.3.2 Product
Separate the raw materials used in the product for recycling according to
their classification (see material information under 2.1).
1.4 Where to store the Instructions for use
Please store these Instructions for use carefully and ensure that these
Instructions for use remain with the product in case of re-use.

06 2. Product description.
2.1 Material information
The base frame and the individual elements are made of aluminium which is
non-corroding and powder-coated. The body supports and lower armrests
are made of PU. The seat is padded and covered. The padding is made from
100% polyester and is flameretardant (in line with DIN EN 1021-1+2).
2.2 Handling / transport
The posterior walker is not designed to be carried, as it is fitted with wheels.
Should you have to carry the equipment due to obstacles, ensure that all
moving parts are tightened. Stand next to the posterior walker, hold on to
the left and right handles and lift it over the obstacle. To transport the pos-
terior walker, fold the frame (see point 3.1).
The frame of the malte. size 0 mini cannot be folded! In this case, set ever-
ything at its most compact (fold up bench, set handles to lowest setting etc.)
Lift the compact unit by stepping between the frame from the rear and then
holding on to it on the left and right.
2.3 Application areas, use according to the intended purpose
Indications
The posterior walker malte. and malte outdoor. have been designed for
children and teenagers to compensate for reduced strength or ability of the
lower extremities using force/support from the upper extremities (possibly
also the torso). The aim is to learn active walking or independent movement,
expansion of a restricted radius and compensation of unsteady walking.
The posterior walker malte.and malte outdoor. are pulled behind the head.
This increases backward stability and oers optimum freedom of leg mo-
vement due to the abducted frame design.
Contraindications
In general, the indications for walking training should be approved by a
doctor or orthopedist. It should therefore be clarified prior to procurement
whether contraindications exist for the patient. In general, any type of pain
represents a contraindication. Walking training should not be provided wi-
thout establishing prior to use whether the patient has an abnormal foot
position, which requires medical attention.

07
2.4 Use not in accordance with the intended
purpose / warning guidelines
• Correctusageofthisproductrequirespreciseandcarefultrainingof
the accompanying person.
•Theproductmaynotbeusedwithoutsupervision.
• malte. may only be used indoors on solid, even ground. Please use the
malte outdoor. for outdoor areas.
• Themax.heightadjustmentisspeciedbyamarking-nosettingsmay
be made beyond this range.
• Pleaseobservepoint 5 „Technical data“ in these Instructions for use for
the maximum permitted patient weight.
• Afteralladjustments,rmlyre-tightenthescrewconnectionsyouhave
loosened!
• Hangingonheavybagsorotheritemscanhaveanegativeimpacton
stability.
• OnlyuseaccessoriesandsparepartsmadebySchuchmann,otherwise
you will endanger the child.
• Pleaseensurethatnoneoftheuser‘sextremitiesareintherespective
area when making adjustments to avoid the risk of injury.
• Userswhohavedicultyreadingmusthavesomeonereadthese
Instructions for use aloud so that they understand how to use the
product.
2.5 Equipment for basic model
• Lightweight,foldingaluminiumframe
(malte. size 0 mini does not fold down)
• Individuallyheightandwidthadjustablehandles
• EVAguidewheelswithdirectionlocks
• EVArearwheelswithintegratedbackwardsstopinthehub,
which can be switched o (malte.)
• EVArearwheels(malte outdoor.)
• Drumbrakeincl.parkinghandbrake(malte outdoor.)
2.6 List of accessories
• Endstopsforhandles
• Combinedpelvisand
buttocks pelotte pads
• Backpelottepadwith
chest strap
• Foldingbench
• Tipprotector
• Storagebasket
• Deectorset(malte.)
2. Product description.
•Parkinghandbrake(malte.)
•Lowerarmrestswithhandles(malte.)
•Lowerarmrestswithgripballs(malte.)
•Frictionbrake
•Bar(malte.)
•Backwardsstop(malte outdoor.)

08
2.7 Product overview
The figures below are intended to show you the designation of the most
important components as well as the terms which you will find in these
Instructions for use.
2. Product description.
Combined pelvis and
buttocks pelotte pads
Bench
Bench
Lightweight, folding
aluminium frame
EVA guide wheels
with direction locks
EVA rear wheels with
drum brake
Lightweight, folding
aluminium frame
Parking brake
Lower armrests
with handles

09 3. Settings.
Settings and adjustments to the product or accessories may only be made
by people who have been given the necessary instructions by a medical
productadvisor.Pleaseensurethatnoneoftheuser‘sextremitiesareinthe
respective area when making adjustments to avoid the risk of injury.
3.1 Closing / folding up the frame
The frame can be folded for easy
transportation or better storage of the
posterior walker using hinges (A). Stand
or crouch down behind the posterior
walker to fold the frame down. Pull both
releases (B) at the same time and press
the frame down (C).
To unfold, pull both releases (C) and
set the frame up again. The posterior
walker is ready to use again as soon as
both hinges have locked in with an au-
dible click.
The frame of the malte. size 0 mini
cannot be folded down!
It is essential that hinges lock back in
when unfolding!
For malte. size 4 another safety pin
(C) is installed!
A
B
B
C
DD
Klick!
Klick!
A

10 3. Einstellungen.
3.2 Handles
The handles can be individually adjusted in height and width for adjustment
to individual body size.
3.2.1 Handle height adjustment
To adjust the height, please loosen the
star handles (A), bring the handles into
the required position and then re-tigh-
ten the star handles. A gauge (B) per-
mits precise height adjustment of the
handles. Make sure that the handle
is not pulled out of the handle mount
beyond the STOP marking (C)assu-
cient clamping can no longer be gu-
aranteed in this case. The height can
also be changed by using the width
adjustment (see 3.2.2).
The handles may not be pulled out of
the handle mount beyond the STOP
mark!
3.2.2 Setting the handle width
To adjust the width, please loosen the
cylinder head screw with inner hexagon
(D), bring the handles into the required
position and then retighten
the cylinder head screw with inner
hexagon. As previously mentioned in
point 3.2.1, the handle height can also
be changed by adjusting the width (E).
After each adjustment, please re-tigh-
ten all screw connections!
A
D
E
B
C

1111 3. Einstellungen.
3.3 Direction locks
It is possible to drive straight ahead by
locking the guide wheels. To release
the guide wheels lock, pull the directi-
on lock (A) gently upwards and turn it
a quarter turn to the left or right. The
guide wheels can now move freely
and allow independent steering. Pull
the direction lock (A) gently upwards
and turn it a quarter turn to the left or
right again to apply the guide wheels
lock. The direction locks click back in as
soon as the guide wheels are aligned
straight.
3.4 Combined pelvis and buttocks pelotte pads
(optional for malte. and malte outdoor.)
The combined pelvis and buttocks pelotte pad is padded with PU and helps
the user straighten up when walking. It can be adjusted in height, depth,
width and angle and can also be swung away to the back.
Height adjustment
The height of the combined pelvis and buttocks pelotte pad can be
adjusted with the handles (B- also refer to point 3.2.1). The height can also
be adjusted by loosening the screws (C).
A
B
C

12 3. Einstellungen.
Depth adjustment
Loosen the 2 grub screws (A) and bring
the combined pelvis and buttock pe-
lotte pads into the required position.
Width adjustment
The pelvis pelotte pad on the com-
bined pelvis and buttocks pelotte pad
can be adjusted in width after loo-
sening the screw connections (B).
Adjustment of the angle
Loosen the cylinder head screw (C) to
adjust the angle of the combined pel-
vis and buttocks pelotte pad.
Swinging away
If the combined pelvis and buttocks
pelotte pad is not required, it can be
simply swung away to the back (D).
After each adjustment, please
re-tighten all screw connections!
3.5 Storage basket
(optional for malte. and malte.outdoor.)
The storage basket can be used to
transport small objects and improves
the look of the posterior walker. The
storage basket has a fixed shape and
cannot be adjusted. The maximum
load of 5 kg must not be exceeded.
A
B
C
B
D

13 3. Einstellungen.
3.6 Tip protector
(optional for malte. and malte outdoor.)
Due to the fact that children sometimes
instinctively want to let themselves fall
backwards, malte. and malte outdoor.
can be equipped with a tip protec-
tor. The tip protector serves to protect
against tipping backwards if the user
leans too far back. It cannot be adjus-
ted.
3.7 Bench
(optional for malte. and malte outdoor.)
The bench is padded and covered. If
the bench is not required, it can be fol-
ded up at the back (A) to provide more
space when walking. Simply lift the
bench gently and fold it backwards.
Simply fold it back down to the use the
bench again.
You cannot afx a bench to the malte.
mini size 0!
Please note the maximum load (see point 5)!
A

14 3. Einstellungen.
3.8 Lower armrests
(optional for malte.)
The lower armrests can be equipped
with a handle or grip ball. They can be
adjusted in depth, height, angle and
inclination.
Depth adjustment
Loosen the cylinder head screw with
inner hexagon (A) beneath the lower
armrest. Now you can slide it onto the
pipe (B) and bring it into the required
position.
Observe the adjustment mark on the
tube (B).
Height adjustment
The handles are used to set the height (see points 3.2.1 + 3.2.2).
Adjustment of the angle
The angle (C) is set using a locking
hinge. Loosen the cylinder head screw
with inner hexagon (A) beneath the lo-
wer armrest and bring the lower arm-
rest into the required position.
Angle adjustment
Loosen the cylinder head screw with
inner hexagon (A) beneath the lower
armrest to set the inclination (D) and
bring the lower armrest into the requi-
red position.
A
E
B
C
D

15 3. Einstellungen.
3.9 Handle / grip ball for lower armrests
(optional for malte.)
Loosen the hexagon socket screws (E)
and bring the grip (F) or grip ball (G) into
the required position.
After each adjustment, please
re-tighten all screw connections!
3.10 Friction brake
(optional for malte.)
The function of the friction brake is to slowly
reduce the speed of the rear wheel rollover.
By turning screw A(loosen lock nut Bbefore-
hand) in and out, you can adjust the pressure
the friction brake has on the wheel and there-
fore the wheel rolling speed.
After each adjustment, please re-tighten
the lock nut!
3.11 Parking brake
(optional for malte.)
For malte outdoor. the parking handbrake is
included in the basic model. Against uninten-
tionally rolling away and for a secure footing
the posterior walker can be equipped with a
parking handbrake. Please pull the brake lever
(C) and lock into the red catch (D). To release,
please pull the lever again (C) and pull at the
same time the red pawls (D).
A
B
C
D
F
G

16 3. Einstellungen.
F
E
3.12 Bar
(optional for malte.)
The bar serves as a horizontal connection bet-
ween the handles and supports an upright
walking position. It can be adjusted in depth
and height and can be swung away.
Depth adjustment
Gently loosen the screws on both clamping devices (E) and bring the bar into
the required position then re-tighten the screws.
Height adjustment
The handles are used to set the height (see point 3.2.1).
Swinging the bar away
Pull the locking bolts (F) out and swing the bar away to the side.
A bar cannot be used for malte sizes 0 + 4 and in combination with
lower armrests (see point 3.8)!
After each adjustment, please re-tighten all screw connections!

17
3.13 Deector
(optional for malte.)
The deflector is used to protect the
product and the environment. The de-
flector prevents damage in the case of
the user walking into furniture, objects
etc. when using the malte. The deflec-
tor is premounted and cannot be ad-
justed.
3.14 Backwards stop
(optional for malte outdoor.)
Due to the fact that children sometimes
instinctively want to let themselves fall
backwards, malte. is equipped with
backward locks as standard and the-
refore gives optimum support. It is an
optional accessory for malte outdoor.
The backwards locks are integrated in
the rear wheels and can be activated
or deactivated depending on the situ-
ation.
Activating the backwards stop
Turn the locking bar by a half turn
upwards (A) and move the wheel back-
wards until the locking bar audibly
clicks in.
Deactivating the backwards stop
Turn the locking bar a half turn down-
wards (B) until it is held in place by the
catch.
3. Einstellungen.
A
B

18
4.1 Cleaning
All frame elements and surfaces can be cleaned with a sponge or moist clo-
th using normal antibacterial household detergents. Please also pay atten-
tion to our general cleaning and hygiene advice. You can find them atwww.
schuchmann.de/malte.
Do not use aggressive cleaning agents such as solvents, hard brushes etc.
4.2 Repairs
Please carry out a daily visual inspection and check the respective posterior
walker regularly for cracks, breaks, missing parts and malfunctions. In case of
a defect or malfunction, please contact the specialist dealer who supplied
you with the product (see point 7.5).
4.3 Spare parts
Should you wish to order spare parts, please contact the specialist dealer
who supplied you with the walker, stating the serial number of the posterior
walker (see point 7.5). Necessary spare parts and accessories must only be
installed by trained personnel.
4.4 Duration of use and re-use
The expected duration of use of our product, dependent on the usage in-
tensity and amount of re-use, totals up to „8“ years, providing the usage ta-
kes place in accordance with the information in these Instructions for use. It
may be possible to use the product over and above this time period if it is in
a safe condition. The expected duration of use does not refer to wear parts,
such as wheels, parking brake, hinges..... The maintenance and evaluation
of the condition, and if applicable the potential for re-use, must be deci-
ded by the specialist trader. The posterior walkers are suitable for re-use.
Prior to forwarding on, please follow the cleaning instructions in Chapter 4.1.
Accompanying documents such as these Instructions for use are part of the
product and must be passed on to the new user. No disassembly is required
prior to re-use. In the case of storage, it is recommended to fold the product
frame (see point 3.1) to the smallest dimension to save
space.
4. Repairs and cleaning.

19
Dimensions - malte. basic model
Size 0* Size 1 Size 2 Size 3 Size 4
A1 Handle height 29 - 53
cm 34 - 58 cm 51 - 75 cm 68 - 94 cm 87- 113 cm
A2 Height of lower arm-
rests - 46 - 70 cm 63 - 87 cm 79- 103 cm 98- 124 cm
BHandle spacing 22 - 36
cm 22 - 36 cm 30 - 44 cm 38 - 52 cm 43 - 57 cm
CSeat height - 33 cm 45 cm 60 cm 70 cm
DTotal width 52 cm 51 cm 61 cm 68 cm 75 cm
ETotal length 58 cm 58 cm 70 cm 77 cm 87 cm
Frame height (folded) 37 cm 25 cm 32 cm 34 cm 37 cm
Transport dimensions
(L x W x H)
58 x
52 x
37 cm
58 x 51 x 25
cm
70 x 61 x 32
cm
77 x 68 x
34 cm
87 x 75 x
37 cm
Max. load 20 kg 30 kg 50 kg 75 kg 100 kg
Weight 3,9 kg 7,1 kg 8,3 kg 8,5 kg 10,2 kg
* Frame cannot be folded up
C
E
A1
A2
B
D
5. Technical data.

20
Dimensions - malte outdoor. basic model
Size 1 Size 2 Size 3
A1 Handle height 34 - 58 cm 51 - 75 cm 68 - 94 cm
A2 Height of lower arm-
rests 46 - 70 cm 63 - 87 cm 79- 103 cm
BHandle spacing 22 - 36 cm 30 - 44 cm 38 - 52 cm
CSeat height 33 cm 45 cm 60 cm
DTotal width 56 cm 66 cm 73 cm
ETotal length 66 cm 75 cm 82 cm
Frame height (folded) 25 cm 32 cm 34 cm
Transport dimensions
(L x W x H) 66 x 56 x 25 cm 75 x 66 x 32 cm 82 x 73 x 34 cm
Max. load 30 kg 50 kg 70 kg
Weight 7,1 kg 8,3 kg 9,8 kg
C
E
A1
A2
B
D
5. Technical data.
