digi-tech DIGIVERB User manual

Warning
For your protection, please read the following:
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Do not use this apparatus near water.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
7. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
8. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
9. Unplug this apparatus during lightning storms or when
unused for long periods of time.
10. No user serviceable parts inside. Refer all servicing to
qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
11.WARNING:To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture.
12. Refer to labels on the unit, including bottom cover, or
other markings and pertinent information.
DECLARATION OF CONFORMITY
Manufacturer’s Name: DigiTech
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070, USA
declares that the product:
Product name: DigiVerb
Product option: all (requires Class II power
adapter that conforms to the
requirements of EN60065,
EN60742, or equivalent.)
conforms to the following Product Specifications:
Safety: IEC 60065 (1998)
EMC: EN 55013 (1990)
EN 55020 (1991)
Supplementary Information:
The product herewith complies with the requirements of the
Low Voltage Directive 72/23/EEC and the EMC Directive
89/336/EEC as amended by Directive 93/68/EEC.
Vice-President of Engineering
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Date:April 12, 2002
European Contact: Your local DigiTech Sales and
Service Office or
Harman Music Group
8760 South Sandy Parkway
Sandy, Utah
84070 USA
Ph: [phone]
Fax: [phone]

WARRANTY: We at DigiTech are proud of our products and back-up each one with the following warranty:
1.The warranty registration card must be mailed within ten days after purchase date to validate this war-
ranty.
2. DigiTech warrants this product, when used solely within the U.S., to be free from defects in materials
and workmanship under normal use and service.
3. DigiTech liability under this warranty is limited to repairing or replacing defective materials that show
evidence of defect, provided the product is returned to DigiTech WITH RETURN AUTHORIZATION,
where all parts and labor will be covered up to a period of one year (this warranty is extended to a
period of six years when the product has been properly registered by mail or through our website).
A Return Authorization number may be obtained from DigiTech by telephone.The company shall not
be liable for any consequential damage as a result of the product's use in any circuit or assembly.
4. Proof-of-purchase is considered to be the burden of the consumer.
5. DigiTech reserves the right to make changes in design, or make additions to, or improvements upon
this product without incurring any obligation to install the same on products previously manufactured.
6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tam-
pered with by anyone other than a certified DigiTech technician or, if the product is used with AC volt-
ages outside of the range suggested by the manufacturer.
7.The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor
authorizes any person to assume any obligation or liability in connection with the sale of this product.
In no event shall DigiTech or its dealers be liable for special or consequential damages or from any
delay in the performance of this warranty due to causes beyond their control.
NOTE:The information contained in this manual is subject to change at any time without notification. Some
information contained in this manual may also be inaccurate due to undocumented changes in the product or
operating system since this version of the manual was completed.The information contained in this version
of the owner's manual supersedes all previous versions.

The DigiVerb is a powerful studio quality reverb housed in a familiar
stompbox design. Seven high quality reverbs are easily accessed with the
twist of a knob.You can adjust decay, change EQ, and balance the level
for your particular application. You can even use the DigiVerb in an
auxiliary send whenever you need that extra reverb in the mix.
1. Level Knob
Controls the output level of the reverb effect. Turn this knob clockwise
to increase the output level, and counter-clockwise to decrease the
output level. When the Level knob is set to its maximum position, the
dry signal is completely removed so the DigiVerb can run in an effects
loop of a mixer.
2. EQ Knob
Controls the amount of high frequency boost or cut in the reverb signal.
Turn this knob clockwise to boost high frequencies, and counter-
clockwise to reduce high frequencies.

1
5
2 3 4
6
9
10
11
7
8

3.AC Adapter Jack
Connect a DigiTech PS200R power supply to this jack. Use the proper
supply for your area’s Mains line voltage.
4. Decay Knob
Controls the amount of reverb decay time. Turn the knob clockwise to
increase the decay time and counter-clockwise to decrease the decay
time.
5.Type Knob
Selects one of seven different studio quality reverb types including
Room, Plate, Hall, Church, Gated, Reverse, and Spring.
6. Input Jack
Connect your instrument to this jack. Connecting a guitar cable to this
jack supplies battery power even though the Indicator LED may not be
lit. To prolong battery life, disconnect all cables from the pedal when not
in use.

7. Pedal Release Pins
These two pins are spring-loaded hinges that hold the pedal in place.
Push these pins in to release the pedal from the pedal chassis exposing
the battery compartment. (See battery replacement diagram.)
8. Pedal
Press the pedal to turn the effect on and off.
9. Out 1(Mono) Jack
Connect this output to a single guitar amplifier when only one amp is
being used.
10. Indicator LED
This LED lights when the effect is turned on. If the LED becomes dim
or does not light when the cables are connected, the battery needs to
be replaced.
11. Out 2 Jack
Connect this output to a second amplifier for stereo reverb. Stereo is
the best way to get the most effective reverb experience from the
DigiVerb pedal.

Connections
The DigiVerb has a single input and a pair of outputs. Out 1 is used if
the DigiVerb is being connected to only one amplifier. Out 2 is used for
stereo operation. Connect Out 1 to amplifier 1 or the input of a mixer
channel and Out 2 to amplifier 2 or the input of another mixer channel.
The Digiverb can also be connected to the effects send/return of a
mixer. Connect the mixer’s effect send to the In (6) of the DigiVerb.
Connect Out 1 (9) and Out 2 (11) of the DigiVerb to the return(s) of
the mixer. Since the DigiVerb is an effect pedal, a line level signal from a
mixer can distort its input. Adjust the mixer’s effect send control to
reduce any distortion.
CIT™ Cabinet Modeling
The DigiVerb also has built-in CIT™ cabinet modeling. This is a useful
tool when running a distortion pedal into the DigiVerb and then running
direct into a mixer or recorder. CIT cabinet modeling creates a guitar-
through-an-amplifier sound without having to use a guitar amp.

To Enable CIT™ Cabinet Modeling:
Press the pedal down and apply power by connecting a guitar cable to
the DigiVerb input or connecting the PS200R power supply to the AC
adapter jack. CIT™ cabinet modeling has to be enabled each time you
apply power to the DigiVerb.
Battery Replacement
1. Using the tip of a 1/4” guitar cable, push one of the release pins in on
either side of the pedal, and remove the pedal from the pedal chassis.
2. Remove the battery from the battery compartment and disconnect
the battery cable.
3. Connect a new battery to the battery cable and put it back in the
battery compartment. Make sure the battery cable does not interfere
with the spring or pedal switch arm.
4. Place one hole of the pedal over its corresponding pin.
5. Push the opposite pin in and lower the other side of the pedal into
place over the depressed pin. Release the pin. When the pedal is
properly fastened, both release pins are flush with the outer side of
the pedal.

9V DC Battery
Pedal Release
Pin
Pedal Chassis
Pedal
Pedal Switch
Arm
Pedal Release
Pin
Battery
Compartment
Spring

DigiTech
8760 South Sandy Parkway
Sandy, Utah 84070
PH [phone]
FAX [phone]
DigiTech and X-Series are trademarks
of the Harman Music Group Inc.
Copyright - Harman Music Group
DigiVerb Digital Reverb
Owners Manual 18-1809V-A
Please visit DigiTech
on the World Wide Web at:
www.digitech.com
Printed in China
SPECIFICATIONS:
• Controls - Level, EQ, Decay,Type,
On/Off Pedal
• Jacks - Input, Out 1 (Mono), Out 2
• Input Impedance - 1 MOhms
• Output Impedance - 100 Ohms
• Power Supply - 9V Alkaline Dry Battery
• Power Consumption - 4.8Watts
(w/optional PS200R power supply)
• Battery Life - Approximately 4 hours
(with continuous usage)
• Dimensions - 4 15/16”(L) x 3 1/8”(W)
x 2 1/8”(H)
• Weight - 1.38 lbs.
• Optional Power Supply
PS200R - 100 (100V ~ 50/60Hz)
PS200R - 120 (120V ~ 60Hz)
PS200R - 230 (230V ~ 50Hz)
PS200R - 240 (240V ~ 50Hz)
