Digi-Wave ANT-5011 User manual

Product Features:
Technical Data:
1 2 34
Frequency Range: VHF87.5-230MHz, UHF470-862MHz
Antenna Gain: 40dB
Max.Output level: 100dBµV
Impedance: 75Ω
Noise Figure: ≤3.5dB
Power Supply: DC 12V 50mA
Remark: amplified
Fig.1 Fig.2
Using the screws to fix the antenna on the wall.
VERTICAL
Dig a hole on the eaves, and arrange
the cable into inner house
The back of antenna
Water-proof cap
U-shape cable arranging
prevents water from entering
HORIZONTAL
ANT-5011
Anti-UV coating and waterproof design.
Lightweight, compact size and easy to install.
For both analog and digital TV signal reception
Built-in high gain and low noise preamplifier
With dipole inbuilt for the excellent VHF & UHF band signal reception.
Specially Compatible with HDTV of various digital terrestrial signal
(DVB-T; ISDB-T; DMB-T/H; ATSC)
DIGITAL OUTDOOR TV ANTENNA
INTRODUCTION:
This is a special designed new concept antenna for digital outdoor analogue and terrestrial HDTV broadcasting reception. It is the best solution
for home reception and digital portable TV reception. Complete accessories are included for wall or pole mounting. With the anti-UV and water
proof housing.
Amplified version
HDTV
Compatible
ATSC
Compati bl e
5
Mounting the antenna:
T
(Fig.1) use the pole mounting accessories to fix the antenna on the pole.
(Fig.2) use the wall mounting accessories to fix the antenna on the wall
his antenna can be used outdoor with the included mounting accessories,it can be mounted on the wall or the pole.
F type connector
Pole fixing mast
Fixing screws
Wall instalation metal
Falling-proof installation hole
Receive TV signal from the
front side, please face it to
the signal tower.
Fixing direction nut
550mm
120mm
90mm
Included in Package:
Before start your installation,please check the contents.
1. Antenna main unit
2. Mounting accessories
3. AC/DC power adaptor
4. DC power insert
5. Water-proof kit

Out side
Ins ide
75Ω cable
(Fig.4) connect the “F” male connector of the coaxial cable to the “F” female connector of the antenna, and wear
the water-proof cap to the end of the connected “F” connector.
(Fig.3)
Fig.4
Note: After the antenna mounting and installation is finished,
Please take reference of following positioning way to adjust the antenna position.
(Fig.7) through the fixing screws to adjust the antenna position in left or right direction
(Fig.8)through turning the antenna body to adjust the antenna position in left or right direction
please adjust the antenna in the best position that can get clear TV
picture, then fix the antenna,organize the coaxial cable for neat, tidy and safety,
Fig.7
0
Turning left/right 45
Installation 1: Directly connected to TV(Fig.5) Installation 2: Connected Through set-top-box (Fig.6)
set-top box
Installation: Please take following (Fig.5) and (Fig.6) installation instruction for the reference.
Operation Instruction:
Note:For the best reception,Please check the following conditions
1. Keep the antenna away from the sources of interference: keep the
antenna away from those big power consumption devices,such as air
conditioner,elevator,hair dryer and microwave oven...ect.
2. Place the antenna near windows when use the antenna in indoor
environment.
3. Install the antenna as high as possible: in digital terrestrital
reception,if there are some interceptions between antenna and
transmission tower,it will cause the signal loss temporary. So if the
antenna is installed as possible, those interceptions will be reduced.
AC110V
AC110V
please face the antenna to the TV signal
transmitter tower direction
Using the pole mounting accessories to fix the antenna on the balcony.
Fig.8
Technical Support: [e-mail]; www.digiwave.ca
