Digiever DFS-4200-RM Series User manual

1
Failover Server
Quick Installation Guide
DFS-4200-RM Series
Version: 1.2.0.6
Information in this document is subject to change without notice.
© Copyright 2023, DIGIEVER Corporation. All rights reserved.

1
Table of Contents
Safety Notice ........................................................................................... 2
Pre-installation Notice ............................................................................. 3
Remote PC System Requirements ......................................................... 3
Package Contents .................................................................................. 5
Hardware Description ............................................................................. 6
Hard Disk Installation ............................................................................... 7
Connection to DIGIEVER Failover Server............................................... 8
Quick Configuration.............................................................................. 11
Appendix
LED Indicators on Front Panel .................................................................... 12
LED Indicators at Rear Panel...................................................................... 13

2
Quick Installation Guide
Thank you for choosing DIGIEVER products. The following quick guide will
lead you to complete the installation and configuration of the product.
Please read the following description carefully.
Safety Notice
The following safety precautions will increase the life of the product.
Follow all precautions and instructions.
Electrical Safety
Unplug this product from the power source before cleaning.
Use only the bundled power adapter. Using other power adapters may
damage your device.
Ensure that you plug the power adapter to the correct power input rating.
Check the label on the power adapter for the power rating.
Caution: Power cord(s) must be plugged into a socket-outlet with earthing
connection.
Operation Safety
DO NOT place this product in a location where it may get wet.
Place this product on a flat and stable surface.
Use this product in environments with an ambient temperature between
0°C and 45°C.
DO NOT block the air vents on the case of this product. Always provide
proper ventilation for this product.
DO NOT insert any object or spill liquid into the air vents. If you encounter
technical problems with this product, contact a qualified service technician
or your retailer. DO NOT attempt to repair this product yourself.
Caution: There is a risk of explosion if the battery is replaced with an incorrect
type. Dispose of used batteries appropriately.
Caution: Slide-rail-mounted equipment is not to be used as a shelf or a work
space.

3
Pre-installation Notice
Please make sure the following items are prepared for installing DIGIEVER
Failover Server.
Network connection
Computer for configuring the Failover Server
1-4 hard disks
Compatibility of hard disk with the Failover Server
1 slotted screwdriver and 1 Philips screwdriver
*For hard disk compatibility, please check our website
https://www.digiever.com/resource/Documents/CompatibleList/HDD/hdd_compatible
_list.php
Remote PC System Requirements
The following are minimum system requirements for a personal computer
to operate the Server in better performance:
Operating System
Microsoft®Windows®10/11
Browsers in Windows OS
Microsoft® Edge 44.18362.387.0 or above, Chrome 56.0.29 or above,
Firefox 51.0.1 or above, Opera 43.0.2 or above
CPU
Intel®i7 CPU or above
Network
Minimum 10/100/1000 Ethernet (Gigabit Ethernet is recommended)
Note: It is suggested to connect cameras and Failover Server with
Gigabit switch.
Memory
16G or above

4
Graphics Adapter
AGP or PCI-Express, minimum 1024 × 768, 16bit colors, 1G memory or
above
Note: It is highly recommended to use a graphics adaptor
which provides higher than resolutions 1024 x 768 in order to
experience the full benefits of the software.
Make sure the display DPI setting is set to default at 96DPI
To set DPI value, right-click on desktop, choose “Settings”
tab >> “Advanced” >> “General.”
CD-ROM Drive
It is necessary to read the operating instructions in the provided CD-
ROM.
Adobe Reader
It is necessary to read the operating instructions in the provided CD-
ROM. The audio function will not work if a sound card is not installed
in the PC. Audio may be interrupted depending on network traffic.

5
Package Contents
Failover Server
Power Cord
Ethernet Cable
Screw Bag
Product CD

6
Hardware Description
Front View Rear View
1. HDD LED indicator
2. Network LED indicator
3. Power LED indicator
4. One-touch backup button with LED indicator
5. 2 x USB3.2 Gen 1x1 (Front)
6. HDD 1
7. HDD 2
8. HDD 3
9. HDD 4
10. Reset button
11. Digital Input/Digital Output (4-in, 4-out)
(L) (R)
(L) Max24V, DI_GND, DI-4, DI-3, DI-2, DI-1, OCOM, DO4, DO3, DO2, DO1 (R)
12. 2 x 2.5 Gigabit LAN ports
13. 4 x USB 3.2 Gen 1x1 ports (Rear)
14. 2 x HDMI 2.0a outputs
15. Power connector

7
Hard Disk Installation
Please follow the steps as illustrated below to install the hardware:
Take out the disk tray from Server.
Connect the Ethernet cable to the
port of 2.5 Gigabit LAN.
Install the hard disk in each tray
and lock the disk with four
screws. Ensure the disk holes
match the holes at the base of
disk tray.
Connect the power cord to power
connector.
Insert the disk tray into the Server
and push it to the end.
Turn on the Server and there is a
beep to indicate the Server is in
booting process. Please wait for
minutes until the Server beeps
another time. The installation of the
Server is complete right now.

8
Connection to DIGIEVER Failover Server
Please insert the product CD-ROM on a PC to install NVR Search. Finally,
you can start Quick Configuration on a web page.
Install NVR Search for finding Failover Server in the network.
Connect to the configured Failover Server, download and install
NVR-Client.exe
Install NVR Search
Please execute the product CD and click “Install NVR Search.”
Follow the instructions to install and the NVR Search will run automatically.

9
Connect to the Failover Server
1. Connect to DIGIEVER Failover Server
After setting the NVR Search, the user can connect to the monitoring
page by the following two options:
1) NVR Search
Once you click “Connect”or double click the selected Server list,
the web browser will pop up automatically.
2) Web browser (Microsoft Edge, Chrome, Firefox, Opera)
Login to the system by entering its IP address in web browser.
Note: There are 2 methods to set network:
Obtain an IP address automatically (Failover Server
Default)
Obtain an available dynamic IP address assigned by a DHCP
server. If this option is selected, the Failover Server will
automatically obtain an available dynamic IP address from
the DHCP server once it connects to the network.
Specify an IP address
If there is no DHCP server existing in network environments, the
static IP address will be given as 192.168.1.245. It should be
adaptable in most networking environment, and user can
choose to maintain the default IP address or change it in this
page. However, it’s recommended setting different IP address
of the Failover Server if there is more than one Failover Server
in the same LAN.

10
2. Enter a user name and password
Log in the Failover Server with the default administrator account (user
name: admin, password: admin).
3. Download and install NVR-Client.exe, a software application, to
execute liveview monitoring and video playback.

11
Quick Configuration
After login, the system will direct you to set Quick Configuration in 5 steps.
Follow the instructions of the Overview of wizard to complete the system
setup.
Once the five steps of Quick Configuration are complete, you can go
Management > Failover section in configuration page to configure
Failover settings. For further details of Quick Configuration, please refer to
Failover User Manual.
After adding NVR to Failover Server, you have successfully installed the
DIGIEVER Failover Server. Congratulations!

12
Appendix
LED Indicators on Front Panel
LED
LED Color &
Status
Indicate
LAN
Off
LAN Link is not established
Orange
LAN Link is established
Orange
blinking
LAN is being accessed
HDD1
~
HDD4
Off
Hard disk drive device is not established
Green
1. Hard disk drive is ready to be accessed
2. Hard disk bad sector detected, but still
can be accessed.
Green blinking
Hard disk drive data is being accessed
Red
1. Hard disk failure and need to be
removed
2. Hard disk power-on hours have been
exceeded.
Power
Off
Power Off
Green
Power On
BACKUP
Off
USB device is not detected
Green
USB device is ready
Green blinking
Data is being copied to the USB device
(Blinking with 1Hz)
Orange
blinking
Backup error occurs

13
LED Indicators at Rear Panel
LED
LED Position
LED/State
Indicate
LAN1
LAN2
Link/Activity
(Right LED)
Off
LAN Link is not established
Yellow
LAN Link is established
Yellow Blinking
LAN activity is occurring
LAN1
LAN2
Speed
(Left LED)
Off
10Mbps connection or no
connection
Off
100Mbps connection
Green
1000Mbps connection
Orange
2500Mbps connection
Note:
USB BACKUP will start and beep after 3 seconds user presses BACKUP button.
To turn off Failover Server, user needs to press power button at least 2 seconds.
