Digiever SS-7000-RM User manual

Streaming Server
User Manual
1.0.0.3
Information in this document is subject to change without notice.
© Copyright 2021. All rights reserved.

i
Table of Contents
Chapter 1. Introduction ..............................................................................4
1.1 Hardware Description .................................................................................4
1.1.1 SS-7000-RM ...................................................................................... 4
1.2 LED Indicators Status....................................................................................5
1.2.1 SS-7000-RM ...................................................................................... 5
1.3 Mirror Display Solution: HDMI/VGA Connection .....................................7
Chapter 2. Streaming Server Installation..................................................8
2.1 Remote Client PC System Requirements..................................................8
2.2 Connect to Streaming Server...................................................................10
2.2.1 Quick Guide.................................................................................... 10
2.2.2 Install NVR Search ......................................................................... 10
2.2.3 Install Upgrade Tool....................................................................... 18
2.2.4 Install NVR Decoder....................................................................... 26
2.2.5 NVRPlayer....................................................................................... 29
2.2.6 Install NVR Check .......................................................................... 32
2.2.7 User Manual.................................................................................... 36
2.2.8 Browse CD...................................................................................... 36
2.2.9 Activate Live View Service ............................................................ 36
2.3 Quick Configuration..................................................................................38
2.3.1 Start................................................................................................. 38
2.3.2 Network Settings............................................................................ 39
2.3.3 Server Settings............................................................................... 40
2.3.4 Date & Time .................................................................................... 41
2.3.5 Camera Settings............................................................................. 43
2.3.6 Finish.............................................................................................. 51
Chapter 3. Use Streaming Server by Local Display...............................52
3.1 Log in System ............................................................................................. 52
1.1.1 Virtual Keyboard ............................................................................ 53

ii
3.2 Quick Configuration..................................................................................54
3.4.1 System Upgrade on Local Display................................................ 54
Chapter 4. Use Streaming Server by Remote Client..............................55
4.1 Liveview ......................................................................................................58
4.1.1 Select View Modes on Liveview Page........................................... 59
4.1.2 Main Functions for Liveview ......................................................... 60
4.1.3 Right Click Functions on Video Window...................................... 73
4.1.4 Zooming with Mouse scroll........................................................... 76
4.1.5 Two-way Audio............................................................................... 77
1.2 Multi-layer Dynamic E-Map ..................................................................... 78
1.2.1 Feature Introduction ...................................................................... 78
1.2.2 Add or Delete Multi-layer E-Maps.................................................. 80
1.2.3 Deploy Cameras............................................................................. 81
1.2.4 Double-click to Pop-out Video Window........................................ 83
1.2.5 Enable/ Disable Automatically Pop-up Event Window ................ 85
1.2.6 Event Log History .......................................................................... 86
1.3 Playback..................................................................................................... 87
1.3.1 Steps to Playback Videos.............................................................. 87
1.3.2 Time-divided Search...................................................................... 92
1.3.3 Smart Search.................................................................................. 93
1.3.4 Main Functions on Playback......................................................... 95
1.3.5 Data Search.................................................................................. 100
1.3.6 Zooming with Mouse scroll......................................................... 103
1.3.7 Export ........................................................................................... 104
Chapter 5. Configuration........................................................................110
5.1 IP Camera................................................................................................. 110
5.1.1 Camera Settings........................................................................... 110
5.1.2 Camera Parameter ....................................................................... 110
5.1.3 System/ Camera Status ............................................................... 114
5.2 Event.......................................................................................................... 115

iii
5.2.1 Event & Action Management....................................................... 115
5.2.2 E-Mail............................................................................................ 119
5.3 Network..................................................................................................... 121
5.5.1 Network Setup.............................................................................. 121
5.5.2 Network Service........................................................................... 127
5.4 Management ........................................................................................... 130
5.6.1 User Management........................................................................ 130
5.6.2 Log System................................................................................... 134
5.6.3 Save/Load Configuration............................................................. 137
5.6.4 UPS Management......................................................................... 138
5.5 System ....................................................................................................... 141
5.7.1 Device Information....................................................................... 141
5.7.2 System Upgrade........................................................................... 143
5.7.3 Language...................................................................................... 147
5.7.4 Date &Time................................................................................... 148
5.7.5 Buzzer/Digital Output................................................................... 149
5.7.6 Reboot & Shutdown..................................................................... 151
Appendix1: Notice and Warning....................................................................... 153

4
Chapter 1. Introduction
Before You Use This Product
When you first open the product’s package, verify that all the accessories listed on the
“Package Contents” of “Quick Installation Guide” are included. Before installing the
NVR, please read the instructions in the “Quick Installation Guide” to avoid misuse.
1.1Hardware Description
1.1.1 SS-7000-RM
Figure 1-1. Front & Rear View of SS-7000-RM
1. LED indicators: LAN
2. LED indicators: Backup
3. LED indicators: Power
4. Power button
5. Backup USB 2.0 x 1
6. USB 2.0 x 1
7. Gigabit LAN x 2
8. USB 2.0 x 4
9. eSATA x 2 (reserved)
10. VGA output
11. HDMI output
12. DI/DO (4 in 2 out)
Right to left: Vcc5V, GND, DI-1, DI-2, DI-3, DI-4, DO1, DO2
13. Reset button
14. Power Connector

5
1.2 LED Indicators Status
1.2.1 SS-7000-RM
Figure 2-7. Front View of SS-7000-RM & RJ-45 Port
LED on Front Panel
LED
LED Color & Status
Indicate
LAN
Off
LAN Link is not established
Orange
LAN Link is established
Orange blinking
LAN is being accessed
Power
Off
Power Off
Green
Power On
BACKUP
Off
USB device is not detected
Blue
USB device is ready
Blue blinking
NVR data is being copied to the USB device
(Blinking with 1Hz)
Red
Backup error occurs
LED on RJ-45 Connection at Rear Panel
LED
LED Position
LED/State
Indicate
LAN1
LAN2
Link/Activity
(Right LED)
Off
LAN Link is not established
Yellow
LAN Link is established
Yellow Blinking
LAN activity is occurring
LAN1
LAN2
Speed
(Left LED)
Off
10Mbps connection or no connection
Green
100Mbps connection
Orange
1000Mbps connection
*USB BACKUP will start and beep after 3 seconds user presses BACKUP button.
**To turn off Streaming Server, user needs to press power button at least 2 seconds.

6
Note: Once users press reset button, configuration of Camera Setting, Event &
Action Setting, E-Mail Settings, and Server Settings will reset to default. It is advised to
backup system configurations. For more information, refer to detail information in user
manual 5.6.3 Save/Load Configuration.

7
1.3 Mirror Display Solution: HDMI/VGA Connection
Streaming Server provides HDMI and VGA port for system configuration. Users can
connect both of HDMI and VGA at the same time for video output.
Mirror display scenario
Scenario A: If both monitors are Full HD (1920x1080), those will be shown as Full HD.
Scenario B: If both monitors are XGA (1024x768), those will be shown all as XGA.
Scenario C: If one of monitors is 1920x1080 and another is 1024x768, both monitors
are set as 1024x768

8
Chapter 2. Streaming Server Installation
2.1 Remote Client PC System Requirements
The following information is the minimum required specification for remote
Windows PC, which users can open a remote browser from the PC to access the
Streaming Server on the network.
Operating System
Microsoft® Windows® Vista /7 / 8 /10 (32-bit and 64-bit)
Browsers in Windows OS
Microsoft® Internet Explorer 10.0 or above, Microsoft® Edge 42.17134.1.0 or
above, Chrome 56.0.29 or above, Firefox 51.0.1 or above, Opera 43.0.2 or above
CPU
For channels under 16 : Intel® Dual core CPU 3.0 GHz or above.
For channels over 16 : Intel® i5/i7 CPU 3.3 GHz or above.
Network
Minimum 10/100 Ethernet (Gigabit Ethernet is recommended)
Note: * User is suggested to connect cameras and NVR with Gigabit switch.
Memory
For channels under 16: DDR3 4G or above.
For channels over 16: DDR3 8G or above
Graphics Adapter
AGP or PCI-Express, minimum 1024×768, 16 bit colors, 1G memory or above
Note: It is highly recommended to use a graphics adaptor which provides
higher than resolutions 1024 x 768 in order to experience the full benefits of
the software.
Make sure the display DPI setting is set to default at 96DPI
To set DPI value, right-click on desktop, choose “Settings” tab >>
“Advanced” >> “General.”
CD-ROM Drive
It is necessary to read the operating instructions in the provided CD-ROM.
Adobe Reader
It is necessary to read the operating instructions in the provided CD-ROM. The
audio function will not work if a sound card is not installed in the PC.
Note: Audio may be interrupted depending on network traffic.

9
Remote Computer Requirement to Enable DG-Decode
Powered by Intel GPU technology, Linux NVR server supports GPU hardware
acceleration decode for H.265 and H.264 IP camera on remote monitoring and
playback to reduce CPU utilization and enhance video fluidity to display multi-channel
high-resolution cameras.
Note: To display H.265 IP camera, please use 6th and above Generation Intel Core
processors.
To use hardware acceleration decode, please ensure Intel CPU supports Intel® Quick
Sync Video Technology.
You can check Intel website for CPU checking:
http://ark.intel.com/search/advanced?s=t&quicksyncvideo=true
Searching method: Processors > Intel® Quick Sync > Yes
Note: For quick search, you may use “Ctrl+F” to enter CPU name.

10
2.2 Connect to Streaming Server
To begin, please insert the product CD-ROM in a PC to access the Quick Guide, User
Manual and install the utilities. As user runs the product CD, the following menu is
displayed.
2.2.1 Quick Guide
Click “Quick Guide” to enter the folder and double click the file to
open. Please read Quick Guide to quickly understand the process of NVR installation.
2.2.2 Install NVR Search
Click “Install NVR Search” to find Streaming Server in the
network. Please follow the instructions to install and EZ Search will run
automatically.

11
When installing EZ Search, Shield Wizard window for EZ Search will pop up.
Click “Next” to continue installation.
Read the license agreement and click “I accept the terms of the license agreement”.
Click “Next” to continue installation.

12
Select a location of destination and select a folder where the setup can install files.
The default location is: C:\Program Files (x86)\NVR\NVR Search. Users can also
install EZ Search in other folder by clicking “Change” and select a location as below.
Click “OK” to save the setting.
Once a folder is selected, please click “OK” to continue installation.

13
The window shows that the InstallShield Wizard is installing NVR Search.
Please wait until the Wizard completes the installation.
The InstallShield has successfully installed NVR Search. Select “Create Desktop
Shortcut”/ “Create Quick Launch Shortcut”/ “Create Start Menu Shortcut”and
please click “Next” to continue.

14
The installation is complete. Please click “Launch application when done installing”
to execute NVR Search.
After finishing the setup, the window of NVR Search will pop up.
NVR Search will execute automatically and show NO., Name, IP Address, Mac
Address and Model name of connected NVR.
Users can click “Search” to search NVR.
You can click “Connect” or double click on one NVR; IE browser will pop up
automatically

15
Introduction of NVR Search
NVR Search provides three kinds of toolbars for users:
1. File
You can click “Exit” to leave NVR Search and close the window.
2. Setting
Configure UPnP and Network by clicking “Setting” in the top left or in the middle
right.

16
Note: Users will be prompted to enter the login information of NVR before
being allowed to change the setting.
When accessing the NVR setting, users will be prompted to enter username and
password. For the first-time use, the default username and password are
admin/admin. When the correct username and password have been entered, click
“Login” to continue.
1) UPnP
Universal Plug and Play (UPnP) simplifies the process of adding a NVR to a local
area network. Once connected to a LAN, NVR will automatically appear on the
internet. You can rename UPnP Name on the NVR. Click “OK” to finish the setting.

17
2) Network
NVR provides two network settings: DHCP and Static IP.

18
3. Option
Option provides users to change language.
2.2.3 Install Upgrade Tool
Click “Upgrade Tool” to upgrade several NVR to the latest
firmware version. Please follow the instructions to install and Upgrade Tool will run
automatically.
When installing Upgrade Tool, Shield Wizard window for Upgrade Tool will pop up.
Click “Next” to continue installation.

19
Read the license agreement and click “I accept the terms of the license agreement”.
Click “Next” to continue installation.
The window shows that the InstallShield Wizard is installing Upgrade Tool.
Please wait until the Wizard completes the installation.
