DigiFarm Ag Leader 6500 Reference guide

BN2001-13
rev 7
DigiFarm Technical Support
319.531.7574
[e-mail]
DigiFarm
Quick Reference Card
Ag Leader 6500, 7500 & Beacon
Ag Leader 6500 & 7500 Display Setup
1 Connect the Beacon and the adapter to the Port B
connection on the Ag Leader 6500/7500 cabling
Note: The null modem cable is not needed for Beacons
2 Connect the Power Tee to the Can B power/
terminator connection on the Display cable
3 Tap the Setup wrench icon, then the icon
4 From the GPS/Guidance setup screen, select the
wrench icon next to “Autodetect”
5 Ensure the Di󱐱erential source is set to “RTK external”

BN2001-13
rev 7
DigiFarm Technical Support
319.531.7574
[e-mail]
DigiFarm
Quick Reference Card
Ag Leader 6500, 7500 & Beacon
Android Quick Reference Card
iOS Quick Reference Card
Note: Not all android devices function the same; please try your device
before purchasing.
1 Pair the Beacon with android device
1 Pair the Beacon with the IOS device via the settings app
2 2 Download the DigiFarm
NTRIP Client app, open it,
and select the gear in the
top right corner
2 Download the
DigiFarm NTRIP Client
app, open it, and allow
notications
3 Select
receiver
settings,
then
receiver
connection
3 Conrm Beacon connection within the app; then select your
receiver type; & enter your username & password
4 Select
external via
Bluetooth,
then choose
Bluetooth
device
5 Check auto-enable Bluetooth box, then go back & select
NTRIP Settings
4 Tap the green Start button and allow location access, then
you will start streaming RTK data
6 Select Network protocol NTRIP
v1.0;
select your receiver type;
enter your DigiFarm username &
and password
7 Return to the app home screen
& tap Connect; the app will start
streaming RTK data
automatically
