Digilock Curve Keypad Basic User manual

INSTALL GUIDE
Keypad & RFID | Basic & Advanced
1
Deadlatch |Motorized Rear Deadbolt |Motorized Rear
Keypad
RFID

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
2
Wood Door Preparation
Required Components ����������������������������������������������������������������������������������������������������������������������������������������������������������3
Required Tools & Materials����������������������������������������������������������������������������������������������������������������������������������������������������3
Strike Installation Steps���������������������������������������������������������������������������������������������������������������������������������������������������������4
Wood Door Drill Instructions �������������������������������������������������������������������������������������������������������������������������������������������������5
Hole Mounting Template�������������������������������������������������������������������������������������������������������������������������������������������������������5
Metal Door Preparation
Compatibility Guide ��������������������������������������������������������������������������������������������������������������������������������������������������������������6
Required Tools & Materials����������������������������������������������������������������������������������������������������������������������������������������������������6
Removal of 3-hole Lock Plug �������������������������������������������������������������������������������������������������������������������������������������������������6
Removal of Padlock Hasp ������������������������������������������������������������������������������������������������������������������������������������������������������6
Nut Post - Cable Connector Installation
For door thickness measuring between 0�16” - 0�91” [4mm - 23mm]
Required Components ����������������������������������������������������������������������������������������������������������������������������������������������������������7
QR Code Sticker Placement ���������������������������������������������������������������������������������������������������������������������������������������������������7
Lock Installation Steps��������������������������������������������������������������������������������������������������������������������������������������������������������8-9
Lock Testing����������������������������������������������������������������������������������������������������������������������������������������������������������������������������9
Screw Post - Pin Connector Installation
For door thickness measuring between 0�01” - 0�16” [0�2mm - 4mm]
Required Components ��������������������������������������������������������������������������������������������������������������������������������������������������������10
QR Code Sticker Placement �������������������������������������������������������������������������������������������������������������������������������������������������10
Lock Installation Steps��������������������������������������������������������������������������������������������������������������������������������������������������� 11-12
Lock Testing��������������������������������������������������������������������������������������������������������������������������������������������������������������������������12
TABLE OF CONTENTS

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
3
Security Strike Plate
Recommended for latch products
Angled Strike Plate
General Purposes Use
Double-Door Strike Plate
Requires a base latch on strike door (Not included)
This section is for new installations with wood, MDF, or non-metal doors�
REQUIRED COMPONENTS
1 - Phillips Driver (#1)* 1 - Phillips Driver (#2)*
1 - Power Drill*
1 - Pencil*
1 - ¹/6" Wood Drill bit*
Removable Tape*
1 - ³/32" Wood Drill bit*
1 - Ruler*
1 - ³/4" Wood Drill bit*
Recommended Forstner Bit
Recommended 90º Square
Recommended Brad Point BitRecommended Brad Point Bit
Note: Mounting hardware requires a torque level of: 21.4 kgf/cm² ±20% for hand or powered tools to insure proper lock functionality.
WOOD DOOR PREPARATION
REQUIRED TOOLS & MATERIALS

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
4
Door Frame
0.32 in
[8mm]
Mark Here
Door Frame
Drill Pilot
Holes Here
Door Frame
0.32 in
(8 mm)
Door Frame
0.32 in
[8mm]
Mark Here
Door Frame
Door Frame
Shown below Angled Strike Plate
Position the strike plate on the door frame aligning it with the
center of the lock’s mounting holes.
" drill bit.
Adjust the strike plate to the proper position 0.32" [8 mm]
from the door edge then tighten the self tapping screws.
Insert and tighten the remaining self tapping screw into the
center opening to secure strike position.
Allow 0.32" [8 mm] from door edge and mark the position of
the adjustment slot holes.
Position the strike plate and the self tapping screws into the
adjustment slot holes. Do not tighten the screws.
1
3
5
2
4
6
STRIKE INSTALLATION STEPS

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
5
(a)
(b)
(b)
(a)
Drill x2
5/16" 0.3125in
[7.94 mm]
Drill 3/4"
0.75in [19mm]
Strike Center
(a)
(b)
0.31”
[7.94mm]
0.31”
[7.94mm]
0.75”
[19mm]
1.09”
[27.75mm]
1.09”
[27.75mm]
2.19”
[55.5mm]
CENTER LINE
CENTER LINE
ALIGN EDGE OF
STRIKE PLATE HERE
FOR LEFT
CLOSING DOOR
ALIGN EDGE OF
STRIKE PLATE HERE
FOR RIGHT
CLOSING DOOR
ALIGN EDGE OF
STRIKE PLATE HERE
FOR LEFT
CLOSING DOOR
ALIGN EDGE OF
STRIKE PLATE HERE
FOR RIGHT
CLOSING DOOR
0.92”
[23.4mm]
0.92”
[23.4mm]
Door Mounting Holes Drill Instruction and Template
With the door open place the Template over the locker frame.
(a) Align the edge of Strike Plate with the Strike Plate Marker.
(b) Center the Template to the center of the Strike Plate.
You may secure the Template with removable tape.
Close the door over the Template.
(a) Mark the door edge at the Template Center Line.
(b) Mark the Template with the edge of the door.
1 2
Place the Template on the front of the door.
(a) Align the drawn mark on the Template with the door edge.
(b) Center the Template with the mark on the door.
Secure the Template with removable tape.
Mark the center points of the door mounting holes on the
front of the door. Drill the holes according to the specified
dimensions.
3 4
Cut along the dashed lines for New Doors or Drawers
Before printing, turn off auto scaling or “Fit to Paper” in your printer setup and print at 100%
WOOD DOOR DRILLING INSTRUCTIONS
HOLE MOUNTING TEMPLATE

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
6
Digilock is compatible with a majority of 3-hole configuration, latch, and handle door types. Some doors may require modification to
clear obstructions.
Types of Metal Box Locker Doors
Single Point Latch HandleStandard Lift Box Locker Padlock Hasp
Hasp Removal Steps
Plug Removal
Close the door and mark the
area to cut the padlock hasp.
Open the door then cut the
padlock hasp on the marked
cut line.
Smooth out rough or sharp
edges.
1 3
1 2
2
Required Tools *Not Included
Hack Saw* Metal File* Screw Driver* Adjustable
Wrench*
See Hasp removal steps
METAL DOOR PREPARATION

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
7
For door thickness measuring between 0�16” - 0�91” [4mm - 23mm]
Required Components
Front Unit Rear Unit
RFID Standard BodyKeypad Standard Body Deadbolt - Cable Deadlatch - Cable
1*- Phillips Head Screwdriver (#2)2 - Split Lock Washers 2 - #10-24 Pan-Head Phillips Screws
D
C
B
A
Screw
Size Length
Door Thickness
Min Max
A 5/8" [15.875 mm] 0.01" [0.2 mm] 0.16" [4 mm]
B 7/8" [22.225 mm] 0.16" [4 mm] 0.43" [11 mm]
C 1 1/8" [28.575 mm] 0.43" [11 mm] 0.67" (17 mm]
D 1 3/8" [34.925 mm] 0.67" [17 mm] 0.91" [23 mm]
* Not Included
Note: Mounting hardware requires a torque level of: 21.4 kgf/cm² ±20% for hand or powered tools to insure proper lock functionality.
For illustration, a keypad front unit with a bolt rear unit is shown�
Rear View Front View
1
With the rear unit behind the door, extend the ribbon cable through the doors center opening.
Cable Connector
Orientation
NUT POST - CABLE CONNECTOR INSTALLATION
LOCK INSTALLATION STEPS (1-6)

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
8
Front View
2 3
4 5
Rear View
ATTENTION: The rear-unit connector must be oriented with the red wire positioned on the top of the
ribbon cable (as highlighted in g-1). Improper connection may result in the lock to improperly function.
With the cable connector properly oriented. Insert the rear units
cable connector to the corresponding front units pin-connector
(as highlighted in fig-1).
The LED will flash red 3 times accompanied with a three-tone
beep, then followed by the LED flashing green 3 times.
Note: The audible/visual feedback may only indicate that the
metal pin's have made contact. It is necessary to further insure
that both connectors are properly seated and connected
(as highlighted in fig-2).
For illustration, a keypad front unit with a bolt rear unit is shown�
Insert the front units nut-post through the doors mounting holes.
Hold and align the rear-unit using the same mounting holes
Note: To avoid pinching of the ribbon cable a recessed pocket is
provided behind the rear unit.
Insert the screw with lock-washer through the mounting holes.
Tighten screws to the torque level of: 21.4 kgf/cm² ±20%
Note: Overtightening of the mounting hardware may result in
the lock to improperly function.
Use the screw chart
to select the proper
screw length for your
door thickness.
Rear View
6
Front View
Test the lock while the door is open to ensure that the bolt or latch is operating properly. Refer to the testing instructions below.
Once installation is complete, refer to the DigiLink Site Setup Guide to add locks.
fig-1 fig-2
LOCK INSTALLATION STEPS

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
9
RFID
CARD
RFID
CARD
To ensure functionality after installation, it is recommended that the lock is tested with the door open�
Repeat test with the door closed.
If ten rapid beeps are heard, the strike plate or door alignment may need adjustment to allow the lock to operate properly.
If the door does not lock when the bolt/latch is extended, the strike plate or lock position may need adjustment.
Press = ` to extend the bolt.
Press = ` again to retract the bolt.
Press = ` to retract the latch.
The latch will extend automatically.
Present any RFID card to reader to extend the bolt.
Present the same RFID card to reader again to retract the bolt.
Present any RFID card to reader to retract the latch.
The latch will extend automatically.
For touch-free RFID locks with deadbolt rear units:
For touch-free RFID locks with deadlatch rear units:For keypad locks with deadlatch rear units:
For keypad locks with deadbolt rear units:
LOCK TESTING INSTRUCTIONS

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
10
For door thickness measuring between 0�01” - 0�16” [0�2mm - 4mm]
2 - Locking Nuts 1*- Deep Socket Nut Driver [3/8”]
* Not Included
For illustration, a keypad front unit with a bolt rear unit is shown�
Note: Mounting hardware requires a torque level of: 21.4 kgf/cm² ±20% for hand or powered tools to insure proper lock functionality.
Required Components
Front Unit
RFID Standard BodyKeypad Standard Body
Rear Unit
Deadbolt - Pin Deadlatch - Pin
Rear View Front View
1
Insert the front unit screw posts through the doors mounting holes.
Cable Connector
Orientation
SCREW POST - PIN CONNECTOR INSTALLATION
LOCK INSTALLATION STEPS (1-4)

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
11
Rear View
Rear View
Front View
2
3
Front View
Insert the front unit screw posts through the doors mounting holes.
Hold the front unit against the front of the door. Use the rear unit mounting holes as a guide, then slide the front and rear units together.
Make sure the connector pins align properly with the connector.
If properly connected, a triple beep will be heard and the LED will flash three times.
For illustration, a keypad front unit with a bolt rear unit is shown�
Note: Mounting hardware requires a torque level of: 21.4 kgf/cm² ±20% for hand or powered tools to insure proper lock functionality.
Rear View
4
Front View
Make sure the connector pins align properly with the connector.
If properly connected, a triple beep will be heard and the LED will flash three times.
LOCK INSTALLATION STEPS

INSTALL GUIDE
Keypad & RFID |Basic & Advanced
12
To ensure functionality after installation, it is recommended that the lock is tested with the door open�
Repeat test with the door closed.
If ten rapid beeps are heard, the strike plate or door alignment may need adjustment to allow the lock to operate properly.
If the door does not lock when the bolt/latch is extended, the strike plate or lock position may need adjustment.
Press = ` to extend the bolt.
Press = ` again to retract the bolt.
Press = ` to retract the latch.
The latch will extend automatically.
Present any RFID card to reader to extend the bolt.
Present the same RFID card to reader again to retract the bolt.
Present any RFID card to reader to retract the latch.
The latch will extend automatically.
For touch-free RFID locks with deadbolt rear units:
For touch-free RFID locks with deadlatch rear units:For keypad locks with deadlatch rear units:
For keypad locks with deadbolt rear units:
LOCK TESTING INSTRUCTIONS

13
INSTALL GUIDE
Keypad & RFID | Basic & Advanced
IG-D6CA-KR-DEN
For inquiries regarding new products, please contact our sales department: 707 766 6000 | [email protected]
For replacement products, returns, or technical support, please contact our support department: 707 766 6000 | [email protected]
060722
LIMITED WARRANTY. Company warrants to the original purchaser of Product manufactured by Company to be free of defects in
material and workmanship, provided: (1) Company has been notified of such defects within two years of purchase date and been given
the opportunity of inspection by return of any alleged defective Product to Company, or its authorized distributor, free and clear of
liens, encumbrances, transportation prepaid, accompanied by the statement of defects and proof of purchase; and (2) Product has not
been subject to modification, abuse, misuse, mishandling, misapplication, neglect (including but not limited to improper maintenance),
accident, improper installation, alteration and/or modification (including but not limited to use of unauthorized parts or attachments),
disassembly, or adjustment or repair performed by anyone other than an authorized service personnel during such period; and (3) such
defect has not been caused by corrosion or ordinary wear and tear. This warranty does not cover batteries, normal wear and tear of
parts and/or damage resulting from any of the following: negligent use or misuse of product, use of improper voltage or current, and/
or use contrary to operating instructions. The exclusive remedy shall not be deemed to have failed of its essential purpose so long as
Company is willing and able to repair or replace non-conforming Product in the prescribed manner.
Unless the product is listed as IP55 rated or otherwise expressed by Company on the sales order acknowledgment, Product is not
designed or intended for exterior use or where exposed to moisture. Any use where Product is exposed to moisture is not covered by
any warranties and voids any warranties and any resulting damage caused by direct exterior exposure or moisture is at the Buyer’s own
risk.
The liability of Company for any breach of the foregoing warranty shall not extend to dismantling, installing or reinstalling, but shall be
limited to repairing or replacing said items, as Company’s option, within a reasonable time after receipt of written notice from Buyer,
within the period of time stipulated herein, of any such non-conforming Product, provided that (i) such notice is given immediately
upon the detection of such non-conformance and (ii) such notice is received within the time period stipulated herein. BUYER AND
COMPANY EXPRESSLY AGREE THAT THE BUYER’S SOLE AND EXCLUSIVE REMEDY AGAINST COMPANY SHALL BE FOR THE REPAIR
OR REPLACEMENT (AT COMPANY’S OPTION) OF NON-CONFORMING PRODUCT AS PROVIDED HEREIN.
COMPANY SPECIFICALLY DISCLAIMS ANY OTHER WARRANTIES, EXPRESS, IMPLIED, OR STATUTORY, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND THE IMPLIED WARRANTY OF
MERCHANTABILITY, AND COMPANY ALSO SPECIFICALLY DISCLAIMS ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES. IN NO EVENT SHALL COMPANY BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN
CONNECTION WITH THIS AGREEMENT (INCLUDING BUT NOT LIMITED TO BREACH OF ANY OBLIGATION IMPOSED ON COMPANY
HEREUNDER OR IN CONNECTION HEREWITH) OR THE USE, STORAGE, DISPOSAL OR HANDLING OF PRODUCT. Consequential
damages for purposes hereof shall include, without limitation, loss of use, income or profit, shutdown, slowdown or stoppage of any
production line or facility, or losses sustained as the result of injury (including death) to any person, or loss of or damage to property
(including without limitation property handled or processed by the use of Product). Buyer shall indemnify Company against all liability,
cost or expense which may be sustained by Company on account of any such loss, damage or injury.
Company will not evaluate warranted Product without Buyer obtaining a Return Merchandise Authorization (RMA) number from
Company. Such returns must be prominently marked with the RMA number and shipped prepaid.
Company makes no other warranty, and the warranty is limited to the duration of the expressed warranty period as set forth above
NOTE: Should Product be considered a consumer product as may be covered by the Magnusson Moss Federal Warranty Act, please be
advised that: (1) some states do not allow limitations on incidental consequential damages or how long an implied warranty lasts so that
the above limitations may not fully apply; (2) this warranty gives specific legal rights, and a buyer may also have other rights which may
vary from state to state.
LIMITATION OF LIABILITY. Company’s maximum liability for any damages resulting from or caused by Product, whether in contract, tort,
or otherwise, is limited to the purchase price of Product. In no event shall Company be liable for any consequential damages of any
nature arising from the sale or use of Product, whether in contract, tort or otherwise, by either use or purchase of Product, the user or
purchaser agrees to this limit on Company’s liability. Company is not responsible for any modification, addition or alteration to Product
by others.
Company reserves the right to make changes in designs and specifications or to make additions or improvements on its products
without notice and without incurring any obligation to incorporate them on products previously manufactured.
WARRANTY
CONTACT INFORMATION
This manual suits for next models
3
Table of contents
Other Digilock RFID System manuals
Popular RFID System manuals by other brands

Rockwell Automation
Rockwell Automation Allen-Bradley 58UHF user manual

Lyngsoe Systems
Lyngsoe Systems S21 user guide

Elatec
Elatec TCPConv Technical manual

Elatec
Elatec TWN4 MultiTech 2 HF manual

Transmitter Solutions
Transmitter Solutions Dolphin UHF-R1 user manual

Elatec
Elatec TWN4 MultiTech 2 HF user manual
