The camera provides high-quality images using PIXIM DPS(Digital Pixel System) 1/3" Wide
Dynamic Range Sensor.
Features:
High resolution and high performance 1/3" CMOS(PIXIM DPS) technology
Wide Dynamic Range(WDR)
Excellent picture quality
Minimal blooming
Zero smear
Built-in NTSC/PAL video encoder
540 lines(Color) of resolution
0.5 Lux(Color) @ F1.2 Sensitivity
C/CS, backfocus cam for easy adjustment
Upto 1/22,000sec electronic shutter at f/1.2
OSD (On Screen Display)
Auto white balance modes
Day & Night (Auto /off)
AGC (Auto Gain Control)
VIDEO OUT(BNC)
Internal/AC line lock
Compatible with Slide Switch
with 4-pin connector
Operates in 12VDC or 24VAC
Use Certified / Listed Class 2 power supply only.
video- or DC-type lenses with select
Quick connect for video or DC lens
INTRODUCTION
IMPORTANT : The user of this camera is responsible for
checking and complying with local, state, and federal laws
and statutes concerning the recording and monitoring of
audio signals.

- 2 -
CAMERA OVERVIEW
SIDE VIEW
1-32UNEF
56.0mm
66.0mm
7.0mm
FRONT VIEW
120.0mm
TOP VIEW
14.0mm 43.0mm
1/4-20UNC
REAR VIEW
1
2
3
4
5
6
7
Left Button
Up Button
Enter Button
Right Button
Down Button
Power Indicator
Video Out Connector (BNC)
AC /DC Compatible Input Terminal
DC or VIDEO Lens Select Switch
8
9
9
7
4
2
3
1
5
8
6

- 3 -
Installation of the camera must be performed by qualified service personnel in accordance
with all local and national electrical and mechanical codes.
Carefully remove the color camera and its accessories from the carton
and verify that they were not damaged in shipment.
The contents of the package includes:
1. Color camera
2. Mini-DIN connector (for video-or dc-type auto-iris lens)
3. CS adapter ring for C mounting “C” lenses
4. This manual
CONTENTS OF PACKAGE

- 4 -
CAMERA SETUP
PRESETS
NORMAL
INDOOR
OUTDOOR
WD NORMAL
AGC LOW
NORMAL
HIGH
WHITE BALANCE
ATW Normal
ATW Xtnd
AWB
SYNC
INTERNAL
LINELOCK
AUTO
OFF
D/N CONTROL
SAVE. EXIT. CANCEL
PUSH AWB CONFIRM
> Save AWB & ALL Chngs.
CANCEL
''' WARNING '''
will
ALL User
be written to ROM
properties
LINELOCK MENU
V PHASE
DAY/NIGHT THRESHOLD SETUP
IN
OUT

- 5 -
CAMERA ADJUSTMENT
<SETTINGS>
Setting can be made using the 5 buttons located on the back of the camera.
<CAMERA SETUP>
1) PRESETS
1) The CAMERA SETUP is displayed on the monitor when press and hold
the ENTER button for more than 1 second.
2) Press the UP and DOWN buttons in the vertical direction and move the cursor(>)
to the desired submenu.
3) ".." indicated submenus.
- NORMAL
- WD NORMAL Standard video with Wide Dynamic Range Limit Max
- INDOOR To brighten the video taken indoors
Standard video
Auto Gain Control selected (LOW / NORMAL / HIGH)
2) AGC
- DEFAULT
Standard video
- INDOOR
To brighten the video taken indoors
- OUTDOOR
3) WHITE BALANCE
hite balance is automatically followed up
- A T W Normal W
(Limits the range of auto tracking by the value of two properties).
When shooting in a bright area outdoors
W
- ATW Xtnd hite balance is automatically followed up.
- AWB One-push automatic white balance control.
Shoot a target white subject and press the ENTER button,
and the white balance will be adjusted.
4) SYNC
- OUTDOOR When shooting in a bright area outdoors
- INTERNAL This mode is necessary for using the internal synchronization.
- LINELOCK This mode is necessary for the operation of multi camera because
it synchronizes the camera phase by using the external signal
(AC Signal).
5) D/N CONTROL
- AUTO This camera has a function which automatically changes to
the appropriate mode for daytime or night-time.
- OFF In this mode, the camera outputs the video image only in color.

CONNECTIONS
- 6 -
CLASS 2
+ DC 12V -
~ AC 24V ~
This terminal accepts a DC12V or AC24V power
source from a DC12V or AC24V ac +/-10% 60/50Hz +/- 1Hz.
Use Certified/Listed Class 2 power supply only.
In DC power, use the Adapter mode than DC 12V
500mA Capacity.
1) POWER INPUT TERMINAL
2) VIDEO OUT CONNECTOR
BNC : This BNC connector provides a 1.0Vp-p/75 ohms composite video Signal.

The lens is not supplied with this camera. Purchase a lens suitable for your environment.
This camera accepts the auto iris lens and both C-and CS-mount lens.
Pin 3
Pin 1
Pin 4
Pin 2
Rib Connector
Cover
Iris Control
Cable
Connector
Automatic
Iris Lens
Heat
Shrinkable
Tubes
2. Remove the protective cap, and attach the lens to the camera by turning clockwise.
- 7 -
LENS
For using main functions it is recommended to use Auto Iris Lens with DC type.
If the lens is marked with fingerprints other marks, the image quality might be poor.
It is recommended to use a high quality lens to improve the image quality under
low illumination.
<INSTALLING AUTO IRIS LENS>
1. Remove the cover from the iris lens plug supplied, and solder the lens cable to the plug as
shown below.
Video type :
Pin 1 --- Red (Power source)
Pin 2 --- N.C
Pin 3 --- White (Video signal)
Pin 4 --- Black (GND)
DC type :
Pin 1 --- Damping-
Pin 2 --- Damping+
Pin 3 --- Drive+
Pin 4 --- Drive-
* Notes *

SPECIFICATIONS
50302661A
WDR Super High Resolution
Color Camera
PRINTED IN KOREA
2-Pin terminal block
0.5 Lux @ F1.2
PRESETS / WD Normal
Default / Indoor / Outdoor
ATW Normal / ATW Xtnd / AWB
Normal /
Lens mount
1/4''-20 UNC (top or bottom)
66 (W) x 56 (H) x 120 (D)mm
250g
4-Pin mini din jack (standard connection)
C/CS mount (Selected through back focus)
Mounting hole
External dimension
Weight
Video output
Auto iris output
Operating temperature
Operating humidity
BNC Connector
0 ~ 96% (non-condencing)
C
O
N
N
E
C
T
O
R
&
ETC.
-10 C ~ +50 C
3.0 Watts
