Digistar SW3300 Operating instructions

D3746-US Rev D JANUARY 28, 2011
STOCK WEIGH
SCALE HARDWARE
MODEL SW3300
MODEL SW6600
MODEL SW10,000
MODEL SW14,000
INSTALLATION AND OPERATION
GUIDE
Ft. Atkinson, Wisconsin USA
Panningen, The Netherlands
www.digi-star.com

SW Scale & Hardware
2 D3746
TABLE OF CONTENTS
INTRODUCTION....................................................................... 3
PRODUCT CHANGES AND IMPROVEMENTS........................ 3
STOCK WEIGH SCALE COMPONENTS:................................. 4
STOCKWEIGH SPECIFICATIONS ........................................... 9
LOAD CELL DIMENSIONS ....................................................... 9
Model 3300 ............................................................................ 9
Model 6600 .......................................................................... 10
Model 10,000 Hybrid............................................................ 11
Model 10,000 ....................................................................... 11
Model 14,000 Hybrid............................................................ 12
Model 14,000 ....................................................................... 12
SW Platform – Wrangler – 90” ............................................. 13
SW Platform – Wrangler Jr. – 54” ........................................ 14
INSTALLATION....................................................................... 15
10K/14K Load Cells ............................................................. 15
J-box Installation.................................................................. 17
Wrangler JR Deck Assembly ............................................... 18
MAINTENANCE ...................................................................... 19
TROUBLESHOOTING GUIDE ................................................ 20
TYPICAL WOOD PLATFORM CONSTRUCTION................... 23
Model 3300 (3300 LB [1500 KG] Gross Capacity)............... 23
Model 6600 (6600 LB [3000 KG] Gross Capacity)............... 24
REPAIR PARTS ...................................................................... 25
STOCK WEIGH 3300 .......................................................... 26
STOCK WEIGH 6600 .......................................................... 27
Stock Weigh – 10,000 LBS .................................................. 29
Stock Weigh – 14,000 LBS .................................................. 30
J-Box Repair Parts............................................................... 31
J-Box Repair Parts............................................................... 32
Wedge Mount....................................................................... 33
WIRING DIAGRAM - LOAD CELL CONNECTOR................... 33

Installation & Operation
D3746 3
INTRODUCTION
Congratulations on your purchase of a Digi-Star Stock Weigh
scale system which is the simplest and most reliable animal
weighing system on the market today. Due to the large number of
load cell capacity options, Stock Weigh scale systems can be
customized to fit your animal weighing needs. The indicator Auto-
Lock feature allows scale to weigh active and restless animals
within ±1% of actual weight. This manual will cover load cell and
other hardware options available in Stock Weigh system. The
load cells option available include following: SW3300 (3300 lbs
capacity), SW6600 (6600 lbs Capacity), SW10K (10,000 lbs
capacity), SW14K (14,000 lbs capacity).
PRODUCT CHANGES AND IMPROVEMENTS
We reserve the right to make changes in design, to add
improvements to or otherwise modify our electronic scale
products without incurring an obligation on goods previously
purchased and to discontinue supplying any parts listed when the
demand does not warrant production.

SW Scale & Hardware
4 D3746
STOCK WEIGH SCALE COMPONENTS:
KEY 1 - INDICATORS
A B C D E
KEY PART NUMBER DESCRIPTION
A SW300 BATTERY OPERATED
404914 SW300 SCALE W/ 2 LOAD CELL
CONNECTOR & WEDGE MOUNT
404915 SW300 SCALE FOR 2 BARE LEAD LOAD
CELL CABLES & WEDGE MOUNT
405408 SW300 SCALE FOR 4 BARE LEAD LOAD
CELL CABLES & WEDGE MOUNT
B 403778 SW600 SCALE
C 404588 SW2600 SCALE
D 404589 SW4600EID SCALE
E 405147 HORIZON XL
405148 HORIZON XLS
405149 HORIZON XLT
Typical Enclosure
Not Included

Installation & Operation
D3746 5
KEY 2 - INDICATOR MOUNTING – FOR SW300 & SW600
SHIPPED WITH WEDGE MOUNT AS STANDARD
RAIL MOUNT WING MOUNT WEDGE MOUNT
STANDARD
KEY PART NUMBER DESCRIPTION
A 403769 BRACKET – STR TOP MOUNT
B 403980 BRACKET – ROBO MOUNTING
C 403770 BRACKET – WING MOUNT
D 405069 U-BOLT, ¼-20 X 3.25 ZP
E 403771 MODIFIED PLASTIC WEDGE MOUNT
F 405124 PACK – WEDGE MOUNT BRACKET,
INCLUDES U-BOLTS & NUTS
G 405084 NUT, ¼-20 TOP LOCKING FLANGE
KEY 2 - OPTIONAL RAM MOUNTING BRACKET OPTIONS
FOR SW300 & SW600
RAM MOUNT
STANDARD U-BOLT BASE TWIST LOCK SUCTION CUP
KEY PART NUMBER DESCRIPTION
A 403180 RAM MOUNT
B 403179 MOUNT BASE-1" BALL U-BOLT
C 404230 RAM SUCTION CUP W/TWIST LOCK

SW Scale & Hardware
6 D3746
KEY 2 - INDICATOR MOUNTING – FOR EZ2600 & EZ4600EID
SHIPPED WITH WEDGE MOUNT AS STANDARD
RAIL MOUNT WING MOUNT WEDGE MOUNT
(STANDARD)
KEY PART NUMBER DESCRIPTION
A 404353 BRACKET-EZ3 PLASTIC RAIL
B 403780 SCR-#10 X 5/8 FHSTS BLACK ZP
C 840459 SUPPORT-HAT BRACKET
D 405069 U-BOLT 1/4-20 X 3.25 ZP
E 405084 NUT-1/4-20 TOP LOCKING FLANGE
F 403770 BRACKET- WING MOUNT
G 405124 PACK-WEDGE MOUNT BRACKET WITH U-
BOLTS & FLANGE NUTS
H 405052 BRACKET-MODIFIED WEDGE MOUNT
(FACTORY INSTALLED)
405244 PACK-EZ3 WEDGE MOUNT (FIELD INSTALLED)
KEY 2 - OPTIONAL RAM MOUNTING BRACKET OPTIONS
EZ2600 & EZ4600EID
KEY PART NUMBER DESCRIPTION
A 404799 PACK-RAM 1.5 DIA KIT FOR EZ3 INIDICATOR
WITH MOUNTING HARDWARE
B 404230 RAM MOUNT SUCTION CUP WITH TWIST LOCK
C 406981 MOUNT – 1.5 RAM WITH U-BOLT

Installation & Operation
D3746 7
KEY 3 - POWER SUPPLY OPTIONS –
BOTH SUPPLIED W/ ALL INDICATORS
KEY PART NUMBER DESCRIPTION
A 404777 BATTERY CLIP ADAPTER, 9’ LONG
B 148156 WALL OUTLET, 12VDC OUTLET, 5’6”
LONG
C1 406507 AC/DC CONVERTER (NOT
ILLUSTRATED) “SW300 ONLY”
C2 406508 AC PLUG (NOT ILLUSTRATED) “SW300
ONLY”
KEY 4 - PLATFORM OPTIONS
KEY PART NUMBER DESCRIPTION
A 403360 STOCK WEIGH ALLEY PLATFORM
B 405043 WRANGLER JR PLATFORM –
INCLUDES INDICATOR STAND &
RAM MOUNT

SW Scale & Hardware
8 D3746
KEY 5 - LOAD CELL OPTIONS
KEY PART
NUMBER DESCRIPTION
A 405536 PACK 10K MOUNT FOR QTY 1 MNT (W/O
LOAD CELL)
B 405537 PACK 14K MOUNT FOR QTY 1 MNT (W/O
LOAD CELL)
KEY PART
NUMBER DESCRIPTION
A
148042
406700
146769
405105
400144
407015
MODEL SW3300
16”
16” W/ CABLE GUARD
24”
24” W/ CABLE GUARD
33.5”
33.5” W/ CABLE GUARD
B
400058
407025
400006
407022
MODEL SW6600
33.5”
33.5” W/ CABLE GUARD
44”
44” W/ CABLE GUARD
C
403441
407032
MODEL SW6600
PAIRED VERSION 16”
PAIRED VERSION 16” W/ CABLE GUARD

Installation & Operation
D3746 9
STOCKWEIGH SPECIFICATIONS
Gross Capacity
Model 3300: 3300 lbs. Max
Model 6600: 6600 lbs. Max
Model 10000 10,000 lbs. Max
Model 14000 14,000 lbs Max
Accuracy : ±1% and ±1Display
Increment
Load Cell Cable Length : 14 Feet
Resolution (For Both Models)
Increment Range
1 lbs or kgs 0-300 lbs or kgs
2 lbs or kgs 300-600 lbs or kgs
5 lbs or kgs 600 lbs or kgs
Power Requirements : 12-14 VDC @
approx 1 Amp (SW300-2-AA Batteries)
AC to DC Converter
110 VAC to 13.8VDC @ 1.2 Amps
LOAD CELL DIMENSIONS
MODEL 3300
SW3300 A B C D E F G H
406700/
148042
16" 16" 12.19" N/A
7.75" 8.25" 7.25" 15.5"
.625" X 1.0"
SLOT
405105/
146769
24" 23.5" 19.69" 17.19" 11.5"
8.25" 7.25" 23" .562" X 1.0"
SLOT
407015/
400144
33.5" 32.5" 28.75" 23.5"
N/A 8.25" 7.25" 33.5"
.562" X 1.0"
SLOT

SW Scale & Hardware
10 D3746
MODEL 6600
SW6600 A B C D E
407025/
400058
33.5” 33.31” 29.5" 28.75” 32.5" 33.5"
407022/
400006
44" 43.81" 40.0" N/A 43.0" 44.0"

Installation & Operation
D3746 11
MODEL 10,000 HYBRID
(BEFORE JUNE 2009)
MODEL 10,000

SW Scale & Hardware
12 D3746
MODEL 14,000 HYBRID
(BEFORE FEBRUARY 2009)
MODEL 14,000

Installation & Operation
D3746 13
SW PLATFORM – WRANGLER – 90”

SW Scale & Hardware
14 D3746
SW PLATFORM – WRANGLER JR. – 54”

Installation & Operation
D3746 15
INSTALLATION
10K/14K LOAD CELLS
10K Mount 14K Mount

SW Scale & Hardware
16 D3746
Install all load cells either widthways across the chute or
lengthways parallel to the chute.
Align load cells so centerlines are lined up (or within ½” (12mm)
of each other)
All load cells must be installed in the same direction so that
weight is distributed evenly.
Each corner of the chute must be level for accurate weighing.
This ensures that the load distributed equally.
IMPORTANT: Do Not weld to load cells with load cell cables
connected to the indicator. If you must weld with load cells
connected, locate welder ground so that current will not flow
through the load cell.

Installation & Operation
D3746 17
J-BOX INSTALLATION
[Lever-Nut Version]
IMPORTANT: Do Not weld to load cells with load cell cables
connected to the indicator. If you must weld with load cells
connected, locate welder ground so that current will not flow
through the load cell.
Decal – Lever Nut Wiring Instructions
Tighten nuts
Load cell cable
See Decal Above For
Wiring Instructions
J-Box Power Cable
Connect to Indicator
bottom panel.

SW Scale & Hardware
18 D3746
WRANGLER JR DECK ASSEMBLY
Figure 1. Load Cell Cable
To Channel
Figure 2. Cable Through Channel
Figure 3. Cable Up From Channel
To Support
Figure 4. Cable Through Support
To Indicator
Push up through slot
in plate at bottom
of channel
Cable must come out of load cell
the same side as the support.
Push cable toward the
end with support.
When both cables are in
channel, pull through the
hole under the su
pp
ort.
Weave cable
through holes
in support as
shown.
Connect
Cables to
Indicator

Installation & Operation
D3746 19
Assemble load cells to deck as shown on page 25. Make sure
both load cell cables come out the same side as the indicator
support and the cable plate (located under one of the side
channels).
Assemble indicator support, 1” ram mount and handle/wheels
option as shown on page 25. The ram mount should be mounted
on the channel support side which has the cable plate.
Load cell cable routing: Loosen cable retainer plate and push the
plate outward. Begin by taking the two cable load cell connectors
and feed them through the 1.5” diameter hole from the bottom
toward the indicator support, Figure 3. Weave the load cell cable
through the support arm toward the indicator, Figure 4. Attach the
load cell connector to the indicator and pull any excess cable
back down toward the deck.
At each load cell, push the cable through the retaining plate slot,
Figure 1 and Figure 2. All extra cable is tucked inside the deck
channel. When complete, push the cable retaining plate toward
the deck to close off the channel. Tighten the three ¼” bolts to
hold the retaining plate in position.
MAINTENANCE
There are no moving parts and no lubrication required. The only
maintenance required is periodic cleaning of the mounts and the
area below the scale to assure free and unencumbered operation
of the scale. If a pressure washer is being used, do not spray or
direct high pressure stream at the load cells. Load cell damage
may occur.
Stand over each of the 4 corners to troubleshoot for problems.
Corners should weigh the same within ± 1% maximum error.

SW Scale & Hardware
20 D3746
TROUBLESHOOTING GUIDE
STOCK WEIGH 3300, 6600, 10K, 14K WITHOUT J-BOX
START
YES NO
Does the indicator come on?
The other load cell is defective.
Check its cables for cuts or flattened
areas or send it back for repair.
Does the Indicator respond when you
step on the scale?
YES
Does the scale weigh you
close to your weight?
YES
Check for debris around
and under the platform and
load cells. Check for
warped or damaged
mounts on platform.
Check for debris
around and under the
scale mounts or
platform. Check the
load cell cables for
cuts and flattened
areas.
NO
Disconnect one of the load cells and stand over
the connected load cell. Does the indicator
display a reading about twice your weight?
NO
Check for 12 VCD at the AC/DC convertor power cord. If you
do not have a multimeter, use a car battery to power the
scale. If the Indicator still does not come on, send in for repair.
The other load cell is
defective. Check its cable
for cuts or flattened areas or
send it back for repair.
Check the defective load
cell by connecting it to the
Indicator and verifying that it
does not weigh.
YES
NO
Disconnect the first load cell and
connect the other load cell to the
same connector on the Indicator.
Does the Indicator display a
reading about half your weight?
Disconnect the load cell cable from the
Indicator. Press the Indicator “TARE” key.
(The Indicator display should go to zero).
Stand on the load cell. Does it display a
reading about twice your weight?
NO
This Load Cell is OK.
Disconnect the first load cell
and connect the other load
cell to the same connector.
Now stand over the second
load cell. Does it weigh twice
your weight?
Disconnect the first load cell
and connect the other load cell
to the same connector. Now
stand over the second load cell.
Does it weigh twice your
weight?
YES
NO
One of the Load Cells is Bad. A
good load cell will weigh you at
about twice your weight with only
one load cell connected.
Perform the paper test. Take two paper clips and
carefully insert one into pin 2 and the other into
pin 3 of either load cell connector jack on the
Indicator. Hold one paper clip in each hand (if
they touch it will not damage the Indicator). Does
the reading on the Indicator jump around?
Both load cells are defective.
The Indicator is probably
OK. Check the cables for
damage and send both load
cells in for repair.
NO
YES
The Indicator is defective. Send it in for
repair. Note: Load cells may also be
defective. Check the load cells by
attaching to a good work in Indicator.
YES NO
The load cell is defective.
Check its cables for cuts or
flattened areas or send it back
for repair. Check indicator
using a known good load cell.
Connect the load cell to the
other connector on the
Indicator. Stand on the load
cell. Does it display about twice
your weight?
YES
Check the platform
for debris and mud
interference. Check
mounts for binding
and obstructions.
YES
NO
YES
The other load
cell is defective.
Check its cables
for cuts or
flattened areas
or send it back
for repair.
Connect both load cells (one at a time)
to the other connector on the Indicator.
Do both load cells weigh you about
twice your weight?
NO YES
The Indicator is defective.
Verify this by substituting a
good working Indicator.
Do both load cells weigh you
about the same but not within
20% of twice your weight?
NO
YES
NO
