BRIEF PROGRAMMING MANUAL EZ 3200/EZ3200V WEIGHING SCALE
24-4-2003 Art. Nr. A5910660 - GB Page 1/2
1GETTING STARTED
1.1 Press On. A brief message is displayed (such as HELLO). The scale then enters the gross weighing mode.
2TO ZERO BALANCE THE SCALE (only with empty machine)
2.1 Press Net/Gross and then, immediately press Zero. Zero is displayed briefly to show that the zero balance
has been set. If 0appears, the zero has been correctly set. If not, repeat procedure.
3TO CHANGE THE LANGUAGE
3.1 Enter 101 using the numerical keypad.
3.2 Press Select. The current language appears on the display.
3.3 Press Select until the required language is displayed.
3.4 Press On to confirm the selected language.
4TO CHANGE THE ENTRY METHOD
4.1 Enter 441 using the numerical keypad
4.2 Press Select. E-MTHD is displayed followed by the number 1, 2 or 3
(1: Amount per Animal in [kg], 2: Percent [%] per Load, 3: Amount per Load in [kg])
4.3 Press Select until the required entry mode is displayed.
4.4 Press On to confirm the selected entry mode.
5TO CHANGE THE TOLERANCE (ALARM)
5.1 Enter 442 using the numerical keypad
5.2 Press Select. TOLER... is displayed and a value between 0,5% and 10%, or off.
5.3 Press Select until required value (e.g. 5%) is displayed.
5.4 Press On to confirm the selected setting.
6TO RENAME INGREDIENTS
6.1 Press and hold Ingr/Accum and then press On. The scale displays progrm, followed by the first ingredient:
ingr 01.
6.2 Press Ingr/Accum until the required ingredient number is displayed. If the display already shows the
correct number, proceed with step 6.3.
6.3 Press On. The ingredient name concerned is displayed.
6.4 Press Clear to delete the name gradually or press and hold Clear to delete the entire name.
6.5 Enter a new ingredient name (max. 6 digits) using the numerical keypad. Each key contains 4 different
characters.
6.6 Press On to confirm the new name . The following ingredient number will appear on the display.
6.7 Repeat steps 6.2 thru 6.6 until the required changes have been made.
6.8 Press Net/Gross to return to the normal weighing mode.
7TO PROGRAM A NEW RECIPE
! First select the required entry method (steps 4.1 thru 4.4)
7.1 Press and hold Recipe and then press On.The scale displays progrm, followed by the first recipe: rec 01,
or rec- _ _ if you have not programmed any recipes.
7.2 Press Recipe until rec- _ _is displayed.
7.3 Enter the required recipe number (e.g. 01:) using the numerical keypad.
7.4 Press Recipe to confirm the entered recipe number. A running text shows the chosen entry method. Then
ingr- _ _ is displayed.
7.5 Enter the required ingredient number (e.g. 01:) using the numerical keypad.
7.6 Press Ingr/Accum. The entered ingredient number with name is briefly displayed, followed by e.g. 01: _
_.00; the first number is the recipe number.
7.7 Enter the required ingredient amount using the numerical keypad.
7.8 Press Load/Unload to confirm this amount. The scale will then display LOADED to indicate that the
ingredient has been saved in the weigher's permanent memory, followed by ingr- _ _.
7.9 Repeat steps 7.5 thru 7.8 until all recipes have been entered.
7.10 Press Net/Gross to exit the recipe entry mode and enter weighing modes.
8TO EDIT A RECIPE (only edit ingredient amount, do not add any ingredients!)
! If you want to add ingredients, the recipe must be deleted (steps 9.1 thru 9.5)
8.1 Press and hold Recipe and then press On. The scale displays progrm.
8.2 Press Recipe until the recipe to be changed is displayed.
8.3 Press Ingr/Accum until the ingredient to be changed is displayed.
8.4 Press Clear to delete the amount and enter the new quantity using the numerical keypad.
8.5 Press Load/Unload to confirm this amount. The scale briefly displays LOADED.
8.6 Repeat steps 8.3 thru 8.5 until all ingredients are edited. The scale displays TOTAL directly followed by rec- _
_to edit another recipe.
8.7 Press Net/Gross to exit the recipe programming mode.

BRIEF PROGRAMMING MANUAL EZ 3200/EZ3200V WEIGHING SCALE
24-4-2003 Art. Nr. A5910660 - GB Page 2/2
9TO DELETE A RECIPE (completely delete a programmed recipe)
9.1 Press and hold Recipe and then press On. The scale displays progrm.
9.2 Press Recipe until the recipe to be deleted is displayed.
9.3 Press and hold Zero and then press On to delete this recipe. A running text with instructions shows that
the old recipe can be printed.
9.4 Press Zero to delete this recipe. The scale displays recipe erased, followed by the next recipe.
9.5 Repeat steps 9.2 thru 9.4 until all recipes have been deleted.
9.6 Press Net/Gross to return to normal weighing mode.
2
10 TO LOAD A BATCH USING A RECIPE
10.1 Press Recipe until the required recipe number is displayed.
10.2 Press Load/Unload. The scale displays the number of animals or the programmed amount.
10.3 a) Press Load/Unload to confirm this number of animals and the programmed amount.
b) To edit the number of animals or the amount, press Clear and enter the new values using the numerical
keypad.
10.4 Press Load/Unload. The scale displays the calculated amount of the first ingredient.
10.5 Depending on the presetting the next ingredient will appear automatically or after Ingr/Accum has been
pressed.
10.6 Once all ingredients have been loaded, the scale displays: recipe completed total = xxx kg.
2
11 TO REVIEW A RECIPE (to check a recipe)
11.1 Press Recipe. The scale displays the first recipe loaded in memory.
11.2 Press Recipe until the required recipe number is displayed.
11.3 Press Ingr/Accum. The scale displays all ingredients of the recipe. At the end it displays the totally
programmed amount, total = xxxx kg.
11.4 Press Net/Gross to return to normal weighing mode.
2
12 TO REVIEW INGREDIENT ACCUMULATION
12.1 Press Ingr/Accum. The scale displays the first recipe and the total amount that has been dosed in since
the last time this ingredient was deleted (see manual, page 30).
12.2 Press Ingr/Accum until all ingredients have been displayed.
12.3 Press Net/Gross to return to normal weighing mode.
For a more detailed description, see manual EZ 3200 / 3200V
1 Getting started Page 8, 9
2 To zero balance the scale Page 9
3 To change the language -Press Net/Gross + On.
-Press Select to select to menu 1 and press On.
-Press Select until the required language is displayed: Englsh / Nederl /
Francs / Deutsh / Italan / Port / Espanl / Vesta / Magiar / Dansk.
-Press On to confirm the selected language.
4 To change the entry
method
Pages 18, 20 1 = Amount per Animal 2 = Percent % 3 = KG. Amount per
Load
5 To change the tolerance Page 24 (to change the tolerance) and page 25 (to change the delay time).
6 To rename ingredients Pages 37, 29
7 To program a new recipe Page 19 and for examples, pages 38, 39, 40.
8 To edit a recipe Page 21
9 To delete a recipe Page 22
10 To load a batch using a
recipe
Pages 25, 26
Attention: (for Triomix Triomix s and Gigant set delay time to MANUAL)
1 Enter 443 using the numerical keypad.
2 Press Select. The scale displays DELAY followed by 5.
3 Press Select until MANUAL is displayed.
4 Press On to confirm the setting.
11 To review a recipe Page 27
12 To review ingredient
accumulation
Page 28
