DIGITAL FORECAST Bridge RS16x16 User manual

Digital Forecast
Bridge”RS 16*16
HD/SD/3G SDI Matrix Router
Instruction Manual

www.dfcast.co.kr
2
Contents
Caution.............................................................................................................4
1. Feature..........................................................................................................6
2. Name and function.........................................................................................7
3. Way of use....................................................................................................8
4. Signal characteristic........................................................................................9
5. Specification.................................................................................................11
6. Attach..........................................................................................................12

www.dfcast.co.kr
3
Copyright in this user manual DIGITAL FORECAST INC. . Unauthorized reproduction is prohibited
that the contents of this manual in whole or part without the prior written consent.
Warranty
The product is warranted by DIGITAL FORECAST INC. against product defects for a limited
warranty period of one (1) year as the date of supplied.
DIGITAL FORECAST INC. will repair or replacement any part proves to be defective at no
charge, as stipulated herein, during the warranty period specified above.
For such misuse, modification, or careless handling of the user of the product, Non-
standard product is not responsible for warranty.
DIGITAL FORECAST INC. does not warrant uninterrupted or error-free operation and
misuse, neglect, misapplication, product alteration or modification; improper or unauthorized
repair.
To request service, the purchaser must contact DIGITAL FORECAST INC. for problem
determination and service procedures.
DIGITAL FORECAST INC. at :
16-4, SK techno-bulding N.303, Seongsu1-ga1-dong,
Seongdong-gu, Seoul, Korea
TEL. [phone] FAX. [phone]
E-mail : [email protected] Web Site : www.dfcast.co.kr
Copyright ⓒ DIGITAL FORECAST INC. All rights reserved. This publication supersedes
all previous releases. Printed in Korea.
Please be sure to read the following instructions before using the product.
Designed and tested in accordance with the standards of this product.
Safety
Please be sure to read the following instructions before using the product.
Designed and tested in accordance with the standards of this product.
Safety Mark

www.dfcast.co.kr
4
symbol indicates a danger. product have high voltage that
can cause concern to body electrical shock.
DANGER symbol indicates a danger.
If do not attention to handling, concerns of personal injury
can result.
Do not ignore the DANGER mark and treat them.
WARNING symbol indicates a warning.
If you deal products negligence or abuse it cause
adversely. Do not ignore the WARNING mark and treat
them.
CAUTION symbol indicates a. caution.
If treats products negligence or abuse it cause damaged.
Do not ignore the CAUTION mark and treat them.
Before operating
1. Check indicated voltage before you turn on product.
※ Use to Earth Ground for safety.
2. Use to rated Fuse.
3. Qualified person could be limited to maintenance, repair and
replace of product.
SERVICE
Bridge series order to satisfy technical requirements and compact size, it could be limit
to repair of SMT(Surface-Mount Technical) and program on site, immediately.
Please request to repair if products have a problem
CAUTION
WARNING
DANGER

www.dfcast.co.kr
5
Bridge RS 16x16
Bridge RS 16x16 is supporting 8x8 SDI input/output of video as "Routing Switcher".
A this model recognizes SD,HD and 3Gb/s SDI signal automatically change, It has the dual power
supply and Reclocking function built-in.
And input state display. APC function(Control by RS422 communication of PC), button Lock function
for the convenience of the user.
1. Feature
2. Support SMPTE 292M, SMPTE 344M, SMPTE 259M, SMPTE 424M
3. Re-clocking
4. Multi-Rate SDI (143M, 177M, 270M, 340M, 540M, 1.485G, 1.485/1.001G, 2.97G)
5. 3G/HD/SD-SDI 16 in x 16 out
6. Auto equalizing (HD grade : compensate for up to 100m, SD : up to 300m of Belden 1694
Cable )
7. RS-422 deck control ports (RJ45,)
8. DC12V 3.33A Power supply included
9. TCP/IP Network control ports (RJ45)

www.dfcast.co.kr
6
2. Name and function
그림 2-1 전면부
1. LED : POWER1, POWER 2, REFERENCE, REMOTE
a. POWER1 : : Power supply input status of Power1 is shown.
b. POWER2 : Power supply input status of Power2 is shown. .
c. REFERENCE : Reference input status is shown. (B.B , Tri-Level)
d. REMOTE : When controlling by communication, it's switched on and off.
2. INPUT : An input signal presence is shown by an LED by 16 of input select button.
(Complete connection : LED ON, No connection : LED flicker)
3. OUTPUT : 16 of output select button
4. ENABLE : When it's pushed for more than 1 second, LED On.
When lighting up, it's possible to control the item number 2,3
When pushing it again, it's turned off.
5. FUNCTION : In Out setting is preserved or, when import, it's used.
그림 2-2 후면부
6. INPUT : 16 of Input BNC
7. NET : Support to TCP/IP NETWORK
8. RCP : Support to RCP by RS-422 Communication(A protocol is in an attachment ..)
9. POWER : 2 of 12V adapter power supply input (can be spare)
10. CPU : CPU CONSOL MINI USB TYPE
11. OUTPUT : 16 of output BNC
12. REFERENCE : Tri-level or 1 of Black Burst input
1. LED
2. INPUT
3. OUTPUT
4. ENABLE
5. FUNCTION
6. INPUT
7. NET
9. POWER
8. RCP
11. OUTPUT
12. REFERENCE
10. CPU

www.dfcast.co.kr
7
3. Way of use
1. Input / Output Setting
To connect the Video source to the INPUT BNC.
To connect the OUTPUT BNC to the input of the equipment that I want try to send the display
equipment and source .
The ON cases the ENABLE button, press the ENABLE button for more than 1 second .
Select the same OUTPUT button and OUTPUT BNC number which is connected to the
equipment that I want try to send the display equipment and source.
Screen output or by pressing the same button as the other INPUT BNC and concatenate
number and transmitted to the appropriate equipment . If all of the settings are completed , ON
causes the ENABLE button press again the ENABLE button.※ equipment seen has to be
selected after selecting the input button the output button first in such a way as above because
it is designed as an output reference .
2. FUNCTION KEY Operating
As the ENABLE button state is on, and press the FUNCTION KEY, It means that four right
buttons and four left buttons are ON.
(However, should a state of being turned ON ENABLE button.)
The left side is a save button, the right side data load button. Save and load data is possible up
to four each. If select the left button to become saved in the appropriate number.
Press the right button to become loaded the value of the corresponding number, it changed into
the initial state. (The input port is to the first port of loading values reveal.)
3. Notices
This device button after selecting the first output in the same way as above because it is
designed to be output should be selected based on the input buttons . Additionally, If the
ENABLE button is ON , it does not communicate.

www.dfcast.co.kr
8
4. Signal Characterisitic
1. HD-SDI Properties
HD-SDI Serial Digital Video
Connector
75Ω BNC
Signal level
800mV ± 10%
DC offset
0V ± 0.5V
Rise and fall time
< 270ps (20% to 80% amplitude)
Overshoot
<10% of amplitude
Timing Jitter
<1 UI
Alignment Jitter
<0.2UI

www.dfcast.co.kr
9
2. SD-SDI Properties
SD-SDI Serial Digital Video
Connector
75Ω BNC
Signal level
800mV ± 10%
DC offset
0V ± 0.5V
Rise and fall time
400~800ps(20% to 80% amplitude)
Overshoot
<10% of amplitude
Timing Jitter
<0.2 UI
Alignment Jitter
<0.2UI

www.dfcast.co.kr
10
5. Specification
Connections
SDI Video Input
SD/HD-SDI, 3Gb/s SDI and ASI. X16 (BNC)
SDI Video Output
SD/HD-SDI, 3Gb/s SDI and ASI with SDI re-clocking. X16 (BNC)
Remote Control
RS-422 (RJ45)
Reference Input
B.B , TRI x1 (BNC)
NET
TCP/IP (RJ45)
Electrical
Voltage
90 ~ 240V AC 50/60Hz
Power
Dissipation
< 28W(12V DC, 3.33A)
Temperature
0 ~ 40˚C
Physical
Size
481mm x 43mm x 133mm(W x H x D)
Weight
1.85Kg
Standards
SD Format
Support
625/25 PAL and 525/29.97 NTSC.
HD Format
Support
1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25,
1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30, 1080i50, 1080i59.94,
1080i60, 1080p50, 1080p59.94, 1080p60, 720p23.98, 720p24, 720p25,
720p29.97, 720p30, 720p50, 720p59.94, 720p60.
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 310M, SMPTE 425M-A,
SMPTE 425M-B
SDI Video
Sampling
4:2:2 and 4:4:4.
SDI Video Rates
SDI video connections are switchable between standard definition, high
definition and 2K. SDI switches between 270 Mb/s standard definition SDI, 1.5
Gb/s HD-SDI and 3 Gb/s HD SDI.
SDI Auto
Switching
Automatically selects between SD-SDI, HD-SDI, 3 Gb/s SDI and DVB-ASI on
each input so that each input can be running a different television standard.

www.dfcast.co.kr
11
6. Attach
Cable connection
※ It consists of PIN MAP like the top, when connecting with RCP, you should manufacture a LAN
cable by 1:1
※ When ENABLE is, the main body can't make ENABLE RCP.
If the main body will be ENABLE even if RCP ENABLE will be, RCP will be a disable.
※ REMOTE LED of RCP is flicker every time when data is received by the main body.
