Lantech TWAP-5006 User manual

TWAP-5006
EN50155 Multifunction VPN Router w/up to 2x WiFi 11ac + 2 serial
ports** + 6 Gigabit X-coded Ethernet Switch
User Manual (Hardware)
Dec. 2019
**optional

Recommendation for Shielded network cables
STP cables have additional shielding material that is used to reduce external interference.
The shield also reduces the emission at any point in the path of the cable. Our
recommendation is to deploy an STP network cable in demanding electrical environments.
Examples of demanding indoor environments are where the network cable is located in
parallel with electrical mains supply cables or where large inductive loads such as motors
or contactors are in close vicinity to the camera or its cable. It is also mandatory to use an
STP cable where the power device (like IP camera) is used outdoors or where the network
cable is routed outdoors.

Important Notice
Lantech Communications Global, Inc. reserves the right to modify the
equipment, its specification or this manual without prior notice, in the interest
of improving performance, reliability, or servicing. At the time of publication
all data is correct for the operation of the equipment at the voltage and/or
temperature referred to. Performance data indicates typical values related to
the particular product.
No part of this documentation or information supplied may be divulged to any
third party without the express written consent of Lantech Communications
Global Inc. Products offered may contain software which is proprietary to
Lantech Communications Global Inc. The offer or supply of these products
and services does not include or infer any transfer of ownership.
Interference Issues
This Equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
commercial or industrial installation. This equipment generates, uses, and
can radiate radio frequency energy. It may cause harmful interference to
radio communications if the equipment is not installed and used in
accordance with the instructions.

FCC Warning
This Equipment has been tested and found to comply with the limits for a
Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate
radio frequency energy. It may cause harmful interference to radio
communications if the equipment is not installed and used in accordance
with the instructions. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

Content
Chapter 1 Hardware Description............................ 5
1.1 Physical Dimension....................................... 5
1.2 Package Content: ......................................... 8
1.3 IP Protection................................................. 8
1.4 LED Indicators.............................................11
Chapter 2 Hardware Installation .......................... 13
2.1 Hardware installation....................................13
Chapter 3 Console Management.......................... 18
3.1. Connecting to the Console Port....................18
3.2. Login in the Console Interface......................18

5
Chapter 1 Hardware Description
In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling
information, and wiring installation.
1.1 Physical Dimension
Aluminum case. IP-65/54,
178mm(W)x99mm(H)x103mm(D)
With 2 serial ports

6
Without 2 serial ports

7
Port description of IP-65/54 series switch
With 2 serial ports
Without 2 serial ports

8
1.2 Package Content:
Multifunction Router x1
Console cable x1
1.3 IP Protection
The IP Code, Ingress Protection Rating, sometimes also interpreted as International
Protection Rating, classifies and rates the degree of protection provided against the
intrusion (including body parts such as hands and fingers), dust, accidental contact, and
water in mechanical casings and with electrical enclosures. It is published by the
International Electrotechnical Commission (IEC)
Solid particle protection
The first digit indicates the level of protection that the enclosure provides against access
to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid
foreign objects.
Level
Object size
protected
against
Effective against
0
—
No protection against contact and ingress of objects
1
>50 mm
Any large surface of the body, such as the back of a
hand, but no protection against deliberate contact
with a body part
2
>12.5 mm
Fingers or similar objects
3
>2.5 mm
Tools, thick wires, etc.
4
>1 mm
Most wires, screws, etc.
5
Dust protected
Ingress of dust is not entirely prevented, but it must

9
not enter in sufficient quantity to interfere with the
satisfactory operation of the equipment; complete
protection against contact
6
Dust tight
No ingress of dust; complete protection against
contact
Liquid ingress protection
The second digit indicates the level of protection that the enclosure provides against
harmful ingress of water.
Level
Protected
against
Testing for
Details
0
Not
protected
—
—
1
Dripping
water
Dripping water (vertically
falling drops) shall have no
harmful effect.
Test duration: 10 minutes
Water equivalent to 1 mm
rainfall per minute
2
Dripping
water when
tilted up to
15°
Vertically dripping water
shall have no harmful
effect when the enclosure
is tilted at an angle up to
15°from its normal
position.
Test duration: 10 minutes
Water equivalent to 3 mm
rainfall per minute
3
Spraying
water
Water falling as a spray at
any angle up to 60°from
the vertical shall have no
harmful effect.
Test duration: 5 minutes
Water volume: 0.7 litres per
minute
Pressure: 80–100 kPa
4
Splashing
of water
Water splashing against
the enclosure from any
direction shall have no
Test duration: 5 minutes
Water volume: 10 litres per
minute

10
harmful effect.
Pressure: 80–100 kPa
5
Water jets
Water projected by a
nozzle (6.3 mm) against
enclosure from any
direction shall have no
harmful effects.
Test duration: at least
15 minutes
Water volume: 12.5 litres
per minute
Pressure: 30 kPa at
distance of 3 m
6
Powerful
water jets
Water projected in
powerful jets (12.5 mm
nozzle) against the
enclosure from any
direction shall have no
harmful effects.
Test duration: at least
3 minutes
Water volume: 100 litres per
minute
Pressure: 100 kPa at
distance of 3 m
7
Immersion
up to 1 m
Ingress of water in harmful
quantity shall not be
possible when the
enclosure is immersed in
water under defined
conditions of pressure and
time (up to 1 m of
submersion).
Test duration: 30 minutes
Immersion at depth of at
least 1 m measured at
bottom of device, and at
least 15 cm measured at top
of device
8
Immersion
beyond 1 m
The equipment is suitable
for continuous immersion
in water under conditions
which shall be specified by
the manufacturer.
Normally, this will mean
that the equipment is
hermetically sealed.
However, with certain
types of equipment, it can
mean that water can enter
Test duration: continuous
immersion in water
Depth specified by
manufacturer

11
but only in such a manner
that it produces no harmful
effects.
9
Powerful
high
temperature
water jets
Protected against close-
range high pressure, high
temperature spray downs.
—
1.4 LED Indicators
The diagnostic LEDs that provide real-time information of system and optional status are
located on the front panel of the industrial switch. The following table provides the
description of the LED status and their meanings for the switch.
LED
Color
Status
Meaning
R.M
Green
On
The switch unit is owner switch of ITU-Ring
Off
The switch is not owner switch
PWR1
Green
On
Power 1 is active
Off
Power 1 is inactive
PWR2
Green
On
Power 2 is active
Off
Power 2 is inactive
FAULT
Red
On
Power or port failure
Off
No failure
P1 ~ P6
Green
(Link/
Act)
On
A network device is detected.
Blinking
The port is transmitting or receiving packets
from the TX device.
Off
No device attached
WLAN
Green
On
WLAN is active

12
Off
WLAN is inactive
Serial 1 &
Serial 2
Green
Blinking
The serial is transmitting or receiving data.
Off
Serial is inactive

13
Chapter 2 Hardware Installation
2.1 Hardware installation
2.1.1Unpack switch and check the accessory with packing content list
2.1.2 Mount the switch on desired position. For the best ventilation, it is
suggested to mount the switch on metallic surface.
2.1.3 Connect the M12 connector of power input.
Voltage of Power Input
WV model:
The power input voltage can be from
16.8V to 137.5VDC.
Dual Power Input
Pin assignment of Power input
The power input can be supported redundantly. The supply voltage is
electrically isolated from the housing.
Note: With single power supply of the mains voltage, the device will

14
report a power failure. You can disable this power fail event via web
browser.
Pin assignment of DI/DO
2.1.4 Fitting the device, grounding
Install the system in a dry and clean area to protect the switch to
get exposed with dirt.
Plug the connector to the power supply plug then turn on the power
supply.
Ground
The chassis is grounded via a separate ground nut (M3).
Use toothed locking washers for a good electrical connection.

15
Ground screw of router
2.1.5 Connect the M12 connector with RJ-45 data cable, ports are not
used shall be caped that comes with the package to insulate the
surrounding.
Pin assignment of M12 10/100/1000T network connector

16
Note:
The protection class IP65/54 is only achieved when bolted together.
The other components attaching to the system have to meet with the
IP65/54 protection class in order to reach the whole system IP65/54
protection.
Empty ports must be sealed with the protective caps supplied.
2.1.6 Connect the M12 serial connector with RS232/RS422/RS485 cable,
ports are not used shall be caped that comes with the package to insulate the
surrounding.
Note:
The serial connectors are only for connecting RS232 or RS422 or
RS485, depending on models. (Model name -2S: RS232; Model name -
2SA: RS422; Model name -2SB: RS485) DO NOT connect Ethernet or
PoE to serial ports. It may cause damage to the router.
2.1.7 Connect the pin1 & pin7 for 10 seconds and the router will be reset to

17
default
2.1.8 Connect the M12 connector to USB if needed
Note: The USB port is USB 2.0 speed, not USB 3.0

18
Chapter 3 Console Management
3.1.Connecting to the Console Port
The supplied cable which one end is M12 8-pole connector and the other end is RS-232
connector. Attach the end of RS-232 connector to PC or terminal and the other end of
M12 connector to the console port of the switch. The connected terminal or PC must
support the terminal emulation program.
3.2.Login in the Console Interface
When the connection between Switch and PC is ready, turn on the PC and run a terminal
emulation program or Hyper Terminal and configure its communication parameters to
match the following default characteristics of the console port:
Baud Rate:115200 bps
Data Bits: 8
Parity: none
Stop Bit: 1

19
Flow control: None
The settings of communication parameters
Having finished theparameter settings, click ‘OK’. When the blank screen shows up, press
Enter key to have the login prompt appears. Key in ‘admin’(default value) for both User
name and Password (use Enter key to switch), then press Enter and the Main Menu of
console management appears. Please see below figure for login screen.
Console login interface
===============Notice===============
For web-based management, please refer to our “Software Management Manual”.
Please contact [e-mail] for more information.
