Digital Lighting Systems Animation Series User manual

Digital Lighting Systems, Inc.
MF802
8 Channel “Mini-Fader/ Chaser ”
Cross Fader/ color mixing/ Animation chaser
MF802-12(12VAC)/
MF802-120(120VAC/ MF802-220(220VAC)
MF802-12DC/ MF802-24DC
MF802-24(24VAC)/
USER'S MANUAL
MF802-UM
07/18
USER'S MANUAL
Animation series

User's Manual - Page 1
General Description
The MF802 is an Eight channel single-phase AC lighting controller (Cross-
Fader/Lighting animation) capable of producing slow level changes( Color Mixing ) as
well as Quick ON/ OFF ( Animation)
A functional block diagram of the MF802 is shown in Figure 1. MF802 contains the
equivalent of 2 sets of four solid-state relays (SSR) 8 dimmers, with two power line
feed. Each dimmer is rated at a maximum output current of 2.5 Amperes. The SSR
dimmers are controlled by low-voltage DC signals from the logic circuit on the board.
These signals are electrically-isolated by Optical couplers from all line voltage
elements. The MF802 logic board contains a powerful microprocessor programmed to
generate 16 user-selectable light sequences or patterns at an adjustable rate (the
MF802 is also available with a “SPELLER” pattern or custom patterns upon request). A
rotary selector is used to select the pattern and a second one is used to set the rate or
speed. Patterns and speed can be monitored by Eight LED's that represent the outputs
of the MF802. The MF802-120 and MF802-220 Require Logic power from an
external step down transformer with output rates at 300mA 8 VAC to 12 VAC
Please contact the factory for additional information by telephone [phone] or
email [email protected]
Figure 1 - MF802 Functional Block Diagram
Table 1 - Terminals Definition
Table 2 - Maximum Electrical Ratings
Electrical Characteristic
Terminal Maximum
Relay Load Current 1 to 8 2.5
Amps.
NAME DESCRIPTION
1,2,3,4 Output Of
Solid-State Relays #1,2,3,4
H1 Hot Line Feed For
Relays 1 , 2 , 3 & 4.
NNeutral Bus/ Common
Connections.
5,6,7,8 Output Of
Solid-State Relays #5,6,7,8
H2 Hot Line Feed For
MF Logic Control
Board
SSR's OPTICAL ISOLATORS
9 VAC
Transformer
SSR1
SSR2
H1 N N 1 2 3 4
SSR3
SSR4
External
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
SSR's OPTICAL ISOLATORS
SSR1
SSR2
H2 N N 5 6 7 8
SSR3
SSR4
Signal cable ch. 5 to 8
MF802
8 channel
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 2
MF802-120 Detail
Figure 2 - MF802-
Table 3 - MF802-120 Circuit Legend
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
1
6
4
5
7
8
9
S1 S2
23
11A 12A 13A 14A
H1 N N 1 2 3 4
OUTPUT TERMINAL
15A
16A 17A
18A
19B
10
H2 N N 5 6 7 8
OUTPUT TERMINAL
11B 12B 13B 14B
15B
16B
19A
17B
18B
C1 C2
1Microprocessor.
2Not Used
3Not Used
4Quartz Crystal.
5Power Supply Capacitor.
6Voltage Regulator.
74 or 3 channel jumper selection
8Logic power connector
9Output LED Monitors.
10 Jumper for Chasing
11A,12A,13A,14A Optical Couplers # 1,2,3,4
11B,12B,13B,14B Optical Couplers # 5,6,7,8
15A,16A,17A,18A Triacs # 1,2,3,4 for VAC; MOSFETs for VDC
15B,16B,17B,18B Triacs # 5,6,7,8 for VAC ; MOSFETs for VDC
19A,19B Fuses 5mm, 10Amps
S1 Speed selector 0 = Slowest ; F = fastest
S2 Pattern Selector
C1,C2 Connectors for CH 5,6,7,8 control cable
MF802
8 channel
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 3
Mechanical Installation
The MF802 modules are designed to be mounted in NEMA enclosures( by others).
Figure 3 - MF802 Dimensional Diagram
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
4.30"4.30"
1.50"
Mounting hole
For # 6 screw
Mounting hole
For # 6 screw
MF802-xxxx
For Chasing
Place jumper
1
2
4
3
1 2 3 4
Optocouplers
S2
0
1
F
2
E
3
D
4
5
C
6
B
7
A
8
9
0
1
F
2
E
3
D
4
5
C
6
B
7
A
8
9
S1
SF408
V0.2
1
10 A.
Fuse
Microprocessor
Channel Indicators
-SpeedPattern
5.00"
1.50"
Mounting hole
For # 6 screw
Mounting hole
For # 6 screw
MF802-xxxx
5
6
8
7
5 6 78
Optocouplers
5
10 A.
Fuse
Channel Indicators
MF802
8 channel
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 4
Wiring Notes
0DO NOT EXCEED 300 W (2.5 Amps. ) per circuit output @ 120VAC.
0MF802 Fader packs may be fed by one 15 A (maximum) branch circuit and may have up to four
separately dimmed loads.
0Loads connected to outputs must be dimmable.
0CAUTION: DO NOT attempt to parallel outputs to increase capacity.
0Installations must conform to local and/or NEC code requirements.
0Each load must have its own Neutral wire for full load operation.
0All line voltage wires must have copper conductors of adequate Gauge with 90° C wire insulation.
0POWER EACH LOAD DIRECTLY BEFORE CONNECTING IT TO THE MF802, TO ENSURE PROPER WIRING.
MF802-120 General Wiring Instructions for 120V version.
Figure 4 - MF802 Typical 120 VAC Wiring.
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
MF802
8 channel
Transformer
9 VAC 300 mAmps
MF802-120
5
6
8
7
56 7 8
5 6 7 8
1
10 A.
Fuse
MF802-120
For Chasing
Place jumper
1
2
4
3
12 3 4
1 2 3 4
S2 S1
SF408
V0.2
1
10 A.
Fuse
Microprocessor
-
Ch: 5,6,7,8 control cable
HOT
120 VAC IN
From 15 Amps
Breaker
NEUT.
HOT
120 VAC IN
From 15 Amps
Breaker
NEUT.
X
X
X
X
N
E
U
T
X
X
X
X
N
E
U
T
Channels 1,2,3,4 Channels 5,6,7,8
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 5
Wiring Notes
0DO NOT EXCEED 600 W (2.5 Amps. ) per circuit output @ 240VAC.
0MF802 Fader packs may be fed by one 15 (maximum) branch circuits and may have up to four
separately switched loads.
0Loads connected to outputs must be dimmable.
0CAUTION: DO NOT attempt to parallel outputs to increase capacity.
0Installations must conform to local and/or NEC code requirements.
0Each load must have its own Neutral wire for full load operation.
0All line voltage wires must have copper conductors of adequate Gauge with 90° C wire insulation.
0POWER EACH LOAD DIRECTLY BEFORE CONNECTING IT TO THE MF802, TO ENSURE PROPER WIRING.
MF802-220 General Wiring Instructions for 220-240V version.
Figure 5 - MF802 Typical 220 VAC Wiring.
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
MF802
8 channel
MF802-240
5
6
8
7
56 7 8
5 6 7 8
1
10 A.
Fuse
MF802-240
For Chasing
Place jumper
1
2
4
3
12 3 4
1 2 3 4
S2 S1
SF408
V0.2
1
10 A.
Fuse
Microprocessor
-
Ch: 5,6,7,8 control cable
HOT
240 VAC IN
From 15 Amps
Breaker
NEUT.
HOT
240 VAC IN
From 15 Amps
Breaker
NEUT.
X
X
X
X
N
E
U
T
X
X
X
X
N
E
U
T
Channels 1,2,3,4 Channels 5,6,7,8
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 6
Wiring Notes
0DO NOT EXCEED 60 W (2.5 Amps. ) per circuit output @ 24VAC. Or 30 W @ 12 VAC
0MF802 Fader packs may be fed by one 15 (maximum) branch circuits and may have up to four separately switched
loads.
MF802-24 0r MF802-12 General Wiring Instructions 24VAC /12VAC
Figure 6 - MF802 Typical 12 VAC or 24 VAC Wiring.
With MF802-24 you may use a single 24 VAC-250 VA or better transformer
.With MF802-12 you may use a single 12 VAC-150 VA or better transformer.
Follow transformer's installation & wiring instructions from manufacturer.
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
MF802
8 channel
5
6
8
7
56 7 8
5 6 7 8
1
10 A.
Fuse
MF802-12 or MF802-24
For Chasing
Place jumper
1
2
4
3
12 3 4
1 2 3 4
S2 S1
SF408
V0.2
1
10 A.
Fuse
Microprocessor
-
Ch: 5,6,7,8 control cable
X
X
X
X
12 VAC
or
24VAC
12VAC
or
24VAC
transformer
X
X
X
X
Channels 1,2,3,4 Channels 5,6,7,8
C
O
M
.
12 VAC
or
24VAC
12VAC
or
24VAC
transformer
MF802-12 or MF802-24
Power inputs to transformers should be on the same phase
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

Common POSITIVE ( Anode ) / Switched Negative (cathode)
User's Manual - Page 7
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
MF802
8 channel
5
6
8
7
56 7 8
5 6 7 8
1
10 A.
Fuse
MF802-12DC
or
MF802-24DC
For Chasing
Place jumper
1
2
4
3
12 3 4
1 2 3 4
S2 S1
SF408
V0.2
1
10 A.
Fuse
Microprocessor
-
Ch: 5,6,7,8 control cable
X
X
X
X
X
X
X
X
Channels 1,2,3,4 Channels 5,6,7,8
12 VDC
or
24 VDC
power
supply
Negative
Positive
+
-+
12 VDC
or
24 VDC
power
supply
Negative
Positive
+
-+
Figure 7 - MF802 Typical 12 VDC or 24 VDC Wiring.
MF802-12DC
or
MF802-24DC
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 8
Controls
The controls consist of two rotary 16-position (0-9 and A-F) selectors. S2 (PATTERN)
is used for selecting the desired Fade pattern. Positions 0 will scroll threw the patterns
automatically to provide an ever changing light show. The MF802 outputs can be
turned to static ON by selecting F. When 0 is selected, the MF802 goes into an
automatic pattern change mode. All other positions cause the MF802 to play a single
pattern indefinitely. S1 is used to select one of 16 individual Fade rates (Rate).
Minimum speed is achieved by selecting position 0. Speed doubles with each
subsequent selector position.
Indicators
LED indicators 1 to 4 indicate the status (On-Dimmed-Off) of their corresponding
S2 S1 Rate
Mode
LED’s
Output
Indicators
Figure 8 - MF802 Indicators and Control Selectors
CAUTION
Use a small Screw driver for
adjusting selector positions
in order to avoid damaging
the Selectors slots.
1 2 34
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
MF802
8 channel
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 9
Patterns for MF802
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
1234
678
Light Fade Fill & Swipe Forward Fill & Swipe Back Light Bounce
Dark Fade
Flip-Flop Flash All
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
1 2 3 4 5 6 7 8
Circuits
Step 9:
Step 10:
Step 11:
Step 12:
Step 13:
Step 14:
Step 15:
Step 16:
5
Dark Bounce
OFF
ON
KEY:
MF802
8 channel
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

1
User's Manual - Page 10
Patterns for MF802
1
16 Pattern
Fader / Chaser
Digital Lighting Systems
www.digitallighting.com
MF802
8 channel
MF802
8 channel
9ABC
EF
Flash Light Fade Spring Forward Spring Back Flash Dark Fade
Crawl Back
ALL ON
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
1 2 3 4 5 6 7 8
Circuits
Step 9:
Step 10:
Step 11:
Step 12:
Step 13:
Step 14:
Step 15:
Step 16:
D
Crawl Forward
OFF
ON
KEY:
0
Automatic Cycle
of Patterns 1-F
4 x each
then repeat
AUTO
12302 SW 128th ct, Miami, Fl. 33186
Tel: [phone] [email protected]
Copyright 2018 Digital Lighting Systems, All rights Reserved Specifications are subject to change without notice. Printed in U.S.A.
www.digitallighting.com

Digital Lighting Systems, warrants to the purFader
that its products have been carefully manufactured
and inspected and are warranted to be free from
defects of workmanship and materials when used as
intended. Any abuse or misuse contrary to normal
operation shall void this warranty.
Digital Lighting Systems' obligation under this
warranty shall be limited to replacement or repair of
any units as shall within one year of date of invoice
from Digital Lighting Systems, prove defective; and
Digital Lighting Systems shall not be liable for any
other damages, whether direct or consequential. The
implied warranties of merchantability and fitness for
a particular purpose are limited to the duration of
the expressed warranty. Some states do not allow
the exclusion of the limitation of incidental or
consequential damages, so the above limitation or
exclusion may not apply to you. This warranty gives
you specific legal rights, you may also have other
legal rights which vary from state to state.
Defective merchandise may be returned to Digital
Lighting Systems, prepaid, after prior notification has
been given and approval obtained for the return. To
obtain prior approval for the return of the defective
items, contact your local Digital Lighting Systems
distributor, representative, or:
Digital Lighting Systems, Inc.
Attn: Customer Service Department
12302 SW 128th ct
Miami, FL 33186
[phone]
Upon request, replacement unit(s) will be shipped as
soon as available. Unless immediate shipment of
replacement merchandise is requested, Digital
Lighting Systems will not ship replacement
merchandise until defective merchandise is
received, inspected, and determined to be defective.
No labor charges in connection with warranty
problems will be reimbursed by Digital Lighting
Systems without prior written approval from the
factory.
Digital Lighting Systems distributors and
representatives have no authority to change this
warranty without written permission.
Digital Lighting Systems reserves the right to
determine the best method of correcting warranty
problems.
LIMITED WARRANTY
Digital Lighting Systems, Inc.
12302 SW 128th ct
Miami, FL 33186
www.digitallighting.com
Tel [phone]
Fax [phone] Printed in U.S.A.
July 2018
