Digital Monitoring Products 1100R User manual

InstallatIon GuIde
1100R Wireless Repeater
Description
The 1100R Wireless Repeater provides increased communication range by forwarding messages from the transmitter to the
wireless receiver. Up to eight repeaters can be installed on a wireless system. The repeater is powered from a
12 VDC power supply and includes a 24-hour battery backup. Using the on-board LEDs, the 1100R Wireless Repeater
provides built-in survey capability to allow for single-person installations, eliminating the requirement for an external
survey kit.
Compatibility
1100X, 1100XI, or 1100XH Receiver using Version 106 software.•
1100D, 1100DI, or 1100DH Receiver using Version 106 software.•
XT50 Series panel with built-in wireless using•
Version 101 (11/21/08) software.
What is Included
The 1100R Wireless Repeater includes the
following items:
• OneModel1100RRepeater
• OneLithiumPolymerRechargeableBattery
• OneModel378BarrelConnectorwithcord
forconnectinga12VDCPowerSupply
• Zonenameandnumberlabel
• Serialnumberlabel
• Hardwarepack
Optionalitemsavailable:
• OneModel376Plug-inDCPowerSupply
Serial Number
For your convenience, an additional pre-printed
serial number label is included. Priortoinstalling
the repeater, record the serial number or place
the pre-printed serial number label on the panel
programming sheet. This number is required
during programming. As needed, use the zone
name and number label to identify the repeater.
Panel Programming the Repeater
To program the repeater in the panel a wireless
zoneisused.ProgramthewirelessHouseCodein
SystemOptionspriortoaddingDMPwirelesszonestothesystem.FollowthesestepsinZone Information:
• ZoneType:SelectanAuxiliaryzonetypeandprogramtroubleforboththeopenandshortconditions.
• Wireless:SelectYEStoprogramthezoneasaDMPwirelesszone.
• SerialNumberEntry:AttheSerialNumber:prompt,entertherepeater’seight-digitserialnumber.
Note: If using multiple repeaters, they must be programmed as sequential zone numbers.
• SupervisionTime: PressCOMMANDtoacceptthedefaulttimeof240minutes.Pressanytoprowkeytoselectthe
supervision time required for the wireless repeater. PresstheSelectkeyundertherequirednumberofminutes.A
check-in time of 60 or 240 minutes should be selected.
The repeater must check in at least once during this time or a missing condition is indicated for that zone.
Since 1100R repeaters automatically check in based on the supervision time selected for the wireless zone, no
additional programming is needed. Any programming prompts for contact or other information can be ignored.
Note: When an 1100 series receiver is installed, powered up, or the panel is reset, the supervision time for any
repeaters and transmitters are reset.
RefertotheXR500SeriesProgrammingGuide(LT-0679),XR100SeriesProgrammingGuide(LT-0896),XT30/XT50
ProgrammingGuide(LT-0981),ortheXRSuper6/XR20/XR40ProgrammingGuide(LT-0305)asneeded.
J4
1
J1
1
Mounting Hole
Locations
LEDs
Tamper
Switch
Battery
Start
DC Power
Supply
Barrel Jack
Squeeze
to Remove
Cover
Squeeze
to Remove
Cover
Figure 1: 1100R Repeater PCB Layout

Digital Monitoring Products 1100R Installation Guide
2
Selecting the Proper Location (LED Survey Operation)
The1100Rprovidesasurveycapabilitytoallowonepersontoconrmcommunicationwiththe1100seriesreceiver
while the cover is removed. The 1100R provides the option to power up using the Lithium battery only for survey
operation.BrieyshorttheBatteryStartpadstogethertopowerup.RefertoFigure1.
Survey LEDs
The 1100R automatically begins establishing communication with the 1100 series receiver at power up. The 1100R
GreenSurveyLEDturnsonsteadywhensuccessfulcommunicationwiththereceiverisestablished.The1100RRed
Survey LED turns on steady when communication cannot be established with the receiver. Relocate the repeater
untiltheGreenLEDturnsonsteadyindicatingsuccessfulcommunicationhasbeenestablished.ThisGreen/Red
surveyLEDoperationisdifferentfromthestandardsingleLEDashfor1100Seriestransmitters.
LED Operation
Three LEDs display repeater operation and activity. Refer to the table below as required.
Label Operation
GOOD SteadyGreenindicatesreliablecommunicationhasbeenestablishedwiththereceiver.Reliable
communicationisdenedasthelast5messagessentbytherepeaterhavebeenacknowledged
immediately by the receiver. A message can be sent by pressing or releasing the tamper switch.
BAD Steady RED indicates the repeater has not established reliable communication with the receiver.
Communication is not considered reliable when the last 5 out of 15 messages sent by the repeater have
notbeenacknowledgedimmediatelybythereceiver.Messagesmaystillbecommunicated,howeverthe
communication link between the repeater and the receiver is not optimum. In this case the repeater
shouldberelocateduntiltheGoodLEDreturnstoasteadyGreen.
PWR SteadyGreentoindicatethereispowertotherepeater.
Installing the Wireless Repeater
Mountthe1100Ronaatsurfacesuchasawallorsingle-gangbox.Iftherepeaterispoweredfromanauxiliary
power supply, mount the repeater away from the metal power supply enclosure. If the repeater is powered from
theoptionalModel376plug-inpowersupply,locatetherepeaternearawalloutletnotcontrolledbyaswitch.The
1100R Wireless Repeater is typically mounted between the 1100 Series Receiver and the 1100 Series transmitter(s)
that are out of range. Locate as far from the 1100 Receiver as needed to provide the required system range. Install
therepeaterawayfromlargemetalobjects.Mountingtherepeateronornearmetalsurfacesimpairsperformance.
Whenselectingthepropermountinglocationofarepeater,refertotheLEDSurveyOperationsectiontoconrm
communication with the 1100 Receiver.
Remove the cover from the plastic housing by squeezing both sides toward each other. Secure the repeater to the
wall in the desired location using the supplied screws in the mounting hole locations as shown in Figure 1. Snap the
cover back on the unit after observing LED operation.
Powering from External 12 VDC Power Supply
The1100Rcanbepoweredfroma12VDCpowersupplysuchasaDMPModel502-12.UsethesuppliedDMPModel
378barrelconnectorwithcord,ortheequivalent5.5x2.1mmbarrelconnectorfromalocalretailoutletand22
AWGwiretoconnecttothepowersupply.Inadditiontopoweringtherepeater,thepowersupplyalsocharges
the back-up battery of the repeater. If the DC power source is removed, the power failure is indicated as an open
condition on the repeater zone.
Use the following steps to connect the power supply:
1. WhenusingtheModel378,connecttheBlackwirewithWhitestripe
totheJ6positiveterminalonthe502-12powersupplyPCBandthe
BlackwiretotheJ6negativeterminal.
2. PlugtheModel378barrelconnectorintotheJ2barreljackatthe
side of the 1100R cover. See Figure 2.
3. Ifinstallingapurchased5.5x2.1mmbarrelconnector,use22AWG
wiretoconnectthepositivewiretothepinandnegativewire(GND)
to the ring (barrel).
4. Connectthe22AWGwiretotheJ6DCconnectoronthe502-12
powersupplyPCB.Observepositiveandnegativepolarityonall
connections.
5. PlugthebarrelconnectorintotheJ3barreljackofthe1100R.
J6
+ DC -
502-12 Power
Supply
12 VDC @
2 Amps
Barrel
Connector
22 AWG Wire
Positive to Pin
Black Wire with
White Stripe
Negative (GND)
to Ring (barrel)
Black Wire
DMP Model 378
(5.5 x 2.1 mm)
- • +
Figure 2: Power Supply Connection

1100R Installation Guide Digital Monitoring Products
3
Optional External DC Plug-in Power Supply
WhenusingtheoptionalModel376plug-inDCpowersupply,mountthe
1100R near a wall outlet. In addition to powering the repeater, the DC
plug-in power supply also charges the back-up battery.
Rechargeable Battery
The 1100R rechargeable battery is used to provide up to 24 hours of
backup battery power when AC power is not available. The battery is
intended for backup power only and not to operate the 1100R Repeater
on a daily basis. If the battery is low, or not plugged into the J4 battery
connector, a low battery condition is indicated for the repeater zone.
Installing or Replacing the Battery Assembly
Observepolaritywhenpluggingthebatteryconnectorintotheheader.UseonlyDMPModel1100RBAT.Replacethe
batteryevery3years.
Removing the Battery Assembly
1. Remove the repeater housing cover.
2. Disconnect the battery lead connector from the repeater J4 battery header.
3.RemovethebatteryPCBfromthefourstandoffsbyunsnappingthetopofthe4plasticclips.
4.Properlydisposeoftheusedbattery.
Caution:Riskofre,explosion,andburns.Donotdisassemble,heatabove212°F(100°C),orincinerate.
 Properlydisposeofusedbatteries.
Installing the Battery Assembly
1.AlignthefourbatteryPCBstandoffmountingholeswiththestandoffs.SeeFigure3.
2. Snap the battery assembly in place.
3.ObservepolarityandconnectthebatteryleadconnectortotherepeaterJ4batteryheader.
J3
DC
Plug-in
Power
Supply
Barrel
Jack
Barrel
Connector
Figure 3: Side View Connection
J4 1
J1
1
Battery Assembly
Battery Assembly
Standoff
J4 1
J1
1
Figure 4: Battery Assembly

LT-0972©2008DigitalMonitoringProducts,Inc.
800-641-4282
www.dmp.com
MadeintheUSA
INTRUSION•FIRE•ACCESS•NETWORKS
2500NorthPartnershipBoulevard
Springfield,Missouri65803-8877
8413
FCC Information
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changesormodicationsmadebytheuserandnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidtheuser’sauthoritytooperatetheequipment.
NOTE: ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Specications
Battery  1100RBAT
Voltage 4.2 VDC
Capacity 800 mAh
Type  LithiumPolymer 
Rechargeable
Standby 24 hours
FrequencyRange: 903-927MHz
Dimensions
Housing 4.65”Lx3.1”Wx1.4”H
Antennas 8.6” H
Color White
HousingMaterial FlameretardantABS
Accessories
376  12VPlug-inDCPowerSupply
1100RBAT ReplacementRechargeableBattery
502-12 12VDCPowerSupply
Compatibility
1100X, 1100XI, or 1100XH Receiver using Version 106
software.
1100D, 1100DI, or 1100DH Receiver using Version 106
software.
XT50 Series panel with built-in wireless using Version 101
(11/21/08) software.
Patents
U.S.PatentNo.7,239,236
Listings and Approvals
FCCPart15ID:CCKPC0110
IndustryCanadaID:5251A-PC0110
