TC Communications TC3007 User manual

Notice!
Althougheveryefforthasbeenmadetoinsurethatthismanualiscurrent
and accurate as of date of publication, no guarantee is given or implied
that this document is error free or accurate with regard to any specifica-
tion. TC Communications, Inc. reserves the right to change or modify
the contents of this manual at any time without prior notification.
TC3007
155 Mbps FIBER OPTIC
MODE CONVERTER/REPEATER
User's Manual
© COPYRIGHT 1992-2007. ALL RIGHTS RESERVED.
MODEL:
S/N:
DATE:
TC Communications, Inc. 17881 Cartwright Road - Irvine, CA 92614

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−2−
Table Of Contents
Chapter 1 - Overview ...................................................................................................3
Description.......................................................................................................................................... 3
Data Rates........................................................................................................................................... 3
Optical Specifications ....................................................................................................................... 4
Transmission Distances (typical) .............................................................................................. 4
Launch Power & Sensitivity ....................................................................................................... 4
Front Panel LEDs, DIP Switches, and Connectors ....................................................................... 5
Rear Panel Connectors..................................................................................................................... 5
Chapter 2 - Installation ................................................................................................6
Unpacking the Unit ............................................................................................................................ 6
Equipment Location .......................................................................................................................... 6
Power Supply...................................................................................................................................... 6
Dry Contact Alarm Relay................................................................................................................... 6
Installation Diagram........................................................................................................................... 7
Chapter 3 - Troubleshooting ........................................................................................8
Chapter 4 - Specifications............................................................................................9
Appendix A................................................................................................................ 10
Return Policy ....................................................................................................................................10
Warranty ............................................................................................................................................10

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−3−
Chapter 1 - Overview
Description
The TC3007 gives users the ability to convert Multimode (or Single Mode) fiber optic signals to Single Mode
format for data transmission over a "One Fiber" optic cable. These conversions can benefit users by
extending transmission distances and/or enabling dissimilar fiber optic devices to be used with different fiber
types. The built-in Wave Division Multiplexer (WDM) enables the combination of 1310nm & 1550nm
wavelengths into one fiber for full duplex communication over a single (One) fiber. The optic receiver on the
left side detects the incoming optical signal and regenerates it for transmission through the optic transceiver.
At the receiving end, the TC3007 separates the optic signal, converts it, and retransmits it to the remote
device via its optic transmitter. The unit is available in multiple configurations depending on your
communication requirements; when both sides have the same wavelength, the TC3007 works like an optical
signalrepeater. Typically,the unit consistsofone setof MultimodeLED/ELED optics(on theleft-hand side
of the unit) and one Single Mode LASER transceiver optic (on the right-hand side of the unit).
Data Rates
155 Mbps*
*Contact factory for higher data rates.

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−4−
Optical Specifications
Transmitter: LED/ELED; typical Launch Power: -16 dBm* (1310nm, Multimode @62.5/125µm)
LASER; typical Launch Power: -6 dBm* (1310nm/1550nm, Single Mode @9/125µm)
Receiver: PIN DIODE; typical Sensitivity: -33 dBm* (1310nm, Multimode @62.5/125µm)
-36 dBm* (1310nm/1550nm, Single Mode @9/125µm)
Loss Budget: LED/ELEC; 1310nm, MM @62.5/125µm 16 dB
LASER; 1310nm/1550nm, SM @9/125µm 25 dB
Distance: 1310nm, Multimode @62.5/125µm up to 2km*
1310nm/1550nm, Single Mode @9/125µm (One Fiber) up to 80km*
Wavelength: 1310nm Multimode (LED/ELED)
1310nm/1550nm Single Mode; LASER (One Fiber)
Connector: ST or SC
*Launch power, sensitivity and distance are listed for reference only. These numbers may vary. Contact
factory for higher loss budgets.

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−5−
Front Panel LEDs, DIP Switches and Connectors
Figure 2. TC3007's Rear Panel
Figure 1. TC3007's Front Panel
Rear Panel Connectors
ALARM
PWR
APWR
B
+ -
(12-14 VDC)
@600mA
+ -
1 2 3 4
ON
Multimode Transmitter
(Tx): Connect to local
equipment's MM
Receiver (Rx).
Not Used.
Reserved
for future
functions.
Not Used.
Reserved
for future
functions.
Single Mode
Transceiver (Tx/Rx):
Connect to
remote unit's SM
Transceiver (Tx/Rx).
Multimode
Receiver (Rx):
Connect to local
equipment's MM
Transmitter (Tx).
Multimode optic receive
status: MM received optic
power is above sensitivity
threshold when lit.
Single Mode optic receive
status: SM received optic
power is above sensitivity
threshold when lit.
Alarm: When lit, it indicates
a broken fiber condition and
closure of alarm dry contact
relay (buzzer will sound).
Buzzer can be disabled by
"DISALM” switch.
DIP Switch Functions
SW1,2,3 - Not Used; reserved for future functions.
SW4 - Down (or Right) Disables the audio buzzer
and Dry Contact Relay Alarm.
Vcc: +5 VDC
operating voltage
derived from either
PWR A or PWR B
Made
i
n
U
.
S
.
A
.
V
c
c
S
M
R
X
B
A
MM RX
TCCOMM.COM
ALM
PWR
S
I
N
G
L
E
F
I
B
E
R
F
I
B
E
R
O
P
T
I
C
M
O
D
E
C
O
N
V
E
R
T
E
R
Rx
Tx
R
x
/
T
x
S
M
MM
DC Power Input Status for
PWR A and/or PWR B: Lit when
power supply is connected to
either PWR A or PWR B
connector on the rear panel

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−6−
Chapter 2 - Installation
Unpacking the Unit
Before unpacking any equipment, inspect all shipping containers for evidence of external damage caused
during transportation. The equipment should also be inspected for damage after it is removed from the
container(s).Claims concerningshipping damageshouldbe madedirectlyto thepertinentshipping agencies.
Any discrepancies should be reported immediately to the Customer Service Department at TC Communi-
cations, Inc.
Equipment Location
The TC3007 should be located in an area that provides adequate light, work space, and ventilation. Avoid
locating it next to any equipment that may produce electrical interference or strong magnetic fields, such as
elevator shafts or heavy duty power supplies. As with any electronic equipment, keep the unit from excessive
moisture, heat, vibration, and freezing temperatures.
Power Supply
Standard input power to the TC3007 is 12VDC @600mA. There are two pairs of terminal block connectors
on the rear panel (labeled "PWR A" and "PWR B"). Only one pair is required to power the unit. Polarity
is indicated on each connector block. If both pairs are connected, the built-in power redundancy feature will
beutilized. When this feature is utilized, both "A" and "B" share the load. If one power sourcefails, theother
willassume thefullload. Polarity isindicated on eachconnector block.Alternatepower sourcesareavailable
as an option (see Chapter 4 - Specifications).
Dry Contact Relay Alarm
A terminal block connector on the rear panel (labeled
"ALARM") provides for the dry contact relay alarm (see Figure
2). Normallyin theOPEN position, theloss ofeither optic signal
will trigger an alarm condition and force the switch to the
CLOSED position. This relay can be used in conjunction with
an external device to monitor the condition of the fiber optic
links. Note: If SW4 (DISALM) on the front panel is in the
Down position, the audio buzzer will not sound and the dry
contact relay will not activate.
Dry Contact Relay
Alarm Switch
To remote alarm status indicator
Max switch voltage: 100VDC
Switchcurrent: 0.5Amp
Max carry current: 1.2Amp
Contactresistance: 0.2Ohm
Reply switch specifications

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−7−
Installation Diagram
Figure 3. Installation Diagram for Dual TC3007 Application
SM Tx/Rx Tx/Rx SM
Single Mode
“One Fiber”
fiber optic cable
TC3007
Fiber Optic Mode Converter
1550nm Tx
1310nm Rx 1310nm Tx
1550nm Rx
Multimode
1310nm
User’s Device
RxTx
MM Tx
MM Rx
Multimode
fiber optic
cable
MM Rx
MM Tx
TC3007
Fiber Optic Mode Converter
Multimode
1310nm
User’s Device
Rx Tx
Multimode
fiber optic
cable

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−8−
Chapter 3 - Troubleshooting
Typically, most problems encountered with the TC3007 are related to optic receiver overdrive. The
maximum optic power that can be received without distortion is referred to as the optic receiver's "saturation
level." When the incoming optic power is greater than the saturation level of the receiver, optic "overdrive"
can occur.
The TC3007's optic receivers have a typical saturation level of -14 dBm. If the user's equipment's launch
power is higher than -14dBm (i.e. -13dBm or greater) and the fiber run is very short and has low signal loss,
it is likely to overdrive the TC3007's Multimode receiver. The consequences of overdrive can be high error
rates or the device's failure to recognize the incoming optic signal at all.
TheTC3007has been adjustedatthefactory so thattheSingleMode transmitter willnotoverdrivethe Single
Mode receiver even when short cables are used to connect them; hence, the overdrive condition happens
most frequently at the Multimode receiver optic.
If you suspect the Multimode receiver has an optic overdrive condition, a simple test will help verify it. At
the receiving optic in question, simply disconnect the optic connector and back it out of the receptacle (about
1/8 of an inch), creating a gap between the fiber connector and the receiver. Verify that the equipment is
still in "sync" with the optic signal and that the overdrive condition has been corrected. To resolve the
overdrive condition permanently, insert a 5dB or 10dB in-line attenuator into the problem link. In-line
attenuators can be purchased from Metrotek* at (727) 547-8307. The part numbers are:
Description: ST@5dB ST@10dB
Part Number: 68-JJ-7-0513 68-JJ-7-1013
The following diagram illustrates a TC3007 Mode Converter used to convert a 1300nm Multimode optical
signal from a Multimode 1310nm Transceiver (155 Mbps) into a 1550nm Single Mode optic signal to be
received by a second TC3007 with a 1550nm receiver optic. In the reverse direction, the Single Mode optic
signal is converted to Multimode format to be received by Transceiver (user's device). In-line attenuators
are used to correct optic overdrive conditions that may exist on Multimode side of the TC3007.
Figure 4. In-line Attenuator Placement Diagram
Note: Launch power measurements are taken at 155Mbps and may vary due to the actual signal's duty cycle.
*Metrotek is a corporate name and is not affiliated with TC Communications, Inc.
Multimode
1310nm
User’s Device
Tx
Tx
1550nm
Rx
1310nm
Rx
Tx Rx
Rx
1310nm
Tx
1550nm
Tx
Rx MM
MM SM
SM
1310nm MM
Multimode
1310nm
User’s Device
Tx
Rx
ATTN
10 dB
ATTN
5 dB
30073007
launch
power:
-6 dBm
receiving
power:
-17 dBm
receiving
power:
-16 dBm
launch
power:
-12 dBm
1310nm MM
1310nm MM
1310nm MM
No Saturation
on the SM side
of the TC3007
units

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−9−
Chapter 4 - Specifications
Data Rates
..........................................................................................................................165 Mbps
Optical
See page 4
Indicators
System status ......................................................................ALARM, PWR A, PWR B, Vcc
Optic Signal Status .................................................................................. MM RX, SM RX
Power Source
Standard ....................................................................................12VDC @600mA (typical)
Optional ..................24VDC, 48VDC, 125VDC or 115/230VAC with an external power cube
Temperature
Operating.....................................................................................................-10oC to 50oC
........................................................................Hi-Temp Version (Optional) -20oC to 70oC
Storage ........................................................................................................-40oC to 90oC
Humidity ..........................................................................................95% non-condensing
Physical Characteristics
Rack Mountable Card Stand Alone Unit
Height: 7.0" (17.7 cm) Height: 1.4" (3.5 cm)
Width: 1.2" (3.1 cm) Width: 7.1" (18 cm)
Depth: 5.8" (14.8 cm) Depth: 6.6" (16.6 cm)
Weight: 8.5 oz. (188 gm) Weight: 1.5 lbs. (512 gm)

TC3007 (1X9)
(LED/ELED/LASER)
User's Manual
Rev. 6.0
−10−
Appendix A
Return Policy
To return a product, you must first obtain a Return Material Authorization number from the Customer
Service Department. If the product’s warranty has expired, you will need to provide a purchase order to
authorize the repair. When returning a product for a suspected failure, please provide a description of the
problem and any results of diagnostic tests that have been conducted.
Warranty
Damages by lightning or power surges are not covered under this warranty.
All products manufactured by TC Communications, Inc. come with a five year (beginning 1-1-02)
warranty. TC Communications, Inc. warrants to the Buyer that all goods sold will perform in accordance
with the applicable data sheets, drawings or written specifications. It also warrants that, at the time of sale,
the goods will be free from defects in material or workmanship. This warranty shall apply for a period of
five years from the date of shipment, unless goods have been subject to misuse, neglect, altered or destroyed
serialnumberlabels, accidents(damages causedin wholeorinpart toaccident, lightning,power surge,floods,
fires, earthquakes, natural disasters, or Acts of God.), improper installation or maintenance, or alteration or
repair by anyone other than Seller or its authorized representative.
Buyer should notify TC Communications, Inc. promptly in writing of any claim based upon warranty, and
TC Communications, Inc., at its option, may first inspect such goods at the premises of the Buyer, or may
give written authorization to Buyer to return the goods to TC Communications, Inc., transportation charges
prepaid, for examination by TC Communications, Inc. Buyer shall bear the risk of loss until all goods
authorized to be returned are delivered to TC Communications, Inc. TC Communications, Inc. shall not be
liable for any inspection, packing or labor costs in connection with the return of goods.
In the event that TC Communications, Inc. breaches its obligation of warranty, the sole and exclusive
remedy of the Buyer is limited to replacement, repair or credit of the purchase price, at TC Communications,
Inc.’s option.
To return a product, you must first obtain a Return Material Authorization (RMA) number and RMA form
from the Customer Service Department. If the product’s warranty has expired, you will need to provide a
purchaseorder to authorizetherepair. When returningaproduct forasuspected failure, pleasefillout RMA
form provided with a description of the problem(s) and any results of diagnostic tests that have been
conducted. The shipping expense to TC Communications should be prepaid. The product should be properly
packaged and insured. After the product is repaired, TC Communications will ship the product back to the
shipper at TC's cost to U.S. domestic destinations. (Foreign customers are responsible for all shipping costs,
duties and taxes [both ways]. We will reject any packages with airway bill indicating TC communications
is responsible for Duties and Taxes. To avoid Customs Duties and Taxes, please include proper documents
indicating the product(s) are returned for repair/retest).
Table of contents
