Digital Vision BitLink Professional User manual

User's Manual
Device:
BitLink Professional HDTV
Decoder
Version:
1.1
Date:
31-October-2003
By Digital Vision
Part no.: DV-TM081001

Head Office
Digital Vision AB
Solna Strandväg 98
SE-171 54 Solna
Sweden
Tel: +46 (0)8 546 182 00
Fax: +46 (0)8 546 182 09
Sales Office, US
Digital Vision (US) Inc.
4605 Lankershim Blvd, Suite 700
North Hollywood, CA 91602
USA
Tel: +1 818 769-8111
Fax: +1 818 769-1888
Homepage
www.digitalvision.se
Copyright © Digital Vision AB, 2003
Microsoft is a registered trademark and Windows®is a registered trademark of
Microsoft.
IBM-PC™ is a trademark of International Business Machines Corporation.
ii User's Manual

Contents
1. OVERVIEW ......................................................................................................1
About the BitLink Professional HDTV Decoder ........................................................................... 1
BitLink Professional HDTV Decoder.............................................................................................. 1
Modular Approach ......................................................................................................................... 2
General Features ........................................................................................................................... 2
2. INSTALLATION ...............................................................................................3
Injury Precautions ........................................................................................................................... 3
Product Damage Precautions ........................................................................................................ 3
Packaging......................................................................................................................................... 4
Visual check................................................................................................................................... 4
Unpacking ...................................................................................................................................... 4
General Installation Instructions ................................................................................................... 4
Site Requirements ......................................................................................................................... 4
Electrical power connection ........................................................................................................... 5
Physical Data ................................................................................................................................. 5
Mounting the BitLink Decoder........................................................................................................ 5
Connecting....................................................................................................................................... 6
Transport Stream Input.................................................................................................................. 6
Video Output .................................................................................................................................. 6
Audio Output .................................................................................................................................. 6
Power............................................................................................................................................. 6
3. GETTING STARTED .......................................................................................7
General ............................................................................................................................................. 7
Front Panel operation ..................................................................................................................... 7
Display ........................................................................................................................................... 7
Status Menu ............................................................................................................................... 7
Selecting a Menu........................................................................................................................ 8
Selecting a Setting ..................................................................................................................... 8
Menu Navigation ............................................................................................................................ 8
Changing Values........................................................................................................................ 9
Alarms............................................................................................................................................ 9
Wizard menu .................................................................................................................................... 9
Input Source................................................................................................................................... 9
Program ......................................................................................................................................... 9
Audio 1 Stream ............................................................................................................................ 10
User's Manual Contents •iii

Audio 1 Decode ........................................................................................................................... 10
Audio 2 Stream ............................................................................................................................ 10
Audio 2 Decode ........................................................................................................................... 10
4. FRONT PANEL CONTROL ...........................................................................11
Input menu ..................................................................................................................................... 11
Input Source................................................................................................................................. 11
RF Settings .................................................................................................................................. 11
Frequency ................................................................................................................................ 11
Symbol Rate............................................................................................................................. 11
Video Ref ..................................................................................................................................... 11
Video Ref Pos .............................................................................................................................. 12
Output menu .................................................................................................................................. 12
Program ....................................................................................................................................... 13
Video............................................................................................................................................ 13
Output Format .......................................................................................................................... 13
Monitor Aspect ......................................................................................................................... 13
Display Mode............................................................................................................................ 13
Analogue SDTV........................................................................................................................ 13
Analogue HDTV ....................................................................................................................... 14
Test Pattern.............................................................................................................................. 14
Audio Embed............................................................................................................................ 14
CC Embed................................................................................................................................ 14
Video PID ................................................................................................................................. 14
PCR PID................................................................................................................................... 14
Audio 1......................................................................................................................................... 14
Stream...................................................................................................................................... 14
Decode ..................................................................................................................................... 15
Type ......................................................................................................................................... 15
PID............................................................................................................................................ 15
Audio 2......................................................................................................................................... 15
ASI 1 ............................................................................................................................................ 15
ASI 2 ............................................................................................................................................ 15
Auto Tune .................................................................................................................................... 15
Utilities menu ................................................................................................................................. 16
Boot Other.................................................................................................................................... 16
Load Defaults............................................................................................................................... 16
Factory Defaults ....................................................................................................................... 16
SW Upgrade ................................................................................................................................ 17
Remote Mode .............................................................................................................................. 17
Clear Alarms ................................................................................................................................ 17
Set-up menu................................................................................................................................... 18
IP Addr ......................................................................................................................................... 18
Netmask....................................................................................................................................... 18
Gateway....................................................................................................................................... 18
Network........................................................................................................................................ 18
Network Restore .......................................................................................................................... 18
Info .................................................................................................................................................. 19
Software....................................................................................................................................... 19
Hardware ..................................................................................................................................... 19
Temperature ................................................................................................................................ 19
5. WEB CONTROL ............................................................................................21
iv •Contents User's Manual

General ........................................................................................................................................... 21
Configuration ................................................................................................................................. 22
Starting ........................................................................................................................................... 22
Settings .......................................................................................................................................... 23
Preset........................................................................................................................................... 23
Input ............................................................................................................................................. 23
Demodulator ................................................................................................................................ 23
Output .......................................................................................................................................... 24
Video ........................................................................................................................................ 24
Display Format ......................................................................................................................... 24
Audio Embedding..................................................................................................................... 25
CC Embedding......................................................................................................................... 25
Audio ........................................................................................................................................ 25
Setup............................................................................................................................................... 26
Event Severities ........................................................................................................................... 26
Date & Time ................................................................................................................................. 26
Boards.......................................................................................................................................... 26
Status.............................................................................................................................................. 27
TS Info.......................................................................................................................................... 27
Decoding...................................................................................................................................... 27
Inputs ........................................................................................................................................... 27
Log .................................................................................................................................................. 28
Live Last Events........................................................................................................................... 28
Event History................................................................................................................................ 28
Upgrade .......................................................................................................................................... 29
6. SERIAL CONTROL .......................................................................................31
General ........................................................................................................................................... 31
7. CONNECTIONS.............................................................................................33
General ........................................................................................................................................... 33
ASI module..................................................................................................................................... 33
8/QPSK Demodulator module (DEM)........................................................................................... 34
Digital Video Output module (DVO)............................................................................................. 34
Analogue Video Output module (AVO) ....................................................................................... 34
Video Reference Input module (GLK) ......................................................................................... 35
Audio Output module (DAO) ........................................................................................................ 35
System Controller module (QMC)................................................................................................ 36
APPENDIX A: REAR PANEL CONNECTORS......................................................37
Analogue Audio Out ................................................................................................................. 37
User's Manual Contents •v

RS232/RS422 .......................................................................................................................... 37
Alarms/Control.......................................................................................................................... 38
APPENDIX B: EVENTS AND SEVERITIES ..........................................................39
APPENDIX C: BITLINK DECODER SPECIFICATIONS .......................................41
Video Decoding............................................................................................................................ 41
Audio Decoding............................................................................................................................ 41
Closed Caption ............................................................................................................................ 41
Control ......................................................................................................................................... 41
Power........................................................................................................................................... 42
Mechanical................................................................................................................................... 42
Environmental .............................................................................................................................. 42
Safety........................................................................................................................................... 42
ASI module (optional) .................................................................................................................. 42
QPSK Demodulator, DEM (optional) ........................................................................................... 42
Digital Video Output module, DVO (optional) .............................................................................. 43
Analogue Video Output module, AVO (optional) ......................................................................... 43
Audio Output module, DAO (optional) ......................................................................................... 43
Video Reference Module, GLK (optional).................................................................................... 43
INDEX .....................................................................................................................45
vi •Contents User's Manual

1. Overview
About the BitLink Professional HDTV Decoder
SD Ref Video Sync
Detector
PLL
Video Reference module
10/100 Base-T Web
Server
System
Controller
Control module
RS232/485 Transceiver Relays Alarms
1x Audio AES
Formatter
DAC
Audio module
SD DAC
Composite
Encoder
Analogue Video module
HD DAC
SD Audio
Embedder
Digital Video module
HD Audio
Embedder
4x Audio Emb
1x Audio AES
Formatter
DAC
Video
Decoder
RGB/YCbCr
CVBS
RGB/YCbCr
SMPTE292M
ITU-R BT.656
Analogue
Analogue
AES/EBU
AES/EBU
SD/HD Clock
H-/V-Ref Control Bus
2x L-Band Tuner
8/QPSK Demodulator
module
Demodulator TS
2x ASI Deserializer
ASI module
Serializer TS
2x ASI
TS
Audio
Decoder Switch
Audio Passthrough
Audio
Router
Demux
CC
Embedder
TS
SD/HD
Audio
Decoder Switch
Audio Passthrough
Front Panel
MPEG-2 Decoder module
4x Audio Emb
4x Audio
BitLink Professional HDTV Decoder block diagram
BitLink Professional HDTV Decoder
The BitLink Professional HDTV Decoder (hereinafter called the
BitLink Decoder) meets the highest standards in picture quality,
flexibility and reliability, for both HDTV and SDTV. The BitLink
platform affords cable, satellite and terrestrial operators, plus new
players, a cost effective and flexible way to transit to the DTV Market.
The BitLink Decoder supports extensive decoding and system modes
making it ideally suitable for use in ATSC/DVB contribution and
professional network monitoring applications.
User's Manual Overview •1

Video decoding formats cover interlaced and progressive HDTV
formats as well as SDTV for 60Hz. Both digital and analogue video
outputs are available.
The BitLink Decoder comprises of a 1RU rack-mounted, forced-air
cooled frame.
Modular Approach
The BitLink Decoder was designed with modularity as a key criteria.
This modularity facilitates easy adaptation to a number of different, and
in some cases not so obvious, decoding/DTV applications. The I/O
modules provide extensive choices in terms of transport stream
interfaces, e.g. 8/QPSK, ASI, analogue or digital video outputs, digital
and analogue audio outputs and video reference input. All transport
stream interfaces, except for the 8/QPSK demodulator, also provides
independent outputs that can be routed from any available input
module. In this way the "decoder" can be used for format conversions,
e.g. from QPSK to ASI.
General Features
MPEG-2 MP@HL and MP@ML
Transport stream input options include: ASI, QPSK
Support for up- and down-conversions
Up to two digital PCM and analogue audio pairs
Pass-through of Dolby Digital (AC-3)
Closed Caption support
Front panel, Web or Serial control
2 •Overview User's Manual

2. Installation
Injury Precautions
WARNING!
If handled improperly, this equipment can be hazardous under certain
conditions. During servicing, this equipment must be handled with care to
avoid high voltage electric shock
Below are precautionary measures that must be considered before
operating the BitLink Decoder
Do not operate without lid
To avoid electrical shock or fire hazard, do not operate this
product without lid properly attached to the units. Only
qualified personnel should perform servicing.
Use proper power cord
To avoid fire hazard, use only the power cord supplied with
this products.
Do not operate in wet or damp conditions
To avoid electrical shock or fire hazard, do not operate this
products in wet or damp conditions.
Product Damage Precautions
WARNING!
Turn off AC power to the chassis before removing or installing printed circuit
assemblies, as this could result in serious damage to the unit’s components.
Below are precautionary measures that must be considered before
operating the BitLink Decoder
Use proper power source
Do not operate this product from a power source that supplies
more or less than the voltage specified for the products.
Provide proper ventilation
User’s Manual Installation •3

To prevent product overheating, provide proper ventilation and
do not obstruct the ventilation areas on the units.
Do not operate with suspected failures
If you suspect there is damage to the products, have it
inspected by qualified service personnel. Do not attempt to
repair the failure even if you suspect it may be a minor
problem.
Packaging
Visual check
When you receive the BitLink Decoder, examine the package for
obvious signs of damage. The delivery should not be accepted if the
packaging is damaged.
Open the packaging carefully and check for any obvious product
damage incurred during shipping. If there is any damage please contact
your distributor immediately.
Unpacking
Check the equipment against the delivery/packing note when
unpacked.
Retain the packaging, as it is required for warranty shipments.
Don’t grasp the unit’s front panel when unpacking.
General Installation Instructions
WARNING!
These installation instructions are for use by trained personnel only. To
reduce risk of electric shock, refer servicing to qualified personnel only.
Site Requirements
An ambient temperature should be maintained between 10 deg C (45
deg F) and 40 deg C (104 deg F) at a relative humidity of 10-90% (non-
condensing)
WARNING!
To avoid electric shock, never remove the unit’s lid. There are no user
serviceable parts inside. Refer servicing to qualified personnel. Failure to
comply may result in equipment damage and/or personal injury.
WARNING!
Always remove main cord from unit before removing the front panel or the I/O
modules.
4 •Installation User's Manual

Electrical power connection
WARNING!
The equipment must be grounded to avoid electrical shock. Failure to ground
the unit may cause equipment damage and/or personal injury. Particular
attention should be given to supply connections when connecting to power
strips rather then direct connections to branch circuits.
Physical Data
Height 1RU
Width 19” (483 mm)
Depth 18,1” (461 mm)
Weight (approx) 1) 9 kg
Power (Max) 1) 60 W
Voltage 90-120 V /60 Hz
Fuse 2,0 A (slow)
1) Depending on configuration
Also see Appendix B for full specification.
Mounting the BitLink Decoder
The BitLink Decoder has forced cooling with airflow from left to right.
When installing the BitLink Decoder, it must be placed so that there is a
gap of minimum 1 inch (25 mm) on the both sides of the unit to allow
for proper cooling.
1 inch 1 inch
Top view
Front
Air
flow
User’s Manual Installation •5

The BitLink Decoder can be mounted directly in a 19” rack, using the
supplied rack mounting hardware (for both front and rear side).
WARNING!
Do not put any extra weight on top of the BitLink Decoder when mounted in a
rack.
Connecting
Transport Stream Input
Ensure you have a valid transport stream on either the ASI or the RF
(demodulator) input.
Default (out of the box) setting is ASI 1.
Note! Coaxial cables for ASI inputs and outputs must be double-shielded.
Video Output
Use one of the video outputs and connect to your monitor.
Note! Coaxial cables for SDI outputs must be double-shielded.
Audio Output
Connect the audio output (if available) from the BitLink Decoder to an
audio amplifier or similar.
Default (out of the box) setting is decoded audio, available on both
analogue and digital outputs.
Power
After connecting TS, Video and Audio, power up the unit.
For detailed information on connectors, see Connections, page 33.
6 •Installation User's Manual

3. Getting Started
General
This section will quickly guide you through the basics of operation and
how to connect and set up the BitLink Decoder from the front panel.
Front Panel operation
BitLink Decoder front panel
Display
The display on the front of the BitLink Decoder is a 2x24 character
backlit LCD display and is used to show status, menu selections and
settings.
Status Menu
When powering up the BitLink Decoder, the Status menu appears. The
Status menu has four different pages, which are navigated using the left
and the right arrow button.
Main status and video format
Prg_#3_ASI1_Trans_DD
Pid_49,_480i/29.97
Selected
program
Video PID Decoded video
stream format
Selected
input source
Output
format
Audio 1 & 2 format
D = Dolby Digital (decode)
d = Dolby Digital (bypass)
M = MPEG (decode)
m = mpeg (bypass)
User’s Manual Getting Started •7

Audio channel 1 status
Audio_channel_1:
Pid_52,_AC3
Audio channel 2 status
Audio_channel_2:
Pid_53,_AC3
RF input level status
RF_-34.55_dBm
BER_0E-6_/_1.5E-15
To return to the Status menu after settings has been changed or menus
have been browsed press the cancel button until the Status menu is
shown again.
Selecting a Menu
MAIN_MENU
Status__>Wizard<___Input
Current Menu
Menus
Selecting a Setting
AUDIO_1_TYPE_(AC-3)
PCM_____>AC-3<___Dolby-E
Current Menu
Settings
Current Setting
Menu Navigation
Navigation Buttons
Press Enter to enter a new menu, selecting a setting to change
and confirm the change
Use the Arrow buttons to go up or down in the menu
structure, browse through a menu or to change settings
Press Cancel to return to a higher level in the menu structure
8 •Getting Started User's Manual

Changing Values
Values (e.g. PIDs) may be modified by first selecting the digit using the
left or right arrow button and then increase with the up arrow button or
decrease with the down arrow button.
Confirm modified value with the Enter button or press the Cancel
button to cancel the change.
Alarms
Alarm Indicators
Alarms (or events) occurring are indicated on the front panel with
different severities; Warning, Minor Alarm and Major Alarm. The Web
interface provides information on the alarm source and an event history.
Alarms are also indicated via the Alarms connector on the rear.
To clear/reset alarms, select menu item Utilities > Clear Alarms.
The severity levels can be changed in the Web interface. Also see
Appendix B for default severity levels.
Wizard menu
Wizard
Input
Output
Utilities
Set-up
Info
Input Source
Program
Audio 1 Stream
Audio 1 Decode
Audio 2 Stream
Audio 2 Decode
ASI 1
ASI 2
RF 1
RF 2
<Select Program>
<Select Stream>
On
Bypass
<Select Stream>
On
Bypass
The Wizard is used to quickly set up the BitLink Decoder. More
advanced settings are available in the other menus.
Confirm and go to next menu item by pressing Enter.
Use Up and Down arrows to step between menu items.
Exit the Wizard by pressing Cancel.
Input Source
Select which input (ASI 1, ASI 2, RF 1 or RF 2) to be used.
Program
Select which Program in the transport stream to decode.
User’s Manual Getting Started •9

Audio 1 Stream
The channel selection provides a list of available audio streams found in
the transport stream. The selection is output to audio out 1.
Audio 1 Decode
The Decode control selects whether the audio is to be decoded (on) or
sent undecoded (bypass) to digital audio out 1.
Audio 2 Stream
The channel selection provides a list of available audio streams found in
the transport stream. The selection is output to audio out 2.
Audio 2 Decode
The Decode control selects whether the audio is to be decoded (on) or
sent undecoded (bypass) to digital audio out 2.
10 •Getting Started User's Manual

4. Front Panel Control
Input menu
Wizard
Input
Output
Utilities
Set-up
Info
Input Source
RF Settings
Video Ref
Video Ref Pos
ASI 1
ASI 2
RF 1
RF 2
Frequency
Symbol Rate
Stream PCR
External
<Enter Frequency>
<Enter Symbol Rate>
SDTV Horizontal
SDTV Vertical
HDTV Horizontal
HDTV Vertical
<Enter Pos>
<Enter Pos>
<Enter Pos>
<Enter Pos>
Input Source
Input > Input Source
The Input Source selection determines which TS input that will be
decoded.
RF Settings
The controls found in the RF Settings menu are used for the optional
QPSK Demodulator.
Frequency
Input > RF Settings > Frequency
Sets L-band frequency, 950 000 – 2 150 000 kHz
Symbol Rate
Input > RF Settings > Symbol Rate
Sets Symbol rate, 1 000 000 – 45 000 000 baud.
Video Ref
Input > Video Ref
User’s Manual Front Panel Control •11

This control determines whether the video and audio outputs should be
locked to the PCR (from the stream) or to an external video reference
connected to the optional Video Reference module (GLK).
For detailed information on connectors, see Connections, page 33.
Video Ref Pos
Input > Video Ref Pos
Adjusts the video relative the video ref position up to ±1000
pixels/lines with 1 pixel/line resolution.
Audio is not affected.
Output menu
Wizard
Input
Output
Utilities
Set-up
Info
Program
Video
Audio 1
Audio 2
ASI 1
ASI 2
Auto Tune
Transparent
SDTV
HDTV
4:3
16:9
Auto
Full Frame
Bars
<Enter Video PID>
<Enter PCR PID>
<Select Stream>
On
Bypass
AC-3
MPEG-1
<Enter PID>
<Select Stream>
On
Bypass
AC-3
MPEG-1
<Enter PID>
Output Format
Monitor Aspect
Display Mode
Analogue SDTV
Analogue HDTV
Test Pattern
Audio Embed
CC Embed
Video PID
PCR PID
<Select Program>
Stream
Decode
Type
PID
Stream
Decode
Type
PID
ASI 1
ASI 2
RF
ASI 1
ASI 2
RF
Cancel
Auto Tune
RGB
YPbPr
CVBS
RGB
YPbPr
On
Off
Auto
Off
Force Bypass
Off
SDTV
HDTV
12 •Front Panel Control User's Manual

Program
Output > Program
The BitLink Decoder scans the transport stream and extracts the
program information. Select the program to output from the list of the
identified programs in the stream.
Video
Output Format
Output > Video > Output Format
This control selects the video format to be displayed. Current selections
available are:
Transparent SD streams are displayed on the SD output. HD
streams are displayed on the HD output.
SDTV All streams are displayed on the SD output. HD
streams are downconverted to SD.
HDTV All streams are displayed on the HD output. SD
streams are upconverted to HD.
Monitor Aspect
Output > Video > Monitor Aspect
Determines the aspect ratio of the SDTV monitor (4:3 or 16:9). HDTV
monitors are always 16:9.
Display Mode
Output > Video > Display Mode
The Display Mode control determines how the stream is displayed:
Auto Does not change the picture.
Full Frame If the aspect ratio flag in the stream is set to 16:9, then
the output picture is cropped for 4:3 monitors.
Bars Compresses the picture either horizontally or vertically
adding black bars depending on Monitor Aspect setting.
Ignores the aspect ratio flag in the stream.
If Monitor Aspect has been set to 4:3, the
picture is compressed to letterbox format
(including horizontal bars).
If Monitor Aspect has been set to 16:9, the
picture is compressed horizontally and
vertical bars are displayed.
Analogue SDTV
Output > Video > Analogue SDTV
Select whether the analogue SDTV output format should be RGB,
YPbPr or CVBS.
User’s Manual Front Panel Control •13

Analogue HDTV
Output > Video > Analogue HDTV
Select whether the analogue HDTV output format should be RGB or
YPbPr.
Note! If YPbPr is selected, the VGA output does not have a valid signal.
Test Pattern
Output > Video > Test Pattern
The BitLink Decoder can output a colour bar test pattern to verify that
video is available. Select SDTV for a test pattern on the SD output or
HDTV for a test pattern on the HD output. Normally off.
Audio Embed
Output > Video > Audio Embed
Enable to embed audio on the optional SDI outputs.
Auto Embeds the audio, encoded or decoded, according to
the Audio Decode setting.
Off No audio embedding.
Force Bypass Embeds the audio from the stream independent of
Audio Decode setting.
CC Embed
Output > Video > CC Embed
Enable to embed Closed Caption on the video outputs.
Video PID
Output > Video > Video PID
Manual selection of Video PID if not available in the current program.
Normally the Program selection will automatically also set the PID.
PCR PID
Output > Video > PCR PID
Manual selection of PCR PID if not available in the current program.
Normally the Program selection will automatically also set the PID.
Audio 1
The settings found under menu Output > Audio 1 are used for audio
output 1. Settings for audio out 2 are identical and found under menu
Output > Audio 2.
Stream
Output > Audio 1 > Stream
The channel selection provides a list of available audio streams found in
the transport stream. The selection is output to audio out 1.
14 •Front Panel Control User's Manual
