Digital Watchdog DWC-P230FMW User manual

DWC-P230FMW
Flush mount for white IP PTZ cameras
Quick Start Guide
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results
for applicable part numbers will populate automatically based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
WHAT’S IN THE BOX
Magnetic Cover 1Quick Setup Guide 1
Safety Wire 2Mounting Template 1
Mounting Screws 2
MOUNTING
TEMPLATE
Ø275,0
MOUNTING
TEMPLATE
Ø275,0
MOUNTING
TEMPLATE
Ø275,0
MOUNTING
TEMPLATE
Ø275,0
MOUNTING
TEMPLATE
Ø275,0

PREPARE THE FLUSH MOUNT FOR INSTALLATION
INSTALLATION
Quick Start Guide
Rev Date: 07/21
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
1. Detach the magnetic cover from the mount base.
2. Remove the three (3) screws to disconnect the mounting plate
from the mounting base.
When using the flush mount, the camera cannot be tilted
more than 20°
1. Using the mounting template mark and drill the necessary holes
in the mounting surface.
2. Connect the first safety wire between the flush mount’s base and
the mounting surface.
3. Adjust the 3-point in-ceiling wing using a screwdriver. Twist the
screws to tighten and expand until the flush mount is secured to
the mounting surface.
4. Pass the wires through the flush mount base.
5. Remove the camera’s base from the camera module by rotating
the base clockwise to the unlock position.
UNLOCK LOCK
6. Connect the camera base to the mounting plate by rotating it
clockwise and secure it with the two (2) mount screws included.
7. Use the second safety wire to secure the camera base and
mounting plate to the mounting base.
8. Connect all wires to the camera.
9. Attach the camera’s body and mounting plate to the camera base and
mounting plate by rotating the base counter-clockwise to the lock
position.
10. Place the dome on the camera module by securing the screws at the
base of the dome.
11. Connect the mounting plate inside to the upper part of the mounting
base using the three (3) screws.
Upper part
12. Attach the magnetic cover to the mounting base by aligning the
connecting points as seen in the image below.
Lower part
13. Remove the protection film when the installation is complete.
Wings
Mounting base
Camera connector neck
Camera base
Mounting plate
Mounting base
