Digital Watchdog STAR-LIGHT PLUS DWC-D4883WTIRW User manual

Quick Start Guide Quick Start Guide
1. The mounting surface must withstand five times the weight of
your camera.
2. Do not let the cables get caught in improper places or the electric
line cover can be damaged. This may cause a short or fire.
3. Detach the camera’s dome cover by pressing on the two small
buttons located at each side of the cover dome.
4. Remove the dome protective film before placing the dome back
on the camera base.
STEP 1 – PREPARING TO MOUNT THE CAMERA
Pass the wires through the mount bracket and make all
necessary connections. Connect the BNC cable and power
cables to the camera.
STEP 2 – CABLING THE CAMERA TO
EXTERNAL DEVICES
Power
Requirements Power Consumption
DC12V/AC24V
dual voltage
DC12V (LED o): 5.76W, 480mA
DC12V (LED on): 7.92W, 660mA
AC24V (LED o): 6.49W, 429mA
AC24V (LED on): 7.15W, 495mA
DWC-D4883WTIRW
WHAT’S IN THE BOX
DC plug
cable 1
Quick
setup
guide
1
Screws and
anchors –
2pcs
1 set Test video
cable 1
Mounting
template 1
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Protective cover
Protective film
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Tel: [phone]
Technical Support Hours:
9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
Attention: This document is intended to serve as a quick reference for the
initial setup. It is recommended that the user read the entire instruction
manual for complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in
the ‘Search by Product’ search bar. Results for
applicable part numbers will populate automatically
based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.

Quick Start Guide
1. The camera supports HD-Analog, HD-CVI and HD-TVI signals as
well as CVBS up to 960H. To switch between the signals:
a. Enter the camera’s OSD menu. You can access it locally from
using the camera’s joystick in the body of the camera, or from a
recorder supporting UTC communication.
Go to SETUP > OUTPUT.
b. Set the camera’s resolution from the following options:
- 4K/2160p @15fps.
- 5MP/1440 @30fps.
- 2.1MP/1080p @30fps.
c. Set the camera’s analog signal output from the following options:
- HD-A - HD-Analog
- HD-T - HD-TVI
- HD-C - HD-CVI
- CVBS - legacy analog signal
d. Change CONFIRM to ON to save the changes.
e. Go to the EXIT menu and select SAVE&EXIT to save all changes.
The camera signal automatically.
1. Once all cables have been connected, use the screws included
with the camera to properly mount and secure the camera to the
mounting surface.
2. Adjust the camera’s pan, tilt and position to achieve the desired view.
The cameras’ max angles are:
Pan: 0°~ 360°
Tilt: 0°~ 75°
Rotation: 0°~ 350°
3. To adjust the camera’s zoom and focus, use the lever at the base of
the camera’s module.
a. Move the lever up to zoom in.
b. Move the lever down to zoom out.
c. Move the lever to the left to adjust focus to near.
d. Move the lever to the right to adjust focus to far.
4. Once the installation is complete, remove the protective film from
the camera’s dome cover.
STEP 4 – INSTALLING THE CAMERASTEP 3 – CHANGING THE SIGNAL IN
THE CAMERA
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.Rev Date: 01/20
NOTE: To use your Star-Light Plus™ 4K cameras at a lower
resolution, you must use a VMAX® A1 4K DVR to access the
camera’s menu due to the cameras being set to 4K as the
default. A DVR that does not support 4K resolution may
recognize the camera, but will not deliver a picture.
Mounting template
