DL-UHDILC Quick Install Guide
Important noce:
• Do not aempt to disassemble or alter the housing. There are no user-serviceable parts
inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostac discharge (ESD), all source and
desnaon equipment must be powered o during installaon.
• Do not connect the device to a telecommunicaon outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through
(point-to-point).
• Allow proper venlaon to reduce the risk of thermal failure.
This guide is for quick installaon only.
For complete owners manual go to www.libav.com or use a QR code reader to
access the manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

DL-UHDILC Quick Guide
The DigitaLinx DL-UHDILC is an HDMI in-line controller that can automate room
peripherals and sink devices when a video signal is introduced to the unit. The
DL-UHDILC is 4K compable, supports HDCP version 2.2, has an analog and digital
de-embedded audio output and has 15 built in EDID presets that can be adjusted by
the rotary dial on the front panel.
When the DL-UHDILC auto-detects an input video signal, the DL-UHDILC will
automacally turn a display or projector on either by CEC or by pre-loaded RS232
serial commands. The DL-UHDILC will trigger the rst relay port to switch a projector
screen or window shade down. When a video signal is no longer present aer a
specied amount of me, the DL-UHDILC will turn o the display or projector by
either CEC or pre-loaded RS232 commands and will trigger the second relay port to
switch a projector screen or window shade up.
Front / Rear Panel
1. DC12V - Locking DC 12V power connector with POWER on/o indicator
2. HDMI IN - Video input; connects to video source
3. EDID - Rotary dial for 15 resoluon presets
• The EDID preset chart is located on the boom of the DL-UHDILC
4. S/PDIF OUT - Digital audio de-embedded output; connects to an AVR or audio amplier
5. AUDIO OUT - Analog audio de-embedded output; connects to an AVR or audio amplier
6. RELAY1 / RELAY2 - Relay triggers; connects to projector screen or window shade relay controls
7. HDMI OUT- Video output; connects to display or projector
8. RS232 - Control port; connects to and controls display device with pre-loaded RS232 serial
commands
• NOTE: The RS232 port can be congured by connecng a computer with a serial to
USB adapter to the DL-UHDILC RS232 port and using the Display Control soware to congure
the port. The serial upload soware is located on the DL-UHDILC product page Online at www.
libav.com

DL-UHDILC Quick Guide
Package Contents
• (1) DL-UHDILC
• (1) DC12 0.5A Power Adapter
• (3) Phoenix 3.5mm 3 pin Male Connectors
• (1) RS232 to 3 pin Phoenix Breakout Cable
Connecvity Instrucons
1. Verify all components included are present before installaon.
2. Connect an HDMI source device to the HDMI IN port using an HDMI cable
3. Connect a display device to the HDMI OUT port using an HDMI cable
4. Adjust EDID preset for desired resoluon seng
5. Connect either S/PDIF OUT or AUDIO OUT to an audio amplier or AVR for audio
reinforcement with an RCA or 3.5mm audio .cable
6. Connect RELAY1 / RELAY2 to the relay pins of a relay switch on a projector screen
or window shade with a shielded 2 conductor cable such as the Liberty 22-1P-EZ
cable
• RELAY1 will automacally switch from normally open (NO) to normally closed (NC) when a
video signal is introduced to the system. RELAY2 will automacally switch from normally open
(NO) to normally closed (NC) when a video signal is absent from system aer a specied me
that has been determined by the serial upload soware
7. Connect the 3 pin phoenix connector of the RS232 breakout cable to the RS232
port on the DL-UHDILC, then connect the DB-9 side of the breakout cable to a
DB9 cable to connect that will connect to the sink device
• NOTE: The RS232 port on the DigitaLinx DL-UHDILC can be congured by connecng a
computer to the RS232 port of the DL-UHDILC and by using the Display Control soware which
is located on the DL-UHDILC product page Online at www.libav.com.
8. Apply power to DL-UHDILC

DL-UHDILC Quick Guide
REV 170506
Liberty AV Soluons
11675 Ridgeline Drive
Colorado Springs, CO 80918
800-530-8998
[e-mail]
Technical Specicaons
VIDEO
Video Inputs (1) HDMI
Video Input Connector (1) HDMI type A
Video Output (1) HDMI
Video Output Connector (1) HDMI type A
Maximum Pixel Clock 600Mhz
Output Resoluon Support 4096x2160; 3840x2160; 1920x1200; 1920x1080; 1680x1050; 1600x1200;
1600x900; 1440x900; 1400x1050; 1366x768; 1360x768; 1280x1024;
1280x960; 1280x800; 1280x768; 1024x768; 800x600
Standards Compliant with HDMI 1.4 & HDCP2.2
Audio
Audio Output (1) S/PDIF
(1) Analog
Audio Output Connector (1) RCA
(1) Stereo 3.5mm
Frequency Response 20Hz~20K Hz
CONTROL
Control Port (2) RELAY
(1) RS232
Control Connector (2) 3 pin phoenix connector (RELAY)
(1) 3 pin phoenix connector (RS232)
Other
Temperature 0 ~ +45 C (32 F - 113 F)
Humidity 10% ~ 90%
Power Supply DC12V 0.5A
Power Consumpon <3W
Dimension (W*H*D) 4.72” x .79” x 3.15”
Weight .5 lbs
Warranty 2 years
Included Accessories (1) Power adapter (12VDC, 0.5A); (1) RS232 to 3 pin phoenix breakout cable;
(3) 3 pin phoenix male connectors; (1) Quick Install Guide
