Dimplex ESTHETIC SERIES User manual

“ESTHETIC” CONVECTOR HEATER SERIES
STEP-BY-STEP INSTALLATION (Note: Please read all instructions before installing)
WARNING
The installation of the convector heater must comply with the applicable
Local and/or National Electrical Codes and utility requirements. This
installation should be entrusted to duly qualified personnel where required
by law.
NOTE
Due to the precision of the convector’s control circuits, the unit is highly
sensitive to air drafts, cold floors, etc. To ensure the thermostat operates
efficiently, be sure to carefully choose the units location before installing.
Avoid installing unit in an area that is susceptible to cold drafts, or near a
cold floor.
WARNING
The convector must be installed in a location preventing anyone using a
bath or shower from touching the control devices.
WARNING
The convector must not be located directly below a fixed power outlet.
CAUTION
The minimum distances between the convector and any object in its
immediate vicinity must be observed to ensure correct operation (Figure 1).
1. Remove the tie wrap from electric cable.
2. Remove the mounting bracket from the rear of the convector casing by
squeezing the release tabs at the top of the bracket and pulling out of
the casing.
3. Place the bracket on the wall at the desired location, and mark the
mounting hole locations using the bracket as a template (Figure 2).
4. Secure the mounting bracket to the wall (Figure 2) using suitable
screws (not included).
5. Install a power receptacle box on the wall next to the convector
mounting bracket.
NOTE
The heater can be installed so the wall receptacle box can be hidden.
6. Feed the power supply wiring into the power receptacle box.
7. Install the convector onto the bottom tabs of the mounting bracket.
8. Snap the top of the convector casing onto the top tabs to secure the
convector to the bracket.
9. Connect the power supply wiring to the convector heater wiring
(Figure 3).
10. Install receptacle box cover.
NOTE
If the power receptacle box is located behind the heater the heater is to be
wire connected and then installed to the mounting bracket.
SAFETY PRECAUTIONS
WARNING
Secure convention heater to wall bracket before using.
1. Do not cover your heating unit in any way. The “DO NOT COVER”
warning tag is there to remind you that any materials covering the
units can catch fire.
2. Do not mask the heating unit with furniture or curtains, as this will
interfere with the operation of the convector.
3. Regularly clean and dust the inlet and outlet grid.
GREEN WIRE – GROUND
BLACK WIRE – POWER
WHITE WIRE – POWER
CONVECTOR HEATER
FIGURE 2
FIGURE 3
1
FIGURE 1
7204310000REV02

START UP
Description
The unit comprises of:
1. A thermostat control knob graduated MINI to MAXI, located in the
control box on the right side (Figure 4).
2. A mode selection knob, indicating the various operating modes
(Figure 3).
i. “PROG” position
The temperature will be the value set using the thermostat control
knob.
ii. “STOP” position
The convector will be placed on standby mode.
iii. “COMF” position
The temperature will be the value set using the thermostat control
knob.
iv. “ECO” position
The temperature will be the value set using the thermostat control
knob less 3.5°C ±0.5°
v. “FREEZE GUARD” position
The temperature will remain at around 7°C (45°F) regardless of the
setting selected on the thermostat control knob.
Setting the room temperature
For a perfect adjustment:
1. Place a thermometer at the center of the room 4ft (1.20m) off the ground (doors and windows closed)
2. Set the mode selection control knob to the comfort position “COMF”.
3. Set the thermostat control knob to the maximum position.
4. Once the desired ambient temperature is reached, for example, when the thermometer indicates 20°C (68°F), slowly turn
back the thermostat control knob until the heating indicator light goes off. Once set, the thermostat will automatically
maintain this temperature in the room by switching the power supply to the unit on and off as required.
OPERATION
1. This unit is supplied with a manual reset temperature limit cutout, which will switch-off the heater should it overheat for
any reason.
2. If the cutout operates, it is the result of abnormal overheating. The source of the overheating must be found and
corrected.
3. After the source of the problem is found and corrected, the reset button can be pushed-in to re-energize the convector.
The reset button is located on the back of the convector casing, along the top edge.
REMOVING THE CONVECTOR
WARNING
Only qualified, approved personnel are authorized to work on our equipment. The convector must be disconnected from the
power supply before starting any work.
1. Before removing the unit from its mounting bracket ensure the power is disconnected.
2. Remove the power receptacle box cover from the wall.
3. Disconnect the convector from the power supply leads.
4. Remove the convector casing from the mounting brackets by squeezing the top release tabs.
5. Lift the convector off the bottom tabs.
PRACTICAL ADVICE
Economic Operation
1. Do not overheat your home by degrees above 20°C (68°F) as your power consumption could increase by 10%.
2. Cut off the power supply to your heating units (“STOP” position) when you vent your rooms for any lengthy period of time.
3. Whenever your don’t use a room (guest room) or if you don’t use your home for any extended period of time (vacation),
set your heating units to the “FREEZE GUARD” position.
Operating Precautions
1. To ensure regular operation of all the heating units in a single room, the thermostats must be set to the same
temperature.
2. Avoid operating a few heating units continuously to heat your entire home as this can result in disorders; unbalanced
heating, reduced comfort, excess consumption and micro-condensation.
3. Switch off the heating units in rooms where a chimney is being used to avoid wasted energy and to prevent circulating
smut and ashes through the convector and into the room.
The descriptions and characteristics are given for information only and are subject to modification with no prior notification
FIGURE 4
2

IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
PLEASE RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
1. Read all instructions before using this convector.
2. This convector is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The grille directly
in front of the heater outlet becomes hot during heater operation. Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes and curtains at least 3 feet (0.9m) from the front of unit.
3. Extreme caution is necessary when any heater is used near children or invalids and whenever the convector
is left operating and unattended.
4. The appliance is not intended for use by young children or infirm persons without supervision.
5. Young children should be supervised to ensure that they do not play with the appliance.
6. Do not operate if the convector has malfunctioned, or if it has been dropped or damaged in any manner.
Contact an authorized service facility for examination, electrical or mechanical adjustment or repair.
7. Do not use outdoors.
8. This convector is not intended for use in bathrooms, laundry areas, damp basements or other areas where
water or moisture may be present.
9. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric
shock or fire, or damage the heater.
10. Do not locate the convector immediately below a fixed socket or connection box.
11. To prevent a possible fire, do not block air intake or exhaust in any manner. Do not use on soft surfaces, like
a bed, where openings may become blocked.
12. All electrical heaters have hot and arcing or sparking parts inside. Do not use in areas where gasoline, paint,
or flammable liquids are used or stored or where the unit will be exposed to flammable vapours.
13. Do not modify this convector. Use it only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock or injury to persons.
14.Always disconnect power before performing any cleaning, maintenance or relocation of the convector.
NOTE: Procedures and techniques that are considered important enough to emphasize.
CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment.
WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of serious
injury or death.
3

LIMITED WARRANTY
In Canada:
CHROMALOX™ products are tested and inspected prior to shipment and are guaranteed from defect to the
purchaser of each new product. Any part that proves to be defective in material or workmanship under normal
use within one year will be repaired or replaced without charge. The Company will not be responsible for any
expense incurred for installation, removal from service, or transportation costs. Any such defect should be
brought to the attention of the Company’s office where the product was purchased and is authorized to repair or
replace within the terms of the warranty. The warranty will not apply if, in the judgement of the Company, damage
or failure has resulted from accident, alteration, misuse, abuse, incorrect installation, or operation on an incorrect
power source. The foregoing is in lieu of all other warranties expressed, implied or statutory, and neither
assumes, nor authorizes any person to assume for it any other obligation, or liability in connection with said
product. Since the paint finish can be damaged through use no warranty applies to the paint finish, except from
manufacturing defects, which become apparent within 30 days from the date of installation. CHROMALOX™
EXTENDED WARRANTY: All CHROMALOX™ baseboard elements are warranted, subject to the above
conditions, to be free from defect in material and workmanship for ten years.
In the United States of America:
All Electromode products are warranted against defects in workmanship and materials for one year from date of
sale. This warranty does not apply to damage from accident, misuse, not where the connected voltage is more
than 5% above the nameplate voltage, nor to equipment improperly installed or wired or maintained in violation of
the instruction sheet. This warranty is valid in the fifty States of the United States. No other written or oral
warranty applies. No employee, agent, dealer or other person is authorized to give any warranties on behalf of
Electromode. The customer shall be responsible for all costs incurred in the removal or reinstallation and
shipping of the product for repairs. Within the limitations of this warranty, inoperative units shall be returned to the
nearest Electromode Authorized Service Center, and we shall repair or replace, at our option, at no charge to you
with return freight paid by Electromode. It is agreed that such repair or replacement is the exclusive remedy
available from Electromode and that ELECTROMODE IS NOT RESPONSIBLE FOR DAMAGES OF ANY KIND,
INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGE. Some States do not allow the exclusion or
limitation of consequential damages, so the above exclusion or limitation of consequential damages, so the above
exclusion or limitation may not apply to you. This warranty gives you specific legal rights and you may also have
other rights, which may vary from State to State.
