Dino-Power DP-3000 User manual

Page 1 of 13
User Manual
Drywall Sander
Model: DP-3000
www.dpairless.com

Page 2 of 13
1. PRODUCT DESCRIPTION
The machine is designed for sanding drywalls, ceilings and walls of the inner and outer surfaces,
clearing the floor residues, paint coatings, adhesive and loose plaster etc.
Our machine is not suitable for processing the object containing asbestos.
You must abide by certain safety precautions when using the equipment. In order to
prevent injuries and damages from occurring, you must always read through this operating manual
carefully.
This manual must be kept in a safe place so that the information that it contains is always available. This
operating manual must accompany the equipment if it is transferred to somebody else.
We do not accept any liability for accidents or damage arising from ignoring this manual and the safety
instructions.
2. SPECIFICATIONS
Model No.
DP-3000
Power
800W
No Load Speed
800-1700 /min
Grinding pad diameter
215mm
Sandpaper diameter
225mm
Tube diameter
32mm
Weight
4.2kg
Protection class
回/Ⅱ

Page 3 of 13
3. SAFETY INSTRUCTIONS
The following pictograms appear throughout these operating instructions:
Indicates danger of injury, risk to life and possible damage to the appliance if
these instructions are not followed.
Indicates the presence of electric shocks.
Read through these operating instructions carefully before using the appliance. Become familiar with the
functions and method of operation. To ensure proper operation, always maintain the appliance according to the
instructions. The operating instructions and associated documents should always be kept close to the appliance.
When using power tools, you must observe the following basic safety precautions in order to ensure protection
from electric shocks, injury and fire. Read and follow all the instructions before using this power tool. Look after
the notes on safety.
Always check if your mains voltage corresponds with the value on the type plate
The machine has been double-insulated in accordance with EN60745: therefore, an earth wire
is not necessary
USE CORRECT SUPPLY VOLTAGE: The power supply voltage must match the information quoted on the
tools identification plate.
USE PROPER EXTENSION CORD: Only use an approved extension cable that is suitable for the machine's
power. The cord must have a diameter of at least 1.5mm2.When the extension cable is on a reel, unroll the cable
in its entirety.
SWITCH OFF THE MACHINE IMMEDIATELY IN CASE OF:
1. Malfunction in the mains plug, power cable or damaging of cable.
2. Broken switch.
3. Smoke or stench of scorched insulation.
4. GENERAL SAFETY RULES
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.

Page 4 of 13
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not
use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energizing power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.

Page 5 of 13
5. PRECAUTIONA ON USING DRYWALL SANDER
Attention! You must abide by the following basic safety measures against electrical shocks, injuries and the
danger of fire when using electric tools. Read and abide by these instructions before you start to use any tools.
These instructions must be kept in a safe place.
_ The equipment must never be used in surroundings where an explosive atmosphere exists.
_ Do not let the cable touch any parts of your body.
_ Only use the extension cable approved for use in the working area.
_ Do not force the machine for unsuitable work, for example, rough grinding, brushing, etc. Otherwise,
dangers and harms will be caused.
-- Only use identical replacement parts when servicing. Otherwise, risk-free operation can’t be guaranteed.
--The accessories’ allowed speed must be at least the same as the maximum speed of the machine. Or else,
they may be broken or cracked when their running speed is go over the machine’s allowed speed.
--Do not use damaged accessories. Before use, always check whether the accessories are nicked or cracked.
For example, to grinding pad, please check the support plate is not cracked. Ensure everybody to be out of
the machine’s rotation area and run the machine at max. speed for one minute, which can fully test the
accessories.
-- Do not put down the machine when it isn’t stopped completely. Otherwise, you will loss control to the
machine.
-- Cleaning the exhaust port on your machine in regular.
When working, control the machine firmly with both hands to ensure safe operation.
--When sanding, do not use too big sandpaper. When choosing grinding disc, please observe the
manufacturer's specifications. The sand paper beyond the grinding block leads to risk of cutting and injury and
cause stuck as well.
--The machine can be connect to one extension tubes at most.
-- We recommend that you always wear industrial safety gloves and safety goggles when working with the
drywall sander.
-- Wearing close-fitting clothes is mandatory.
-- Always allow for reaction torque
-- Wear protection mask P2 to protect you from hazardous dusts and choose suitable vacuum cleaner.
6. HOW TO USE DRYWALL SANDER
Before setting up, repair or maintenance of the appliance you must always turn off
the operating switch and pull out the mains plug!
Before Initial Operation
-- Check if the rated frequency of the mains supply corresponds to the details of the type place.
-- Before using the tool, read the instruction book carefully.
6.1 How to Operate
-- Loosen the lock spanner，take the extension rod to connect with machine[1-1].

Page 6 of 13
--With dust hose and the dustproof ring and connected with the extension rod[1-2]
6.2 Electronic Control
This machine has the characteristics as below：
--Lock-on switch [1-3]；
--Adjustable Speed [1-4]
Adjust the speed from 800-1700rpm by turning the speed wheel [1-4]. In this way, user can choose different
speed for different sanding surface.
6.3 Replace Sanding Pad 【1-5】
-- Insert the hex wrench (size 5) into the hexagonal screw bolt on the sanding pad
-- Hold the sanding pad firmly, and then turn the wrench to dismount the pad.
-- Install new sanding pad by tightening the bolt

Page 7 of 13
Attention: Only install the specified sanding pad on the machine.
6.4 Stick the Sanding Paper to the Pad【1-6】
Please ensure the holes on the sanding paper to fit the holes on the pad accurately.
6.5 LED【1-7】;【1-8】
LED light,3.8W can work in a dark environment. LED light can be adjusted on every side.
6.6 Suction power adjustment【1-9】
Clockwise to reduce suction power, counter-clockwise to increase suction power.

Page 8 of 13
6.7Grinding Adjacent Edges【1-10】
Detachable brush segment can reach up to the adjacent edge with ease.
6.8 To change the dust hose.
-- Loosen the hoop by the screwdriver, take out the dust hose [1-11]
-- Counterclockwise rotation of the dust hose [1-12]
6.9 Disassemble the extension rod [1-13]
When disassemble the extension rod, pls must press the limited knob, then take out the extension rod.

Page 9 of 13
7. Operate the Machine
--Do not control the machine’s head.
--Hold the machine with both hands.
--Before operating the machine, make sure every fastening handle is closed.
--Connect the machine to the main power supply.
-- Before switching on the machine, keep the sanding head slightly away from the work surface.
-- Start the machine for necessary sanding work.
Operate the machine with short length in narrow and awkward area.
Run the machine with medium length for higher walls.
Use the machine with longest length for ceilings.
-- Do not over-press machine so that to avoid overloading! Press with proper pressure for better grinding
effects. Good grinding effects and quality are mainly decided by choosing the right abrasive material.
--Once finishing the sanding task, switch off the machine.
8. CARE AND MAINTENANCE
Remove the plug from the socket before carrying out any adjustment,
servicing or maintenance.
Your power tool requires no additional lubrication or maintenance. Always store your power tool in a dry
place.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
If a fault can not be rectified, return the mixer to an authorized dealer for repair.
Cleaning
_ Keep the safety devices, ventilation slots and Motor housing as free of dirt and dust as possible. Clean the
unit by rubbing it with a clean cloth or blow it clean using low-pressure compressed air.
_ We recommend that you always clean the unit immediately after using it.
_ Clean the unit regularly by rubbing it with a damp cloth and a little soft soap. Do not use cleaners or solvents;
these will attack the plastic parts in the unit. You must also ensure that water cannot get into the inside of the
unit.
Carbon brushes
_ If excessive sparking occurs you must have the carbon brushes checked by a qualified electrician.
Attention! Only a qualified electrician is allowed to change the brushes.
9. CORRECTIVE ACTION IN CASE OF FAILURE
(1) The operating switch is switched on, but the motor is not working.
-- Wires in the mains plug or in the socket are loose.
Have socket and plug checked or repaired.
-- The switch is faulty.
Have the switch replaced.
(2) The operating switch is switched on, but unusual noises can be heard, the motor is not working or only
very slowly.
-- Switch contact has failed.
Have the switch replaced.
-- Component jammed.
Have the electric tool checked or repaired.
-- Too much thrust, as a result the motor is dragging.

Page 10 of 13
Use less thrust during the task.
(3) Motor gets hot.
-- Foreign substances have got inside the motor.
Have the foreign substances removed.
-- Lack of or contaminated lubrication grease.
Have lubricating grease applied or replaced.
-- Pressure too high
Use less thrust during the task
(4) Frequent or strong sparks on the commutator.
-- Short circuit on the armature.
Have the armature replaced.
-- Carbon brushes worn out or jammed
Have the carbon brushes checked.
-- Rough running of the commutator.
Have the surface of the commutator cleaned or ground.
For your own safety, never remove parts or accessories of the electric tool during operation. In case of fault or
damage have the electric tool repaired only by a specialist workshop or by the manufacturer.
10. LABELS ON YOUR TOOL (if any)
V
Volts
Hz
Hertz
Alternating current
W
Watts
n0
No load speed
/min or
min-1
Revolutions or reciprocation per
minute
Class II tool
To reduce the risk of injury, user
must read instruction manual
Wear Ear Protection
Wear Eye Protection
For your personal safety, READ and UNDERSTAND before using.
Save This Instruction For Future Reference
Always Wear Ear Protection With This Tool
Always Wear Eye Protection With This Tool
Always Wear a breathing Mask With This Tool
11. ENVIRONMENTAL PROTECTION
Do not dispose of in general household waste. Instead dispose of in an
environmental way, contact your local recycling centre of council
for advice. Please take the care of the environment very seriously.

Page 11 of 13
Exploded view

Page 12 of 13

Page 13 of 13
