CRAFTSMAN
4 in. BELT SANDER
MODEL NO. 315.268190
REPAIR SHEET

CRAFTSMAN BELT SANDER – MODEL NUMBER 315.268190
NOTE : The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the sys-
tem, service should be performed by your nearest Sears Repair Center. Contact your nearest Sears retail store for service center information.
SEE NOTE
2
1
3
2
4
5
7
6
6
8
10
11
12
13
14
9

CRAFTSMAN BELT SANDER – MODEL NUMBER 315.268190
3
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
BELT SANDER or when ordering repair parts.
** AVAILABLE FROM DIV. 98 – SOURCE 980.00
*** COMPLETE ASSORTMENT AVAILABLE AT YOUR NEAREST SEARS RETAIL STORE
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 940051014 LOGO PLATE.................................................................................................................................................1
2 *** SANDING BELT .............................................................................................................................................1
3 940078033 DATA PLATE...................................................................................................................................................1
4 300027035 DUST COLLECTION BAG .............................................................................................................................1
5 301041001 WEAR PLATE ................................................................................................................................................1
6 660327002 SCREW (8-32 x 1/2 in. PAN HD.) **STD510805 ............................................................................................5
7 590546001 BELT COVER .................................................................................................................................................1
8 511973001 BELT ..............................................................................................................................................................1
9 660106002 LOCK NUT.....................................................................................................................................................1
10 680335009 WASHER........................................................................................................................................................1
11 680335011 WASHER........................................................................................................................................................1
12 680335010 WASHER........................................................................................................................................................1
13 690725001 COMPRESSION SPRING..............................................................................................................................1
14 300898002 TRACKING KNOB ASSEMBLY......................................................................................................................1

CRAFTSMAN BELT SANDER – MODEL NUMBER 315.268190
SECTION "A
SECTION "A" REPRESENTS AN IMPORTANT PART OF THE DOUBLE INSULATED SYSTEM OF THIS TOOL. ANY REPAIR TO THIS TOOL RE-
QUIRES DIELECTRIC TESTING TO INSURE CUSTOMER SAFETY AND TO COMPLY WITH COMPANY REQUIREMENTS.
4
8
6
5
4
3
2
1
16
17
48
22
39
910
11
14
15
33
24
23
31
32
54
29
28 2726
25 53
48
20
51
50
47
46
52
49
42
41
40
26
38
26 45
30
31
32
37
36
34
35
1
19 20
18
21
13
743 44
12
1
53
40
41
42

CRAFTSMAN BELT SANDER – MODEL NUMBER 315.268190
5
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
BELT SANDER or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
23 300777003 REAR ROLLER ASSEMBLY.................... 1
24 660106004 LOCK NUT.............................................. 1
25 660299004 SCREW (M5 X 18 mm) ...........................1
26 280013041 CIRCUIT BOARD (SS) ............................1
27 6611303 SCREW................................................... 1
28 740524001 FIELD...................................................... 1
29 660299006 SCREW (M5 X 44 mm) ...........................2
30 300998003 ARMATURE ASSEMBLY......................... 1
31 690777001 RETAINING RING ................................... 2
32 6939501 BALL BEARING ..................................... 2
33 640755004 GLAMOR PLATE..................................... 1
34 610326001 DRIVE PULLEY....................................... 1
35 640585001 DRIVEN PULLEY .................................... 1
36 730393001 POWER CORD ....................................... 1
37 5927402 BEND RELIEF ......................................... 1
38 400873003 DIAL (VS)................................................. 1
39 590541001 RELEASE LEVER.................................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
1660327002 SCREW (8-32 X 1/2 in. PAN HD.) ........... 11
2 640584001 GEAR BOX COVER .................................. 1
3 900729001 SEAL......................................................... 1
4 610327001 DRIVEN GEAR .......................................... 1
5 6807001 BALL BEARING ........................................ 1
6 620234001 GEAR SHAFT............................................ 1
7 680582005 NEEDLE BEARING (HK0709) ................... 1
8 640583001 BASE ........................................................ 1
9 690715002 WEAR STRIP ............................................ 1
10 6939601 RETAINING RING ..................................... 1
11 632450004 YOKE W/SHAFT ....................................... 1
12 660299005 SCREW (M5 X 11 mm) ............................. 4
13 630438002 SPRING PLATE......................................... 1
14 620233001 FRONT ROLLER SHAFT........................... 1
15 300432006 FRONT ROLLER ASSEMBLY ................... 1
16 680071002 BALL BEARING ........................................ 1
17 620255001 OUTPUT SHAFT....................................... 1
18 590547001 ROTOR SIT COVER.................................. 1
19 590539001 FAN BOX COVER ..................................... 1
20 300141037 HOUSING ASSEMBLY ............................. 1
21 660366001 SCREW (M4 X 12.5 mm FLAT HD.) .......... 2
22 660013005 SHOULDER SCREW ................................ 1

CRAFTSMAN BELT SANDER – MODEL NUMBER 315.268190
6
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
BELT SANDER or when ordering repair parts.
PARTS LIST
40 301035001 BRUSH HOLDER ASSEMBLY.....................................................................................................................................2
41 301036001 BRUSH AND SPRING .................................................................................................................................................2
42 512010001 BRUSH CAP................................................................................................................................................................2
43 550339001 RUBBER PLUG ...........................................................................................................................................................1
44 660568001 T-8 SOCKET SET (M3.5 X 9 mm) ................................................................................................................................2
45 760314002 SWITCH.......................................................................................................................................................................1
46 6627201 SCREW (M4 X 14 mm) ................................................................................................................................................2
47 5950101 CORD CLAMP.............................................................................................................................................................1
48 6620805 SCREW (M4 X 16 mm) ................................................................................................................................................7
49 511184001 DUST GUIDE PLATE....................................................................................................................................................1
50 660279003 SCREW (M4 X 11 mm) ................................................................................................................................................2
51 690715003 WEAR PLATE...............................................................................................................................................................1
52 660008003 SCREW (M3 X 14 mm) ................................................................................................................................................2
53 6620803 SCREW (M4 X 22 mm) ................................................................................................................................................9
54 690761001 SPRING .......................................................................................................................................................................1
983000172 OPERATOR'S MANUAL
9-30-09
REV:01
KEY PART
NO. NUMBER DESCRIPTION QTY.

CRAFTSMAN BELT SANDER – MODEL NUMBER 315.268190
7
WIRING DIAGRAM
BROWN
BLACK
BLACK
BLACK
WHITE
WHITE
WHITE
WHITE
BLUE
BLUE
BLUE
VARIABLE SPEED CB
SOFT START CB
CIRCUIT BOARD
SWITCH
RED
