DirectConnect DCC5HIR-1 User manual

HIGH SPEED HDMI ™
SINGLE CAT5e/6 EXTENDER
WITH IR
Model# DCC5HIR-1 SKU# .27980
Plug and play: No extensive configuring required
Auto-adjustment of feedback, equalization, and amplification.
Supports digital formats in Deep Color Mode up to 36 bits (12 bits color)
Video amplifier bandwidth: Up to 225MHz
Single (1) Cat5e/6 UTP cables with cross stand inside, can substitute
an HDMI™ cable to achieve long distance transmission of 164 feet
(50 meters).
Supports 3D function
Supports uncompressed 2 channel audio such as LPCM
Supports compressed audio such as Dolby TrueHD, Dolby Digital Plus and
DTS-HD Master Audio
USER MANUAL
IMPORTANT: If you do not understand correct installation instructions, please consult
your installation specialist.

2
Thank you for choosing DirectConnect® Products
For optimum performance and safety, please read these instructions
carefully before connecting, operating, or adjusting this product. Please
keep this manual for future reference.
Table of Content
1.0 Specifications…………………………………... 3
2.0 Features…………………………………………... 4
3.0 Package Contents ……………………………. 4
4.0 Connection and Operation.………..……. 4
4.1 Connection Diagram………………………... 5
5.0 Troubleshooting………………………………. 6
6.0 Limited Warranty…………………………..... 8
Liability Statement
Every effort has been made to ensure that this product is free of defects.
DirectConnect®cannot be held liable for the use of this hardware or any direct
or indirect consequential damages arising from its use. It is the responsibility
of the user of the hardware to check that it is suitable for his/her require-
ments and that it is installed correctly. All rights reserved. No parts of this
manual may be reproduced or transmitted by any form or means electronic
or mechanical, including photocopying, recording or by any information
storage or retrieval system without the written consent of the publisher.
DirectConnect®reserves the right to revise any of its hardware and software
following its policy to modify and/or improve its products where necessary or
desirable. This statement does not affect the legal rights of the user in any
way.
All third-party trademarks and copyrights are recognized.
DirectConnect® is a registered trademark
HDMI™ is a registered trademark
UL® is a registered trademark of Underwriters Laboratories

3
Signal Inputs/Output
Signaling rates 2.25Gpbs x 3
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 1920X1080P
Output Video HDMI™ + HDCP1.1 and DV11.0
Video format supported
DTV/HDTV 480i/576i/480p/576p/720p/1080i/1080P
Digital Signal I/O
HDMI™ Compliance Yes - standard
Operating Frequency
Frequency Up to 225MHz
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 2.25Gpbs/225MHz
Resolutions (HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size (H-W-D) 3.15” x 1.61” x .98” (80 x 41 x 25mm)
Warranty
Limited Warranty 2 Year Parts and Labor
Environmental
Operating Temperature 320F - 1040F (-00C - 400C)
Storage Temperature -40F - 1400F (-200C - 600C)
Relative Humidity 20% to 90% RH (no condensation)
Power Requirement
5 Volt DC Power Adapter 5V DC@1A Power Consumption: 5 Watts
maximum
Accessories
(2) 5 Volt DC Power Adapter
UL,CE, & FCC 100-240v, 50-60Hz to 5.0vdc
User Manual English Version
1.0 SPECIFICATIONS
NOTE: Specifications are subject to change without notice

4
2.0 FEATURES
This high-performance DirectConnect® Extender via CAT5e or CAT6 with cross
stand inside UTP cable has many benefits and features that enable it to perform
in a superior manner. Among those benefits and features you will find:
Uses Cat5e or Cat6 with cross stand inside UTP cable to substitute for
HDMI™ cable to achieve long distance transmission without signal loss.
Auto-adjustment of feedback, equalization and amplification. The user
does not need to adjust these variables to compensate for the length of
the cable.
Supports up to 1080p, uncompressed 2 channelaudio, and IEEE-568B standard.
Supports 3D function
3.0 PACKAGE CONTENTS
DirectConnect®HDMI™ Extender one (1) transmitter and one (1) receiver
One (1) IR receiver and one (1) IR emitter
One (2) 5 Volt DC Power Adapter
User's Manual
Note: Please retain the original packing material in case you need to return
the unit.
4.0 CONNECTION AND OPERATION (REFERENCE SECTION 4.1 ON PAGE 5)
Make sure that all power is disconnected from display, source and ex-
tender.
Connect the single CAT5e or CAT6 cables into the transmitter and receiver
units. (1)
Connect the IR receiver (3) to the display and the IR emitter (3) to the
source you want to control
Attach the HDMI cable (4) from the source to the receiver and the HDMI
cable (4) from the source to the transmitter
Plug In the power (5) to the receiver and transmitter of the balun

5
Power on the source unit (6)
Power on the display unit (7)
NOTE: Power on sequence—BALUN, SOURCE, DISPLAY.
4.1 CONNECTION DIAGRAM
7
1
3
3
4
4
5
6
5

6
5.0 TROUBLESHOOTING
If this DirectConnect®product does not appear to be functioning, please
make certain that the source and the destination device connected to the
unit are functioning correctly. If other problems exist please check the condi-
tions below carefully.
In the event of problems, first make certain that the dual Cat5/6 cables are not
longer than specification. Next, make certain that the HDMI™ Extenders are
receiving power.
If all is well in these areas, remember that HDMI™ devices communicate with
one another so the source devices and destination device must be fully
HDMI™ capable. If you experience problems using the HDMI™ Extender, you
should attempt to determine what is wrong by attaching each of the source
devices –one at a time –directly to the destination device using the same
cables you are using with the expanded system. This is a way of determining
if the problem is due to bad cables or a problem with the other devices. If
you are unable to obtain a signal using this simplified path, double check the
cables, the source device(s) and/or the destination device.
If a DVI device does not appear to work, make certain that the device is
HDCP-compliant. A non-HDCP-compliant DVI device will not work with a
signal that has HDCP encoding present.
DO NOT open the HDMI™ extender boxes. There are no user repairable parts
inside. Once opened, all warranties will be voided.
Refer to the troubleshooting chart on page 7 for additional help.
Notice: DirectConnect®reserves the right to make changes to the hardware,
packaging and/or any accompanying documentation without prior written
notice.

7
CONDITION POSSIBLE SOLUTIONS
No display image/LED light on
Extender Receiver is OFF
Is the power adapter connected? If a power strip is used,
is the ON/OFF switch set to “ON” position?
No display image/LED light ON
Transmitter & Receiver are ON
Is the display unit turned on? Is the display unit set to
the correct video input? Are your HDMI™ and/ or
Cat5e/6 cables damaged? Are the cables connected
properly? Please refer to the connection diagram.
Image without sound
Note: That units connected with a
DVI adapter will not have sound –
DVI is a video-only connection
standard
1- Check the display unit’s volume
2- Turn off the HDMI™ source (DVD, PS3 etc.) and power
on again. If there is still no sound, then:
3- Unplug the power adapter on the Extender transmit-
ter and receiver unit for 10 seconds and then plug
in again.
4- Repeat step 2 again if still not working.
Note: Some devices not HDMI™ certified may have
compatibility problems.
Poor picture quality
(snow, sparkles, banding, etc)
Examine the HDMI™ and/or Cat 5e/6 cable and replace
with new cables if possible. To ensure that the extender
units are operating correctly, test with the shortest
HDMI™ and/or Cat 5e/6 cable possible. Longer or
inferior/ damaged cables will compromise image qual-
ity. Use only Cat5e/6 UTP cable with cross stand inside
for the best results possible.

8
6.0 LIMITED WARRANTY
Should any consumer product from DirectConnect®fail due to defects in mate-
rials or workmanship within two years from the date of the original sale to the
end-user, DirectConnect®guarantees replacement of the defective product at
no cost. Freight charges for the replacement unit will be paid by the customer.
A copy of the invoice showing the item number and date of purchase (proof-of-
purchase) must be submitted with the defective unit to constitute a valid in-
warranty claim.
Units that fail after the warranty period has expired may be returned to the
factory for repair at a nominal charge, if not damaged beyond the point of
repair. All freight charges for out-of-warranty returns for repair are the respon-
sibility of the customer. Units returned for repair must have a Return Authori-
zation Number assigned by DirectConnect®.
This is a limited warranty and is not applicable for products which, in our opin-
ion, have been damaged, altered, abused, misused, or improperly installed.
DirectConnect®makes no other warranties either expressed or implied, includ-
ing limitation warranties as to merchantability or fitness for a particular pur-
pose. Additionally, there are no allowances or credits available for service work
or installation performed in the field by the end user.
DirectConnect®
Houston, TX 77027
800.531.3224
Scan the code to visit our
website.
www.DirectConnectHome.com
