Directechs HKHT1 User manual

HKHT1
INSTALLATION GUIDE
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.
2020-03-03
© 2020 Directed, Vista CA
Directed Digital
Solutions
Designed by Installers for Installers

Contents
Warning! Safety first ....................................................................................................................... 3
Introduction .................................................................................................................................... 4
Pre-installation and application warnings ..................................................................................... 4
Vehicle application guide........................................................................................................... 5
Wiring connections ......................................................................................................................... 6
Main power harness (H1), 12-pin thick gauge connector ............................................................... 6
Auxiliary output harness (H2), 16-pin black connector ................................................................... 6
Analog harness (H3), 18-pin white connector ............................................................................... 7
MC501 harness (H4), 8 thick-gauge wires (optional)..................................................................... 7
Installation (wiring diagrams & vehicle wiring reference charts) ............................................................ 8
Type 1 ..................................................................................................................................... 8
Type 2 ................................................................................................................................... 11
Type 3 without OEM alarm....................................................................................................... 13
Type 3 with OEM alarm........................................................................................................... 14
Type 4 without OEM alarm....................................................................................................... 17
Type 4 with OEM alarm........................................................................................................... 18
Type 5 without OEM alarm....................................................................................................... 21
Type 5 with OEM alarm........................................................................................................... 22
Type 6 without OEM alarm....................................................................................................... 25
Type 6 with OEM alarm........................................................................................................... 26
Type 7 without OEM alarm....................................................................................................... 28
Type 7 with OEM alarm........................................................................................................... 29
Type 8 ................................................................................................................................... 33
Type 9 ................................................................................................................................... 35
Type 10 ................................................................................................................................. 37
Connecting the module .................................................................................................................. 39
Important! .............................................................................................................................. 39
Manual or automatic transmission selection ................................................................................ 39
Optional sensors ..................................................................................................................... 39
RF Systems ............................................................................................................................. 40
When used in conjunction with SmartStart.................................................................................. 40
Module programming.............................................................................................................. 41
Method 1 - With HS CAN & FT CAN connections & with transponder immobilizer....................... 41
Method 2 - Without FT CAN & with HS CAN connections & with transponder immobilizer............ 42
Method 3 - With HS CAN & FT CAN connections & without transponder immobilizer................... 43
Method 4 - Without FT CAN & with HS CAN connections & without transponder immobilizer. ...... 44
LED diagnostics and troubleshooting.......................................................................................... 45
Soft reset................................................................................................................................ 47
Hard reset .............................................................................................................................. 47
Learning the Tach (not needed with Virtual Tach) ............................................................................... 48
Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 48
Limited lifetime consumer warranty .................................................................................................. 49
Quick Reference Guide.................................................................................................................. 50

Warning! Safety first
The following safety warnings must be observed at all times:
• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.
• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never
operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:
• Never use a test light or logic probe when installing this unit. Always use a multimeter.
• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must
be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from
children all remote controls to assure that the system does not unintentionally remote start the vehicle.
• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.
ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or
death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with
the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the
neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to fix the problem
immediately.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF
OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE
OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When testing to ensure the
installation is working properly, only remote start the vehicle in neutral gear, on a flat surface and with a functional, fully engaged
parking brake. Do not allow anyone to stand in front of or behind the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such
vehicles may pose certain risk.
3Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Introduction
The HKHT1 firmware for Directed Digital Solutions is compatible with specific Hyundai and Kia vehicles. It
is a complete solution for remote start, security (if applicable), bypass interface, and convenience. This guide
provides information on the installation of the module using HKHT1. If you would prefer using this system as a
digital solution, go to www.directechs.com and search for the make, model and year of the vehicle. This will
allow you to find the proper firmware and corresponding installation guide.
Warning! This module can only be programmed via the web tool, which can be found on www.directechs.com or using the
Directechs Mobile application for mobile devices. Features and functions will become accessible when you connect the module
using the XKLoader.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Keys required for
programming 1Keys required for operation 0
Important! If your vehicle is NOT equipped with transponder immobilizer AND also does not use CAN's connections, then
please flash your module with an analog firmware.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
Refer to the "Vehicle wiring reference chart" following each installation type.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] The Green wire is ONLY required for starter disable and antigrind applications.
[4] EMS COM connections ONLY needed if vehicle has a transponder immobilizer.
[5] Required ONLY if RAP Off does not operate over data.
[6] Factory Disarm Output is required ONLY if the vehicle is equipped with an OEM alarm.
Additional parts required (maximum required):
6A Diode
4 x 1A Diodes 86 85
30
87a
87
0 x Relay
Resistor 100Ω
0 x Resistor
Fuse 7.5A
1 x 15A Fuse
4Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Vehicle application guide
The following table lists the vehicles and features which are compatible with this product. The number assigned to each year
allows you to determine which installation type should be used for your vehicle.
Vehicles
2017 2016 2015 2014 2013 2012 2011 2010 2009 2008 PK-Immobilizer Bypass-Data No Key Req'd DL-Arm Factory Security DL-Disarm Factory Security DL-Door Lock Control DL-Door Unlock DL-Driver Priority Unlock DL-Trunk / Hatch Release
FOB-Control of aftermarket alarm with OEM remote
RS-RAP Shut Down (Retained ACC Power) RS-Remote Start Takeover RS-SmartStart RS-Tach / RPM Output SS-Entry Monitoring ALL Door Pins SS-Entry Monitoring Hood Pin SS-Entry Monitoring Trunk/Hatch Pin SS-Factory Alarm Trigger Monitoring ST-Brake Status (foot brake) ST-Door Locks Status ST-E-Brake Status
Hyundai
Accent 6 6 6 6 6 6 • • • •
Accent 2 2 2 2 • • •
Elantra 111111 •••••••••••••••••••
Elantra 7 7 7 • • •
Elantra Coupe 11 •••••••• •••••••••
Elantra Touring 3 3 3 3 • • • •
Genesis Coupe 7 7 7 • • •
Santa Fe 3 3 3 3 3 • • • •
Sonata 1111 •••••••••••••••••••
Sonata 7 7 7 • • •
Tucson 888888 •••••••••••••••••••
Kia 17 16 15 14 13 12 11 10 09 08
Forte 4 4 4 4 • • • •
Forte5 4 4 4 • • • •
Magentis 10 10 • • •
Optima 11111 •••••••••••••••••••
Optima 7 7 7 • • •
Rio 2 2 2 2 • • •
Rondo 3 3 3 3 3 • • • •
Sorento 5 5 5 5 5 • • •
Soul 4 4 4 4 • • • •
Sportage 888888 •••••••••••••••••••
Sportage (4-cylinder) 9 9 9 • • •
Sportage (V6) 9 9 9 • • •
Legend:
PK: Transponder & Immobilizer Override
DL: OE Door Lock & Alarm Controls
FOB: Sync CAN Interface w/ FOB Remote
RS: Remote Start & Engine Controls
SS: Integrated Security & Monitoring
ST: Function/Feature Status
5Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Wiring connections
The wiring connections listed below are specific to this firmware.
Main power harness (H1), 12-pin thick gauge connector
Conn./Pin Color Description
H1/1 White Relay 3 COM – No Connection 1
H1/2 White/Brown Relay 3 N.O. – No Connection 1
H1/3 Brown/Red Relay 2 N.O. – No Connection
H1/4 Yellow/Red Relay 2 COM – Lock Detection Interrupt (vehicle side)
H1/5 Orange/Red Relay 2 N.C. – Lock Detection Interrupt (connector side)
H1/6 Yellow Relay 1 COM – EMS COM Data (Vehicle side) 1
H1/7 White Relay 3 COM – No Connection 1
H1/8 White/Brown Relay 3 N.O. – No Connection 1
H1/9 Black (-) Ground
H1/10 Red (+) 12 Volt (Battery)
H1/11 Orange/Yellow Relay 1 N.C. – EMS COM Data (connector side) 1
H1/12 Brown Relay 1 N.O. – No Connection 1
Auxiliary output harness (H2), 16-pin black connector
Conn./Pin Color Description
H2/1 Violet/Brown No Connection
H2/2 Yellow/Black EMS COM Data (Connector side)
H2/3 Orange/Black EMS COM Data (Vehicle side)
H2/4 Tan HS CAN Low
H2/5 Tan/Black HS CAN High
H2/6 Light Green No Connection
H2/7 Orange/Green FT CAN High
H2/8 Orange/Brown FT CAN Low
H2/9 Violet/Green No Connection
H2/10 Green/Black (-) Parking Light Output 2
H2/11 White/Violet (-) RAP Off Output 2
H2/12 White/Red No Connection 2
H2/13 Lt. Blue/Black (-) Disarm Output 2
H2/14 Green/Red No Connection 2
H2/15 N/A No Connection
H2/16 Violet/Yellow No Connection
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
2. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
6Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Analog harness (H3), 18-pin white connector
Conn./Pin Color Description
H3/1 Lt. Blue/Red No Connection
H3/2 Black/White (-) Parking Brake Input (Manual Transmission) 2
H3/3 Gray (-) Hood Input 2
H3/4 N/A No Connection
H3/5 Gray/Black (+) Glow Plug Input 2
H3/6 Violet/White (AC) Tach Input 2
H3/7 Dark Blue (-) Unlock Output 1
H3/8 Brown/Black (-) Horn 1
H3/9 Red/White (-) Trunk Release Output 1
H3/10 White/Green No Connection 2
H3/11 Yellow/Green (+) Door Input 2
H3/12 Blue/Red No Connection
H3/13 Light Blue (-) Trunk Trigger Input 2
H3/14 Pink/Yellow (-) Activation (Start Trigger) Input
H3/15 Dark Green (-) Lock Output 1
H3/16 Brown/White (+) Brake Input 2
H3/17 Brown (+) Siren Output 1
H3/18 Blue/White (-) Ground When Running (Status) Output 1
MC501 harness (H4), 8 thick-gauge wires (optional)
Conn./Pin Color Description
H4/1 Pink/White (+) Ignition 2/Flex Relay Output 3
H4/2 Red/White (+) Fused (30A) Ignition 2/Flex Relay Input
H4/3 Pink (+) Ignition Output (Also Input to Yellow in Ribbon Cable)
H4/4 Red (+) 12 Volt (Battery) Input
H4/5 Orange (+) Accessory Output
H4/6 Red (+) 12 Volt (Battery) Input
H4/7 Green Starter Input (From Key Switch) 4
H4/8 Violet (+) Starter Output (To Starter)
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 5 for a
list of compatible features.
3. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
4. The Green wire is only required for starter disable and anti-grind applications.
7Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Installation (wiring diagrams & vehicle wiring reference charts)
Type 1
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
16
8
9
1
Ignition Switch
(white 6-pin connector)
HS CAN Low: Tan: 4
Immobilizer Data Interrupt (vehicle side): Yellow/Black: 2
Immobilizer Data Interrupt (connector side): Orange/Black: 3
HS CAN High: Tan/Black: 5
C-CAN High: pin 6
C-CAN Low: pin 14
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
9: Black: (-) Ground
10: Red: (+) 12V (+) 12V
7 White4 White
8 thick-gauge wires
MC501
B-CAN Wires & Parking Lights
Refer to the Vehicle wiring
reference charts for the
connector, pin and wire color
in your vehicle.
(+) Ignition Output (also input
to Yellow wire in ribbon
cable): Pink
(+) 12V Input: Red
(+) Accessory Output: Orange
(+) 12V Input: Red
(+) Starter Output
(to starter): Violet
OBDII Diagnostic
(connector side view)
(-) Hood Input: Gray: 3
Hood Pin
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
(+) Siren Output: Brown: 17
Starter Input (from
key switch): Green
11: Orange/Yellow:
Immobilizer Data Interrupt
(vehicle side)
6: Yellow:
Immobilizer Data Interrupt
(connector side)
(-) Parking Lights Output: Green/Black: 10
3 - EM11, White 43-pin connector
1 - EM11, White 55-pin connector 2 - EM11, White 58-pin connector
12
41
OR OR
10 10
Connector
The EMS COM connections are only needed
if the vehicle has a transponder/immobilizer.
Refer to the Vehicle wiring reference chart for
the connector, pin and wire color for your specific vehicle. Cut
(+)Starter:
Yellow, pin 3
(+)Accessory:Orange, pin 2
(+) Ignition:
Pink,
pin 4
(+)12V: Green,
pin 1
8Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Locating components in the vehicle
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Hyundai Elantra 2011-2013
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 2 (-) Headlight switch. White 10 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High White/Orange or Brown 13 Data Junction Box (Rear), I/P-G. White 24 D
B-CAN Low Yellow/Orange or White 1 Data Junction Box (Rear), I/P-G. White 24 D
EMS COM Blue or Blue/Orange 10 Data Driver kick panel, EM11. White 55 E
Hyundai Elantra 2014-2016
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 2 (-) Headlight switch. White 10 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High Green or Brown 13 Data Junction Box (Rear), I/P-G. White 24 D
B-CAN Low Orange or White 1 Data Junction Box (Rear), I/P-G. White 24 D
EMS COM Blue 12 Data Driver kick panel, EM11. White 58 E
Hyundai Elantra Coupe 2013
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 2 (-) Headlight switch. White 10 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High White/Orange or Brown 13 Data Junction Box (Rear), I/P-G. White 24 D
B-CAN Low Yellow/Orange or White 1 Data Junction Box (Rear), I/P-G. White 24 D
EMS COM Blue 10 Data Driver kick panel, EM11. White 55 E
9Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Hyundai Elantra Coupe 2014
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 2 (-) Headlight switch. White 10 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High Green or Brown 13 Data Junction Box (Rear), I/P-G. White 24 D
B-CAN Low Orange or White 1 Data Junction Box (Rear), I/P-G. White 24 D
EMS COM Blue 10 Data Driver kick panel, EM11. White 55 E
Hyundai Sonata 2011-2014
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 2 (-) Headlight switch. White 10 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High White/Orange or Blue 12 Data Junction Box (Rear), I/P-F. White 24 D
B-CAN Low Yellow/Orange 11 Data Junction Box (Rear), I/P-F. White 24 D
EMS COM Blue or Blue/Black 10 Data Driver kick panel, EM11. White 43 E
Kia Optima 2011-2013
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 1 (-) Headlight switch. White 13 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High White/Orange 25 Data Junction Box (Rear), I/P-E. White 39 D
B-CAN Low Yellow/Orange 38 Data Junction Box (Rear), I/P-E. White 39 D
EMS COM Blue 10 Data Driver kick panel, EM11. White 43 E
Kia Optima 2014-2015
12V Green 1 (+) Ignition switch. White 6 A
Accessory Orange 2 (+) Ignition switch. White 6 A
Ignition Pink 4 (+) Ignition switch. White 6 A
Starter Yellow 3 (+) Ignition switch. White 6 A
Parking Lights Pink 1 (-) Headlight switch. White 13 C
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
B-CAN High White/Orange 13 Data Junction Box (Rear), I/P-G. White 24 D
B-CAN Low Yellow/Orange 1 Data Junction Box (Rear), I/P-G. White 24 D
EMS COM Blue 41 Data Driver kick panel, EM11. White 58 E
10 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Type 2
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
16
8
9
1
Ignition Switch
(white 6-pin connector)
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
10: Red: (+) 12V Input
7 White4 White
8 thick-gauge wires
MC501
(-) RAP Off Output: White/Violet: 11
(+) Brake Input: Brown/White: 16 9: Black: (-) Ground
Siren
Hood Pin
C-CAN High: pin 6
C-CAN Low: pin 14
OBDII Diagnostic
(connector side view)
(+) Ignition Output:
Pink
(+) 12V Input: Red
(+) 12V: Green,
pin 5
(+) Ignition: Pink, pin 6
(+) Accessory
Orange,
pin 3
(+) Starter
White,
pin 1
(+) Accessory Output:
Orange
(+) 12V Input: Red
(+) Starter Output
(to starter): Violet
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
(-) Unlock Output: Dark Blue: 7
(-) Lock Output: Dark Green: 15
11: Orange/Yellow:
Immobilizer Data Interrupt
(connector side)
6: Yellow:
Immobilizer Data Interrupt
(vehicle side)
Immobilizer Data Interrupt (connector side): Orange/Black: 3
Immobilizer Data Interrupt (vehicle side): Yellow/Black: 2
Refer to the Vehicle
wiring reference charts
for pin, wire and
connector details
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
Starter Input (from
key switch): Green
(-) Parking Light Output: Green/Black: 10
(-) Disarm Output: Lt. Blue/Black: 13
Note: program
for double
pulse when
flashing.
OR
2 - EM01, Gray 39-pin connector
15
15
1 - EM01, Black or Blue 39-pin connector
Connector
The EMS COM connections are only needed
if the vehicle has a transponder/immobilizer.
Cut
Refer to the Vehicle wiring reference chart for
the connector, pin and wire color for your specific vehicle.
11 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Locating components in the vehicle
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Hyundai Accent 2008-2011
12V Green 5 (+) Ignition switch. White 6 A
Accessory Orange 3 (+) Ignition switch. White 6 A
Ignition Pink 6 (+) Ignition switch. White 6 A
Starter White 1 (+) Ignition switch. White 6 A
EMS COM Blue/Black 15 Data Left of dash fuseb box, EM01. Black 39 E
C-CAN High Red 6 Data OBDII. Black 16 B
C-CAN Low Blue 14 Data OBDII. Black 16 B
Parking Lights Red or Pink/
Black 10 (-) Drivers kick panel. Blue 20 D
Lock Blue 6 (-) Dash fuse box. White 16 E
Unlock Yellow/Black 16 (-) Dash fuse box. White 16 E
Factory Alarm Disarm
White/Black
(driver door key
unlock)
33 double (-) Drivers kick panel. Blue 41 D
Drivers Door Green 2 (-) Drivers kick panel. Blue 42 D
Brake Green 2 (+) Dash fuse box. Gray 18 E
Kia Rio 2008-2011
12V Pink 5 (+) Ignition switch. White 6 A
Accessory Orange 3 (+) Ignition switch. White 6 A
Ignition Pink 6 (+) Ignition switch. White 6 A
Starter White 1 (+) Ignition switch. White 6 A
EMS COM Blue/Black 15 Data Right of dash fuse box, EM01 Gray 39 E
C-CAN High Red 6 Data OBDII. Black 16 B
C-CAN Low Blue 14 Data OBDII. Black 16 B
Parking Lights
"Pink/Black
(without BCM)
Red (with
BCM)"
14 (-) Headlight switch. Blue 20 C
Lock Blue 6 (-) Dash fuse box. White 16 E
Unlock Yellow/Black 16 (-) Dash fuse box. White 16 E
Factory Alarm Disarm
White/Black
(driver door key
unlock)
33 double (-) Drivers kick panel. Green 33 D
Drivers Door Green 2 (-) Drivers kick panel. Green 42 D
Brake Red/Orange 2 (+) Dash fuse box. Gray 18 E
12 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Type 3 without OEM alarm
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
11: Orange/Yellow: Immobilizer Data Interrupt
(vehicle side)
6: Yellow: Immobilizer Data Interrupt
(connector side)
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
10: Red: (+) 12V Input
(-) Trunk Release Output: Red/White: 9
9: Black: (-) Ground
Immobilizer Data Interrupt (vehicle side): Orange/Black: 3
Immobilizer Data Interrupt (connector side): Yellow/Black: 2
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
(-) Unlock Output: Dark Blue: 7
(-) Lock Output: Dark Green: 15
Siren
Hood Pin
Refer to the Vehicle
wiring reference chart.
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
(-) RAP Off Output: White/Violet: 11
(-) Parking Light Output: Green/Black: 10
7 White4 White
8 thick-gauge wires
MC501
16
8
9
1
C-CAN High: pin 6
C-CAN Low: pin 14
OBDII Diagnostic
(connector side view)
OR OR
3 - EM11, Blue 42-pin connector
18
2 - MC211, Blue 24-pin connector
19
1 - EM11, Gray 39-pin connector
15
Connector
EMS COM connections only needed
if vehicle has transponder/immobilizer.
Refer to the Vehicle wiring reference charts section for
the connector, pin and wire color in your specific vehicle. Cut
Ignition Switch
(6-pin connector)
(+) Ignition Output:
Pink
(+) Starter:
White, pin 1
(+) 12V: Orange, pin 5
(+) Ignition :
Blue, pin 6
(+) Accessory: Pink, pin 3
(+) 12V Input: Red
(+) Accessory Output:
Orange
(+) 12V Input: Red
(+) Starter Output
(to starter): Violet
Starter Input (from
key switch): Green
C-CAN wires MUST be
connected for proper
operation.
13 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Type 3 with OEM alarm
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
11: Orange/Yellow: Immobilizer
Data Interrupt (vehicle side)
6: Yellow: Immo. Data Interrupt
(connector side)
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
10: Red: (+) 12V Input
(-) Trunk Release Output: Red/White: 9
9: Black: (-) Ground
Immobilizer Data Interrupt (vehicle side): Orange/Black: 3
Immobilizer Data Interrupt (connector side): Yellow/Black: 2
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
(-) Unlock Output: Dark Blue: 7
(-) Lock Output: Dark Green: 15
Siren
Hood Pin
Refer to the Vehicle
wiring reference chart.
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
(-) RAP Off Output: White/Violet: 11
(-) Parking Light Output: Green/Black: 10
7 White4 White
8 thick-gauge wires
MC501
16
8
9
1
C-CAN High: pin 6
C-CAN Low: pin 14
OBDII Diagnostic
(connector side view)
OR OR
3 - EM11, Blue 42-pin connector
18
2 - MC211, Blue 24-pin connector
19
1 - EM11, Gray 39-pin connector
15
Connector
EMS COM are connections only needed
if the vehicle has transponder/immobilizer.
Refer to the Vehicle wiring reference charts section for
the connector, pin and wire color in your specific vehicle. Cut
(-) Disarm Output: Lt. Blue/Black: 13
(-) Lock Detection
(-) Unlock
(-) Factory Alarm Arm
(-) Lock
4 x
1A Diodes
5: Orange/Red: Lock Detection Interrupt
(connector side)
4: Yellow/Red: Lock Detection Interrupt
(vehicle side)
(-) Factory Alarm Disarm
Ignition Switch
(6-pin connector)
(+) Ignition Output:
Pink
(+) Starter:
White, pin 1
(+) 12V: Orange, pin 5
(+) Ignition :
Blue, pin 6
(+) Accessory: Pink, pin 3
(+) 12V Input: Red
(+) Accessory Output:
Orange
(+) 12V Input: Red
(+) Starter Output
(to starter): Violet
Starter Input (from
key switch): Green
C-CAN wires MUST be
connected for proper
operation.
14 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Locating components in the vehicle
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Hyundai Elantra Touring 2009-2012
12V Orange 5 (+) Ignition switch. White 6 A
Accessory Pink 3 (+) Ignition switch. White 6 A
Ignition Blue 6 (+) Ignition switch. White 6 A
Starter White 1 (+) Ignition switch. White 6 A
C-CAN High White 6 Data OBDII. Black 16 B
C-CAN Low Yellow 14 Data OBDII. Black 16 B
EMS COM Blue/Black 15 Data Passenger kick panel, EM11. Gray 39 F
Parking Lights Blue 8 (-) Headlight switch. White 14 C
Lock Green 25 (-) Drivers kick panel. Gray 39 D
Unlock Yellow 39 (-) Drivers kick panel. Gray 39 D
Factory Alarm Arm Green 23 (-) Drivers kick panel. Gray 39 D
Factory Alarm Disarm Yellow 6 (-) Drivers kick panel. Gray 39 D
Lock Detection Black/Orange 2 open Drivers kick panel. Gray 40 D
Trunk Release White 5 (-) Drivers kick panel. Gray 39 D
Drivers Door Red 36 (-) Drivers kick panel. Gray 39 D
15 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Hyundai Santa Fe 2008-2012
12V Red 5 (+) Ignition switch. Black 6 A
Accessory Red or Blue 3 (+) Ignition switch. Black 6 A
Ignition Orange 6 (+) Ignition switch. Black 6 A
Starter Green 1 (+) Ignition switch. Black 6 A
C-CAN High Red/Black or Blue 6 Data OBDII. Black 16 B
C-CAN Low Red or Orange 14 Data OBDII. Black 16 B
EMS COM White/Orange or
White or Red 19 Data Passenger kick panel, MC211. Blue 24 F
Parking Lights Blue/Orange 14 (-) Headlight switch. White 18 C
Lock Blue/Black 18 (-) Drivers kick panel. Brown 24 D
Unlock Gray/Black 19 (-) Drivers kick panel. Brown 24 D
Factory Alarm Arm Brown/Orange 5 (-) Drivers kick panel. Brown 24 D
Factory Alarm Disarm Pink 6 (-) Drivers kick panel. Brown 24 D
Lock Detection Gray 4 open Drivers kick panel. Brown 24 D
Drivers Door Green/Orange N/A (-) Drivers kick panel harness to rear. N/A N/A D
Kia Rondo 2008-2012
12V Red or Pink 5 (+) Ignition switch. Black 6 A
Accessory White or Pink 3 (+) Ignition switch. Black 6 A
Ignition White/Blue or Blue 6 (+) Ignition switch. Black 6 A
Starter Black/Yellow or
Green 1 (+) Ignition switch. Black 6 A
C-CAN High Red 6 Data OBDII. Black 16 B
C-CAN Low Blue 14 Data OBDII. Black 16 B
EMS COM Brown 18 Data Driver kick panel, EM11. Blue 42 D
Parking Lights Yellow 10 (-) BCM above brake pedal. White 26 E
Lock White 8 (-) Drivers kick panel. Gray 39 D
Unlock White/Black 9 (-) Drivers kick panel. Gray 39 D
Factory Alarm Arm Gray 3 (-) Drivers kick panel. Gray 39 D
Factory Alarm Disarm Brown 2 (-) Drivers kick panel. Gray 39 D
Lock Detection Yellow 1 open Drivers kick panel. Gray 39 D
Trunk Release Blue/Orange 18 (-) BCM above brake pedal. White 22 E
Drivers Door Red 36 (-) BCM above brake pedal. White 22 E
16 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Type 4 without OEM alarm
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
11: Orange/Yellow:Immobilizer
Data Interrupt (vehicle side)
6: Yellow: Immobilizer Data Interrupt
(connector side)
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
10: Red: (+) 12V Input
(-) Trunk Release Output: Red/White: 9
9: Black: (-) Ground
Immobilizer Data Interrupt
(vehicle side): Orange/Black: 3
Immobilizer Data Interrupt
(connector side): Yellow/Black: 2
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
(-) Unlock Output: Dark Blue: 7
(-) Lock Output: Dark Green: 15
Siren
Hood Pin
Refer to the Vehicle
wiring reference chart.
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
(-) RAP Off Output: White/Violet: 11
(-) Parking Light Output: Green/Black: 10
7 White4 White
8 thick-gauge wires
MC501
16
8
9
1
C-CAN High: pin 6
C-CAN Low: pin 14
OBDII Diagnostic
(connector side view)
OR
2 - EM11, Blue 39-pin conn.
10
1 - MC12, Gray 39-pin conn.
15
Connector
Cut
Ignition Switch
(white 6-pin connector)
(+) Ignition Output: Pink
(+) Starter:
White,
pin 1
(+) Accessory Output: Orange
(+) 12V Input: Red
(+) 12V Input: Red
(+) Starter Output (to starter): Violet
(+) 12V Input: Red/White
(+) Accessory 2 Output:
Pink/White
Starter Input (from key switch): Green
(+) Accessory Interrupt
(connector side)
(+) Accessory Interrupt
(vehicle side)
86 85
87a
87
30
(+) Accessory:
Orange, pin 3
(+) Accessory 2:
Yellow, pin 4
(+) 12V: Black,pin 5
15A fuse
(+) Ignition:
Blue, pin 6
The EMS COM connections are only needed
if the vehicle has a transponder/immobilizer.
Refer to the Vehicle wiring reference chart for
the connector, pin and wire color for your specific vehicle.
C-CAN wires MUST be connected for
proper operation.
Note: For the 2012-2013 Kia Soul,
HS CAN High and Low may be reversed.
17 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Type 4 with OEM alarm
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram ( ).
11: Orange/Yellow: Immo. Data
Interrupt (vehicle side)
6: Yellow: Immo. Data
Interrupt (connector side)
HS CAN Low: Tan: 4
HS CAN High: Tan/Black: 5
10: Red: (+) 12V Input
(-) Trunk Release Output: Red/White: 9
9: Black: (-) Ground
Immobilizer Data Interrupt
(vehicle side): Orange/Black: 3
Immobilizer Data Interrupt
(connector side): Yellow/Black: 2
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
(-) Unlock Output: Dark Blue: 7
(-) Lock Output: Dark Green: 15
Siren
Hood Pin
Refer to the Vehicle
wiring reference chart.
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
(-) RAP Off Output: White/Violet: 11
(-) Parking Light Output: Green/Black: 10
16
8
9
1
C-CAN High: pin 6
C-CAN Low: pin 14
OBDII Diagnostic
(connector side view)
OR
2 - EM11, Blue 39-pin connector
10
1 - MC12, Gray 39-pin connector
15
Connector
Cut
(-) Disarm Output: Lt. Blue/Black: 13
(-) Lock Detection
(-) Unlock
(-) Factory Alarm Arm
(-) Lock
4 x
1A Diodes
5: Orange/Red: Lock Detection
Interrupt (connector side)
4: Yellow/Red: Lock Detection
Interrupt (vehicle side)
(-) Factory Alarm Disarm
C-CAN wires MUST be connected for
proper operation.
Note: For the 2012-2013 Kia Soul,
HS CAN High and Low may be reversed.
EMS COM are connections
only needed if the vehicle has
a transponder/immobilizer.
Refer to the Vehicle wiring reference
charts section for the connector, pin and
wire color in your specific vehicle.
7 White4 White
8 thick-gauge wires
MC501
Ignition Switch
(white 6-pin connector)
(+) Ignition Output: Pink
(+) Starter:
White,
pin 1
(+) Accessory Output: Orange
(+) 12V Input: Red
(+) 12V Input: Red
(+) Starter Output (to starter): Violet
(+) 12V Input: Red/White
(+) Accessory 2 Output:
Pink/White
Starter Input (from key switch): Green
(+) Accessory Interrupt
(connector side)
(+) Accessory Interrupt
(vehicle side)
86 85
87a
87
30
(+) Accessory:
Orange, pin 3
(+) Accessory 2:
Yellow, pin 4
(+) 12V: Black,pin 5
15A fuse
(+) Ignition:
Blue, pin 6
18 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Kia Forte 2010-2013
12V Black 5 (+) Ignition switch. Black 6 A
Accessory Interrupt Orange 3 (+) Ignition switch. Black 6 A
Accessory 2 Yellow 4 (+) Ignition switch. Black 6 A
Ignition Blue 6 (+) Ignition switch. Black 6 A
Starter White 1 (+) Ignition switch. Black 6 A
C-CAN High Black 6 Data OBDII. Black 16 B
C-CAN Low White 14 Data OBDII. Black 16 B
EMS COM Blue/Black 15 Data Passenger kick panel, MC12. Gray 39 F
Parking Lights Blue/Orange 14 (-) Headlight switch. White 18 C
Lock Blue/Black 18 (-) Drivers kick panel. Brown 24 D
Unlock Green/Orange 19 (-) Drivers kick panel. Brown 24 D
Factory Alarm Arm Green/Orange 23 (-) Drivers kick panel. Gray 39 D
Factory Alarm Disarm Blue/Orange 6 (-) Drivers kick panel. Gray 39 D
Lock Detection Black/Orange 2 open Drivers kick panel. Gray 39 D
Drivers Door Green/Orange N/A (-) Drivers kick panel. N/A N/A D
19 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.

Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Kia Forte5 2011-2013
12V Black 5 (+) Ignition switch. Black 6 A
Accessory Interrupt Orange 3 (+) Ignition switch. Black 6 A
Accessory 2 Yellow 4 (+) Ignition switch. Black 6 A
Ignition Blue 6 (+) Ignition switch. Black 6 A
Starter White 1 (+) Ignition switch. Black 6 A
C-CAN High Black 6 Data OBDII. Black 16 B
C-CAN Low White 14 Data OBDII. Black 16 B
EMS COM Blue/Black 15 Data Passenger kick panel, MC12. Gray 39 F
Parking Lights Orange 1 (-) Headlight switch. White 13 C
Lock Blue/Black 18 (-) Drivers kick panel. Gray 39 D
Unlock Green/Orange 19 (-) Drivers kick panel. Gray 39 D
Factory Alarm Arm Green/Orange 23 (-) Drivers kick panel. Gray 39 D
Factory Alarm Disarm Blue/Orange 6 (-) Drivers kick panel. Gray 39 D
Lock Detection Black/Orange 2 open Drivers kick panel. Gray 39 D
Trunk Release Blue/Black 2 (-) Rear of dash fuse box. White 18 E
Drivers Door Red 36 (-) Drivers kick panel. Gray 39 D
Kia Soul 2010-2013
12V White 5 (+) Ignition switch. Black 6 A
Accessory Interrupt White 3 (+) Ignition switch. Black 6 A
Accessory 2 Yellow 4 (+) Ignition switch. Black 6 A
Ignition Pink 6 (+) Ignition switch. Black 6 A
Starter Blue 1 (+) Ignition switch. Black 6 A
C-CAN High Red 6 Data OBDII. Black 16 B
C-CAN Low Blue 14 Data OBDII. Black 16 B
EMS COM Blue/Black 10 Data Above driver kick panel, EM11. Blue 39 G
Parking Lights Pink 1 (-) Headlight switch. White 13 C
Lock Brown N/A (-) Drivers kick panel harness to rear. N/A N/A D
Unlock Green N/A (-) Drivers kick panel harness to rear. N/A N/A D
Factory Alarm Arm Brown 24 (-) Drivers kick panel. White 26 D
Factory Alarm Disarm Gray 13 (-) Drivers kick panel. White 26 D
Lock Detection Yellow 23 open Drivers kick panel. White 26 D
Trunk Release Pink 10 (-) Passenger kick panel. White 26 F
Drivers Door Green 9 (-) Passenger kick panel. White 26 F
20 Directed Digital Solutions HKHT1
© 2020-03-03 Directed. All rights reserved.
