Directed Electronics 3000 User manual

3000
OOwwnneerr’’ssGGuuiiddee
®

i
© 2005 directed electronics, all rights reserved
limited lifetime consumer warranty
For a period of one calendar year from the date of purchase of this auto-security device,
Directed Electronics promises to the ORIGINAL PURCHASER to repair or replace (with a com-
parable reconditioned model), free of cost, any electronic control module which proves to be
defective in workmanship or material under normal use, SO LONG AS THE SYSTEM WAS SOLD,
INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR
IN WHICH THE SYSTEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you must
have a clear copy of your sales receipt containing all of the information shown on the follow-
ing page.
After the first calendar year, from the date of purchase of this auto-security device, Directed
Electronics promises to the ORIGINAL PURCHASER to repair or replace (with a comparable
reconditioned model) any electronic control module which proves to be defective in work-
manship or material under normal use FOR A CHARGE OF $45.00, SO LONG AS THE SYSTEM
WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO INSTALLER, AND REMAINS
IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY INSTALLED. If warranty service is neces-
sary you must have a clear copy of your sales receipt containing all of the information shown
on the following page.
This warranty contains the entire agreement relating to warranty and supersedes all previous
and contemporaneous representations or understandings, whether written or oral. IN ANY
EVENT, DIRECTED ELECTRONICS IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS
CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable
use, neglect, improper service or other causes not arising out of defects in materials or con-
struction. This warranty is nontransferable and does not apply to any unit that has been mod-
ified or used in a manner contrary to its intended purpose and does not cover batteries. The
unit in question must be returned to the manufacturer, postage prepaid. This warranty does
not cover labor costs for the removal, diagnosis, troubleshooting or reinstallation of the unit.
For service on an out-of-warranty product a flat rate fee by model is charged. Contact your
authorized dealer to obtain the service charge for your unit.
These systems are a deterrent against possible theft. Directed Electronics is not offering a guar-
antee or insuring against the theft of the automobile or its contents and disclaims any liability
for the theft of the vehicle and/or its contents. Directed Electronics does not authorize any per-
son to create for it any other obligation or liability in connection with this security system.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUDED
BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE
THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY
AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF
PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD. NEITHER THE MANUFAC-
TURER OR ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR LIABLE FOR
ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO ANY CONSEQUENTIAL
DAMAGES, INCIDENTAL DAMAGES, TOWING, REPAIR, REPLACEMENT, DAMAGES FOR LOSS

ii © 2005 directed electronics, all rights reserved
OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND
THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WAR-
RANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states
do not allow limitations on how long an implied warranty will last or the exclusion or limita-
tion of incidental or consequential damages. This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state.
IMPORTANT NOTE:
This product warranty is automatically void if its date code or serial number is defaced, miss-
ing, or altered. This warranty will not be valid unless you have completed the warranty card
and mailed it to Directed Electronics within 10 days after purchase to the address listed on the
warranty registration card.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
zDate of purchase
zYour full name and address
zAuthorised dealer's company name and address
zType of alarm installed
zYear, make, model and colour of the vehicle
zVehicle registration number
zVehicle identification number
zAll security options installed on vehicle
zInstallation receipts
trademarks and copyrights
Bitwriter®, Clifford®, Code-Hopping®, Directed®, Doubleguard®, ESP®, FailSafe®, Ghost Switch™,
Learn Routine™, Nite-Lite®, Nuisance Prevention® Circuitry, NPC®, Revenger®, Silent Mode™, Soft
Chirp®, Stealth Coding™, Stinger®, Valet®, Vehicle Recovery SystemTM, VRS®, and Warn Away®
are all Trademarks or Registered Trademarks of Directed Electronics.

1
© 2005 directed electronics, all rights reserved
limited lifetime consumer
warranty . . . . . . . . . . . . . . . . . . . . .i
trademarks and copyrights . . . . .ii
table of contents . . . . . . . . . . . . .1
what is included . . . . . . . . . . . . . .2
important information . . . . . . . . .2
your warranty . . . . . . . . . . . . .3
remote configurations . . . . . . . . .4
standard configuration for
in-key 2-button remote . . . . . .5
standard configuration for
3-button remote . . . . . . . . . . .5
using your system . . . . . . . . . . . . .6
arming . . . . . . . . . . . . . . . . . . .6
disarming . . . . . . . . . . . . . . . . .8
disarming without a remote . . .8
auto-immobilisation . . . . . . . . .9
remote siren silencing . . . . . . .9
remote chirp muting
(3-button remote only) . . . . . .10
remote sensor disable . . . . . .11
remote start sensor bypass . . .11
auxiliary channel bypass . . . . .12
valet mode . . . . . . . . . . . . . . .12
remote valet mode . . . . . . . . .13
instant auto-arming bypass . .14
nuisance prevention® circuitry 14
multiple event total recall . . . .15
battery back-up siren . . . . . . . . .15
diagnostics . . . . . . . . . . . . . . . . . .16
arming diagnostics . . . . . . . . .16
disarming diagnostics . . . . . . .17
arm/disarm diagnostic chart . .17
table of zones . . . . . . . . . . . .18
high frequency . . . . . . . . . . . . . .19
rapid resume logic . . . . . . . . . . .19
power saver mode . . . . . . . . . . .20
system sensors and adjustments 20
programming options . . . . . . . .21
manual programming
instructions . . . . . . . . . . . . . .22
user selectable features . . . . .24
user selectable features
descriptions - column one . . .24
user selectable features
descriptions - column two . . .26
user selectable features
descriptions - column three . .27
pin programming . . . . . . . . . .29
glossary of terms . . . . . . . . . . . . .31
security & convenience
expansions . . . . . . . . . . . . . . . . . .32
quick reference guide . . . . . . . .33
table of contents

2© 2005 directed electronics, all rights reserved
what is included
zOne control module/siren with built-in Tilt sensor and 24 pin
main wiring harness (attached)
zOne Mini-Blue status LED
zOne 2-button Valet switch
zOne in-key 2-button remote
zOne 3-button remote
zTwo Merlin decal’s
zThis Owner’s Guide
zWarranty Card
important information
Congratulations on the purchase of your state-of-the-art motorcycle
security system. It has been designed to provide years of trouble-free
operation. This system must be installed by an authorised dealer.
Installation of this product by anyone other than an authorised dealer
voids the warranty. As verification of authorization, all authorised deal-
ers are provided with preprinted dealer certificates.
In order to maximize the use of this system, please review this owner's
guide carefully prior to using your system. You can print additional or
replacement copies of this owner’s guide by accessing the Directed
website at www.directed.com.
nnoottee::Your system MUST be installed by an Authorised dealer in accor-
dance with the instructions we supply them. The Merlin 3000 system
is designed to be installed on any 12-volt, negative ground motorcy-
cle or moped.

3
© 2005 directed electronics, all rights reserved
system maintenance
The system requires no specific maintenance. The batteries in your
remotes will last approximately one year under normal use. Your 3-but-
ton remote is powered by a miniature 3V lithium battery (CR2032). Your
in-key 2-button remote is powered by a 12V miniature battery (type
27A).
your warranty
It is necessary to retain your sales receipt, which reflects that the prod-
uct was installed by an authorised dealer. For full details regarding your
warranty coverage, please refer to the consumer warranty section of
this guide.
nnoottee::Other than the remote controls, this system has no user-service-
able parts. Your authorized dealer can correct any system wiring prob-
lems and, if needed, can return any malfunctioning component to
Directed Electronics for repair/replacement under the terms of the
Limited Lifetime Warranty printed at the beginning of this guide.

4© 2005 directed electronics, all rights reserved
remote configurations
The 3000 system has an in-key 2-button remote control and a 3-button
remote control. Two additional Merlin remote controls can be added.
3-BUTTON REMOTE CONTROL
A
RM/DISARM/PANIC
LED
SILENT ARM/DISARM
ACCESSORY
FRONT REAR
LED
A
RM/DISARM/PANIC ACCESSORY
IN-KEY 2-BUTTON REMOTE CONTROL

5
© 2005 directed electronics, all rights reserved
remote functions
This system uses computer-based code learning to learn the remote
buttons. This makes it possible to assign any remote button to any sys-
tem function. The remotes initially come programmed with standard
configuration. The buttons in all of the instructions in this manual cor-
respond to a standard configuration remote.
standard configuration for in-key 2-button remote
Button
The arming, disarming, and panic functions are controlled by this button.
Button
An optional accessory convenience or expansion function that you have
added to your system can be activated by pressing this button.
and Buttons
When pressed together, these buttons disable the on-board control
module tilt sensor and any optionally installed sensors.
standard configuration for 3-button remote
Button
The arming, disarming, and panic functions are controlled by this button.

6© 2005 directed electronics, all rights reserved
Button
An optional accessory convenience or expansion function that you have
added to your system can be activated by pressing this button.
Button
Silent arm and disarm is controlled by this button.
and Buttons
When pressed together, these buttons disable the on-board control
module tilt sensor and any optionally installed sensors.
and Buttons
Remotely enters or exits Valet.
using your system
The buttons used in the instructions in this manual correspond to the
standard remote configuration. If your remote has been custom con-
figured, the icons on your remote buttons may not correspond to the
indicated functions.
arming
You can activate, or arm, the system by pressing on your remote
for one second. When the system arms, you will hear one short siren
sound, or chirp, and see the parking lights flash once. The LED will illu-
minate steadily.

7
© 2005 directed electronics, all rights reserved
While the system is armed, the LED status indicator will flash approxi-
mately once per second showing that the system is actively protecting
your vehicle. If you hear more than one chirp when arming, refer to the
Diagnostics section of this guide. These extra chirps confirm a malfunc-
tion autobypass.
The security system also can be programmed to arm itself
automatically without a remote (called passive arming). If the system is
programmed for passive arming, it will automatically arm 30-seconds
after the ignition is turned off. Whenever the system is in its 30-second
passive-arming countdown, the siren will chirp once and the lights will
flash once five seconds after countdown has commenced. This is indi-
cated by the rapid flash from the status LED. The system is not actually
armed at that point. The system arms after the 30-second countdown
has elapsed, but the siren will not chirp. The early chirps provide you
with a 25-second warning prior to arming.
When armed, your vehicle is protected as follows:
zThe LED will flash as a visible theft deterrent.
zIf the tilt sensor detects the motorcycle is being moved in an
attempt to steal it, the system will immediately trigger the
siren and flash the indicator lights.
This sensor is capable of independently learning the bike’s ini-
tial angles of vertical and horizontal inclination each time it is
parked, ensuring the most accurate tilt (vertical and horizon-
tal) sensing possible.
zIf a protected switch is opened, the system will immediately
trigger the siren and flash the indicator lights.
zThe immobiliser prevents the motorcycle’s engine from starting.
nnoottee::If one of the zone 4 or 5 switch inputs is active or the ignition is
on, the system will not passively arm. Additionally, if one of these
switches is activated or the ignition is turned on, the countdown will
cease, then begin again when the input is removed.
