Directed Electronics Hornet 563T User manual

MMooddeell556633TT
➤
OOwwnneerr’’ssGGuuiiddee

i
© 2003 directed electronics, inc.
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or
replace with a comparable reconditioned model any Directed unit (hereafter the "unit"),
excluding without limitation the siren, the remote transmitters, the associated sensors and
accessories, which proves to be defective in workmanship or material under reasonable use
during the lifetime of the vehicle provided the following conditions are met: the unit was
professionally installed and serviced by an authorized Directed dealer; the unit will be pro-
fessionally reinstalled in the vehicle in which it was originally installed by an authorized
Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy
of the bill of sale or other dated proof of purchase bearing the following information: con-
sumer's name, telephone number and address; the authorized dealers name, telephone
number and address; complete product description, including accessories; the year, make
and model of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote trans-
mitters and the associated sensors and accessories, carry a one-year warranty from the date
of purchase of the same. This warranty is non-transferable and is automatically void if: the
original purchaser has not completed the warranty card and mailed it within ten (10) days
of the date of purchase to the address listed on the card; the unit's date code or serial num-
ber is defaced, missing or altered; the unit has been modified or used in a manner con-
trary to its intended purpose; the unit has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising out of defects in materi-
als or construction. The warranty does not cover damage to the unit caused by installa-
tion or removal of the unit. Directed, in its sole discretion, will determine what consti-
tutes excessive damage and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-
ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,
WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,
ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,
OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-
ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS
UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-
AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND
HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-
ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR
MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

ii © 2003 directed electronics, inc.
CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM
OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER
VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY
AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY
CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.
DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-
ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con-
sequential damages. This warranty gives you specific legal rights and you may also have
other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-
rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-
876-0800. Directed security systems, including this unit, are deterrents against possible
theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability what-
soever, including without limitation, liability for theft, damage and/or vandalism.
Directed does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
➤Date of purchase
➤Your full name and address
➤Authorized dealer's company name and address
➤Type of alarm installed
➤Year, make, model and color of the automobile
➤Automobile license number
➤Vehicle identification number
➤All security options installed on automobile
➤Installation receipts

1
© 2003 directed electronics, inc.
ttaabblleeooffccoonntteennttss
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy................................................................................ii
ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn................................................................................33
wwhhaattiissiinncclluuddeedd............................................................................................................44
iimmppoorrttaannttiinnffoorrmmaattiioonn..................................................................................................44
system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ttrraannssmmiitttteerrffuunnccttiioonnss....................................................................................................66
standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
uussiinnggyyoouurrssyysstteemm........................................................................................................88
warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
active arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
passive arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
multi-level security arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
arming while driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
high security disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
disarming without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
remote start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
valet take-over . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
short-run/turbo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ssaaffeettyyffeeaattuurreess..............................................................................................................2222
starter anti-grind circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
disabling the remote start system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
over and under rev protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
shut down inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
nuisance prevention circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
ddiiaaggnnoossttiiccss..................................................................................................................2255
arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
system status chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
interpreting zone diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
ccooddeehhooppppiinngg..............................................................................................................2288
hhiigghhffrreeqquueennccyy............................................................................................................2299

2© 2003 directed electronics, inc.
oowwnneerrrreeccooggnniittiioonn......................................................................................................2299
rraappiiddrreessuummeellooggiicc......................................................................................................3300
ppoowweerrssaavveerrmmooddee......................................................................................................3300
pprrooggrraammmmiinnggooppttiioonnss................................................................................................3311
sseeccuurriittyy&&ccoonnvveenniieenncceeeexxppaannssiioonnss............................................................................3344
gglloossssaarryyoofftteerrmmss........................................................................................................3366

3
© 2003 directed electronics, inc.
ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn
controls the AArrmmand PPaanniiccOn/Off function.
controls the DDiissaarrmmand PPaanniiccOff function.
controls SSiilleennttMMooddee™™and AAuuxxiilliiaarryychannel 22output.
controls the RReemmootteeSSttaarrttfunction.
and pressed together control the TTiimmeerrmode.
and pressed together control TTuurrbboo//SShhoorrttRRuunn.
and pressed together control channel 44output.
and pressed together control channel 55output

4© 2003 directed electronics, inc.
wwhhaattiissiinncclluuddeedd
➤A control module
➤An XHF receiver/antenna
➤Two four-button transmitters
➤A Stinger™ DoubleGuard® two-stage shock sensor
➤A Revenger™ Soft Chirp™ six-tone programmable siren
➤A red status LED indicator light
➤A push-button Valet® switch
➤Your warranty registration
➤A shut-down toggle switch
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your combination remote
start alarm system. Due to the complexity of this system, it must
be installed by an authorized dealer only. Installation of this
product by anyone other than an authorized dealer voids the
warranty. All dealers are provided with a preprinted dealer certifi-
cate to verify authorization.
By carefully reading this Owner's Guide prior to using your
system, you will maximize the use of this system and its features.
You can print additional or replacement copies of this manual by
accessing our web site at www.directed.com.

5
© 2003 directed electronics, inc.
system maintenance
The system requires no specific maintenance. Your remote is
powered by a small, lightweight 3-volt lithium battery that will
last approximately one year under normal use. When the battery
begins to weaken, operating range will be reduced and the LED
on the remote will dim.
your warranty
Your warranty registration must be completely filled out and
returned within 10 days of purchase. Your product warranty
will not be validated if your warranty registration is not returned.
Make sure you receive the warranty registration from your dealer.
It is also necessary to keep your proof of purchase, which reflects
that the product was installed by an authorized dealer.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
➜
➜
➜

6© 2003 directed electronics, inc.
caution
This product is designed for fuel injected, automatic transmis-
sion vehicles only. Use of this product in a standard transmission
vehicle is dangerous and contrary the product's intended use.
ttrraannssmmiitttteerrffuunnccttiioonnss
The receiver uses a computer-based Learn Routine to learn the
transmitter buttons. This makes it possible to assign any remote
transmitter button to any receiver function. The transmitter
initially comes programmed with Standard Configuration, but
may also be customized by an authorized dealer. The buttons in
all of the instructions in this manual correspond to a Standard
Configuration transmitter.
standard configuration
Button
The arming and panic functions are controlled by pressing this
button for one second.
Button
The disarming function is controlled by pressing this button for
one second.
Button
Silent Mode™ and an optional auxiliary function are controlled
by this button. (Silent Mode works by pressing this button for
➜
➜

7
© 2003 directed electronics, inc.
less than one second before arming or disarming. An optional
auxiliary function, such as trunk release, can be controlled by
pressing this button for 1.5 seconds.)
The auxiliary output controls __________________________.
Button
The remote start function of your system is controlled by
pressing this button twice within 3 seconds.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
and Buttons
The remote start timer mode is controlled by pressing these
buttons simultaneously.
and Buttons
The short-run turbo mode is activated when these buttons are
pressed simultaneously.

8© 2003 directed electronics, inc.
uussiinnggyyoouurrssyysstteemm
warning! safety first
The following safety warnings must be observed at all times:
➤Due to the complexity of this system, installation of this
product must only be performed by an authorized Directed
dealer.
➤When properly installed, this system can start the vehicle via
a command signal from the remote control transmitter.
Therefore, never operate the system in an enclosed area or
partially enclosed area without ventilation (such as a garage).
When parking in an enclosed or partially enclosed area or
when having the vehicle serviced, the remote start system
must be disabled using the installed toggle switch. It is the
user's sole responsibility to properly handle and keep out of
reach from children all remote control transmitters to assure
that the system does not unintentionally remote start the
vehicle. TTHHEEUUSSEERRMMUUSSTTIINNSSTTAALLLLAACCAARRBBOONN
MMOONNOOXXIIDDEEDDEETTEECCTTOORRIINNOORRAABBOOUUTTTTHHEE
LLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOOTTHHEEVVEEHHIICCLLEE..AALLLL
DDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTTLLIIVVIINNGGAARREEAASS
TTOOTTHHEEEENNCCLLOOSSEEDDOORRPPAARRTTIIAALLLLYYEENNCCLLOOSSEEDD
VVEEHHIICCLLEESSTTOORRAAGGEEAARREEAAMMUUSSTTAATTAALLLLTTIIMMEESS
RREEMMAAIINNCCLLOOSSEEDD..These precautions are the sole respon-
sibility of the user.
➤Use of this product in a manner contrary to its intended
➜

9
© 2003 directed electronics, inc.
mode of operation may result in property damage, personal
injury, or death. (1) Never remotely start the vehicle with the
vehicle in gear, and (2) Never remotely start the vehicle with
the keys in the ignition. The user must also have the neutral
safety feature of the vehicle periodically checked, wherein the
vehicle must not remotely start while the car is in gear. This
testing should be performed by an authorized Directed dealer
in accordance with the Safety Check outlined in the product
installation guide. If the vehicle starts in gear, cease remote
start operation immediately and consult with the authorized
Directed dealer to fix the problem.
➤After the remote start module has been installed, contact
your authorized dealer to have him or her test the remote
start module by performing the Safety Check outlined in the
product installation guide. If the vehicle starts when
performing the Neutral Safety Shutdown Circuit test, the
remote start unit has not been properly installed. The remote
start module must be removed or the installer must properly
reinstall the remote start system so that the vehicle does not
start in gear. All installations must be performed by an autho-
rized Directed dealer. OOPPEERRAATTIIOONNOOFFTTHHEERREEMMOOTTEE
SSTTAARRTTMMOODDUULLEEIIFFTTHHEEVVEEHHIICCLLEESSTTAARRTTSSIINNGGEEAARR
IISSCCOONNTTRRAARRYYTTOOIITTSSIINNTTEENNDDEEDDMMOODDEEOOFFOOPPEERR--
AATTIIOONN..OOPPEERRAATTIINNGGTTHHEERREEMMOOTTEESSTTAARRTTSSYYSSTTEEMM
UUNNDDEERRTTHHEESSEECCOONNDDIITTIIOONNSSMMAAYYRREESSUULLTTIINN
PPRROOPPEERRTTYYDDAAMMAAGGEEOORRPPEERRSSOONNAALLIINNJJUURRYY..YYOOUU
MMUUSSTTIIMMMMEEDDIIAATTEELLYYCCEEAASSEETTHHEEUUSSEEOOFFTTHHEE

10 © 2003 directed electronics, inc.
UUNNIITTAANNDDSSEEEEKKTTHHEEAASSSSIISSTTAANNCCEEOOFFAANNAAUUTTHHOO--
RRIIZZEEDDDDIIRREECCTTEEDDDDEEAALLEERRTTOORREEPPAAIIRROORR
DDIISSCCOONNNNEECCTTTTHHEEIINNSSTTAALLLLEEDDRREEMMOOTTEESSTTAARRTT
MMOODDUULLEE..DDIIRREECCTTEEDDWWIILLLLNNOOTTBBEEHHEELLDD
RREESSPPOONNSSIIBBLLEEOORRPPAAYYFFOORRIINNSSTTAALLLLAATTIIOONNOORR
RREEIINNSSTTAALLLLAATTIIOONNCCOOSSTTSS..
active arming
You can arm the system by pressing of your transmitter for
one second. When the system arms, you will hear a short siren
sound, or chirp, and see the parking lights flash once. If the
power door locks are controlled by the system, the doors will also
lock. While the system is armed, the status LED will flash
approximately once per second, indicating that the system is
actively protecting your vehicle. If you hear a second chirp after
arming and note that the status LED is flashing in groups, see the
Diagnostics Section of this guide. This extra chirp is called Bypass
Notification.
passive arming
The system can be programmed to arm itself automatically (called
passive arming). If the system is programmed for passive arming, it
will automatically arm 30 seconds after the ignition is turned off
and the system detects that you have left the vehicle by opening and
closing a door. Whenever the system is in its 30-second passive
arming countdown, the status LED will flash twice as fast as it does
when the system is armed. At the 20-second point of the count-
➜
➜

11
© 2003 directed electronics, inc.
down, the siren will chirp to indicate that the system is about to
arm. At the 30-second point, the parking lights will flash to indicate
that the system is armed.
When armed your vehicle is protected as follows:
➤Light impacts trigger the Warn Away®signal. When trig-
gered, the siren chirps and the parking lights flash for a few
seconds.
➤Heavy impacts trip a Triggered Sequence. The sequence
consists of the siren sounding continuously and the parking
lights flashing for a pre-programmed period, which can range
in duration from 1 to 180 seconds.
➤If a door is opened, the system will immediately start
chirping the siren and flashing the parking lights. Three
seconds later, the siren output changes to a continuous blast.
This progressive response gives you time to disarm the system
with your transmitter if you inadvertently open the door
while the system is armed, while still providing instant re-
sponse (even if the door is immediately closed).
➤Turning on the ignition key will trip the same progressive re-
sponse as opening a door.
➤The optional starter kill prevents the vehicle’s starter from
cranking.
note: If any protected entry point (such as a door or a
switch-protected trunk or hood) is open, the system will
not passively arm (unless forced passive arming is pro-
grammed on. See Programming Options section.) Addi-
tionally, each time a sensor is triggered during the arming
countdown, the 30-second countdown starts over.

© 2003 directed electronics, inc.
multi-level security arming
Multi-Level Security Arming allows you to select which of the
system's inputs or sensors will be active and which will be
bypassed when the system is armed. (See Table of Zones section
of this guide.) Pressing (only in Standard Configuration)
again within five seconds of arming the system will activate the
Multi-Level Security feature. Each time is pressed again, a
different security level is selected. The different security levels are
selected as follows:
➤Press once: The siren chirps once. The system is armed.
➤Press a second time within five seconds: The siren
chirps twice followed by a long chirp. Zone 2 is now
bypassed.
➤Press a third time within five seconds: The siren chirps
three times followed by a long chirp. Zone 4 is now
bypassed.
➤Press a fourth time within five seconds: The siren chirps
four times followed by a long chirp. Zones 2 and 4 are now
bypassed.
➤Press a fifth time within five seconds: The siren chirps
five times followed by a long chirp. All input zones, except
the ignition, are now bypassed.
➜

13
© 2003 directed electronics, inc.
arming while driving
Your security system can be armed while driving the vehicle!
Simply press on the transmitter for two seconds while the
vehicle is running. The siren will chirp once to indicate that the
security system is armed, and then once more to indicate that the
ignition is on. The system will not respond to any input except
the door triggers, and the starter kill relay (if installed) will not be
activated. Once you have arrived at your destination, the system
will disarm when the ignition is turned off. The siren will chirp
twice and the LED will then stop flashing. The system can also
be disarmed at any time by pressing ..
disarming
To disarm the security system, press . You will hear two
chirps, and the parking lights will flash twice. If the power locks
are controlled by the system, the doors will also unlock. The siren
chirping either four or five times when disarming indicates
Tamper Alert, which is described in the Diagnostics Section of
this guide.
➜
➜
note: Multi-Level Security Arming only applies to a sin-
gle arming cycle. Once the system is disarmed and then
re-armed, all the zones will be active again.

© 2003 directed electronics, inc.
high security disarm
This security system offers High Security Disarm. High Security
Disarm is a feature that makes it possible to silence and reset the
system while it is triggering, without disarming the system. If the
system is triggered and the siren has been sounding for longer
than six seconds, pressing on the remote transmitter will
stop the trigger and return the unit to the armed state. The
system will not disarm, but rather reset. This prevents you from
disabling the system should you wish to disarm it without visu-
ally checking the vehicle. Pressing after resetting the system
will disarm the system; pressing this button during the first six
seconds of the triggered sequence will disarm the security system
immediately. The six second timer is provided for your conve-
nience, in case the system is accidentally triggered.
disarming without a transmitter
If your remote transmitter is lost or damaged, you can manually
disarm your vehicle security system. To disarm the system
without a transmitter, you must have the vehicle's ignition key
and know where the Valet®switch is located. Be sure to check
with your installer at the time of installation for both the location
and the preset response (1-5 presses) of the Valet®switch.
➜
➜

15
© 2003 directed electronics, inc.
To disarm the security system,
turn the ignition to the ON posi-
tion. Press the Valet button the
preset number of times (one to
five times) within 15 seconds.
After five seconds, the system
will disarm. If the system does
not disarm, you may have waited
too long; turn the ignition off and on and try again.
Location of Valet Button_________________________________
Number of Presses_____________________________________
silent mode
To temporarily turn off the arm or disarm chirps, use Silent
Mode™. Simply press for less than one second before
arming or disarming, and the confirmation chirp(s) will be elim-
inated for that one operation only. If you want the arm/disarm
chirps turned off permanently, your dealer can do this for you.
note: The Warn Away® response to lighter impacts is
bypassed if the system is armed using Silent Mode. This
ensures that no chirps will be emitted by the siren in an
area you want chirp-free. The system is still fully capable
of triggering. Only the Warn Away® response is
bypassed.
➜
important! The Valet®switch can be programmed to
respond to 1-5 presses for the disarm function. You must
check with the installer to verify the programming for
your individual unit.
DRW-35

16 © 2003 directed electronics, inc.
panic mode
If you are threatened in or near your vehicle, you can attract
attention by triggering the system with your transmitter. Just
press for two seconds, and you will enter Panic Mode. The
siren will sound and the parking lights will flash for the
programmed siren duration. To stop Panic Mode at any time,
press on the remote transmitter again.
valet mode
You can prevent your security system from automatically arming
and triggering by using Valet Mode. This is very useful when
washing the vehicle or having it serviced. In Valet Mode, the
security system will not arm, even with the remote transmitter,
but all convenience functions (door locks, trunk release, etc.) will
continue to work normally.
To enter or exit Valet Mode:
1. Turn the ignition on.
2. Turn the ignition off.
3. Press and release the Valet
switch within 10 seconds.
The status LED will light solidly if you are entering Valet Mode,
and it will go out if you are exiting Valet Mode.
To enter or exit Valet Mode using the transmitter:
1. Open any vehicle door.
2. Press .
DRW-35
➜
➜

17
© 2003 directed electronics, inc.
3. Press .
4. Press again.
The status LED will light solidly if you are entering Valet Mode,
and it will go out if you are exiting Valet Mode.
remote start
This feature allows you to remotely start and run your vehicle for
a programmable period of time. This makes it possible to warm
up the engine, as well as adjust the interior temperature of the ve-
hicle with the climate control system. If interior heating or
cooling is desired, the climate controls must be preset, and the
fan blower must be set to the desired level prior to remote starting
the vehicle.
To remote start the vehicle:
1. Press on the transmitter twice within 3 seconds.
2. The parking lights will flash to confirm that the vehicle will
attempt to start.
3. In gasoline vehicles, the engine will start 4 seconds after the
parking lights flash. In diesel vehicles, the engine will start
when the WAIT-TO-START indicator on the vehicle's dash
goes out.
iimmppoorrttaanntt!!(1) Never remote start your vehicle when the
keys are in the ignition, except when performing Valet®
Take-Over, and (2) Never start the vehicle if it is not in
either PARK or NEUTRAL.
➜
