Directed Electronics 436 Series User manual

443366SSeerriieess
➤
OOwwnneerr’’ssGGuuiiddee

i
© 2002 directed electronics, inc.
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or
replace with a comparable reconditioned model any Directed unit (hereafter the "unit"),
excluding without limitation the siren, the remote transmitters, the associated sensors and
accessories, which proves to be defective in workmanship or material under reasonable use
during the lifetime of the vehicle provided the following conditions are met: the unit was
professionally installed and serviced by an authorized Directed dealer; the unit will be pro-
fessionally reinstalled in the vehicle in which it was originally installed by an authorized
Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy
of the bill of sale or other dated proof of purchase bearing the following information: con-
sumer's name, telephone number and address; the authorized dealers name, telephone
number and address; complete product description, including accessories; the year, make
and model of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote trans-
mitters and the associated sensors and accessories, carry a one-year warranty from the date
of purchase of the same. This warranty is non-transferable and is automatically void if: the
original purchaser has not completed the warranty card and mailed it within ten (10) days
of the date of purchase to the address listed on the card; the unit's date code or serial num-
ber is defaced, missing or altered; the unit has been modified or used in a manner con-
trary to its intended purpose; the unit has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising out of defects in materi-
als or construction. The warranty does not cover damage to the unit caused by installa-
tion or removal of the unit. Directed, in its sole discretion, will determine what consti-
tutes excessive damage and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-
ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,
WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,
ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,
OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-
ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS
UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-
AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND
HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-
ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR
MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

ii © 2002 directed electronics, inc.
CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM
OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER
VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY
AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY
CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.
DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-
ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con-
sequential damages. This warranty gives you specific legal rights and you may also have
other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-
rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-
876-0800. Directed security systems, including this unit, are deterrents against possible
theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability what-
soever, including without limitation, liability for theft, damage and/or vandalism.
Directed does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
➤Date of purchase
➤Your full name and address
➤Authorized dealer's company name and address
➤Type of alarm installed
➤Year, make, model and color of the automobile
➤Automobile license number
➤Vehicle identification number
➤All security options installed on automobile
➤Installation receipts

1
© 2002 directed electronics, inc.
ttaabblleeooffccoonntteennttss
LLiimmiitteeddLLiiffeettiimmeeCCoonnssuummeerrWWaarrrraannttyy......................................................................ii
SSttaannddaarrddTTrraannssmmiitttteerrCCoonnffiigguurraattiioonn........................................................................22
WWhhaattiissIInncclluuddeedd................................................................................................33
IImmppoorrttaannttIInnffoorrmmaattiioonn............................................................................................33
System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Your Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC/ID Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TTrraannssmmiitttteerrFFuunnccttiioonnss............................................................................................55
Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
UUssiinnggYYoouurrSSyysstteemm..............................................................................................66
Active Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Passive Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Arming While Driving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disarming Without a Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Silent Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Panic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Nuisance Prevention® Circuitry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DDiiaaggnnoossttiiccss............................................................................................................1155
Arming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Disarming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
System Status Chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table of Zones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Interpreting Zone Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
CCooddeeHHooppppiinngg......................................................................................................1188
HHiigghhFFrreeqquueennccyy....................................................................................................1199
OOwwnneerrRReeccooggnniittiioonn................................................................................................1199
RRaappiiddRReessuummeeLLooggiicc..............................................................................................2200
PPoowweerrSSaavveerrMMooddee................................................................................................2200
PPrrooggrraammmmiinnggOOppttiioonnss........................................................................................2211
IInnssttaallllaattiioonnOOppttiioonnss............................................................................................2244
VVeehhiicclleeRReeccoovveerryySSyysstteemm((VVRRSS®®))..........................................................................2255
Arming the VRS®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
VRS® Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Disarming the VRS® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
GGlloossssaarryyooffTTeerrmmss..................................................................................................2288
SSeeccuurriittyy&&CCoonnvveenniieenncceeEExxppaannssiioonnss......................................................................3300
QQuuiicckkRReeffeerreenncceeGGuuiiddee((RReemmoovvaabbllee))......................................................................3333

2© 2002 directed electronics, inc.
ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn
controls the AArrmmfunction.
controls the DDiissaarrmmfunction.
controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt.
controls the PPaanniiccfunction.
and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt.

3
© 2002 directed electronics, inc.
wwhhaattiissiinncclluuddeedd
➤One control module
➤A pair of four-button transmitters
➤A Stinger® Doubleguard® dual-stage shock sensor
➤The Revenger® Soft Chirp® six-tone programmable siren
➤The red status LED indicator light
➤A push-button Valet button
➤Your warranty registration
➤Failsafe® Starter Kill ready circuitry
(may require additional labor)
➤XHF external receiver/antenna
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years
of trouble-free operation. Due to the complexity of this system,
it must be installed by an authorized dealer only. Installation of
this product by anyone other than an authorized dealer voids the
warranty. All dealers are provided with preprinted dealer certifi-
cates to verify that they are authorized.
This owner’s guide should help you to get the most out of your
system. Please take the time to read it prior to using the system.

4© 2002 directed electronics, inc.
system maintenance
The system requires no specific maintenance. Your remote
control is powered by a small, lightweight 3 volt lithium battery
that will last approximately one year under normal use. When
the battery weakens, operating range will be reduced and the
LED on the remote will dim.
your warranty
Your warranty registration must be returned and the bar code
serial number must not be removed. If the warranty registration
is not returned, you do not have a warranty. It is also necessary
to keep your proof of purchase, which reflects that the product
was installed by an authorized dealer. Make sure that you receive
the warranty registration from your dealer.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
➜
➜
➜

5
© 2002 directed electronics, inc.
ttrraannssmmiitttteerrffuunnccttiioonnss
This system uses a computer-based learn routine to learn the
transmitter buttons. This makes it possible to assign any trans-
mitter button to any system function. The transmitter initially
comes programmed with Standard Configuration, but may also
be customized by an authorized dealer. The buttons in all of the
instructions in this manual correspond to a Standard
Configuration transmitter.
standard configuration
Button
The arming function is controlled by pressing this button for one
second.
Button
The disarming function is controlled by pressing this button for
one second.
Button
Silent Mode™ and an optional auxiliary function are controlled
by pressing this button. (Silent Mode works by pressing this
button for less than one second before arming or disarming. An
optional auxiliary function, such as trunk release, can be
controlled by pressing this button for 1.5 seconds.)
The auxiliary output controls __________________________.
Button
The panic feature is controlled by pressing this button for two
seconds.
➜

6© 2002 directed electronics, inc.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls_________________________.
uussiinnggyyoouurrssyysstteemm
The buttons used in the instructions in this manual correspond
to the standard configuration. Remember, this is not the only
way your transmitter may be set up. It can be custom configured
to meet your needs.
active arming
You can activate, or arm, the system by pressing on your
transmitter for one second. When the system arms, you will hear
a short siren sound, or chirp, and the parking lights will flash
once. If the vehicle’s power door locks have been connected to
the system, the doors will lock.
While the system is armed, the status LED will flash approxi-
mately once per second, indicating that the system is actively
protecting your vehicle. If you hear a second chirp after arming,
and see the status LED flashing in groups, refer to the Diagnostics
section of this guide. This extra chirp is called Bypass Notification.
➜

7
© 2002 directed electronics, inc.
passive arming
The system also can be programmed to arm itself automatically
(called passive arming). If the system is programmed for passive
arming, it will automatically arm 30 seconds after the ignition is
turned off and the system "sees" you leave the vehicle by opening
and closing a door. Whenever the system is in its 30-second
passive-arming countdown, the status LED will flash twice as fast
as it does when the system is armed. The siren will chirp once 20
seconds after the last door has been closed. The system is not
actually armed at that point. The system arms and the doors lock
(if connected and programmed for passive locking) at the 30
second mark, but the siren will not chirp. The early chirp
provides you with a 10-second warning prior to arming.
When armed, your vehicle is protected as follows:
➤Light impacts will trigger the Warn Away®signal. When trig-
gered, the siren will chirp and the parking lights will flash for
a few seconds.
➤Heavy impacts will trigger the system. The triggered
sequence is between 1-180 seconds of constant siren and
flashing parking lights.
➤If a door is opened, the system will immediately start
note: If any protected entry point (such as a door or a
switch-protected trunk or hood) is open, the system will
not passively arm (unless forced passive arming is pro-
grammed on). See Programming Options section of this
guide. Additionally, each time a protected entry is trig-
gered during the arming countdown, the 30-second
countdown starts over.
➜

8© 2002 directed electronics, inc.
chirping the siren and flashing the parking lights. Three
seconds later, the siren output changes to a continuous blast.
This progressive response gives you time to disarm the sys-
tem with your transmitter if you inadvertently open the door
while the system is armed, while still providing an instant
response (even if the door is immediately closed).
➤Turning on the ignition key will trip the same two-stage
response as opening a door.
➤The optional starter kill prevents the vehicle’s starter from
cranking.
multi-level security arming
Multi-Level Security Arming allows you to select which of the
security system's inputs or sensors will be active and which will
be bypassed at the time that the system is armed. (See the Table
of Zones section of this guide.) Pressing again within five
seconds of arming the security system will activate the Multi-
Level Security Arming feature. Each time is pressed again, a
different security level is selected. The different security levels
can be selected as follows:
➤Press one time: The siren chirps once. The system is
armed.
➤Press a second time within five seconds: The siren
chirps twice followed by a long chirp. Zone 2 is now
bypassed.
➤Press a third time within five seconds: The siren chirps
➜

9
© 2002 directed electronics, inc.
three times followed by a long chirp. Zone 4 is now
bypassed.
➤Press a fourth time within five seconds: The siren chirps
four times followed by a long chirp. Zones 2 and 4 are now
bypassed.
➤Press a fifth time within five seconds: The siren chirps
five times followed by a long chirp. All input zones, except
the ignition, are now bypassed.
➤Continued pressing of will begin the Multi-Level
Security Arming cycle over again.
arming while driving
Your system can be armed while driving the vehicle. Simply press
on your transmitter for two second while the vehicle is running
or while the ignition is on. The siren will chirp once and then once
more to indicate that the ignition is on. The security system will not
respond to any input except the door triggers and the Failsafe®
Starter Kill (if installed) will not be activated. The security system
will disarm automatically whenever the ignition is turned off. The
siren will chirp twice and the LED will stop flashing.
➜
note: Multi-Level Security Arming only applies to a sin-
gle arming cycle. Once the system is disarmed and then
re-armed, all the zones will be active again.

10 © 2002 directed electronics, inc.
disarming
To disarm the system, press . You will hear two chirps, and
the parking lights will flash twice. If the power locks are
connected to the system, the doors will unlock. If the siren chirps
either four or five times when disarming, refer to the Diagnostics
section of this guide. This is called Tamper Alert.
high security disarm
This security system offers High Security Disarm. High Security
Disarm is a feature that makes it possible to silence and reset the
system while it is triggering, without disarming the system. If the
system is triggered and the siren has been sounding for longer
than six seconds, pressing or on the remote transmitter
will stop the trigger and return the unit to the armed state. The
system will not disarm, but rather reset. This prevents you from
disabling the system should you wish to disarm it without visu-
ally checking the vehicle. Pressing after resetting the system
will disarm the system; pressing this button during the first six
seconds of the triggered sequence will disarm the security system
immediately. The six second timer is provided for your conve-
nience, in case the system is accidentally triggered.
➜
➜
note: If programmed for the optional Vehicle Recovery
System (VRS®) feature, arming with the transmitter will
arm the VRS® feature. (See Vehicle Recovery System®
section of this guide.)

11
© 2002 directed electronics, inc.
disarming without a transmitter
This feature allows you to disarm the security system without the
remote transmitter should it be lost, damaged, or disabled. In order
to disarm the system without a remote transmitter, you must have
the vehicle’s ignition key and know where the Valet button is
located. Be sure to check with the installer for the location and the
number of presses of the Valet button required to disarm the system.
To disarm the security system,
turn the ignition to the ON posi-
tion. Press the Valet button the
preset number of times (one to
five times) within 15 seconds.
After five seconds the system will
disarm. If the system does not
disarm, you may have waited too
long; turn the ignition off and on
and try again.
Location of Valet Button_________________________________
Number of Pulses______________________________________
important! The unit can be programmed to respond to
one to five pulses of the Valet button for the disarm func-
tion. Be sure to check with the installer for the desired
programming.
DRW-35
➜

12 © 2002 directed electronics, inc.
silent mode
To temporarily turn off the arm or disarm chirps, use Silent
Mode™. Simply press for less than one second before
arming or disarming, and the confirmation chirp(s) will be elim-
inated for that one operation only. If you want the arm/disarm
chirps turned off permanently, your dealer can do this for you.
panic mode
If you are threatened in or near your vehicle, you can attract
attention by triggering the system with your transmitter. Just
press for two seconds, and you will enter Panic Mode. The
siren will sound and the parking lights will flash for the
programmed siren duration. To stop Panic Mode at any time,
press on the remote transmitter again.
➜
note: The Warn Away® response to lighter impacts is
bypassed if the system is armed using Silent Mode. This
ensures that no chirps will be emitted by the siren in an
area you want chirp-free. The system is still fully capable
of triggering. Only the Warn Away® response is
bypassed.
➜

13
© 2002 directed electronics, inc.
valet mode
You can prevent your security system from automatically arming
and triggering by using Valet Mode. This is very useful when
washing the vehicle or having it serviced. In Valet Mode, the
security system will not arm, even with the remote transmitter,
but all convenience functions (door locks, trunk release, etc.)
will continue to work normally.
To enter or exit Valet Mode:
1. Turn the ignition on.
2. Turn the ignition off.
3. Press and release the Valet
switch within 10 seconds.
The status LED will light solidly if you are entering Valet Mode,
and it will go out if you are exiting Valet Mode.
To enter or exit Valet Mode using the transmitter:
1. Open any vehicle door.
2. Press .
3. Press .
4. Press again.
The status LED will light solidly if you are entering Valet Mode,
and it will go out if you are exiting Valet Mode.
DRW-35
➜

14 © 2002 directed electronics, inc.
nuisance prevention® circuitry
Your system has Directed’s Nuisance Prevention®Circuitry
(NPC®). It prevents annoying repetitive trigger sequences due to
faulty door pin switches or environmental conditions such as
thunder, jackhammers, airport noise, etc.
Example
If the alarm triggers three times within a 60-minute period and
each time the same sensor or switch triggers the alarm, NPC®will
interpret those triggers as false alarms. After the third trigger,
NPC®ignores, or bypasses, that sensor or switch (along with any
other sensors or switches sharing the same zone) for 60 minutes.
If the bypassed sensor tries to trigger the system while it is being
bypassed, the 60-minute bypass period will start over. This
ensures that a sensor that continually triggers will remain
bypassed.
Doors are covered by NPC®differently; if the alarm is triggered
by an open door for three full cycles, the doors will be bypassed
until the trigger ceases.
NPC®is programmable. See Programming Options section of this
guide.
note: Arming and disarming the system does not reset this
function.The only ways to reset a bypassed zone are for it
to not trigger for 60 minutes, or to turn on the ignition. If
testing your system, it is important to remember that the
NPC® programming can cause zones to be bypassed and
appear to stop working. If five chirps are heard when dis-
arming, NPC® has been engaged. If you wish to clear the
NPC® memory, turn the ignition key on.
➜

15
© 2002 directed electronics, inc.
ddiiaaggnnoossttiiccss
The microprocessor at the heart of your security system is
constantly monitoring all of the switches and sensors that are
connected to it. It detects any faulty switches and sensors and
prevents them from disabling the entire system. The micropro-
cessor will also record and report any triggers that occurred
during your absence. Refer to the System Status Chirps and Table
of Zones charts for diagnostic information.
arming diagnostics
If the system is armed while an input is active (door open, sensor
triggering, etc.) the unit will chirp once when arming and then
one more time a few seconds later. This is called Bypass
Notification.
The security system will ignore the input that was active when
the system was armed, until the input goes away. Three seconds
later the system will monitor that input normally. For example,
if your vehicle has interior light exit delay, and you arm the
system before the interior light goes out, you may hear Bypass
Notification chirps. Once the light shuts off, however, the doors
are monitored normally.
note: Bypass Notification will not occur when using
Silent Mode™ or if chirps have been programmed OFF.
➜

16 © 2002 directed electronics, inc.
disarming diagnostics
Extra disarm chirps are the Tamper Alert. If four chirps are heard
when disarming, the system was triggered in your absence. If five
chirps are heard, a zone was triggered so many times that Nuisance
Prevention®Circuitry has bypassed that zone. The status LED will
indicate which zone was involved. (See Table of Zones section of this
guide.) The system will retain this information in its memory, and
continue to chirp four or five times each time it is disarmed, until
the next time the ignition key is turned on.
system status chirps
The siren will chirp when arming/disarming the system. The
pattern of chirps will audibly report the system’s status as
described below.
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3-second delay), 1 System armed with
Bypass Notification
Disarm 2 System disarmed
Disarm 4 System disarmed with
Tamper Alert
Disarm 5 System disarmed NPC
active
➜
➜

17
© 2002 directed electronics, inc.
table of zones
The zone number is the number of LED flashes used by the
system to identify that input. The standard input assignments
are listed below, along with spaces to write in any optional
sensors or switches you have had installed.
interpreting zone diagnostics
Warn Away responses are not reported by arming or disarming
diagnostics. If you receive a Bypass notification when arming or
a Tamper Alert notification when disarming, look at the LED.
Active or triggered zones will be indicated by a pattern of blinks
by the LED.
Example
If Zone 3 was active or triggered, the LED will blink three times
with a two-second pause. Then it will blink three times again,
and repeat until the ignition is turned on.
➜
Zone - Number Dealer-Installed
of LED Flashes Description Options
1 Instant trigger - often used
for hood/trunk pinswitches
2 Instant trigger - a heavier impact
detected by the shock sensor
3 Door switch trigger
4 Instant trigger - for optional sensors
5 Ignition trigger
➜
