736T Alarm System –
Owner’s Guide
TTRRAANNSSMMIITTTTEERR
VVEEHHIICCLLEEPPRROOTTEECCTTIIOONNFFEEAATTUURREESS
Your vehicle is protected while parked in armed mode. If a door is
opened or the vehicle struck the parking lights will flash for 30-seconds
and siren will sound for 30-seconds. A Vehicle Recovery System offers
the means to recover your vehicle after a carjacking.
AArrmmiinngg– To arm the system.
1. Press the button once.
2. Siren will chirp and parking lights will flash once.
3. The doors will lock (if connected).
4. The LED will start to flash once-per-second.
5. The engine starter will be disabled (if the starter kill relay is connected).
6. 3-seconds later, the alarm is armed. If the shock sensor or an exter-
nal sensor is triggered before 3-seconds, that sensor circuit will be
bypassed. The sensor will rearm itself only when the sensor is
stable for greater than 3-seconds.
AArrmmiinngg--bypass shock sensor
1. Press the button once and then within 2-seconds—
2. Press the button once. This bypasses the shock sensor and
arms the system.
SSiilleennttAArrmmiinngg//DDiissaarrmmiinngg--To arm/disarm system without siren sounding
1. Press the and buttons simultaneously.
SSiil
leennttAArrmmiinngg--bypassing sensors.
1. Press the and buttons simultaneously, and then within
2-seconds—
2. Press the button again
AArrmmiinngg--Diagnostics
If any door is open (or sensor is active) while the system is being
armed, the LED will blink quickly and the siren will chirp 3 times. (The
open door or active sensor will not trip the alarm.) If the system is in
Silent Arming mode the chirps will not be bypassed.
DDiissaarrmmiinngg––To disarm the system.
1. Press the button once.
2. The siren will chirp and the lights will flash 2 times.
3. The doors will unlock (if connected).
4. The engine starter will be enabled (if the starter kill relay is connected).
Arm/Disarm
Valet
Trunk
DDiissaarrmmiinngg--Diagnostics
If siren chirps and parking lights flash 4 times, this indicates that the
alarm had been activated. If in SILENT DISARMING MODE, only the
parking lights will flash.
RReemmootteeSSiirreennSSiilleenncciinngg
Remote siren silencing is a feature that makes it possible to silence and
reset the system when it is triggering without disarming the system. If
the system is triggered and the siren has been sounding, press the
button on the transmitter to stop the trigger and return the unit to the
armed state.
EEmmeerrggeennccyyOOvveerrrriiddee
If the transmitter is lost or misplaced while the system is armed, use
the following steps to disarm the system.
1. Turn the ignition on and off three times
2. The LED will flash rapidly for 3 seconds, then will flash once every
second.
3. Count these flashes and turn the ignition off after the number of
flashes is equal to your pin code.
4. If the correct PIN code is entered the will disarm when the ignition
is shut off.
NNoottee::If an incorrect PIN code is entered twice in a row the
system will flash the LED at a double rate and block all PIN
codes for 3 minutes.
PPaanniicc
1. With IGN OFF, press and hold the button for 3-seconds, the
siren will sound, and parking lights will flash.
2. Press the button to cancel panic mode.
CCaarrFFiinnddeerr
NNoottee::The system must be armed and ignition OFF before the
Car Finder can be used.
Pressing the button will cause the siren to beep once and the
parking lights to flash 6 times to facilitate locating your car.
SShhoocckkSSeennssoorr
1. If the car receives a light shock, the siren will chirp five times and
the parking lights will flash once for warning purposes.
2. If the car receives a heavy shock, the siren will sound and parking
lights will flash for 30 seconds.
PPaassssiivveeAArrmmiinngg
The system will passively arm (if programmed) when the ignition is
turned off, and 30 seconds after the last door is closed.
PPaassssiivveeRRee--aarrmmiinngg
When the alarm is disarmed, 30-seconds later, if the ignition is not
turned On, or the doors are not opened, the system will then automat-
ically rearm and lock the doors.
TTrruunnkkRReelleeaassee
Press and hold the button for 2-seconds to open the trunk.

22
© 2005 Directed Electronics, all rights reserved G736T 11-05
VVAALLEETTMMooddee
1. When disarmed and with the ignition On, press the for three
seconds.
2. The LED will be On continuously even with the ignition Off (this
indicates that system entered VALET mode).
3. In VALET mode, the siren will chirp twice and the parking lights will
flash twice when the door is locked.
4. Exit VALET mode: With the ignition On, press the for three
seconds The LED will extinguish to indicate exit from VALET mode.
IIggnniittiioonnDDoooorrLLoocckk//UUnnlloocckk
1. Turn ignition On, the doors lock after 5-seconds (if programmed on).
Note: the doors will not lock after 5-seconds if a door is left open.
2. Turn ignition Off, the doors unlock immediately.
MMeemmoorryyFFuunnccttiioonn
If the battery is disconnected, the system will remember the condition
prior to the removal of the 12V power.
LLEEDDCCoonnddiittiioonnss
1. Armed: The LED will flash slowly (once per second).
2. Passive arming mode: The LED will flash rapidly.
3. Valet Mode: LED continuously On.
4. Pin Code Entry Blocked: LED will flash at double rate.
DDiissaarrmmAAllaarrmmDDiiaaggn
noossttiiccss
When the ignition is first turned on, any alarm trigger will be indicated
by the number of LED flashes.
TTrraannssmmiitttteerrLLeeaarrnniinngg
The alarm system is supplied with 2 Code Hopping transmitters. The
system has the ability to recognize up to 4 transmitters at the same
time. New or replacement transmitters can be taught to the system
using the following procedure:
1. Turn the ignition ON and OFF twice and then turn the ignition back
ON within a 7-second period.
2. The LED will flash quickly for 3-seconds.
3. After the 3-second flashing, there is a 1 second break and then the
LED flashes at a 1-second rate.
4. Count the flashes and turn the ignition OFF after the number of
flashes equal to the PIN code.
5. Turn the ignition back ON and press the button on a new
transmitter to teach it to the system.
6. Turn the ignition OFF. Leave the ignition OFF for 10-seconds to exit
the learn routine.
AANNTTII--CCAARRJJAACCKKIINNGG
Anti-carjacking feature will stop a car thief from driving far from where
a theft attempt occurred, and to protect you whether the theft was
while you are driving your car or it is parked. The anti-carjacking trig-
gering sequence begins after the thief is a safe distance away from you
and your passengers and allows time for you to notify the authorities of
the theft. Anti-carjacking can be programmed ON or OFF (default is OFF).
It is important to familiarize yourself with anti-carjacking operation.
Carefully read the following instruction so the anti-carjacking feature
can fully protect you and your car.
LED Flashes Trigger Input
2Shock Sensor
3Doors
4Hood/Trunk
5Ignition
AANNTTII--CCAARRJJAACCKKIINNGGAACCTTIIVVAATTIIOONN
1. Door is opened and closed with the ignition switched ON (Only the
driver’s door, if the driver’s door option is selected), there is a 30
second grace period to allow the driver to exit anti-carjacking.
During this period, the LED will slowly flash.
2. After the grace period, the 30 second warning period will start and
the siren will beep once every 5-seconds as a warning.
3. If the anti-carjacking mode is not exited during the grace period or
the warning period, the system will move to alarming stage where
the siren will sound (constant), the parking lights will flash. The
immobiliser remains disengaged.
4. As soon as the ignition is turned OFF, the immobiliser will engage,
the siren will stop sounding, but the parking lights will continue to
flash.
TTOOEEXXIITTIINNGGAANNTTII--CCAARRJJAACCKKIINNGGMMOODDEE
Two methods exist for exiting Anti-carjacking mode depending on the
current stage in the procedure.
1. During grace or warning periods pressing and holding the
button for 2-seconds can be used to exit the anti-carjack mode. If
the incorrect button is pressed the system will immediately move
to the alarming stage.
2. Once the system has entered the alarming period, the button
can not be used to exit the mode, all transmitter operations will be
ignored and the driver must turn off the ignition and enter the PIN
code to exit anti-carjack mode.
EEXXIITTFFUULLLLTTRRIIGGGGEERRMMOODDEE
Full trigger mode is entered when the siren begins chirping. Only this
procedure will exit Anti-carjacking at this time.
Note: If you are driving the car at this time, pull to a safe
location away from traffic to perform this procedure.
1. Turn the ignition OFF.
2. Turn the ignition to the ON position or start the engine. (The
engine will not start if starter kill is connected.)
3. Within 15 seconds of turning the ignition on press the Valet®
switch and hold it for 1 second.
4. The siren will chirp twice and the lights will flash twice to indicate
Anti-carjacking mode has been exited.
ZZOONNEESS
When the ignition is first turned on, the zone (sensor) that has trig-
gered the alarm system will be indicated by the number of flashes from
the LED.
ZZoonneeTTrriiggggeerrIInnppuutt
2Shock Sensor
3Doors
4Hood/Trunk
5Ignition
