Directed Electronics DV-POD User manual

RReemmoovvaabbllee
DDVVDDPPllaayyeerr
MMOODDEELLDDVV--PPOODD
OOWWNNEERR’’SSGGUUIIDDEE
IINNSSTTAALLLLAATTIIOONNGGUUIIDDEE
© 2005 Directed Electronics, Inc. N83200 03-05
AAPPPPLLIICCAABBLLEEFFOORR
MMOODDEELLSS
OHV901 OHV901A
OHV1021 OHV1021A
OHV1202

© 2005 Directed Electronics, Inc.
2
NNOONN--TTRRAANNSSFFEERRAABBLLEELLIIMMIITTEEDDOONNEEYYEEAARRCCOONNSSUUMMEERRWWAARRRRAANNTTYY
Directed Electronics, Inc. (Directed) promises to the original purchaser that the new automotive video
monitor and/or source unit(s) (the Product) that is purchased and installed from a Directed authorized
dealer more than ninety (90) days after the purchase of a new vehicle are warranted for a period of one
(1) year from date of purchase of the Product.
Directed promises to the original purchaser that all video accessories will be free from defects in materi-
als and workmanship under normal use and condition for a period of ninety (90) days after the date of
purchase. A sales receipt and/or warranty registration card is required to provide proof of date of purchase
of the Product or accessories.
Should the Product be determined defective during the applicable warranty period, the defect(s) will be
repaired or replaced with a new or reconditioned part(s), at Directed’s option. To obtain warranty service, the
Product must be returned to a Directed authorized dealer along with proof of purchase and installation.
Note: This warranty does not cover labor costs for the removal and reinstallation of the Product. IN
ORDER FOR THIS WARRANTY TO BE VALID, YOUR PRODUCT MUST BE SHIPPED WITH PROOF OF
PURCHASE AND INSTALLATION BY AN AUTHORIZED DIRECTED DEALER. ALL PRODUCTS
RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF DIRECTED DEALER
INSTALLATION WILL BE DENIED.
This warranty is non-transferable and does not apply to any Product that has been modified or used in a
manner contrary to its intended purpose, and does not cover damage to the Product caused by installa-
tion or removal of the Product. This warranty is VOID if the product has not been purchased from an
authorized Directed dealer or has been damaged by accident or unreasonable use, negligence, acts of
God, neglect, improper service or other causes not arising out of defect in materials or construction. This
warranty does not cover the elimination of externally generated static or noise, or the correction of anten-
na problems or weak television reception, damage to tapes, video games, software, camcorders, discs,
speakers, accessories or vehicle electrical systems, cosmetic damage or damage due to negligence, mis-
use, abuse, failure to follow operating instructions, accidental spills or customer applied cleaners, damage
due to environmental causes such as floods, airborne fallout, chemicals, salt, hail, windstorms, lightning
or extreme temperatures, damage due to accidents, road hazards, fire, theft, loss or vandalism, damage
due to improper connection to equipment of another manufacturer, modification of existing equipment,
damage caused by faulty media or the cleaning of components, or Product which has been opened or
tampered with for any reason or which has been damaged due to alteration or service performed by any-
one other than Directed Electronics, Inc.
ALL WARRANTIES INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRAN-
TY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, AND WARRANTY
OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY ARE EXPRESSLY EXCLUDED TO THE
MAXIMUM EXTENT ALLOWED BY LAW, AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES
ANY PERSON TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE OF THE
PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PAR-
TIES INCLUDING ITS LICENSED DEALERS OR INSTALLERS. IN NO EVENT WILL DIRECTED ELEC-
TRONICS, INC. BE LIABLE FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES
(INCLUDING LOSS OF PROFITS), BY PURCHASING THIS PRODUCT, THE CONSUMER AGREES
AND CONSENTS THAT ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE
RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA.
Some states do not allow limitation on how long an implied warranty lasts. In such states, the limitations
or exclusions of this Limited Warranty may not apply. Some states do not allow the exclusion or limitation
of incidental or consequential damages. In such states, the exclusion or limitation of this Limited Warranty
may not apply to you. This Limited Warranty gives you specific legal rights, and you may have other rights
which vary from state to state.
Some states do not allow the exclusion or limitation of incidental or consequential damages. In such
states, the exclusion or limitations of this Limited Warranty may not apply to you. This Limited Warranty
gives you specific legal rights and you may have other rights which vary from state to state.
March 01, 2005

© 2005 Directed Electronics, Inc.
TTaabblleeooffCCoonntteennttss
NNoonn--TTrraannssffeerraabblleeLLiimmiitteeddOOnneeYYeeaarrCCoonnssuummeerrWWaarrrraannttyy............................................22
SSaaffe
ettyyIInnssttrruuccttiioonnssaannddCCaauuttiioonnss..........................................................................55
WWeellccoommee..........................................................................................................66
WWhhaatt’’ssIInncclluuddeedd................................................................................................66
IImmppoorrttaanntt........................................................................................................66
When Cleaning the Vehicle .............................................................................6
Disc Handling and Cleaning ............................................................................6
Repairs........................................................................................................7
Installation ..................................................................................................7
IImmppoorrttaannttIInnffoorrmmaattiioonn.............................
...........................................................77
FCC Notice ...................................................................................................7
Your Warranty ...............................................................................................7
CCoonnttrroollss.............................
...............................................................................88
DVD—Mounted .............................................................................................8
DVD—UnMounted........................................................................................10
DVD—Memory Card Mounting ........................................................................11
DDVVDDPPllaayyeerr——IInnssttaalll
laattiioonn..................................................................................1111
DDVVDDPPllaayyeerr——RReemmoovvaall........................................................................................1133
RReemmootteeCCoonnttrroollUUnniitt........................................................................................1144
Remote Buttons ..........................................................................................14
IR Remote Feedthrough................................................................................15
Battery Replacement....................................................................................16
Precautions ................................................................................................16
LLooaaddiinnggaannddUUnnllooaaddiinnggDDiissccss..............................................................
..............1166
Loading Disc...............................................................................................16
Unloading Disc............................................................................................17
BBaassiiccFFuunnccttiioonnss..................................................................
..............................1188
DVD Playback..............................................................................................18
Play/Pause (DVD/MP3/CD) ............................................................................19
Stop (DVD/MP3/CD).....................................................................................19
Selecting a Track or Chapter..........................................................................20
MP3 and JPEG Playback on CD or Memory Card ................................................20
Playback Programming .................................................................................21
Advanced Playback (DVD/MP3/CD) .................................................................22
SSeettuupp............................................................
..................................................2233
AAcccceessssiinnggSSeettuuppMMeennuuss......................................................................................2233
SSyysstteemmSSeettuupp.........................
.........................................................................2244
1. TV System .............................................................................................24
2. Screen Saver ..........................................................................................24
3. TV Type.................................................................................................25
4. Password ...............................................................................................25
3

© 2005 Directed Electronics, Inc.
5. Rating (Parental Settings)........................................................................25
6. Default .................................................................................................26
7. Exit ......................................................................................................26
LLaanngguuaaggeeSSeettuupp...................................................................................
.............2266
1. OSD Language ........................................................................................26
2. Audio Lang ............................................................................................26
3. Subtitle Lang .........................................................................................27
4. Menu Lang.............................................................................................27
IInnssttaallllaattiioonnGGuuiiddee................................................................
............................2277
Precautions ................................................................................................27
Connections................................................................................................28
TTrroouubblleesshhoooottiinngg....................................................
..........................................2299
SSppeecciiffiiccaattiioonnss..................................................................................................3311
4

© 2005 Directed Electronics, Inc.
SSaaffeettyyIInnssttrruuccttiioonnssaannddCCaauuttiioonnss
WWAARRNNIINNGG::TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIP-
MENT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND
ANNOYING INTERFERENCE, USE ONLY THE INCLUDED HARDWARE.
DIRECTED ELECTRONICS, INC. DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY,
INCLUDING FATALITIES, OR PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR
UNINTENDED USES OF THIS PRODUCT.
WHEN MOUNTED IN A MONITOR, DO NNOOTTCLOSE THE LCD SCREEN IF A MEMORY CARD HAS
BEEN INSERTED INTO THE DVD PLAYER. THIS CAN CAUSE THE LCD PANEL TO BREAK OR LEAK
FLUID (SEE ABOVE WARNING). REMOVE MEMORY CARD(S) BEFORE CLOSING SCREEN.
■During operation, if the unit should over-heat or malfunction, switch off the unit and see your
dealer. Do not disassemble the unit as there are no user-serviceable parts in this unit and the war-
ranty will be voided.
■Should there be a need to replace a blown fuse, turn off the unit and disconnect all power to
the player. Use only the correct rating fuse to avoid electrical damage to the unit.
■Only operate the DVD player as described in this guide. Attempts to use or modify this DVD
player contrary to the descriptions in this guide may cause damage and void the warranty.
■Extremes in temperature can cause abnormal display operation. The DVD player has an optimal
operating temperature range between 32–120 degrees Fahrenheit. If the vehicle interior is outside
this range, do NOT operate the DVD player until the temperature is within its operating range.
■Exposure to moisture or dust can cause harmful damage to the internal electronics. Do not
mount near cup holders or in areas where spills may occur.
■This DVD player is designed for use in vehicles with standard (-) 12 volt ground electrical sys-
tems.
■Do not operate for an extended period of time without the engine running or the vehicle’s bat-
tery voltage may drop to levels precluding engine starting.
■Keep unit away from equipment with strong magnets such as large loudspeakers.
■To prevent malfunction, do not play discs other than the ones listed below: DVD audio discs, CD-
ROMs, JPEGs, MP3s and DVDs with region numbers other than this player's region number.
5

© 2005 Directed Electronics, Inc.
WWeellccoommee
Thank you for your purchase of Directed’s removable and portable DVD player. Prior to operating this
unit, please fully read this instruction manual and retain it for future reference. This unit can be
used with many of our monitors to allow viewing of movies, digital photographs and for the enjoy-
ment of listening to music.
WWhhaatt’’ssIInncclluuddeedd
The following items are included with your purchase:
IImmppoorrttaanntt
WWHHEENNCCLLEEAANNIINNGGTTHHEEVVEEHHIICCLLEE
Do not spray this unit with water or cleaning solutions. Moisture and the chemicals found in cleaning
fluids could damage the consoles finish and interior electronics. A soft damp, lens cleaning cloth
should be used to wipe the screen. Do NOT use any type of scouring pad, abrasive cleaners, or solvents.
DDIISSCCHHAANNDDLLIINNGGAANNDDCCLLEEAANNIINNGG
Always handle the discs by the edge. Never touch the shiny side of the discs, as this can impair prop-
er playback.
Mount and dismount the discs with care not to damage or scratch the shiny side of the disc. This
will cause playback faults.
Do not expose the discs to direct sunlight.
After playing, store the disc back in its case.
To clean the disc, use a clean soft lint-free cloth and wipe the disc from the center out. Do not wipe
with a circular motion. Do not use any solvents.
zDVD Player zA/V Cable
zRemote Control zAC/DC Adaptor
6

© 2005 Directed Electronics, Inc.
RREEPPAAIIRRSS
If the DVD player stops working for any reason, discontinue use immediately and consult with your
retailer about any necessary repairs.
IINNSSTTAALLLLAATTIIOONN
Avoid installing the DVD player at a location, where it will be under direct sunlight or a hot air vent.
The operating temperature of the unit is from 32–120°F (0–50°C). Install the unit at a dry location,
where it is away from condensation.
Use only the correct cables during installation. Failure to do so may cause an electrical failure and
create a fire hazard.
NNOOTTEE::If the internal temperature of the vehicle is higher than the normal oper-
ating temperature, please allow the vehicle to cool down (or warm up) prior
to operating the unit.
IImmppoorrttaannttIInnffoorrmmaattiioonn
FFCCCCNNOOTTIICCEE
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interfer-
ence received, including interference that may cause undesirable operation.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this device.
YYOOUURRWWAARRRRAANNTTYY
Your warranty registration must be completely filled out and returned within 10 days of purchase.
Your product warranty will not be validated if your warranty registration is not returned. Make sure
you receive the warranty registration from your dealer. It is also necessary to keep your proof of pur-
chase, which reflects that the product was installed by an authorized dealer.
7

© 2005 Directed Electronics, Inc.
CCoonnttrroollss
DDVVDD——MMOOUUNNTTEEDD
The illustration below shows the DVD player mounted in a typical LCD monitor.
1. LOCK/UNLOCK—To dock or undock the DVD player.
2. OPEN—Press this button to open the access door to mount or dismount a disc.
3. AUDIO—Each press of this button accesses each audio track recorded on the DVD (multiple lan-
gauges, commentary, etc.)
4. MENU—Displays the menu on the DVD. Use the Up, Down, Left, and Right buttons to scroll
through the available selections. Use the Enter button to select.
5. UP— *
6. DOWN— *
7. LEFT— *
8. RIGHT— *
9. ENTER *
10. PLAY/PAUSE—When pressed pauses the playback until pressed again.
1712
2
3
5
9
10
13
4
8
6
11
14
8

© 2005 Directed Electronics, Inc.
11. STOP—Halts playback. If the Play button is pressed the playback will continue from where
stopped. If the Stop button is pressed twice, playback will now start from the beginning.
WWAARRNNIINNGG::DO NOT CLOSE THE LCD SCREEN IF A MEMORY CARD HAS BEEN INSERTED INTO
THE DVD PLAYER. THIS CAN CAUSE THE LCD SCREEN TO BREAK OR LEAK FLUID. IF YOU
SHOULD COME IN CONTACT WITH LEAKED FLUID, WASH THE AFFECTED AREA THOROUGHLY
WITH WATER AND SEEK IMMEDIATE MEDICAL ATTENTION. REMOVE ALL MEMORY CARDS
BEFORE CLOSING THE LCD SCREEN.
12. MS Card—Memory Stick, allows playback of music, photographs, movies, etc.
13. SD Card—Secure Digital, allows playback of music, photographs, movies, etc.
14. CF Card—Compact Flash, allows playback of music, photographs, movies, etc.
NNOOTTEE::To read from a memory card, there must not be mounted a DVD or CD in the
player and the player door must be closed. Only 1 memory card can be
inserted into the player at a time.
* These buttons are used to navigate through the menus on the screen and then use the Enter but-
ton to select the option.
9

© 2005 Directed Electronics, Inc.
DDVVDD——UUNNMMOOUUNNTTEEDD
The illustration below shows the side of the DVD player when removed from the LCD monitor.
1. Electrical connector—This connector provides the electrical interface when mounted in the LCD
monitor.
2. VOL Control—Controls the volume to the phone jack output.
3. PHONE Jack—An optional headphone set can be connected here.
4. A/V OUT Jack—Audio/video output jack.
5. DC 12V Jack—Input power from the AC/DC converter.
6. IR Receiver—For receiving commands from the remote control.
VOL PHONE A/V OUT
DC 12V
12345 6
10

© 2005 Directed Electronics, Inc.
DDVVDD——MMEEMMOORRYYCCAARRDDMMOOUUNNTTIINNGG
Ensure that the memory cards are mounted with the logo side of the memory cards oriented with the
arrows as shown below:
WWAARRNNIINNGG::DO NOT CLOSE THE LCD SCREEN IF A MEMORY CARD HAS BEEN INSERTED INTO
THE DVD PLAYER. THIS CAN CAUSE THE LCD SCREEN TO BREAK OR LEAK FLUID. IF YOU
SHOULD COME IN CONTACT WITH LEAKED FLUID, WASH THE AFFECTED AREA THOROUGHLY
WITH WATER AND SEEK IMMEDIATE MEDICAL ATTENTION. REMOVE ALL MEMORY CARDS
BEFORE CLOSING THE LCD SCREEN.
DDVVDDPPllaayyeerr——IInnssttaallllaattiioonn
1. Ensure power to the monitor is off and that the ignition key is off.
2. Align the notches in the side of the player with the tabs in the sides of the monitor DVD mount-
ing area and slide the player into the monitor.
3. Slide the player towards the LCD screen until the lock/unlock button latches.
NNOOTTEE::If the DVD player doesn’t power up correctly, remove the player (see instruc-
tions below) and then re-install.
Memory Stick
Compact Flash
Secure Digital
Logo
Side
Logo
Side
Logo
Side
11

© 2005 Directed Electronics, Inc.
Electrical
Connector
Lock/Unlock
Button

Insert DVD Player
and then slide down
until unit locks.
12

© 2005 Directed Electronics, Inc.
DDVVDDPPllaayyeerr——RReemmoovvaall
1. While holding and supporting the DVD player.
2. Move and hold the lock/unlock button to the right.
3. Slide the player away from the screen and carefully remove.
13

© 2005 Directed Electronics, Inc.
RReemmootteeCCoonnttrroollUUnniitt
RREEMMOOTTEEBBUUTTTTOONNSS
1. POWER (source) 28. ANGLE
2. IR (on/off) 29. SUBTITLE (on/off)
3. FM (on/off) 30. DOWN (Cursor)
4. Picture (PIP) (17” & 12” models only) 31. AUDIO
5-7. Numeric 32. ZOOM (2, 3, 4, 1/2, 1/3, 1/4, OFF)
8. UP (display) 33. F.REV (Fast Reverse)
9-11. Numeric 34. PLAY/PAUSE
12. Console MENU 35. F.FWD (Fast Forward)
13-15. Numeric 36. SLOW


1
2
5
6
9
10
13
14
17
18
21
22
25
26
29
30
33
34
37
38
41
42
45
46
4
3
8
7
12
11
16
15
20
19
24
23
28
27
32
31
36
35
40
39
44
43
48
47
14

© 2005 Directed Electronics, Inc.
16. DOWN (display) 37. BACK
17. MENU/PBC 38. STOP
18-19 Numeric 39. NEXT
20. Image (wide, zoom, full, normal) 40. REPEAT
21. TITLE 41. POWER (Tuner)*
22. UP (Cursor) 42. DSP (channel display)*
23. SETUP 43. TV/AV (selects Tuner or Aux input)*
24. MUTE (on/off) 44. DISPLAY
25. LEFT (Cursor) 45. CH+ (channel up)*
26. ENTER 46. CH- (channel down)*
27. RIGHT (Cursor) 47. AUTO (auto programming of TV channels)*
48. PROGRAM
IIRRRREEMMOOTTEEFFEEEEDDTTHHRROOUUGGHH
The remote will operate, through the monitor, and transmit commands to other compatible devices
attached to the AV1 or AV2 source at the switch-box. The IR signals are compatible with models
DV2602, DV2605 DVD players, and TV100 tuner.
NNOOTTEE::Some remote buttons only function with the overhead monitors.
* These buttons are for use only with the TV tuner (model TV100).



15

© 2005 Directed Electronics, Inc.
BBAATTTTEERRYYRREEPPLLAACCEEMMEENNTT
NNOOTTEE::Before using remote after installation, remove the battery plastic protective slip.
1. Move the small latch to the right and slide out the battery holder.
2. Remove old battery and replace it with a new battery (CR2025) with the positive “+” sign facing
as shown above.
3. Push battery holder back into its compartment until it is locked.
PPRREECCAAUUTTIIOONNSS
1. Properly dispose of used battery.
2. Do not misuse battery by shorting the positive “+” and negative “-” terminal or put it into fire.
Overheating may cause the battery to explode and cause a fire hazard.
3. If the remote is not to be used for a long period, remove the battery from the remote to prevent
damage from battery leakage.
4. To avoid accidents, prevent children from playing with the battery.
LLooaaddiinnggaannddUUnnllooaaddiinnggDDiissccss
You can use single side and dual layer DVDs, VCDs, CD-audio and CD-R compatible 12cm discs with
this system.
NNOOTTEE::When playing discs with the DVD player removed from the monitor, the player
must be in a horizontal position.
LLOOAADDIINNGGDDIISSCC
Remote Controller
Battery
Battery Holder
Latch
+ side
16

© 2005 Directed Electronics, Inc.
1. Press OPEN at the upper right corner to open the door.
2. Load with the recorded side (the shiny side) facing up. With double-sided discs, load with the
side you want to watch facing up. Ensure that the disc is seated properly before pushing tray back
into its locking position.
3. Push to close the door.
UUNNLLOOAADDIINNGGDDIISSCC
1. Press OPEN at the upper right corner to open the door.
2. Remove the disc. (Avoid touching the recorded surface.)
3. Push to close the door, until you hear a click sound from the door mechanism.
17

© 2005 Directed Electronics, Inc.
BBaassiiccFFuunnccttiioonnss
DDVVDDPPLLAAYYBBAACCKK
1. Press the remote control’s POWER button to turn on the unit’s power or the power button
on the monitor if the DVD player is mounted in the monitor.
2. Select video source (DVD).
NNOOTTEE::If there is no disc in the DVD player, a “NNOODDIISSCC” message will be displayed
in the upper left corner of the screen.
3. Load a disc into the unit. The message “READ” will appear in the upper left corner of the
screen.
4. DVD playback commences.
NNOOTTEE::The disc will start to play if there are no titles recorded on the disc. If one or
more titles are recorded on the disc, a menu will appear on the LCD screen.
5. Press / / / on the remote (or their equivalent on the DVD player) to select the
preferred item or title from the menu.
6. Press the ENTER (on remote or DVD player) button, the selected item will now start playing.
7. To return to the menu screen, press the DVD MENU button.
8. After viewing completion, press the POWER button to put the unit into standby mode.
NNOOTTEE::If the “WRONG REGION” message appears, it means that the corresponding
operation is prohibited either by the player or by the disc.
FFAASSTTFFOORRWWAARRDDOORRRREEVVEERRSSEE((DDVVDD//MMPP33//CCDD))
1. Press the "FFFF" button during playback. Each time this button is pressed, the unit will go
into a rapid advance playback mode. This will be shown on the LCD, depending on the speed of the
playback selected.
■playback
FF 2X FF 4X FF 8X FF 20X PLAY
Press "PPLLAAYY" button, the speed will go back to standard.




18

© 2005 Directed Electronics, Inc.
2. Press the “FFRR” button during playback. Each time this button is pressed, the unit will go
into a rapid reverse playback mode. This will be shown on the LCD, depending on the speed of the
playback selected.
■playback
FR 2X FR 4X FR 8X FR 20X PLAY
Press “PPLLAAYY” button, the speed will go back to standard.
NNEEXXTTTTRRAACCKKOORRPPRREEVVIIOOUUSSTTRRAACCKK((DDVVDD//MMPP33//CCDD))
1. Press the "NNEEXXTT" button during playback.
■MP3/Audio CD
The player will skip forward to the next track each time the button is pressed. "NEXT" will be
displayed on the LCD screen.
■DVD
The player will skip forward to the next title/chapter each time the button is pressed.
2. Press the "PREV" button during playback.
■MP3/Audio CD
The player will skip to the beginning of the previous track each time the button is pressed.
"PPRREEVVIIOOUUSS" will be displayed on the LCD screen.
■DVD
The player will skip to the beginning of the previous chapter each time the button is pressed.
PPLLAAYY//PPAAUUSSEE((DDVVDD//MMPP33//CCDD))
1. Press the "PPLLAAYY//PPAAUUSSEE" button, during playback. "PAUSE" will display on the LCD. The play-
er is placed in the pause mode.
2. Press the "PPLLAAYY//PPAAUUSSEE" button again. "PLAY" will momentarily display on the LCD. The
player returns to normal playback.
SSTTOOPP((DDVVDD//MMPP33//CCDD))
1. During playback, when the "SSTTOOPP" button is pressed,the playback will stop. “PRE STOP” will
display on the LCD. Press the "PPLLAAYY//PPAAUUSSEE" button to continue playback from the point where
the "SSTTOOPP" button was pressed.
2. During playback, if the "SSTTOOPP" button is pressed twice. "STOP" will display on the LCD. Press
the "PPLLAAYY//PPAAUUSSEE" button to resume playback from the beginning.




19

© 2005 Directed Electronics, Inc.
SSEELLEECCTTIINNGGAATTRRAACCKKOORRCCHHAAPPTTEERR
Selecting tracks or chapters can be accomplished by either using the remote or front mounted con-
trols. These controls allow the operator to skip over undesirable tracks or repeat a particular track.
When playing a DVD, press the numeric buttons on the menu or title page to select tracks. During
DVD playback, you can input the desired title number directly.
MMPP33AANNDDJJPPEEGGPPLLAAYYBBAACCKKOONNCCDDOORRMMEEMMOORRYYCCAARRDD
Place a MP3, or JPEG disc or memory card into the DVD player. The player will search the media for
the saved directories and files. It will automatically go to the first directory saved and play or dis-
play the first file in that directory.
By using the arrow and ENTER buttons on the DVD player or the remote you can navigate and select
the directories (left side of the screen), or the file (right side of the screen).
When the disc or memory card contains JPEGs press the "PPLLAAYY//PPAAUUSSEE" button to present these
in slide show mode (displays each JPEG for a few seconds before advancing to the next JPEG). Press
the "PPLLAAYY//PPAAUUSSEE" button to pause the slide show at a photograph of interest. Use the arrow
buttons / / / on the remote (or their equivalent on the DVD player) to change the
orientation of the photograph. Pressing the PROGRAM button on the remote as the slide show is
being presented will change the “wipe” as each JPEG is displayed (there are 16 choices to from,
including RANDOM and NONE [off]).
The bottom of the screen will display the contents of the media - music , camera , video
icons. For example if a memory stick contains MP3 and JPEG files but does not contain any video
files, the music and camera icons will appear white, but the video icon will appear dark. If a
file is playing or displaying, the icon associated with that file will turn RED.








20
