Directed Electronics 560T User manual

556600TT
➤
OOwwnneerr’’ssGGuuiiddee

i
© 2004 Directed Electronics, Inc.
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
For a period of one calendar year from the date of purchase of this auto-security device,
Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or replace
(with a comparable reconditioned model), free of cost, any electronic control module
which proves to be defective in workmanship or material under normal use, SO LONG
AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFES-
SIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYS-
TEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you must have
a clear copy of your sales receipt containing all of the information shown on the follow-
ing page.
After the first calendar year, from the date of purchase of this auto-security device,
Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace
(with a comparable reconditioned model) any electronic control module which proves to
be defective in workmanship or material under normal use FFOORRAACCHHAARRGGEEOOFF$$4455..0000,,
SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A
PROFESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH
THE SYSTEM WAS ORIGINALLY INSTALLED. If warranty service is necessary you
must have a clear copy of your sales receipt containing all of the information shown on
the following page.
This warranty contains the entire agreement relating to warranty and supersedes all pre-
vious and contemporaneous representations or understandings, whether written or oral.
IN ANY EVENT, DIRECTED ELECTRONICS IS NOT LIABLE FOR THE THEFT
OF THE VEHICLE AND/OR ITS CONTENTS.
This warranty is void if the product has been damaged by accident, unreasonable use,
neglect, improper service or other causes not arising out of defects in materials or con-
struction. This warranty is nontransferable and does not apply to any unit that has been
modified or used in a manner contrary to its intended purpose and does not cover bat-
teries. The unit in question must be returned to the manufacturer, postage prepaid. This
warranty does not cover labor costs for the removal, diagnosis, troubleshooting or rein-
stallation of the unit. For service on an out-of-warranty product a flat rate fee by model is
charged. Contact your authorized dealer to obtain the service charge for your unit.
These systems are a deterrent against possible theft. Directed Electronics, Inc. is not offer-
ing a guarantee or insuring against the theft of the automobile or its contents and dis-
claims any liability for the theft of the vehicle and/or its contents. Directed Electronics
does not authorize any person to create for it any other obligation or liability in connec-
tion with this security system.

ii © 2004 Directed Electronics, Inc.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WAR-
RANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY
PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS
EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY
AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-
RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL
WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED
STATES OF AMERICA AND/OR ABROAD. NEITHER THE MANUFACTURER
OR ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR
LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMIT-
ED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOW-
ING, REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con-
sequential damages. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
IIMMPPOORRTTAANNTTNNOOTTEE::
This product warranty is automatically void if its date code or serial number is defaced,
missing, or altered. This warranty will not be valid unless you have completed the war-
ranty card and mailed it to Directed Electronics, Inc. within 10 days after purchase to the
address listed on the warranty registration card.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
➤Date of purchase
➤Your full name and address
➤Authorized dealer's company name and address
➤Type of system installed
➤Year, make, model and color of the automobile
➤Automobile license number
➤Vehicle identification number
➤All security options installed on automobile
➤Installation receipts

1
© 2004 Directed Electronics, Inc.
ttaabblleeooffccoonntteennttss
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy................................................................................ii
wwhhaattiissiinncclluuddeedd.....................................................................
.......................................22
iimmppoorrttaannttiinnffoorrmmaattiioonn......................................
............................................................22
system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
wwaarrnniinngg!!ssaaffeettyyffiirrsstt...............
.......................................................................................33
ttrraannssmmiitttteer
rffuunnccttiioonnss..........................................................................................
..........66
uussiinnggyyoouurrssyysstteemm.......................................................................
.................................77
remote start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ppiittssttooppmmooddee..................................................
............................................................1100
lleeaarrnniinnggttrraannssmmiitttteerr.................
...................................................................................1111
ccooddeehhooppppiinngg®®rree--ssyynncchhrroonniizzee....................................................................................1122
g
glloossssaarryyoofftteerrmmss....................................................................................
....................1122
qquuiicckkrreeffeerreenncceegguuiiddee::.......................................................
.........................................1133

2© 2004 Directed Electronics, Inc.
wwhhaattiissiinncclluuddeedd
➤Control Module
➤One 2-Button Transmitter
➤8-Pin Main H/1 Harness
➤6-Relay Wires
➤Shutdown Toggle Switch
➤Hood Pin Switch
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your remote start system.
This system has been designed to provide years of trouble-free
operation. By carefully reading this owner's guide prior to using
your system, you will maximize the use of this system and its
features. Additional or replacement copies of this guide can be
printed by accessing the Directed Electronics internet website at
www.directed.com.
system maintenance
The system requires no specific maintenance. Your transmitter is
powered by a miniature 12-volt battery (type GP23) that will last
approximately one year under normal use. When the battery
begins to weaken, the operating range will be reduced.
➜

3
© 2004 Directed Electronics, Inc.
your warranty
Your warranty registration must be completely filled out and
returned within 10 days of purchase. Your product warranty
will not be validated if your warranty registration is not returned.
Please note that it is necessary to keep your proof of purchase.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
wwaarrnniinngg!!ssaaffeettyyffiirrsstt
The following safety warnings must be observed at all times:
➤When properly installed, this system can start the vehicle via
a command signal from the remote control transmitter.
Therefore, never operate the system in an area that does not
have adequate ventilation. The following precautions are the
sole responsibility of the user; however, the following recom-
mendations should be made to all users of this system:
➜
➜

4© 2004 Directed Electronics, Inc.
1. Never operate the system in an enclosed or partially
enclosed area without ventilation (such as a garage).
2. When parking in an enclosed or partially enclosed area
or when having the vehicle serviced, the remote start
system must be disabled using the toggle switch.
3. It is the user's sole responsibility to properly handle and
keep out of reach from children all remote control
transmitters to assure that the system does not uninten-
tionally remote start the vehicle.
4. TTHHEEUUSSEERRMMUUSSTTIINNSSTTAALLLLAACCAARRBBOONN
MMOONNOOXXIIDDEEDDEETTEECCTTOORRIINNOORRAABBOOUUTTTTHHEE
LLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOOTTHHEE
VVEEHHIICCLLEE..
AALLLLDDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTT
LLIIVVIINNGGAARREEAASSTTOOTTHHEEEENNCCLLOOSSEEDDOORR
PPAARRTTIIAALLLLYYEENNCCLLOOSSEEDDVVEEHHIICCLLEE
SSTTOORRAAGGEE
AARREEAAMMUUSSTTAATTAALLLLTTIIMMEESSRREEMMAAIINNCCLLOOSSEEDD..
➤Use of this product in a manner contrary to its intended
mode of operation may result in property damage, personal
injury, or death. Except when performing the Safety Check
outlined in this user’s guide, (1) Never remotely start the
vehicle with the vehicle in gear, and (2) Never remotely start
the vehicle with the keys in the ignition. The user will be
responsible for having the neutral safety feature of the vehicle
periodically checked, wherein the vehicle must not remotely
start while the car is in gear. This testing should be performed
by an authorized Directed dealer in accordance with the
Safety Check outlined in this product installation guide. If

5
© 2004 Directed Electronics, Inc.
the vehicle starts in gear, cease remote start operation imme-
diately and consult with the Dealer to fix the problem imme-
diately.
➤After the remote start module has been installed, test the
remote start module in accordance with the Safety Check
outlined in this installation guide. If the vehicle starts when
performing the Neutral Safety Shutdown Circuit test, the
remote start unit has not been properly installed. The remote
start module must be removed or properly reinstalled so that
the vehicle does not start in gear. OOPPEERRAATTIIOONNOOFFTTHHEE
RREEMMOOTTEESSTTAARRTTMMOODDUULLEEIIFFTTHHEEVVEEHHIICCLLEE
SSTTAARRTTSSIINNGGEEAARRIISSCCOONNTTRRAARRYYTTOOIITTSSIINNTTEENNDDEEDD
MMOODDE
EOOFFOOPPEERRAATTIIOONN..OOPPEERRAATTIINNGGTTHHEE
RREEMMOOTTEESSTTAARRTTSSYYSSTTEEMMUUNNDDEERRTTHHEESSEECCOONNDDII--
TTIIOONNSSMMAAYYRREESSUULLTTIINNPPRROOPPEERRTTYYDDAAM
MAAGGEEOORR
PPEERRSSOONNAALLIINNJJUURRYY..IIMMMMEEDDIIAATTEELLYYCCEEAASSEETTHHEE
UUSSEEOOFFTTHHEEUUNNIITTAANNDDRREEPPAAIIRROORRDDIISSCCOONNNNEECCTT
TTHHEEIINNSSTTAALLLLEED
DRREEMMOOTTEESSTTAARRTTMMOODDUULLEE..
DDIIRREECCTTEEDDWWIILLLLNNOOTTBBEEHHEELLDDRREESSPPOONNSSIIBBLLEEOORR
PPAAYYFFOORRIINNSSTTAALLLLAATTIIOONNOORRRREEIINNSSTTAALLLLAATTIIOON
N
CCOOSSTTSS..

6© 2004 Directed Electronics, Inc.
ttrraannssmmiitttteerrffuunnccttiioonnss
The receiver uses a computer-based learn routine to learn the
transmitter buttons.
Button
Press the button once to remote start the vehicle.
Button
Press the button once to remote stop the vehicle.
Buttons and
These buttons when pressed simultaneously, engage timer mode.
The timer starts the engine every 3 hours (12-minute run time).
Button
Press the button once for Pit Stop mode (with engine
running).
Timer/Prog
Mode
LED
Stop
Start
and
Pit Stop

7
© 2004 Directed Electronics, Inc.
uussiinnggyyoouurrssyysstteemm
remote start
Press the button to remotely start your vehicle. This feature
makes it possible to warm up the engine, as well as adjust the
interior temperature of the vehicle with the climate control
system. If interior heating or cooling is desired, the climate
controls must be preset, and the fan blower must be set to the
desired level prior to remote starting the vehicle.
WWhheennyyoouuaarreerreeaaddyyttooddrriivveetthheevveehhiiccllee::
1. Insert the ignition key and turn it to the
ON (not the START) position.
2. Press the brake pedal.
While the vehicle is running during remote start operation, the
system will monitor the vehicle and will automatically shut down
the engine if the system receives any of the following shut-down
inputs:
nnoottee::If the brake pedal is pressed
before the key is in the ON posi-
tion, the engine will shut down.
nnoottee::(1) Never remotely start the vehicle with the vehi-
cle in gear, and (2) Never remotely start the vehicle with the
key in the ignition.
➜

8© 2004 Directed Electronics, Inc.
■The brake pedal is pressed.
■The hood is opened.
■The shutdown toggle switch is put into the ON position.
■The pre-programmed run time has elapsed (12-minutes).
■The button is pressed.
■The tachometer is either too high or low.
■The battery voltage is too low.
timer mode
This feature allows you to remotely start and run your vehicle for
12-minutes every 3 hours (for a maximum of 6 starts for cold
weather conditions). This makes it possible to warm up the
engine, as well as adjust the interior temperature of the vehicle
with the climate control system. If interior heating or cooling is
desired, the climate controls must be preset, and the fan blower
must be set to the desired level prior to remote starting the
vehicle.
nnoottee::Never remotely start the vehicle with the vehicle in gear.
➜

9
© 2004 Directed Electronics, Inc.
To remote start the vehicle in timer mode:
1. Press the and buttons simultaneously on the trans-
mitter.
2. The parking lights will flash 4 times to confirm remote start
timer operation. The vehicle will start and run for the timed
duration. The vehicle can be remotely shut-down without exiting
timer mode.
3. The vehicle will start every 3 hours, it will run for a period
of 12-minutes or until a shutdown input is triggered.
Remote start timer mode is cancelled by:
■Activation of the ignition (turning the ignition key On)
■The car has started 6 times.
■The brake pedal is pressed.
■The hood is opened.
■The shutdown toggle switch is put into the ON position.
nnoottee::The stop button does not affect the 3-hour time
interval between engine starts. If the engine fails to start
on 3 attempts it is counted as one start in timer mode.
The system will attempt to start again 3-hours later (if
this wasn’t its 6th start attempt).

10 © 2004 Directed Electronics, Inc.
ppiittssttooppmmooddee
This feature allows you to exit the car and leave the engine
running. Use the following procedure to enter Pit Stop Mode:
1. Place the transmission in park and put the parking brake
on.
2. Leave the engine running.
3. Do not step on the brake.
4. Press the button once. The parking lights will flash once
to confirm pit stop mode.
5. Turn the key off and remove the key.
6. Exit and lock the vehicle.
Use the following procedure to exit Pit Stop Mode:
1. Enter the vehicle.
2. Place the key to ignition (not the crank or start position).
3. Step on the brake (this causes the system to exit Pit Stop
Mode).
4. Or press the button.

11
© 2004 Directed Electronics, Inc.
lleeaarrnniinnggttrraannssmmiitttteerr
The system comes with one transmitter. The receiver can store
up to 4 different transmitter codes in memory. Use the following
to learn the transmitter or to add a transmitter to the system.
The following is the basic sequence of steps to remember whenever
programming this unit:
1. KKeeyy..Turn the ignition to the ON position.
2. PPrrooggrraamm..After 5-seconds, press and hold both buttons on
the transmitter, until—(see step 3).
3. PPaarrkkiinnggLLiigghhttssFFllaasshh..The parking lights will flash twice to
acknowledge programming of this transmitter.
To add a second transmitter (within 5-seconds of the first trans-
mitter parking light flash learn acknowledgment):
note: The system can only learn, after
being connected and with the FIRST
IGNITION ON. If not learned with
the first ignition on the battery will
have to be disconnected and then
reconnected and the procedure
repeated.

12 © 2004 Directed Electronics, Inc.
1. PPrrooggrraamm..Hold both buttons on the additional transmitter
for an additional 5-seconds, until—(see step 2).
2. PPaarrkkiinnggLLiigghhttssFFllaasshh..The parking lights will flash twice to
acknowledge programming of this transmitter.
ccooddeehhooppppiinngg
®®
rree--ssyynncchhrroonniizzee
If the transmitter is pressed many times out of range, or the
battery is removed, the transmitter may get temporarily out of
sync and fail to operate the system. To synchronize the trans-
mitter, simply press or several times within range of the
vehicle. The system will automatically synchronize and the trans-
mitter will respond normally.
gglloossssaarryyoofftteerrmmss
Control Module: The “brain” of your system. Usually hidden
under the dash area of the vehicle. It houses the microprocessor
that monitors your vehicle and controls all system functions.
Transmitter: A hand-held, remote control which operates the
various functions of your system.

CCuuttaalloonnggddootttteeddlliinneeaannddffoollddffoorraaqquuiicckkaannddeeaassyyrreeffeerreenncceettookkeeeeppiinnyyoouurrppuurrsseeoorrwwaalllleett..
✂
✂
QQUUIICCKKRREEFFEERREENNCCEEGGUUIIDDEE::
TToorreemmootteessttaarrttuussiinnggyyoouurrrreemmoottee
■Press once. The parking lights will flash once to confirm.
TToorreemmootteessttooppuussiinnggyyoouurrrreemmoottee
■Press once.
TToouusseettiimmeerrmmooddee
■Press both and buttons simultaneously. The parking lights will
flash four times to confirm entry into timer mode operation (ignition off
only).
TToouusseePPiittSSttooppmmooddee((eennggiinneerruunnnniinngg))
■Parking brake on, transmission in Park.
■Press once or activation input twice (don’t hit the brake pedal)
■Exit and lock vehicle.
■To Exit pit stop mode, enter vehicle.
■Place the ignition key to the on (not start or crank) position.
■Depress brake pedal or press .
QQUUIICCKKRREEFFEERREENNCCEEGGUUIIDDEE::
TToorreemmootteessttaarrttuussiinnggyyoouurrrreemmoottee
■Press once. The parking lights will flash once to confirm.
TToorreemmootteessttooppuussiinnggyyoouurrrreemmoottee
■Press once.
TToouusseettiimmeerrmmooddee
■Press both and buttons simultaneously. The parking lights will
flash four times to confirm entry into timer mode operation (ignition off
only).
TToouusseePPiittSSttooppmmooddee((eennggiinneerruunnnniinngg))
■Parking brake on, transmission in Park.
■Press once or activation input twice (don’t hit the brake pedal)
■Exit and lock vehicle.
■To Exit pit stop mode, enter vehicle.
■Place the ignition key to the on (not start or crank) position.
■Depress brake pedal or press .

The company behind this system is Directed Electronics, Inc.
Since its inception, Directed Electronics has had one purpose, to provide consumers with
the finest vehicle security and car stereo products and accessories available. The recipient of
nearly 100 patents and Innovations Awards in the field of advanced electronic
technology, DIRECTED is ISO 9001 registered.
Quality Directed Electronics products are sold and serviced throughout North America
and around the world.
Call ((880000))227744--00220000for more information about our products and services.
Directed Electronics, Inc.
Vista, CA 92081
www.directed.com
© 2004 Directed Electronics, Inc. - All rights reserved
G560T 08-04
Directed Electronics is committed to delivering world class quality products
and services that excite and delight our customers.
