Directed Python 4115P User manual

Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
OWNER’S GUIDE
©2015 Directed. All rights reserved.
The company behind Python®Auto Security
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
car stereo products and accessories available. The
recipient of nearly 100 patents and Innovations Awards
in the field of advanced electronic technology.
Quality Directed products are sold and serviced
throughout North America and around the world.
Call [phone] for more information about our
products and services.
SECURITY FOR THE BEST®
G4115P ML 2015 09
Vista, CA 92081
www.pythoncarsecurity.com
MODEL
4115P

i
© 2015 Directed. All rights reserved.
Congratulations
Congratulations on the purchase of your remote start system. Reading
this Owner’s Guide prior to using your system will help maximize the
use of your system and its many features. For more information please
visit us online (see back cover for URL). For any additional questions
please contact your authorized Directed dealer or contact Directed at
1-800-753-0600. (U.S. only) or 1-800-361-7271 (Canada only)
Additional support is also available at: http://support.directed.com
Important Information
Government Regulations and Safety Information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
This product is designed for fuel injected, automatic trans-
mission vehicles only. Use of this product in a standard
transmission vehicle is dangerous and contrary to the
product’s intended use.

ii © 2015 Directed. All rights reserved.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an authorized
Directed dealer. Please register online (see back cover for URL).
Replacement Remote Controls
Please see your authorized dealer or visit us at www.directedstore.com
to order additional remote controls. Remote control part numbers are
found on the back of the device.
Patent Information
This product is covered by one or more of the following United States
patents:
Remote Start Patents:
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Vehicle Security Patents:
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Other patents pending.

Contents
Congratulations .................................................................................................i
Important Information .........................................................................................i
Government Regulations and Safety Information............................................i
Your Warranty..........................................................................................ii
Replacement Remote Controls.....................................................................ii
Patent Information .............................................................................................ii
Using Your System ...........................................................................................2
Commands At a Glance ............................................................................2
Start Engine .............................................................................................2
Unlock Doors ...........................................................................................2
Stop Engine .............................................................................................2
Car Finder ...............................................................................................2
Using Remote Start............................................................................................3
Key Takeover............................................................................................4
Safety Features.........................................................................................4
Pit Stop....................................................................................................5
Optional Rear Defogger ............................................................................5
Optional Starter Anti-Grind Circuitry ...........................................................6
Disabling the Remote Start System ..............................................................6
Remote Programming ........................................................................................6
Programming Options........................................................................................7
Rapid Resume Logic .........................................................................................8
Battery Information............................................................................................8
Replacing the Battery ................................................................................8
Battery Disposal .......................................................................................8
Government Regulations ....................................................................................9
Warning! Safety first .......................................................................................10
Installation .............................................................................................10
Remote Start Capable .............................................................................10
Manual Transmission Vehicles ..................................................................10
Interference............................................................................................12
Upgrades ..............................................................................................12
Water/Heat Resistance ...........................................................................12
Limited lifetime consumer warranty....................................................................13

2© 2015 Directed. All rights reserved.
Using Your System
Commands At a Glance
System State Press/Release Press/Hold for 3 sec.
ENGINE OFF START ENGINE CAR FINDER
ENGINE ON UNLOCK DOORS STOP ENGINE
Start Engine
When the engine is OFF, press and release the remote control button
to start the engine.
See"Using Remote Start" on page 3 for more feature details.
Unlock Doors
When the engine is ON, press and release the remote control but-
ton. The doors unlock, the parking lights flash, the horn sounds (if con-
nected) as confirmation.
Note: Horn honk may be an optional feature that requires additional
parts and labor.
Stop Engine
When the engine is ON, press and hold the remote control button for
3 seconds. The engine stops running and the parking lights turn off.
Car Finder
When the engine is OFF, press and hold the remote control button for
three seconds. The parking lights flash slowly several times allowing
you to locate your vehicle.

3
© 2015 Directed. All rights reserved.
Using Remote Start
This feature allows you to remotely start and run your vehicle for a
programmable period of time. This makes it possible to warm up the
engine, and adjust the interior temperature of the vehicle with the cli-
mate control system. If interior heating or cooling is desired, the climate
controls must be preset, and the fan blower must be set to the desired
level prior to remote starting the vehicle.
Important! (1) Never remotely start the vehicle with the vehicle
in gear, and (2) Never remotely start the vehicle with the key
in the ignition.
Starting the Engine:
1. Make sure the parking brake is set. Press and release the remote
control button once* (or the amount of times the system has been
programmed to activate the remote start).
2. The parking lights flash to confirm that the vehicle is attempting to
start. In gasoline vehicles the engine will start 4 seconds after the
parking lights flash, in diesel vehicles the engine starts after the
WAIT-TO-START timer has expired.
3. Once the vehicle has started, it will run for the pre-programmed
period of time (12, 24, or 60 minutes) or until a shutdown input
is triggered.
* The factory setting is one press but this can also be programmed for
two or three presses maximum (See your authorized Directed installer
for the amount of presses programmed).
Record the number of presses to activate remote start here:

4© 2015 Directed. All rights reserved.
Warning! It is unsafe to operate a vehicle’s motor in a
garage or other closed off area. Breathing the exhaust
from the vehicle is hazardous to your health. Never
activate the remote start in an enclosed space.
Key Takeover
When you are ready to drive the vehicle:
1. Unlock the doors
2. Enter the vehicle. Do not step on the foot brake
3. Insert the key, turn it to the run (not start) position. Step on the foot
brake. The remote start is disabled and the parking lights turn off.
4. Disengage the parking brake and begin driving.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Safety Features
The following safety features will disable the remote start when acti-
vated or not allow the engine to start if not properly set before starting.
• Foot Brake is depressed
• Hood is open
• Remote Start shutoff switch is OFF
• The pre-programmed run time (12, 24 or 60 minutes) has elapsed
• Pressing and holding the button on the remote for three seconds
while the remote start is active.
• Parking brake is disengaged
• Engine over-rev protection (Tachometer mode only)

5
© 2015 Directed. All rights reserved.
Pit Stop
This remote start can keep the engine running during short trips away
from the vehicle.
Enabling Pit Stop mode:
1. Park in a well ventilated area and set the parking brake.
2. With the engine running set the transmission in the park position.
3. Press and release the remote control button once (or the amount
of times the system has been programmed to activate the remote
start). The parking lights turn on to confirm.
4. Turn off the ignition and remove the key, the engine continues
running.
5. Exit and secure the vehicle, the engine runs for the programmed
runtime.
Important: This feature will not work if the brake pedal is being pressed.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) system,
please refer to the vehicle specific instructions included with
the owner's guide of the interface module or consult your
authorized dealer.
Optional Rear Defogger
If connected, the Defogger circuit automatically activates after remote
starting the vehicle.
Note: The optional rear defogger feature can be programmed to be on
during remote start by your installer, however you do not have the capa-
bility to turn on and off the feature at will from the 1 button remote. The
rear defogger will always be active during the remote start run time.

6© 2015 Directed. All rights reserved.
Optional Starter Anti-Grind Circuitry
This system includes an anti-grind circuit that can prevent damage to
the starter motor if the key is turned to the start position while the remote
start is ON.
Note: Anti-grind circuitry only works if an optional relay has been add-
ed and the remote start system is operating the motor.
Disabling the Remote Start System
When the Remote Start shutoff switch is set to the OFF position, remote
engine starting is defeated. DO this when the vehicle is being serviced
or driven by someone unfamiliar with remote start system operations.
Location Of Shutdown Switch: _________________________
Remote Programming
Your system comes with the remote controls already programmed, how-
ever if you are replacing or adding additional remote controls, they
must be programmed to the system prior to operating the system. To
program the remote, you need to know where the valet button is lo-
cated. If the horn honk is not connected, the main unit LED needs to be
visible for visual confirmation. If you cannot locate or access the main
unit, it is recommended that you visit your authorized dealer for remote
programming. The system is capable of accepting up to four remote
controls.
1. Turn key to the ON position
2. Within 10 seconds, press and release Valet button one time.
3. Within 10 seconds, press and hold the Valet button. The LED on the mod-
ule flashes one time and the horn honks (if connected) to confirm entry into

7
© 2015 Directed. All rights reserved.
remote programming. Do not release the valet button.
4. Press the button on the remote control. The horn honks to confirm the remote
has been programmed.
5. Release the Valet button.
6. Turn the key to the Off position. The horn sounds one long honk to confirm
that remote programming has been exited.
The programming routine exits if any of the following occurs:
• The ignition is turned off
• There is no activity for 30 seconds
• The Valet button is pressed too many times
Programming Options
Feature options will control your system's normal operation. Some op-
tions may require additional parts and installation labor. The following
is a list of the programmable options with the factory settings in bold.
• 12 minute to 60 minute runtime. Your system can be programmed
to allow the vehicle to run for up to 60 minutes when remote
started. This can be set up to minute increments by your installer.
• Parking lights flashing or constant. Your system can be programmed
to flash the parking lights or have them come on constantly during
the remote start operation.
• Ignition switch controlled door locking ON or OFF. With this fea-
ture on, the doors will lock 3 seconds after the ignition key is
turned on, and will unlock when the ignition key is turned off.
Important: The door lock option must be installed for the ignition con-
trolled door lock feature to work.
