diversey TASKI SO4 User manual

Version: S0001-0520
www.diversey.com
SO4
DE.
EN.
ES.
FR.
IT.
NL.
PL.

Always read the instructions of use and the safety
instructions before using the machine for the first
time. The instructions of use must be kept in a
safe and well accessible place so that you can
refer to them at any time.
Warnings and information plates on the machine
provide directions for safe operation.
Apart from the instructions provided please
observe any legislation for prevention of
accidents in the country/place of use.
Symbols used throughout the safety
instructions and on the machine
This sign designates important information.
Failure to follow these instructions may result in
danger to persons and/or extensive damage to
property!
This sign designates important information.
Failure to follow these instructions may result in
danger to persons, malfunction and damage to
property!
This sign designates important information.
Failure to follow these instructions may result in
faults and damage to property!
This sign designates important information
regarding the efficient use of the product. Failure
to follow these instructions may result in faults!
-
Do not touch surface may be hot
-
Do not point or spray toward people,
animals or any electrical appliances
Table of Contents
Safety Instructions………………………………….3
Further Information…………………………………3
Transport & Storage………………………………..4
Appliance Socket…………………………………...4
Structural Layout……………………………………4
Operating Instructions……………………………..5
During Use…………………………………………..6
Safety Precautions…………………………………6
Maintenance………………………………………...6
Service Centre……………………………………...6
Guarantee…………………………………………...7
Technical Data……………………………………...7
Accessories…………………………………………7
Machine Dimensions……………………………….7
Malfunctions………………………………………...8
Disposal……………………………………………..8
Intended Use
The machine is manufactured and designed to
generate steam.
Wear safety shoes and gloves and any other PPE
as specified by local regulations.
The appliance is suitable for commercial use e.g.
in hotels, schools, hospitals, factories, shops,
offices and hire shops.
Any other use is considered as improper use.
Diversey accepts no liability for any damage
resulting from such use. The risk is solely borne
by the user.
Proper use also includes correct operation,
service and repair specified by Diversey.
Changes to the machine that have not been
authorized by Diversey will lead to the expiry of
safety marks and CE conformity. Using the
machine for purposes other than the intended
purpose can cause injuries to persons, and
damage to the machine and the working
environment. Such cases will usually result in the
termination of any warranty and possible
guarantee claims.
Danger
Warning
Caution
Notice
Danger
EN Translation of the original
instructions
of use

Safety instructions
Due to their design and construction, TASKI
machines comply with the relevant essential
health and safety requirements of the EC
directives; they therefore have the CE sign.
Safety Instructions
The machine may only be used by persons who
are adequately trained for the use of the machine
or who have provided proof of their skills
regarding the use of the machine and who are
explicitly commissioned to use the machine.
The machine must not be used by people with
reduced physical, sensory or mental capacities,
including children or people who lack experience
or knowledge.
Children must be supervised to ensure that they do not
play with the machine.
Do not use the machine in rooms where explosive
or highly combustible substances (e.g. gas,
solvents, heating fuel, dust, etc.) are stored or
processed.
These substances could be ignited by the electrical or
mechanical components of the machine.
Pay attention to the local situation as well as to
third persons and children! In the vicinity of blind
spots such as doors or curves in particular, it is
important to reduce speed.
Do not transport other persons and objects with
this machine.
In case of malfunction or defect or after collisions
or toppling over, the machine must be inspected
by an authorized expert before restarting. The
same applies if the machine was left outdoors,
immersed in water or subjected to moisture.
The machine must be stopped immediately in the
event of damage to safety-relevant parts such as
power supply cords, or covers that enable access
to live parts.
The machine must not be stopped, parked or
stored on slopes.
The machine must be switched off for any work
carried out on the machine.
The machine must not be used on slopes >2%.
Sharp cornering on slopes can affect the stability
of the machine and is therefore prohibited.
Danger of accident.
The machine may only be used on a fixed, stable
and sufficiently load-bearing surface.
In the case of non-adherence there is a risk of
accidents.
Operate and keep the machine in a dry and low-
dust environment at temperatures between
+10°C / + 50°F and +35°C/ + 95 °F degrees only.
Only authorized experts who are familiar with all
safety instructions relevant for this machine are
allowed to repair mechanical or electrical machine
parts.
Only tools (brushes, nozzles or similar) that are
specified in these instructions of use under
accessories, or which have been recommended
by a TASKI consultant, may be used. Any other
brushes might impair the safety and functions of
the machine.
National regulations for personal protection and
accident prevention as well as the manufacturer's
instructions for the use of cleaning solutions must
be consistently observed.
In case of water leakage from the machine, the
unit must be switched off immediately.
The machine must be protected against
unauthorized use. Therefore, keep the machine in
a locked room before leaving it.
Further Information
The electric diagram of this machine is
provided in the spare parts list.
- Please contact your customer service for further
information.
These instructions of use as well as all
instructions of use for TASKI machines are
available on the following website:
www.taski.com/instructions-use
Danger
Danger
Warning
Warning
Warning
Warning
Danger
Danger
Danger
Danger
Danger
Danger
Danger
Danger
Danger
Caution
Notice
Notice
Notice

Transport and Storage
Before transporting make sure all the lids are on
and fully tightened or locked in place.
Only transport and use in an upright position, do
not tilt or lie on its side.
Protect the unit from rain and frost. Do not store
outside or use in the rain.
The voltage specified on the type plate must
correspond to the voltage of the electrical source.
It is recommended that the machine is connected
via a residual current circuit breaker with
overprotection switch (max 30mA for 30ms).
Please use the mains cable provided by the
manufacturer and check for damage regularly. If
the cord becomes damaged please contact
Diversey for a replacement (using part code:
11RM00061 for UK plug and 11RM00062 for EU
Plug) prior to using the machine again.
Inadequate extension cords can be dangerous. If
an extension cord is used, it should be suitable
for outdoor use and the connection has to be kept
dry and off the ground by at least 60mm.
Turn off and remove the plug from the power
source when replacing parts or cleaning the
machine.
Appliance Socket
The appliance socket is only designed for the
purposes defined in the operating instructions.
The connection of different appliances can result
in damage.
Prior to plugging in the hose, switch off the
machine and only use the hoses as specified by
the manufacturer.
The machine has a pressure release valve built
into the unit which will open if the machine
pressure ever gets too high. This will release from
the bottom of the machine, if this happens please
contact your supplier or Diversey for repair or
information
If liquid or foam escapes from the machine,
switch off immediately and contact the distributor
or Diversey direct.
Structural Layout
1 2
6 7 8
1 Cold water tank
2 Variable steam control
3 Steam hose socket
4 No braked casters (rear)
5 Braked casters (front)
6 LED temperature display
7 LED heater on
8 Power on/off switch
9 LED steam ready
10 LED cold water refill
Danger
Danger
Caution
3
4
5
9
10

Operating Procedures
Fill the cold water tank (1) with clean cold water
only.
Anything other
than clean cold
water used in
the water tank
will void the
manufacturer’s
warranty.
Connect the Steam Hose to the front of the
machine (3)
Ensuring it is pushed in all the way and the pin on
the flap locks into the hole on the hose.
Ensure the
steam hose
cannot be pulled
out.
IMPORTANT
- Grease “O” rings on steam pin before
connecting.
- To release the steam hose, lift the flap
and pull.
- Plug the power cable into a 240 Volt
supply.
IMPORTANT
- Inspect the electric cable before every
use. If the cable becomes damaged at
any time the complete cable must be
replaced by a Diversey approved
distributor.
- Never touch the power cable or plug with
wet hands
- Always unplug the machine when the
machine is not in use when:
o Cleaning the machine
o Any maintenance work is being
carried out
Switch the On/Off switch (8) to the ON position.
The Heater On light LED (7) will illuminate.
Allow approximately 5
minutes for the boiler to
heat the water
When the Steam Ready LED (9) illuminates the
machine is ready to be used.
The handle controls on the steam hose are now
active. The black rocker switch on the hose
handle will release steam when pressed.
Direct into a suitable container to allow any
excess water/air to escape.
Re-allow the temperature to
increase and the steam ready
light will re illuminate (9)

The steam output can be adjusted by the variable
steam control (2)
Choose and fit the required accessory to the hose
handle.
When changing accessories during use please
note these will be hot!!
During Use
Cold water tank empty
Refill the cold water tank (1) when the refill cold
water LED (10) is illuminated.
A buzzer will sound and the steam will no longer
come out of the nozzle when the steam switch on
the handle is pressed.
The pumps will not work when the cold-water tank
is empty.
Once the cold water refill LED is illuminated the
boiler heater will remain on for 30 minutes. If the
cold-water tank is not refilled within 30 minutes
and the machine is left powered on the boiler
heater will switch off.
Storing the hose after use
On completion remove the hose from the front of
the machine and store in basket/bag provided,
once cooled.
Safety Precautions
This machine is to be used by trained
operatives only
DO
 Check the cable and plug are safe and intact
before plugging the machine in.
 Place cleaning in progress signs where
necessary
 Point the steam nozzle away from your body
during use
 Empty and clean machine after each use
DON’T
 Use the machine near people, children or
animals
 Point steam at electrical apparatus
 Use the machine to clean the machine down
 Do not use on Velvet, satin or leather
 Leave the machine unattended
Maintenance
The maintenance of the machine is a prerequisite for
impeccable operation and a long service life.
Use original TASKI parts only; otherwise, any
warranty and liability claims will expire.
In order to rule out unintended machine functions,
before starting maintenance works the following
must always be carried out
- the machine must be switched off,
Daily Maintenance
To be carried out every day or every 8 hours of
operation.
1. Grease “O” rings on the steam pin in the
steam hose.
2. Wipe down the body of the machine with a
clean damp cloth
3. Always wash the accessories in hot soapy
water. (Do not immerse the machine or
hose in water)
4. Wrap the power cable up before storing
away.
Weekly Maintenance
To be carried out every week or every 50 hours of
operation.
As for daily maintenance plus the following:
1. Inspect the power cable for any signs of
damage. If damaged do not repair, contact
the supplier of this product. Do not use
until repaired.
2. Inspect the hose assembly for any signs of
damage. If damaged do not repair, contact
the supplier of this product. Do not use
until repaired.
3. Inspect castors to ensure all securing bolts
are fully tightened.
Service Centre
Please always indicate the type and number of
the machine whenever you contact us for order
placing or in case of malfunctions.
The required data are provided on the nameplate
of your machine.
The address of your closest TASKI service
partner is provided on the last page of these
instructions of use.
Warning
Caution
Notice

Guarantee
If this appliance, or any parts thereof, is proved to
be defective by reason of faulty workmanship or
materials. Please contact the supplier you
purchased from, and at their option repair or
replace the same free of charge for labour and
materials, provided that:
 The appliance has been installed and
used in accordance with our operating and
servicing instructions.
 If the appliance has been serviced,
maintained, repaired, modified taken apart
or tampered with by any person not
authorised by us, then we will not be liable
under this guarantee for any fault arising
from their defective workmanship.
 We shall not be liable under this
guarantee for any fault in the appliance
arising from the use of spare parts not
supplied and recommended by us.
 Excluded from this guarantee are parts
that need replacement due to normal wear
and tear such as hoses, nozzles and
accessories.
Technical data
Boiler
Wattage
2100 watts
Type
Powder coated
Capacity
1.8 Litres
Continuous Fill
Yes
Steam pressure
4.5 bar
Steam at Source
165C 
Electrical
Voltage
240V ~ single phase
Low voltage controls
5V
Po
wer cable length
10m
Nominal input power
2150 watts
Hand
-
arm vibration
level
<2.5m/s
Capacities
Boiler
1.8 Litres
Cold water tank
5 litres (easy-fill)
Accessories
No
.
Item
.
Qty
7523560
4m Steam only hose
X1
7523561
Extension tube
X2
Floor brush X1
7523562
Triangular brush X1
7523563
Large brush elbow X1
7523564
Window squeegee
X1
Long steam nozzle X1
Curved steam nozzle X1
7523565
Detail brush nozzle X1
7523566
Nylon detail brush X5
7523567
Brass detail brush
X5
Accessory bag X1
7523568
55mm Round brush
X1
Machine Dimensions
Dimensions
Height
46cm
Depth
42cm
Width
32cm
Net weight
12kg
Packaging height
60cm
Packaging depth
49cm
Packaging width
41cm
Packaging gross weight
16kg
Commented [NA1]: Same for all
Commented [NA2]: 160
Commented [NA3]: 161
Commented [NA4]: 162
Commented [NA5]: 163
Commented [NA6]: 164
Commented [NA7]: 165
Commented [NA8]: 166
Commented [NA9]: 167
Commented [NA10]: 168
Commented [NA11]: 169
Commented [NA12]: 170
Commented [NA13]: 171
Commented [NA14]: 172
Commented [NA15]: 173
Commented [NA16]: 174
Commented [NA17]: 175
Commented [NA18]: 176
Commented [NA19]: 177
Commented [NA20]: 178
Commented [NA21]: 179
Commented [NA22]: 180
Commented [NA23]: 181
Commented [NA24]: 182
Commented [NA25]: 183
Commented [NA26]: 184

Malfunctions
Symptom
Possible Cause
Action Required
No Power
Faulty wall socket or not connected Check connection to wall socket and
socket switch. Try other wall socket
On/Off switch not illuminated Press to the On position
Fuse Blown Replace fuse with approved 13A fuse
(UK machines only)
Unknown Call for service
No Steam
Steam Control turned down fully
clockwise Turn the control half way
Steamer not ready Wait for the “Steam Ready” light on the
front of the machine to illuminate
Clean water tank is low (Beeping
Sound & “Refill Clean Water” light
is illuminated)
Pour CLEAN COLD WATER into the
clean water tank. The beeping will stop.
Await for the “Steam Ready” light to
illuminate.
Unknown Call for service
No Steam, Just
Water
Steamer not ready Wait for the “Steam Ready” light to
illuminate
Boiler at pressure and not heating
(temperature less than 110 ºC
Hold the steam switch on for
approximately one minute, even if just
water is coming out. This will result in
the heater coming back on
Unknown Call for service
Steam Leaking
from front
socket
“O” Rings split
Change and re grease “O” Rings. To
avoid this happening ensure “O” rings
are grease before every use
“O” rings worn
Change and re grease “O” Rings. To
avoid this happening ensure “O” rings
are grease before every use
CLD on display
Machine frozen or ambient
temperature is below 3 ºC
Place machine in a warmer environment
for an hour and then turn on the
machine again. If the problem persist
call for service
Pft on display
Boiler/pump fault Call for service
Disposal
After withdrawal from service, the machine and
Accessory parts must be adequately disposed of
in compliance with the national regulations.
- Please contact your Diversey service partner for help.
Notice
Commented [NA27]: 185
Commented [NA28]: 186
Commented [NA29]: 187
Commented [NA30]: 188
Commented [NA31]: 189
Commented [NA32]: 190
Commented [NA33]: 194
Commented [NA34]: 191
Commented [NA35]: 195
Commented [NA36]: 192
Commented [NA37]: 196
Commented [NA38]: 193
Commented [NA39]: 197
Commented [NA40]: 198
Commented [NA41]: 199
Commented [NA42]: 202
Commented [NA43]: 200
Commented [NA44]: 203
Commented [NA45]: 201
Commented [NA46]: 204
Commented [NA47R46]:
Commented [NA48]: 193
Commented [NA49]: 197
Commented [NA50]: 205
Commented [NA51]: 200
Commented [NA52]: 203
Commented [NA53]: 206
Commented [NA54]: 207
Commented [NA55]: 193
Commented [NA56]: 197
Commented [NA57]: 208
Commented [NA58]: 209
Commented [NA59]: 211
Commented [NA60]: 212
Commented [NA61]: 213
Commented [NA62]: 214
Commented [NA63]: 215
Commented [NA64]: 213
Commented [NA65]: 216
Commented [NA66]: 197
Commented [NA67]: 217
Commented [NA68]: 218
Commented [NA69]: 219

AT
Diversey
BE
Diversey Belgium BVBA
CH
Diversey Europe B.V.,
CZ
Diversey
Austria Trading GmbH
Haachtsesteenweg 672
Utrecht
Ceska republika, s.r.o
Guglgasse 7-9 1910 Kampenhout Zweigniederlassung K Hájum 1233/2
1030 Wien Tel [phone] Münchwilen 155 00 Praha 5
Tel [phone] Eschlikonerstrasse Tel [phone]
9542 Münchwilen
Tel [phone]
DE
Diversey
DK
Diversey Danmark ApS
ES
Diversey Es
paña S.L.
FI
Diversey
Deutschland
Teglbuen 10 C/Orense 4, 5 planta Eliel Saarisentie 2
GmbH & Co. OHG
2990 Nivaa 28020 Madrid 00400 Helsinki
Mallaustrasse 50-56 Tel [phone] Tel [phone] Tel [phone]
68219 Mannheim
Tel [phone]
FR
Diversey (France) S.A.S
GB
Diversey Limited
GR
Diversey Hellas S.A.
HU
Diversey Ltd.
9/11, avenue du Val de Weston Favell Centre 5 Himaras St Puskás Tivadar u. 6.
Fontenay NN3 8PD Northampton 15125 Marousi 2040 Budaors
94133 Fontenay sous Tel [phone] Tel [phone] Tel [phone]
Bois Cédex
Tel [phone]
IE
Diversey Hygiene Sales
IT
Diversey S.r.L.
MT
Forestals (Appliances)
NL
Diver
sey B.V.
Limited
Via Meucci 40
Ltd
Maarssenbroeksedijk 2
Ballyfermot office Westlink 20128 Milano The Strand P.O. Box:40441
industrial estate Kylemore Tel [phone] SLM 07 Sliema 3542 DN Utrecht
Road Tel [phone] Tel [phone]
Dublin 10
Tel [phone]
NO
Lilleborg Profesjonell
PL
Diversey Polska Sp.
PT
Diversey Portugal
RO
Diversey Romania
Postboks 673 – Skøyen z.o.o Sistemas de Higiene e S.R.L
0214 Oslo Ul.Fabryczna 5a Limpeza Unipessoal Lda Baneasa Business
Tel [phone] Warszawa Z. Ind.Abrunheira Center, Etaj 5
Tel [phone]-505 Sintra Sos.Bucuresti – Ploiesti
Tel [phone]-21
Sector 1, Bucuresti
Tel [phone]
RU
LLC Diversey
SV
Diversey Sverige AB
SK
Diversey Slovensko
SL
Diversey d.o.o.
125445, Russia, Liljeholmsvägen 18 s.r.o Trzaska cesta 37a
Moscow Box 47313 Rybničná 40 2000 Maribor
24D Smolnaya str, 10074 Stockholm 831 06 Bratislava Tel [phone]
Meridian Commercial Tel [phone] Tel [phone]
Tower 2d floor
Tel [phone]
TR
Diversey Sanayi ve
US
Diversey
CA
Diversey
Ticaret A.S. 2415 Cascade Pointe 3755 Laird Road
İçerenköy Mahallesi, Boulevard Mississauga, Ontario
Bahçelerarası Sok.No:43 Charlotte, NC CANADA L5L 0B3
34752 Ataşehir / İstanbul, USA, 28277 Tel [phone]
Türkiye Tel [phone]
Tel [phone]
