DIVIMATH HDZero EventVRX User manual
1
HDZero EventVRX
What is HDZero?
PUSH YOUR SKILLS TO THE LIMIT
HDZero offers industry-leading low latency, giving you more time to react and the best possible chance
of hitting that next gap. With its smooth, consistent FPV video feed, you’ll experience the same locked-
in feeling you get with analog video–but with the clarity of HD.
MAKE IT AN EVENT
HDZero supports the standard 5.8ghz video channels, meaning you can have up to 8 simultaneous pilots
flying either full-quality HDZero or analog video. When you’re ready to take a break and spectate, you
can tune in to any channel and view the pilot’s feed with no loss of quality, giving you the same feeling
of being in the air yourself.
UPGRADE YOUR FLEET
From 1S whoops to long-range wings, HDZero offers a variety of VTX and camera options to suit every
build. You may even be able to use the gear you already have–the HDZero receiver will work with any
FPV goggle with an HDMI input. HDZero can grow with your needs and fit perfectly into your preferred
FPV craft.
RAPIDLY EVOLVING SYSTEM
HDZero is rapidly evolving. Please always use the latest firmware that is located at www.hd-
zero.com/document.
2
Contents
What is HDZero? .................................................................................................................................1
Features.................................................................................................................................................3
Introduction..........................................................................................................................................3
Operation..............................................................................................................................................4
Firmware Update Guide.....................................................................................................................5
Prerequisites.....................................................................................................................................5
Directories ........................................................................................................................................5
Install Driver .....................................................................................................................................5
Flash Firmware.................................................................................................................................5
3
Features
-Effortless HDZero and analog auto-switching receiver for racing events
-4 channels per box, each of which can receive either an HDZero or analog signal
-4x HDMI and 4x CVBS (composite analog) outputs so you can connect to HDMI capture cards
or to legacy analog DVR recorders
-Both digital and analog signals are output on HDMI and CVBS – system chooses video source
based on signal
-2x SMA antenna jacks that are shared between all 4 channels, so you only need 2 antennas for
4 channels of video
-Rugged steel enclosure that is designed for mounting to a tower
-2D De-interlacer improves analog video quality on HDMI output
-OLED configuration screen for channel and setting changes
-30W power draw, 8-20V DC input
-AC to DC Power supply included
-Firmware updates via USB and included Windows PC software
Introduction
Designed in collaboration with racing pilots and MultiGP event coordinators, the HDZero Event VRX
makes it seamless to integrate HDZero into race DVR and live stream setups.
The Event VRX automatically switches between analog and HDZero video based on received video signal.
This means separate software is not needed to switch the recorded video between the two and no
special setup is needed ahead of time.
The Event VRX outputs both HDZero and analog video on HDMI and CVBS outputs. This means you can
use existing legacy analog video capture equipment such as an Owl DVR box or analog capture card,
keeping cost and complexity to a minimum.
The Event VRX packs four 2-antenna HDZero receivers into one enclosure, which reduces cost and
simplifies setup. The 2-antenna HDZero receivers have less noise rejection than full goggle VRX’s with 4
antennas, but still have excellent video reception for outdoor race events. 8 analog receivers are
included, setup in a diversity arrangement (2 analog receivers per channel).
4
Operation
Boot
Work (Display auto off within 60 seconds)
R
2
R
4
F
2R
7
1. UP/DNkey Selects between Channels (R1~R8, F2,F4)
2. Short Press Entermoves tri-angle cursor
3. Black dot means HDZero only
3. Long Press Entertoggles Black dot.
D0: ON when it is connected to a PC with USB cable
D1-D4:
OFF: No HDZero/Analog detected
ON: HDZero locked
BLINK: Analog locked
D5: Power LED
D0 D1 D5
UP
DN
Enter
Rev: 02062022
D2 D3 D4
5
Firmware Update Guide
Prerequisites
-Windows PC
-.NET Framework 3.5
Directories
-Document
-Driver
-Firmware
-Software
Install Driver
Run driver/Install.bat
Flash Firmware (For Production units)
1. Connect EventVRX to PC with an USB cable. D0 LED on EventVRX will be lit.
2. Power on EventVRX (Very important!)
3. Double click Software/HDZero ProgrammerVx.y.exe (x,y denotes FW version)
4. Click “Browse”, Select /Firmware/EventVRX.bin
5. Click “Update”, and wait for completion
6. Power off EventVRX, and unplug USB cable.
Flash Firmware (For the Prototype units)
1. Power on EventVRX (Very important!)
2. Connect EventVRX to PC with an USB cable. D0 LED on EventVRX will be lit.
3. Double click Software/HDZero ProgrammerVx.y.exe (x,y denotes FW version)
4. Click “Browse”, Select /Firmware/EventVRX.bin
5. Click “Update”, and wait for completion
6. Power off EventVRX, and unplug USB cable.
Production Unit
Prototype Unit
FIG: How to identify: Production or Prototype
