Operating Instructions
Color CCTV Camera
Model No. WV-CW630S/G
WV-CW634SE
This illustration represents WV-CW630S/G.

2
Preface
About the user manuals
The operating instructions of the camera consist of 2 sets: these operating instructions (PDF) and Installation Guide.
This document explains how to configure the settings of the camera.
Refer to the installation guide for further information about how to install the camera.
Adobe® Reader® is required to read PDF. When the Adobe® Reader® is not installed on the PC, download the latest Adobe® Reader®
from the Adobe web site and install it.
Trademarks and registered trademarks
Adobe, Acrobat Reader and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries.

3
Contents
Preface .................................................................................. 2
About the user manuals .................................................... 2
Trademarks and registered trademarks ............................ 2
Contents ................................................................................ 3
About the setup menus ......................................................... 4
List of setup menu ............................................................. 4
Basic operation ................................................................ 5
Screen transition diagram ................................................ 6
Camera title setting [CAMERA ID] .........................................7
Camera operation setting [CAMERA SETUP] .......................8
1. Register a scene file [SCENE1/SCENE2] ..................... 8
2. Light quantity control method selection [ALC/ELC] ...... 8
About Super Dynamic 6 Functions ...............................9
SUPER-D6 setting ........................................................9
About the highlight compensation (HLC) function ....... 10
About the fog compensation function ......................... 11
3. Electronic shutter setting [SHUTTER] ........................ 11
4. Gain control setting [AGC] .........................................11
5. Electronic sensitivity enhancement setting
[SENS UP] .................................................................. 11
6. White balance setting [WHITE BAL] ..........................12
Manual fine adjustment of white balance ................... 13
7. Digital noise reduction function setting [DNR] ............. 13
8. Black-and-white mode setting [D&N (IR) ] ..................14
9. VMD setting [VMD] .................................................... 15
Setting of motion detection .........................................15
Setting of scene change detection ............................. 17
Camera system setting [SYSTEM SETUP] ........................18
10. Synchronization method [SYNC] .............................. 18
11. Privacy zone setting [PRIVACY ZONE] .................... 18
12. Image stabilizer setting [STABILIZER] ...................... 19
13. Electronic zoom setting [EL-ZOOM] ........................ 19
14. Upside-down setting [UPSIDE-DOWN] ...................20
15. Lens distortion correction [LDC] ................................ 20
Back focus setting [BACK-FOCUS SETUP] ........................21
Special menu setting [SPECIAL SETUP] ...........................23
16. Chroma level adjustment [CHROMA GAIN] ............23
17. Aperture level adjustment [AP GAIN] ........................ 23
18. Pedestal level adjustment [PEDESTAL] ..................23
19. Display Settings [DISPLAY] ..................................... 23
20. Pixel compensation [PIX OFF] .................................24
21. Communication setting [COMMUNICATION] ........24
22. Default resetting [CAMERA RESET] ....................... 24
23. Serial number viewing [SER.NO.] ............................ 24
Camera language selection [LANGUAGE SETUP] .............25
Shortcut operation .............................................................. 26

4
Setup item Description
CAMERA ID This item specifies the camera title. The camera title that indicates the camera location and other information
about the camera is created with alphanumeric characters and symbol, and then displayed on the screen.
CAMERA Performs the camera operation settings.
SCENE 1/
SCENE 2
Selects a scene file. It is possible to register and save the settings as a scene file in case that it is necessary
to change the settings such when shooting at night.
ALC/ELC Selects the method of controlling the quantity of light in accordance with the lens to be used.
SHUTTER Specifies the electronic shutter speed.
AGC Specifies gain adjustment.
SENS UP Specifies electronic sensitivity enhancement.
WHITE BAL Specifies white balance adjustment.
DNR Selects the level of the digital noise reduction function.
D&N (IR) Performs each setting regarding the black-and-white mode such as switching between color and black-and-
white images.
VMD Performs settings regarding VMD (Video Motion Detection)
SYSTEM Performs the settings regarding the camera system such as synchronization and privacy zone.
SYNC Only INT method can be used.
PRIVACY ZONE Hides undesired portions in the camera shooting area.
STABILIZER Decides whether or not to enable the image stabilizer.
EL-ZOOM Switches the electronic zoom on and off.
UPSIDE-DOWN Flips the camera images vertically or horizontally.
LDC Adjusts the lens distortion correction to convert the image so that it matches the square monitor.
BACK FOCUS Selects the back focus setting type and performs fine adjustment.
SPECIAL
CHROMA GAIN Adjusts the chroma level (color density).
AP GAIN Adjusts the aperture level.
PEDESTAL Adjusts the pedestal (brightness) level.
DISPLAY Performs the image display setting.
PIX OFF Corrects image defects such as flaws.
COMMUNICATION Performs the communication setting of the system with a receiver into which this unit is integrated.
CAMERA RESET Restores the settings in the setup menu to the default settings.
SER.NO. Displays the serial number of this unit.
LANGUAGE Selects a language to be used in the setup menu.
About the setup menus
Performing each setting item in the setup menu should be completed in advance to use this unit.
Perform the settings for each item in accordance with the conditions of the camera shooting area.
List of setup menu

5
Basic operation
The operations in the setup menu are performed with the operation buttons after calling up the setup menu on the connected video
monitor.
The description below explains how to operate the setup menu basically.
Screenshots of WV-CW630S/G are shown as an example.
Screenshot 2
The setup mode changes to “ENABLE”, and the setup menu
becomes ready to be set. Step 3
Move the cursor to the item to be set, and press the [SET]
button.
Screenshot 1
Hold down the [SET] button for about 2 seconds to call up the
top screen of the setup menu. Step 1
Press the [UP] or [DOWN] button to move the cursor to “END”.
Step 2
Press the [RIGHT] button to move the cursor to “SETUP”,
and press the [SET] button to change the setup mode from
“DISABLE” to “ENABLE”.
MODEL WV-CW630 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP DISABIE
BACK-FOCUS
MODEL WV-CW630 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP ENABLE
BACK-FOCUS
Screenshot 3
The selected setup screen in the setup menu appears on the
screen.
Note:
• If the top screen of the setup menu is called up with the
[SET] button while the camera is operated, the setup
mode is always “DISABLE” to prevent operation errors.
To perform settings in the setup menu, change the setup
mode to “ENABLE”.
• The cursor is a reversely highlighted part.
Step 4
Perform the settings for each item.
• Selection of setting item:
Press the [UP] or [DOWN] button to move the cursor.
• Change of settings:
Press the [RIGHT] or [LEFT] button.
• Display of advanced setup screen:
Press the [SET] button when “ ” is attached to the target
setting item.
• Return to previous setup screen:
Move the cursor to “RET” and press the [SET] button.
• Return to the top screen:
Move the cursor to “TOP” and press the [SET] button, to
display the top screen of the setup menu.
Step 5
Move the cursor to “END” and press the [SET] button to return
to the camera image screen, or wait about 5 minutes and the
setup menu will automatically close.
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR)
OFF

6
Screen transition diagram
Top screen “CAMERA ID” screen
“CAMERA SETUP” screen
“SYSTEM SETUP” screen
“SPECIAL SETUP” screen
“LANGUAGE SETUP” screen
MODEL WV-CW630 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP DISABLE
**LANGUAGE SETUP**
LANGUAGE ENGLISH
SET
RET TOP END
**CAMERA ID**
0123456789
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
().,'":;&#!?=
+-*/%$
SPACE POSI
RET TOP END RESET
................
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE OFF
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END
**SPECIAL SETUP**
CHROMA GAIN ....I..160
AP GAIN ..I.... 20
PEDESTAL ...I... 32
- +
PIX OFF
DISPLAY ALARM
CAMERA RESET PUSH SET
SER.NO. XXXXXXXX
COMMUNICATION COAX
RET TOP END
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF
BACK-FOCUS
**BACK-FOCUS SETUP**
ABF PUSH SET
MANUAL-ADJ
C/L B/W AUTO
SETUP-SW LOCK OFF
NEAR FAR
......... |.........
INDICATOR XXXX
RET TOP END
“BACK-FOCUS SETUP” screen

7
Camera title setting [CAMERA ID]
This item specified the camera title. The camera title that indicates the camera location and other information about the camera is
created with alphanumerics and symbols, and is displayed on the screen. The camera title is named with up to 16 characters.
Follow the procedure below to specify the camera title.
Step 1
Select “ON” for “CAMERA ID”, and then press the [SET] button.
→ The “CAMERA ID” screen appears.
Important:
• When “CAMERA ID” is set to “OFF”, the camera title does not appear even after setting the camera title.
Step 2
Move the cursor to the target item with use of the [UP], [DOWN], [RIGHT] and [LEFT] buttons, and press the [SET] button to enter the
character.
→ The entered characters are displayed in the editing area.
<Character entry>
• To revise a character, move the arrow (↑) in the editing area to a wrong character with use of the [RIGHT] or [LEFT] button, and
enter a correct character.
• To enter a blank, move the cursor to “SPACE” and press the [SET] button.
• To delete all the entered characters, move the cursor to “RESET” and press the [SET] button.
Step 3
Move the cursor to “POSI” and press the [SET] button after title entered.
→ The display positioning screen appears.
Step 4
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to decide the title position and press the [SET] button.
→ The title position is specified.
FLOOR 1
Editing area
Top screen “CAMERA ID” screen Display positioning screen
MODEL WV-CW630 SERIES
CAMERA ID ON
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP ENABLE
**CAMERA ID**
0123456789
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
().,'":;&#!?=
+-*/%$
SPACE POSI
RET TOP END RESET
................
BACK-FOCUS

8
Camera operation setting [CAMERA SETUP]
The following describes the camera operation settings. The following settings can be configured on the “CAMERA SETUP”
screen displayed from the top screen.
Refer to page 5 for how to call up the screen.
The settings configured on the “CAMERA SETUP” screen will be saved as a scene file.
1. Register a scene file [SCENE1/SCENE2]
There are two scene modes. Change between the scene files can be made by shortcut operation. (☞ page 26) The default setting is
“SCENE1”.
Step 1
After confirming that “SCENE1” is selected, configure the settings of “ALC/ELC” through “VMD”. (☞ page 8-17)
To change the scene files, go to step 2.
Step 2
Move the cursor to “SCENE1” and press the [RIGHT] or [LEFT] button to select “SCENE2”.
→ The screen changes and displays “SCENE2”.
Step 3
Set the items you want to change.
The number displayed at the right side of the title on each setting screen indicates a scene file
number.
Step 4
Move the cursor to “SCENE2” and press the [RIGHT] or [LEFT] button to select “SCENE1” to
resume normal operation.
2. Light quantity control method selection [ALC/ELC]
The method of controlling the quantity of light is selected from the following in accordance with the lens to be used.
ALC (default): The iris of the lens is automatically adjusted in accordance with the brightness of a subject. Select “ALC” when using
an ALC lens.
ALC+: Controls the quantity of light with a combination of the electronic shutter and auto iris. This selection is suitable at shooting
a bright subject such as an outdoor subject with auto iris lens. Be aware that flicker may occur when a subject is under
fluorescent lighting.
ELC: Controls the quantity of light with the electronic shutter. This selection is suitable for use of a lens with fixed iris or manual iris.
Screen when "SCENE1" is selected Screen when "SCENE2" is selected
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
**CAMERA SETUP**
SCENE2
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
Scene file
number
**ALC CONT**(1)
BACK LIGHT COMP
“SYSTEM SETUP” screen
ON
- +
LEVEL .I..... 0
RET TOP END
SUPER-D6
HLC
FOG COMP
---
---

9
About Super Dynamic 6 Functions
If there is high contrast between the bright and dark areas
in a shooting zone, the dark area becomes less visible
because the camera adjusts the iris in accordance with the
bright area. Conversely, adjusting the lens brightness for the
darker areas causes the brighter areas to become washed
out. The SUPER DYNAMIC 6 function digitally combines
an image that is set up for a clear view of the brighter areas
with an image that is set up for a clear view of the darker
areas, creating a final image that preserves overall detail.
SUPER-D6 setting
When "ALC/ELC" is set to "ALC", the SUPER-D6 function is available.
Follow the procedure below.
Mask setting screen“CAMERA SETUP” screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
“ALC CONT” screen
**ALC CONT**(1)
BACK LIGHT COMP
OFF
MASK SET
- +
LEVEL .I..... 0
RET TOP END
SUPER-D6
HLC
FOG COMP
OFF
OFF
Step 1
Set “ALC/ELC” to “ALC”, and press the [SET] button.
→The “ALC CONT” screen appears.
Note:
• When “ALC/ELC” is set to “ELC” or “ALC+” and the [SET] button is pressed, the “ELC CONT” or “ALC+ CONT” screen will appear.
• When “ELC” or “ALC+” is selected, the SUPER-D6 function is disabled. “---” appears and “OFF” is selected. (Go to Step 3)
Step 2
Move the cursor to "SUPER-D6" and select the "ON" or "OFF".
ON (default): Activates the SUPER-D6 function. (Go to Step 6)
OFF: Deactivates the SUPER-D6 function. (Go to Step 3)
Note:
• Once the “SUPER-D6” function is set to “ON”, the settings of the following items will be restricted.
SHUTTER: It can only be set to “OFF” or “1/120”.
SENS UP: It can only be set to “OFF” or “AUTO”.
• Once the “SUPER-D6” function is set to “ON”, a shadow (black line) may appear at the border of the brighter part and darker
part. This is not a fault.
• When flickering or noise is observed frequently due to the illumination of light, select “OFF”.
• When flickering or color deterioration is observed
• When noise is produced in a bright area on the screen
• Once the “SUPER-D6” function is set to “ON”, “---” is displayed for “HLC” and “FOG COMP”. In this case, the “HLC” and “FOG
COMP” functions cannot be set.
Creates a clearer
image by digitally
combining images
Subject in the dark
area is hard to notice.
Subject in the bright
area is hard to notice.

10
Step 3
When the SUPER-D6 function is set to "OFF", bright areas of an image are masked to facilitate the visibility of dark areas.
Move the cursor to “MASK SET” and press the [SET] button.
→ The mask setting screen appears.
Step 4
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to move the flashing cursor to the area to be masked and press the [SET]
button.
When the selected area is masked, the masked area will start blinking (between stripes and white). When the flashing cursor is moved
to other areas, the masked area will be displayed in white.
Repeat the above procedure to mask other areas as necessary.
Note:
• To cancel the masking, select the masked area to be canceled, and then press the [SET] button. The masked area will be deleted.
Step 5
Hold down the [SET] button for more than 2 seconds after completion of masking.
→ Return to the previous menu.
Step 6
Move the cursor to “LEVEL” and press the [RIGHT] or [LEFT] button to adjust the level.
About the highlight compensation (HLC) function
This function is a backlight compensation technology that enables the camera to obtain clear images in a strong light environment.
When “SUPER-D6” is set to “ON”, this function cannot be set.
Available options: ON (1)/ON (2)/OFF
ON (1): When the camera faces the light source, this function can be used to block strong light so as to reduce over exposure as
much as possible and retain lots of screen details.
The mask area has three options: small (S), medium (M) and large (L), which are used to adjust the area of the mask zone.
When the mask level cursor moves towards the “+” direction, the mask color becomes pale; when the mask level cursor moves towards
the “-
” direction, the mask color becomes dark.
ON (2): When the camera faces the light source, strong light can be effectively suppressed and screen details can be retained to the
maximum extent.
“ALC CONT” screen
**ALC CONT**(1)
BACK LIGHT COMP
OFF
MASK SET
- +
LEVEL .I..... 0
RET TOP END
SUPER-D6
FOG COMP ---
ON(1)
HLC
HLC setting screen
**HLC**(1)
S
- +
..I....2
RET TOP END
AREA
MASK LEVEL
Note:
• According to different highlight parts on the screen, different HLC functions may be provided.
• The HLC function can be enabled only when the brightness area exceeds the normal specification.
• When the HLC function is set to “ON (1)” or “ON (2)”, “FOG COMP” is displayed as “---” and the fog compensation function can-
not be set.
• After “SUPER-D6” switches from “ON” to “OFF”, “HLC” and “FOG COMP” are displayed as “OFF”.

11
About the fog compensation function
This function enables the camera to obtain clear images in hazy weather. When “SUPER-D6” or “HLC” is set to “ON”, this function is
not available.
Adjust the amplitude of fog compensation. When the cursor moves towards the “+” direction, the fog compensation level increases;
when the cursor moves towards the “-” direction, the fog compensation level decreases.
“ALC CONT” screen
**ALC CONT**(1)
BACK LIGHT COMP
OFF
OFF
MASK SET
- +
LEVEL .I..... 0
RET TOP END
**FOG COMP**(1)
SUPER-D6
FOG COMP
ON
HLC
Fog compensation setting screen
- +
...I...64
RET TOP END
LEVEL
3. Electronic shutter setting [SHUTTER]
The variation in shutter speed allows users to perform the following.
• Increased shutter speed prevents blurring fast-moving subjects.
• If flicker is observed under fluorescent lighting of 60 Hz, selection of “1/120” for the speed can reduce flicker.
The shutter speed is selectable from the following.
OFF (1/50) (default), 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/120000
Note:
• When “ALC/ELC” is set to “ELC” or “ALC+”, “---” appears and the shutter function cannot be activated.
4. Gain control setting [AGC]
Select a gain control setting from the following.
ON (HIGH) (default)/ON (MID) /ON (LOW): Automatically increases the gain to make the screen brighter when the illuminance of the
subject becomes darker.
HIGH, MID and LOW indicate the gain level.
OFF: Does not increase the gain.
Note:
• When “SENS UP” is set to the AUTO mode, “AGC” cannot be set to “OFF”.
5. Electronic sensitivity enhancement setting [SENS UP]
Use of the electronic sensitivity enhancement function increases the light sensitivity of the CCD, and accordingly the image becomes
brighter. The magnification is unchanged for selection of FIX, and the magnification is automatically adjusted in accordance with the
illuminance of a photographic subject for selection of AUTO.
The magnification of the electronic sensitivity is selectable from the following.
Setting of the SUPER-D6 function restricts the available setting range.
When the SUPER-D6 function is set to "OFF":
OFF (default)/X2 AUTO/X4 AUTO/X6 AUTO/X10 AUTO/X16 AUTO/X32 AUTO/OFF/X2 FIX/X4 FIX/X6 FIX/X10 FIX/X16 FIX/
X32 FIX/X64 FIX/X128 FIX/X256 FIX/X512 FIX
When the SUPER-D6 function is set to "ON":
OFF (default)/X2 AUTO/X4 AUTO/X6 AUTO/X10 AUTO/X16 AUTO/X32 AUTO

12
Note:
• When “ALC/ELC” is set to “ELC” or “ALC+”, only the AUTO mode is enabled.
• When “SHUTTER” is set to options other than “OFF”, the electronic sensitivity enhancement setting cannot be performed and
“---” appears.
• When the magnification of “SENS UP” is increased, the screen becomes coarser, more whitish, or more flawed. However, this
phenomenon is normal.
6. White balance setting [WHITE BAL]
The white balance adjustment is selectable from the following.
ATW1 (default): Activates the automatic color temperature tracking mode.
The camera continuously check the color temperature of the light source and automatically adjusts the white
balance. The adjustment of the color temperature ranges from approx. 2700 K to 6000 K.
ATW2: Activates the sodium lamp automatic color temperature tracking mode. The camera automatically achieves an optimal white
balance under the sodium lamp. The adjustment of the color temperature ranges from approx. 2000 K to 6000 K.
AWC: Activates the automatic white balance control mode. This adjustment is suitable for a location where a light source is stable.
The adjustment of the color temperature ranges from 2000 K to 10000 K. When “AWC” is selected, the white balance needs
to be adjusted.
Note:
• If the situation meets one of the followings, color may not be accurately reproduced.
• The subject is mostly highly-colored.
• The photographic scene is under the bright blue sky or at nightfall.
• The illumination of the light illuminating the subject is insufficient.
When “AWC” is selected, follow the steps below to adjust the white balance.
"CAMERA
SETUP" screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL AWC PUSH SET
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
Step 1
Set “WHITE BAL” to “AWC” and press the [LEFT] button to change to “AWC → PUSH SET”.
Step 2
Press the [SET] button and adjust the white balance. “AWC → PUSH SET” is reversely highlighted during adjustment. When the
reversely highlighted display is restored, the white balance adjustment is completed.
Step 3
Press the [RIGHT] button to select “AWC”. Refer to next page for fine adjustment of the white balance.
Note:
• The adjustment of the color temperature ranges from approx. 2000 K to 10000 K. If the range is out of this adjustment range or
lighting directed to a subject is too dark, the white balance may not be adjusted. In such a case, “AWC → PUSH SET” stays
reversely highlighted.

13
Manual ne adjustment of white balance
The white balance is manually fine adjusted after white balance automatically adjustment in the automatic color temperature tracking
mode (ATW1, ATW2) or automatic white balance control mode (AWC).
Follow the procedures below.
**ATW1**(1)
R
- +
B
- +
AREA
RET TOP END
**ATW1 AREA**(1)
POSITION PUSH SET
RET TOP END
Area setting screen
RESET
...I... 0
...I... 0
“CAMERA SETUP” screen Fine adjustment screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
Step 1
Set “WHITE BAL” to “ATW1”, “ATW2” or “AWC” and press the [SET] button.
→ The fine adjustment screen appears.
Step 2
Move the cursor to “R” and “B” and press the [RIGHT] or [LEFT] button to fine adjust the level for each. “R” stands for red and “B”
stands for blue.
When the level indicator moves in the “+” direction, the color becomes deeper, and when the level indicator moves in the “–”
direction, the color becomes lighter.
Step 3
Move the cursor to “AREA” and press the [SET] button to enter “AREA” setting screen.
The area to detect white area of white balance can be set on the area setting screen. The area to detect white area of white balance
is displayed full-screen by default.
Step 4
Move the cursor to “POSITION” and press the [SET] button.
Step 5
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to move to the upper-left part of the area to be set, and press the [SET] button.
Step 6
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to move to the lower-right part of the area to be set, and press the [SET] button.
7. Digital noise reduction function setting [DNR]
The digital noise reduction function reduces noise automatically under the condition of low illuminance.
The effect level of the noise reduction function is selectable from the following.
LOW: Low level of noise reduction (small residual image)
HIGH (default): High level of noise reduction (large residual image)

14
8. Black-and-white mode setting [D&N (IR) ]
The settings relating to the black-and-white mode can be configured.
Follow the procedure below
AUTO1
**D&N(IR) **(1)
LEVELHIGH

DURATION TIME

S L
BURST(BW)
ON
RET TOP END
.I..
“CAMERA SETUP” screen “D&N (IR)” screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD OFF
RET TOP END
D&N(IR)
Step 1
Move the cursor to “D&N (IR)” and select the mode from the following.
AUTO1 (default): Automatically switches between color and black-and-white images in accordance with the illuminance. The
black-and-white mode is selected for dark images, and the color mode is selected for bright images.
AUTO2: Used a near-infrared light source at night time.
ON: Displays black-and-white images.
OFF: Displays color images.
Note:
• When “AUTO1” or “AUTO2” is selected, it is recommended to set “AGC” to “ON”.
• If a subject is always moving or the screen is occupied with a uniform color, brightness determination may not be performed suc-
cessfully because the brightness is merely determined by information from the CCD image sensor. When “AUTO2” is selected,
the wave length of the light source shall be 800 nm or longer.
Step 2
Press the [SET] button.
→ The “D&N (IR)” screen appears.
Step 3
Move the cursor to “LEVEL” and select a brightness level at which switching between color and black-and-white images is performed
from the following.
LOW: Switches from color to black-and-white images when the ambient illuminance of the camera is less than 0.1 lx.
HIGH (default): Switches from color to black-and-white images when the ambient illuminance of the camera is less than 0.2 lx.
Note:
• The switching illuminance level varies with subjects, light sources, and lenses.
• The switching illuminance level varies in accordance with AGC setting. (☞ page 11)
• The switching illuminances described above are reference values. The switching illuminance shall be decided based on the actual
installation environment.
• There may be repeated switching between color and black-and-white images depending on the setting and environment.
Step 4
Move the cursor to “DURATION TIME” and select a time for switching between color and black-and-white images from the following.
2 seconds - 10 seconds (default) - 30 seconds - 60 seconds
(S) (L)

15
Step 5
Move the cursor to “BURST (BW)”, and decide whether or not to provide a burst signal output in the black-and-white mode.
ON (default): Provides a burst signal output.
OFF: Does not provide any burst signal output.
Note:
• Images may not be displayed appropriately without burst signals when camera images are displayed in the black-and-white
mode depending on a monitor or VTR model to be used. In such a case, set the burst signal output to “ON”.
9. VMD setting [VMD]
The VMD function allows the camera to detect motion and scene change with the camera. Detection of motion or scene change with
the camera can be announced by issuing an alarm signal.
Important:
• The following circumstances may result in detection failure or false detection. Use the camera after adjusting the detection area
and sensitivity.
• Not enough difference in brightness between the background and the moving photographic subject, or significant changes in
brightness
• Dirt or water drops on the lens
• Insufficient brightness, for example, when shooting at night
• The subject is moving straight at the camera
• The subject is moving too fast or too slow
• The subject is too small or too large
• There are too many moving objects
• Light reflected through a window or from a road surface
• The camera is shaking
• Entry of outside light, such as sunlight or the headlights of a car
• Flickering fluorescent light
• Subject change detection may fail in the following cases.
• The lens is partially covered or covered with a transparent item
• The photographic subjects before and after changing the camera direction are similar
• False detection may occur for approx. 1 minute after turning on the power, after completing settings in the SETUP menu, or after
changing the camera view angle.
• Motion detection is the detection function within the screen range for electronic zoom of 1x.
Setting of motion detection
Move the cursor to “VMD”, press the [RIGHT] or [LEFT] button to select “MOTION DET”.
“MOTION DET” screen
** MOTION DET **(1)
RET TOP END
LEVEL
2S
OFF
DWELL TIME
DISPLAY MODE
ALARM
MASK SET
....I..
20
- +
“CAMERA SETUP” screen
MOTION DET
AUTO1
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
VMD
RET TOP END
D&N(IR)

16
Step 1
Move the cursor to “MOTION DET” and press the [SET] button.
→ The “MOTION DET” screen appears.
Step 2
Move the cursor to “MASK SET” and press the [SET] button.
→ The mask setting screen appears.
“MOTION DET” screen Mask setting screen
** MOTION DET **(1)
RET TOP END
LEVEL
2S
OFF
DWELL TIME
DISPLAY MODE
ALARM
MASK SET
....I..
20
- +
In the masked area, no alarm will be issued even if a moving object is detected. The masked area is set in the same way as the
masked area setting in “Light quantity control method selection”. (☞ page 8)
Step 3
Hold down the [SET] button for more than 2 seconds after completion of masking.
→ Return to the previous menu.
Step 4
Move the cursor to “ALARM” and press the [RIGHT] and [LEFT] buttons to select “ON” or “OFF”.
ON: Outputs alarm signal when in display mode. Actions may be confirmed through the motion detection mode when a moving
object is detected.
OFF (default): Does not output alarm signal when in display mode.
Step 5
Move the cursor to “DISPLAY MODE” and press the [SET] button.
→ The display mode screen appears.
If a moving object is detected in the set area, the area will be reversely highlighted. Hold down the [SET] button for more than 2
seconds to return.
Display mode screen
“MOTION DET” screen
** MOTION DET **(1)
RET TOP END
LEVEL
2S
OFF
DWELL TIME
DISPLAY MODE
ALARM
MASK SET
....I..
20
- +
Step 6
Move the cursor to “LEVEL” and press the [RIGHT] or [LEFT] button to adjust the level.
Repeat step 5 and 6 to adjust to optimal level.

17
Step 7
Move the cursor to “DWELL TIME ” and select the dwell time from the following. (unit: seconds)
2S (default)/5S /10S /30S
Alarm signal will be issued once a continuously moving object is detected within the specified time.
Setting of scene change detection
This function detects a change in the subject state that occurs by covering the camera with a cloth, a cap, or others, or by changing
the camera direction largely.
Follow the procedure below.
“CAMERA SETUP” screen
VMD SCENE CHANGE
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
RET TOP END
D&N(IR)
Step 1
Move the cursor to “VMD” and press the [RIGHT] or [LEFT] button to select “SCENE CHANGE”.
Note:
• The Scene Change function is activated after exit from the menu.

18
Camera system setting [SYSTEM SETUP]
Performs the settings relating to the camera system such as synchronization and privacy zone. The following settings can be
configured on the “SYSTEM SETUP” screen displayed from the top screen.
Refer to page 5 for how to call up the screen.
10. Synchronization method [SYNC]
Only internal synchronization (INT) can be used.
Multiplexed vertical drive (VD2) synchronization cannot be used.
11. Privacy zone setting [PRIVACY ZONE]
When undesired portions in the camera shooting area (on the screen) exist, those portions (privacy zone) can be set to be hidden. Up
to 8 portions can be specified for the privacy zone.
ON (1): Grays the zone.
ON (2): Mosaics the zone.
OFF (default): Displays the zone normally.
Follow the procedure below to set the privacy zone.
Note:
• The privacy zone function is disabled at initializing the unit, i.e. right after turning on the power.
“SYSTEM SETUP” screen “ZONE NUMBER” screen
ON(2)
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END
**ZONE NUMBER 1 /8**
PUSH SET
POSITION
UPPER LEFT
RET TOP END
DEL
- +
ZONE LEVEL ..I.... 2
Step 1
Move the cursor to “PRIVACY ZONE”, select “ON (1)” or “ON (2)”, and press the [SET] button.
→ The “ZONE NUMBER” screen appears.
Step 2
Move the cursor to the number at the right of the title and select the zone number using the [RIGHT] or [LEFT] button.
Step 3
Move the cursor to “POSITION” and press the [SET] button.
Step 4
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to determine the left upper position of the zone to be set and press the [SET]
button.
“SYSTEM SETUP” screen
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE OFF
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END

19
Step 5
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to determine the lower right position of the zone to be set and press the [SET]
button.
→ An asterisk “*” will be displayed after the number and the zone setting will be saved.
Step 6
When “ON (2)” is selected for “PRIVACY ZONE”, the mosaic level may be adjusted. The mosaic level may be set through “ZONE
LEVEL”. (Range: 1 to 4)
Note:
• To delete a zone, select the zone number and press the [SET] button after moving the cursor to “DEL”.
• To change the settings of a zone, select the zone number and repeat from step 3.
12. Image stabilizer setting [STABILIZER]
Whether or not to enable the image stabilizer is determined.
This function is effective for the case that the camera is installed at a place with slight shaking.
ON: Enables the image stabilizer.
OFF (default): Disables the image stabilizer.
Important:
• When “ON” is selected for the image stabilizer, the view angle becomes narrower and the resolution becomes lower. When “ON”
is selected for the image stabilizer, check the view angle and resolution at camera installation.
• The image stabilizer function may not work for the following subjects or conditions.
• Dark subject
• Less contrasty subject (e.g. white wall)
• Subject shaking at excessive speed
• Large amplitude image shaking
13. Electronic zoom setting [EL-ZOOM]
Whether or not to use the electronic zoom is determined.
ON: Uses the electronic zoom.
OFF (default): Does not use the electronic zoom.
When “ON” is selected, the zoom factor and the panning/tilting settings can be configured.
Follow the procedure below.
**EL-ZOOM**
**EL-ZOOM** **EL-ZOOM**
PUSH SET
PUSH SET
ZOOM
PAN/TILT
PUSH SET
PUSH SET
ZOOM
PAN/TILT
PUSH SET
PUSH SET
ZOOM
PAN/TILT
U ZOOM D U TILT D/L PAN R
“SYSTEM SETUP” screen “EL-ZOOM” screen Pan/tilt setting screenZoom setting screen
RET TOP END RET TOP END RET TOP END
OFF
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE
STABILIZER OFF
EL-ZOOM ON
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END
Step 1
Move the cursor to “EL-ZOOM” and select “ON” and press the [SET] button.
→ The “EL-ZOOM” screen appears.
Step 2
Move the cursor to “→ PUSH SET” of “ZOOM” and press the [SET] button.
→ The zoom setting screen appears.

20
Step 3
Adjust the angular field of view by changing the electronic zoom factor (up to 2x) using the [UP] or [DOWN] button, and press the [SET]
button.
Note:
• When the zoom factor is incremented, resolution will be deteriorated.
Step 4
Move the cursor to “→ PUSH SET” of “PAN/TILT” and press the [SET] button.
→ The pan/tilt setting screen appears.
Step 5
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to determine the position of the area to be set and press the [SET] button.
The position can be changed in the range of zoom factor set in the zoom setting screen.
14. Upside-down setting [UPSIDE-DOWN]
ON: The video image can be reversed upside down.
OFF (default): The video image cannot be reversed upside down.
15. Lens distortion correction [LDC]
The image may be distorted depending on the lens used and the zoom factor. By adjusting the lens distortion correction setting, the
distorted image can be converted to match the square monitor and achieve effects desired by the user.
Note:
• Depending on the lens used, complete correction may not be achieved.
