Dixie Chopper Vortex 2008 Operating instructions

Model # ____________________
Serial # ____________________
Date Purchased ____________________
April
2008
700134
2008 Vortex
Installation/Owner’s Manual
6302 E. County Road 100 N • Coatesville, IN 46121 • [phone] • Fax: [phone]
dixiechopper.com

II
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
AUTHORIZED DEALER
About This Manual
This owner’s manual is considered a permanent part of the accessory. It must be available to all of the
operators and/or person(s) servicing the accessory. Should the accessory be resold, this manual must
remain with the accessory.
All information, illustrations, and specifi cations contained in this manual were in effect at the time of
publication. Dixie Chopper reserves the right to change, modify, and/or discontinue specifi cations and/
or design without notice. If there is a change that has been made to your accessory which is not shown
or refl ected in this manual, please see your authorized Dixie Chopper Mower dealer before operating
and/or servicing the equipment.
Congratulations on the purchase of your new Dixie Chopper mower accessory. We at Dixie Chopper
are confi dent that this accessory will provide you with years of excellent performance, durability, and
trouble free service when operated and maintained as directed in this manual.
Should you ever have any questions regarding the operation, maintenance, or safety of your accessory,
please contact your authorized Dixie Chopper Mower dealer who has been specially trained on opera-
tion and service of Dixie Chopper Mower Accessories.
A space has been provided on the cover and below to record information about your new Dixie Chopper
Mower Accessory. Please take time to record such information for future reference, especially when
you contact an authorized Dixie Chopper Mower dealer with questions.
Date Purchased: ___________________________________________
Model Number: ___________________________________________
Serial Number: ___________________________________________
Purchased From: ___________________________________________

1
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
TABLE OF CONTENTS
Warranty Policies
Warranty Policies
2
Safety Information
Safety Information
3
Safety Precautions
Safety Precautions
4
Safety Decals
Safety Decals
6
Kit Components
Kit Components
7
Blower Installation
12
Silver Eagle Hopper Installation
Silver Eagle Hopper Installation
15
Standard Hopper Installation
Standard Hopper Installation
16
Propane Hopper
Installation
16
F2/F4/F5 Pre-Installation
17
F2/F4/F5 Hopper Installation
F2/F4/F5 Hopper Installation
17
F4/F5 Door Linkage Adjustment
F4/F5 Door Linkage Adjustment
18
Counter Weight Installation
Counter Weight Installation
18
Diesel Hopper Installation
19

2
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Warranty Policies
There are no understandings, agreements, representations, or warranties expressed or implied (including but not
limited to any regarding the merchantability or fi tness for a particular purpose), not specifi ed herein, regarding the
equipment which is the subject of this warranty.
Owner/Operator Knowledge Respon
Owner/Operator Knowledge Respon
sibility
sibility
As a condition of the Dixie Chopper warranty, the owner and operator(s) are fully responsible for having read, and
reasonably understood the proper operation and care of the Dixie Chopper Bagger unit
before attempting to
operate the machine.
Through the terms and conditions contained herein, Magic Circle Corporation, a.k.a. Dixie Chopper, warrants that
it will adjust, repair, or replace any factory original part used in the manufacturing of a Dixie Chopper Bagger unit,
found to be defective in material or workmanship.
Bagger Access
Bagger Access
ory
ory
The warranty period is limited to one year from the date of retail purchase on behalf of the original owner of a Dixie
Chopper bagger unit. This warranty will provide the cost of repair or replacement ( at the discretion of Dixie
Chopper) of the defective part, including labor.
Hose
,
,
Bags, and Belts
Bags, and Belts
Hose, bags, and belts are considered to be consumable wear items, and are therefore warranted for an initial period
of 90 days against materials or workmanship defects, not for wear or abuse.
Transportation for Warranty Repairs
Transportation for Warranty Repairs
A Dixie Chopper Bagger unit (including any defective part(s) requiring warranty repair, must be returned to an
authorized Dixie Chopper Service Dealer within the warranty period. The expense of transporting the unit to and
from the dealer for warranty work will be the responsibility of the unit owner.
L
imitation of Warranty
imitation of Warranty
The Product Registration/Dealer Delivery Certifi cation must be mailed to Dixie Chopper within three days of the
original retail purchase date to enable accurate validation of the warranty period provided. Proof of purchase may
be required ( invoice & copy of product registration) from the unit owner to substantiate any warranty claim..
All warranty work must be performed by an authorized Dixie Chopper Servicing Dea
All warranty work must be performed by an authorized Dixie Chopper Servicing Dea
ler, using only Dixie
ler, using only Dixie
Chopper OEM parts
Chopper OEM parts
.
This warranty covers only Dixie Chopper Baggger units that are registered with the factory
when purchased new, properly maintained, and operated under conditions considered normal for commercial turf
equipment.

3
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
SAFETY INFORMATION
Read This Manual Carefully And Thoroughly Before Operating The Mower!
Training
1. Carefully and thoroughly read the owner’s manual. Allow adequate time to fully understand the
controls and operation of the equipment.
2. Never allow anyone to operate the mower that has not read and fully understood the owner’s
manual.
3. Do not carry passengers. Avoid mowing while people, especially children and pets are nearby,
since rotating blades can throw rocks and other items with enough force to cause serious in-
jury.
Before Use of Equipment
Operator:
Wear protective clothing while mowing. Long trousers and safety glasses will help reduce the risk
of injury from thrown objects. It is recommended that steel toe shoes with aggressive soles or some
other type of substantial footwear be worn to help protect your feet and maintain traction on slopes or
uneven ground. Always wear hearing protection.
Mowing Area:
Thoroughly inspect the area where the equipment is to be used. Look for items such as stones,
sticks, wire and other foreign objects. When struck by the mower, these and other objects may
become projectiles that could lead to serious injury and/or death.
Mower:
For your safety and the long life of your mower, always inspect the mower before each use. Before
inspection, make sure it is on a fl at and level surface, the blades are disengaged, the ignition switch
off with the key removed, and the spark plug wire is off of the spark plugs.
General Condition:
• Walk around the mower looking for any fl uid spills or leaks on or underneath the mower.
Remove any and all excessive debris, dirt, and/or fl uids.
• Look for signs of damage or excessive wear. Check the tightness of all nuts, bolts, pins, and
screws. Tighten any that may be loose and replace any that may have been lost during use.
• Be sure the safety interlock seat switch is operating properly so that the engine can not be
started unless the operator is in the seat with the blades disengaged.
• Check the mower blades for any damage or abnormal wear and replace in sets so that they
are balanced.
• Check the tire pressure on all four tires.
• Check all belts for proper wear and correct tension.
• Check engine oil and air fi lters as recommended in the engine manufacturers’ operators
manual.

4
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
GENERAL SAFETY PRECAUTIONS
1. Never allow individuals who have not read this Operator Manual to operate the mower.
2. Never allow children to operate mower. This mower is intended for adult use only.
3. Never operate the mower when barefoot or when wearing open sandals.
4. Thouroughly clear the work area of objects (wire, stones, sticks, bones, etc.) which may
damage the mower or cause personal injury to the operator, bystanders, or other property.
5. Before attempting to start the engine, engage parking brake, disengage the deck and all
attachment clutches and position the steering levers into the neutral lock position.
6. Give complete, undivided attention to the job at hand.
7. Whenever the deck is engaged, NEVER direct the discharge of material toward bystanders nor
allow anyone near the mower while in operation.
8. Whenever possible, avoid operating the mower in wet grass.
9. Mow only in well lit areas.
10. Use EXTREME CAUTION when mowing and/or turning on hill sides.
11. Reduce speed and exercise EXTREME CAUTION on slopes to prevent tipping over or loss of
control.
12. Never operate mower on slopes exceeding 15 degrees.
13. To avoid tipping over, avoid sudden motion when mowing uphill.
14. When mowing downhill, loss of traction may occur. Weight transfer to the front wheels may
cause drive wheels to slip and result in loss of control. To help re-gain control, increase
ground speed and gradually turn left or right followed by a decrease in ground speed to regain
directional control.
15. Do not mow slopes when grass is wet.
16. Be especially cautious when changing direction on slopes.
17. Stay alert for holes, rocks and roots in the terrain, which may cause the mower to upset.
18. Keep away from drop-offs.
19. Do not operate the mower near any body of water, (lakes, ponds, riverbanks, etc.).
20. When backing up, make sure the area behind you is clear. Dixie Chopper’s zero turning radius
nearly eliminates the need for backing up. Simply turn the mower around within its own
dimension and proceed forward.
21. Disengage power to attachments, set parking brake, and stop engine before leaving the
operator position.
22. Disengage power to attachments, set parking brake, and stop engine before making any
adjustments.
23. Disengage power to deck and other attachemnts when the mower is being transported or not
in use.
24. Take all possible precautions when leaving mower unattended; such as disengaging deck,
engaging parking brake, lowerning attachments, placing steering levers into the neutral lock
position, stopping the engine, and removing the key.
25. Never operate the mower with defective guards, shields, or covers. Always have safety
shields, guards, switches, and other devices in place and in proper working condition.
26. Place OCDC in the down or operating position when discharge is toward road, street, or
property.
27. Keep hands, feet and clothing away from rotating parts anytime the mower engine is running.
28. Do not mow with damaged or worn blades. Make sure blades are properly balanced.

5
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
GENERAL SAFETY PRECAUTIONS
29. Stop the engine, set parking brake, and remove the key:
• After striking a foreign object. Inspect the mower for damage and make any repairs
before starting and operating the mower.
• Before making any adjustments or repairs.
• Before unclogging discharge chute.
• Before refueling.
• Before exiting the mower.
30. Do not change the engine governor settings or overspeed the engine.
31. Uses care when pulling loads or using heavy equipment.
• Use only approved drawbar hitch points.
• Limit loads to those you can safely control.
• Do not turn sharply.
• Use care when backing.
• Use extreme caution on slopes.
• Loads should not be pulled down slopes. Load may exceed braking capabilities of the
mower causing serious injury or death.
32. Use caution when near or crossing driveways, parking lots, roads, and sidewalks.
33. Always run engine at idle for at least one minute (fi ve minutes maximum) for each hour of
previous running, before shutting down engine.
34. Never attempt to service or adjust the blower attachment while engine is running.

6
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
SAFETY INFORMATION DECALS
The following decals are intended to alert you to potential hazards and to provide you
with important safety information. Should these decals become diffi cult to read or
are missing from the mower, contact your Dixe Chopper dealer for a replacement.

7
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
44” Silver Eagle Deck Hanger
DAPDF5044-6
50” Deck Spacer Baffl e
DAPDF5044-5
44”/50” Spindle-Drive
Blower Pulley
0-06-144-0282-0
44”/50” Scroll Baffl e
DAPDF5044 60” Scroll Baffl e
DAPDF60 72” Scroll Baffl e
DAPDF72
44” Front Baffl e
DAPDF5044-11
60” Front Baffl e
DAPDF60-6
50” Front Baffl e
DAPDF5044-10
72” Front Baffl e
DAPDF72-5
V idler Pulley
AVI-56-006
60” Spindle Drive/
Blower Pulley
0-06-144-0279
Flat idler Pulley
FH-5216-2
72” Spindle-Drive
Blower Pulley
0-06-144-0281
Hopper Mounting
Bracket Left
FCPDF001-L
Hopper Mounting
Bracket Right
FCPDF001-R
Front WeighT
CWFPDF
Counterweight
Housing
CWDPDF-1
Counterweight
CWPDF-1
Bagger Ring
F2PDF005
Mounting Bracket
Foot
FCPDF020
PART IDENTIFICATION
50” Pulley Guard
PG50
60”/72” Pulley Guard
PG6072
DCB037
Hose
DAPDF72Kit
72” Deck Kit
DCD077
F2 Bag
FCPDF001-D
Diesel Hopper Kit
2006A62R
A62 Belt
A62 Belt
BLPDF020
Discharge Liner
DAPDF44Kit
44” Deck Kit
FCPDF029
Hardware Kit
DAPDF60Kit
60” Deck Kit
DAPDF50Kit
50” Deck Kit
FCPDF029-1
Clamps
DCT077
F3 Bag

8
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
F5 PART IDENTIFICATION
Ref. #
Part #
Description
1
FCPDF002
Leg
2
FCPDF016-L
Angle Leg LH
Angle Leg LH
3
FCPDF016-R
Angle Leg RH
Angle Leg RH
4
F5PDF002
Main Body
5
FCPDF003
Inlet Tube
6
F5PDF003
F5 Door Assembly
7
F5PDF013
Handle Assembly
8
FCPDF026
Push Bar Straight
9
FCPDF028-R
Latch RH
10
FCPDF028-L
Latch LH
11
FCPDF027-L
Push Bar Left Bent
12
FCPDF027-R
Push Bar Right Bent
13
FCPDF023
Heat Shield
14
FCPDF024
L-Bracket
15
FCPDF025
Stabilizer
16
N/A
Clevis

9
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
1
14
3
4
5
6
7
8
10
9
12
11
2
13
F4 PART IDENTIFICATION
Ref. #
Part #
Description
1
FCPDF002
Leg
2
FCPDF016-L
Angle Leg LH
Angle Leg LH
3
FCPDF016-R
Angle Leg RH
Angle Leg RH
4
F4PDF002
F4 Main Body
5
FCPDF003
Inlet Tube
6
F4PDF003
F4 Door Assembly
7
F4PDF013
F4 Handle Assembly
8
FCPDF026
Push Bar Straight
9
FCPDF027-L
Push Bar Left Bent
10
FCPDF027-R
Push Bar Right Bent
11
FCPDF028-L
Latch LH
12
FCPDF028-R
Latch RH
13
FCPDF023
Heat Shield
14
FCPDF024
L-Bracket

10
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
1
2
3
4
5
6
7
8
9
10
F2 PART IDENTIFICATION
Ref. #
Part #
Description
1
F2PDF004-R
Leg RH
2
F2PDF004-L
Leg LH
3
F2PDF002
Support Frame
4
F2PDF003
Hood
5
F2PDF005
Bag Hoop
6
F2PDF008
Square Tube
7
F2PDF009
Stabilizer Angle
8
F2PDF011
Hood Stop
9
F2PDF010
Stabilizer
10
F2PDF012
Heat Shield
DCD022
Hood Latch
F2PDF014
Hood Spring

11
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
1
2
12
7
8
5
15
11
3
4
6
13
10
9
14
BLOWER ASSEMBLY
PART IDENTIFICATION
Ref. #
Part #
Description
1
BLPDF002
Inlet Plate
2
BLPDF003
Sand Liner
3
BLPDF004
Impeller
4
BLPDF005
Mounting Plate
5
BLPDF006
Mounting Hitch (BLWR)
6
BLPDF007
Engaging Handle (BLWR)
7
BLPDF008
Vertical Alignment Brkt.
8
BLPDF009
Discharge Alignment Angle
9
BLPDF010
Pulley Cover
10
BLPDF011
Belt Take-up
11
BLPDF012
Hitch Adjustment Plate
12
BLPDF013
Handle
13
BLPDF014
Hook Latch
14
BLPDF019
Blower Housing
15
BLPDF016
Alignment Plate
Alignment Plate
BLPDF020
Discharge Liner
B-319
Liner Bolt

12
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Bagger Installation Instructions
(specify deck size when ordering)
Blower Installation
1. Remove OCDC by taking out 3/8” carriage bolts. Save bolts and nuts
for later use.
2. Remove pulley guard and discharge baffl e, if equipped, (Fig. 1-1).
3. Remove hub spindle nut from discharge side with 1-1/2” socket.
4. Install spindle drive blower pulley (collar down), removing washers so
that nut is fl ush with top of shaft, (Fig. 1-1A).
5. If your mower is a 44-inch Silver Eagle, replace the chain with the deck
hanger for belt clearance (Fig. 1-2).
NOTE:
If the machine has a 50-inch deck, a spacer baffl e must be
installed, (Fig.1-3). Before installing the blower mounting
bracket on a 50-inch machine, you must install the spacer.
6. Using bolts removed from the OCDC earlier, mount the blower bracket
to the deck and fi nger-tighten them.
Fig. 1-1
Fig. 1-2
Fig. 1-1A
Fig. 1-3

13
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Blower Installation (continued)
7. Loosen the four receiver bolts on the receiver tower, (Fig. 1-4).
If your mower has a 44- or 50-inch deck, remove the small blow-out baffl e from the blower
assembly. (Fig. 1-5).
8. Install the blower to the receiver bracket. Secure it in position on the tower with the hairpin clip
through the gold clevis pin. Secure the linch-pin at the rear of the assembly.
9. Locate the rear scroll baffl e (component in specifi c deck kit) and loosen the two 5/16” bolts at the
rear of the mounting bracket, (Fig 1-6). Install the baffl e fi nger-tight. Note: Scroll baffl e should be
pushed up against the inside back and top of the deck as tightly as possible to be correctly seated,
(Fig. 1-7,1-8).
10. Tighten the two nuts that were left fi nger-tightened on the mounting bracket, (Fig. 1-6).
11. Tighten the four receiver tower bolts, making sure the blower is at a right angle (90 degrees) to
the deck, (Fig. 1-4). You may have to adjust the blower in order to achieve proper alignment.
Fig. 1-4 Fig. 1-5
Fig. 1-6 Fig. 1-7 Fig. 1-8

14
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
14. Installing the belt.
Procedure for 44” and 50” Deck, (steps 14A-14D)
A. Remove the V-idler mounting bracket from the blower, (Fig. 2-1).
B. Remove idler arm nut to change position of idler arm pulley (center hole is the factory-set
hole). Move to the next bolt hole to the left (closest to the tire) to assure V-idler clearance
with the back tire, (Fig. 2-1A).
C. Reinstall idler arm and pulley (don’t overtighten).
D. Reinstall V-idler mounting bracket.
Procedure for all decks. (44” and 50” decks must fi rst perform steps 14A-14D)
E. Pull idler arm over and latch and hook into place, (Fig. 2-2).
F. Using a 9/16” wrench, loosen the V-idler pulley and install an A62 belt, (Fig. 2-3).
G. Push V-idler toward the tire, push by hand until the belt is somewhat taut and tighten the
bolt on the bottom of the V-idler.
VERY IMPORTANT:
To ensure longevity of the belt,
carefully check the belt alignment.
H. Once tightened, release the idler arm from the hook.
I. Before operating, be sure blower hub is full of grease.
J. Install new pulley guard (Fig. 2-4).
Verify that all fasteners are fully tightened before proceeding.
Blower Installation (continued)
12. Remove front blow-out baffl e from deck (see photo
1-9
). You need to identify the type of deck you
have. The Elite deck has only two blow-out baffl es (
1-10
), while the Standard deck has three
blow-out baffl es (one on each side with a short one in the middle). If it is not an Elite deck,
blow-out baffl es need to be cut at the notches on the baffl es to accommodate the deck, (Fig. 1-11)
13. Install the blow-out baffl e by making sure the wide, angled end
slides into the blower mouth, (Fig. 1-12). Then tighten baffl e down.
Left side baffl e should be lowered to the same level as the new
blow-out baffl e that has been installed. Once baffl es are secure,
fully tighten the mounting bracket bolts in step 6.
A. Remove the V-idler mounting bracket from the blower, (Fig. 2-1).
Fig. 1-9 Fig. 1-10 Fig. 1-11
Fig. 1-12

15
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Blower Installation (continued)
Hopper Installation Instructions
Silver Eagle Hopper Mounting Bracket Installation
1. Remove rear guard (If equipped, muffl er guard, remains on the mower).
2. Using four 3/8”-18 x 1” carriage bolts, re-secure the wheelie bars to
the frame (Fig. 3-1).
3. Using a 3/4” wrench, remove the 1/2” bolts on each side of the rear
of the machine (Fig. 3-2).
4. Locate hopper mounting brackets and four 1/2”-13 x 1-1/4” bolts
(Fig. 3-3).
5. Replace the front bolts with the 1/2”-13 x 1-1/4” bolts from the kit.
In replacing the front bolts, leave 1/2” gap to enable the mounting
bracket to slide into place (Fig. 3-4). Install the back bolts through
the bracket (Fig. 3-5).
6. Securely tighten all four bolts.
Fig. 2-1A
Fig. 2-2
Fig. 2-1
Fig. 3-1
Fig. 3-2
Fig. 2-3
Fig. 3-3 Fig. 3-4
Fig. 3-5
Move to this hole for
44”/50”
Factory setting
Hopper Installation Instructions
Fig. 2-4
Mounting
Holes
Pulley Guard Mounting Diagram

16
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Hopper Installation Instructions (continued)
Standard machine (Classic, Xtremes) Mounting Bracket
Installation
1. Remove rear guard (mowers equipped with a 90-degree tailpipe
will need to have it removed).
2. Locate foot clamps and hardware. (Fig. 3-6)
3. Using foot clamps and hardware provided, attach the hopper
mounting bracket to the frame. Pull back until against the hitch.
(Fig. 3-7)
4. Securely tighten all eight bolts.
Propane/LP 3000 Left Side Mounting Bracket Instructions
1. Perform steps 1-4 for the standard machine mounting bracket
installation for the right side bracket.
Follow the following steps, below, for the left side mounting bracket.
2. Attach mounting bracket to the frame with U-bolts, supplied in
hardware kit, and coupler nuts from the engine guard for the left
side of the propane mower (due to the presence of vaporizer).
(Fig. 3-8).
3. Securely fasten the four bolts on right side and 4 coupler nuts on
left side.
Fig. 3-6
Fig. 3-7
Fig. 3-8

17
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
F2/F4/F5 Hopper Installation Instructions
Pre-installation notes:
F2 Hopper
--The legs may have been turned around due to shipping purposes.
--Loosen the four leg support bolts to accomodate differing frame widths.
(Fig. 4-1).
F4/F5 Hopper
--Loosen the eight leg mounting bolts to accomodate differing frame widths.
(Fig. 4-2).
Hopper Installation
1. Lift hopper into place, sliding the legs squarely into the mounting brackets.
2. Locate the two clevis pins and two hairclip pins,included with kit, and
insert the clevis pin into the hole on the mounting bracket, (Fig. 4-3),
then insert the hairpin clip in the clevis pin on bottom.
3. Using 3/4” wrench, tighten 1/2”-13 bolt on the mounting bracket to
prevent wobbling, (Fig. 4-4).
4. Attach support arms to the mounting brackets with two 1/2”-13 carriage
bolts and two 1/2”-13 whiz-fl ange lock nuts, provided in the kit.
10. Retighten the support arm mounting bracket on the hopper that were
loosened during the pre-installation steps.
Note:
On some machines, it may be necessary to adjust the height
of the legs to prevent hopper lid from hitting the air cleaner.
11. Find the short piece of hose that came with the bagger and the clamp
that came with the hardware kit.
Hopper Installation
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Fig. 4-1 Fig. 4-2
Fig. 4-3
Fig. 4-4

18
Dixie Chopper • 6302 E. County Road 100 N. • Coatesville, IN • 46121 • www.dixiechopper.com
Counterweight Installation
1. Remove the two carriage bolts from the trim side of the mower deck,
(Fig. 5-1).
2. Using the same bolts from previous step, fasten the counterweight to
the deck (Fig. 5-2).
3. Install the front counterweight
A. Silver Eagle
The weight will slide over the frame rails and bolt to the frame (Fig. 5-3).
B. Standard Mowers
The front bumper will need to be loosened and the weight will slide under it. After
fastening weight to the frame, re-tighten bumper hardware (Fig. 5-4).
Notes:
Upon completion of hopper and blower installation, check deck for proper level and pitch.
Center the hopper to the seat so that its weight is distributed evenly.
Hopper Installation (continued)
12. Attach the hose to the hopper lid and use the clamp to tighten it
down. (On some machines, the length of hose may need to be
cut-off to fi t properly.)
Note:
There is no clamp between the short hose and black connector
pipe in order to facilitate ease in disconnecting or cleaning if
clogging occurs.
F4/F5 Door Linkage Adjustment Procedure
1. Put the hopper arm at a position between 3:30 and 4:00 and hold in
this position.
2. Push the door shut while still holding the handle, at the position in
step 1, and attach the top yoke, (Fig. 4-5).
Final note:
Make sure everything that has been loosened is retightened
before operating.
The weight will slide over the frame rails and bolt to the frame (Fig. 5-3).
Fig. 4-5
Fig. 5-1
Fig. 5-2
Fig. 5-3 Fig. 5-4
