Dixie Chopper Zee 2 2348 Manual

700561 2/2017
2017 ZEE 2 Safety, Operation & Maintenance Manual

1 CONTENTS
en-1
1Contents
Contents
Introduction
2.1 Important.............................................................................2
2.2 Product Identification...........................................................3
2.3 Serial Numbers ...................................................................3
2.4 Guidelines for the Disposal of Scrap Products....................4
Safety
3.1 How to Operate Safely........................................................5
Specifications
4.1 Engine Specifications........................................................10
4.2 Dimensions and Weights ..................................................11
4.3 Mower Specification..........................................................13
4.4 Cutting Unit Specification..................................................13
4.5 Belt Specification...............................................................13
4.6 Recommended Lubricants ................................................14
4.7 Accessories.......................................................................14
4.8 Support Literature .............................................................15
Decals
5.1 Safety Decals....................................................................16
5.2 Instruction Decals..............................................................17
Controls
6.1 Mower Controls.................................................................19
6.2 Control Panel ....................................................................20
6.3 Steering Control Levers ....................................................22
6.4 Parking Brake....................................................................22
6.5 Cutting Unit HOC Pedal ....................................................23
6.6 Lift Stop Lever...................................................................23
Operation
7.1 Daily Inspection.................................................................24
7.2 Interlock System................................................................25
7.3 Operating Procedure.........................................................26
7.4 Starting The Engine ..........................................................27
7.5 To Stop The Engine ..........................................................27
7.6 Driving...............................................................................28
7.7 Height of Cut .....................................................................29
7.8 Mowing..............................................................................29
7.9 Mowing On Slopes............................................................30
7.10 Towing The Mower..........................................................32
Maintenance and Lubrication Charts
8.1 Maintenance Chart............................................................33
8.2 Fluid Requirements...........................................................34
Maintenance
9.1 General Precautions .........................................................35
9.2 Engine...............................................................................35
9.3 Engine Oil .........................................................................36
9.4 Engine Air Filter ................................................................37
9.5 Engine Exhaust.................................................................37
9.6 Fuel ...................................................................................38
9.7 Charge the battery ............................................................38
9.8 Battery...............................................................................39
9.9 Drive Axle Fluid.................................................................40
9.10 Tires ................................................................................41
9.11 Wheel Mounting Procedure ............................................41
9.12 Folding ROPS Accessory ...............................................42
9.13 Air Cooling System .........................................................43
9.14 Inspecting Blades............................................................43
9.15 Sharpening Blades..........................................................44
9.16 Electrical System ............................................................44
9.17 Belts ................................................................................45
9.18 Care and Cleaning ..........................................................46
9.19 Mower Storage................................................................47
Adjustments
10.1 General Precautions .......................................................48
10.2 Steering Lever Adjustment..............................................48
10.3 Forward Speed Limit Screws ..........................................49
10.4 Torque Specification .......................................................50
Problem Solving
11.1 General ...........................................................................51
Notes
© 2016, Dixie Chopper/Textron Innovations Inc. “All rights
reserved, including the right to reproduce this material or portions
thereof in any form.”
Proposition 65 Warning
This product contains or release
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Litho In U.S.A. 2-2017

INTRODUCTION 2
en-2
2Introduc tion
2.1 IMPORTANT ______________________________________________________________
The Dixie Chopper Zee 2 2348, 2354, 2348BR, 2354 BR, 2342KO, 2348KO and 2354KO with a Gasoline engine is a
self propelled rotary mower.
If you follow all instructions in this manual, you increase the life of your mower and keep its maximum performance.
Adjustments and maintenance must always be done by an approved technician.
IMPORTANT: Do the maintenance included in this manual to make sure that the quality of cut is kept at a high level.
This SAFETY, OPERATION AND MAINTENANCE MANUAL is part of the mower and must stay with the mower always.
Suppliers of both original and used mowers need to keep the documentation that comes with the mower.
You must use the mower to cut the grass and not for any other purpose. Compliance with the conditions or operation,
service and repair specified by the manufacturer, are understood to be part of the correct use.
ALL operators MUST read through this manual and understand the Safety Instructions, controls, lubrication and
maintenance procedures.
Make sure that you obey all safety and road traffic regulations.
You must not make any changes to the mower that the manufacturer does not approve. This type of change can
release the manufacturer from the liability for any damage or injury.
When you discard worn parts, know the environmental result and use the systems available in the country where the
mower is used. When the mower is at its end of life, there are guidelines in this manual for the removal of the mower
from use.
Use only Dixie Chopper approved parts.
2006/42/EC
The instructions recorded here are the original instructions confirmed by Dixie Chopper, A Textron Company.

2 INTRODUCTION
en-3
2.2 PRODUCT IDENTIFICATION_________________________________________________
Mower Serial number plate
A Product code and Serial number
Location of Mower Serial number plate
The serial number plate (A) is found on the right frame tube near the front
caster wheel mount.
Engine Identification Number
The engine serial number is found on a label on the side of the engine.
Drive Axle Identification Numbers
The drive axle serial number is found on a plate on the drive axle. There will be a separate serial number for each drive
axle.
2.3 SERIAL NUMBERS ________________________________________________________
Record the mower, engine and drive axle serial numbers below:
Mower Number:_________________________
Engine Number:__________________________
Left Drive Axle:__________________________
Right Drive Axle:_________________________
Eight digit serial number
17XXXXXX
BARCODE
A

INTRODUCTION 2
en-4
2.4 GUIDELINES FOR THE DISPOSAL OF SCRAP PRODUCTS _______________________
2.4.1 DURING SERVICE LIFE _____________________________________________________
The used oil, oil filters and engine coolant are hazardous materials. Follow the recommended procedures for their safe
removal.
If a fluid leaks, contain the spill to make sure that the leak does not flow into the ground or drainage system. Follow the
local laws to make sure that leaks are controlled safely.
The maintenance procedures in this manual make sure that the damage that the mower can cause in the local
environment is controlled safely.
Take these actions after the mower complete its full service life.
2.4.2 END OF SERVICE LIFE _____________________________________________________
Use these guidelines with applicable Health, Safety and Environmental laws. Always use the approved local waste
disposal and agencies for recycled materials.
• Park the mower in a location to use all of the necessary lifting equipment.
• Use the correct tools and Personal Protective Equipment (PPE) and take instruction from the technical manuals
applicable to the mower.
• Remove and keep correctly
1. Batteries
2. Fuel
3. Engine coolant
4. Oils
• Disassemble the structure of the mower and refer to the technical manuals. Give attention to parts that have
mechanical pressure or tension applied to the part in the mower, including springs.
• Separate items that continue to have service life and returned to storage.
• Separate items that are worn into the material groups and removed according to the agencies for the recycled
materials that are available. Common types are as shown:
• Steel
• Non ferrous metals
• Aluminum
• Brass
• Copper
• Plastic Materials
• Identified
• Can be recycled
• Can not be recycled
• Not Identified
• Rubber
• Electrical and Electronic Components
• Add items that can not be easily separated into different materials to the “General discarded materials” area.
• Do not burn the discarded materials
Change the mower records to show that the mower is not in service and is discarded. Supply this serial number to Dixie
Chopper Warranty Department to close their records.

3 SAFETY
en-5
3Safety
3.1 HOW TO OPERATE SAFELY ______________________________________________________
3.1.1 SAFE OPERATION
a Read the Operator’s Manual and other training material. If the operator or technician can not read this manual,
the owner is responsible to describe this material to the operators and technicians.
a Read all of the instructions for this mower carefully. Know the controls and the correct operation of the
equipment.
b Children or persons who do not understand these instructions must not use the mower. The local regulations can
limit the age of the operator.
c Never use a mower near persons, including children or animals.
d Remember that the operator or owner is responsible for accidents or hazards that occur to other persons or their
property.
e Never carry passengers.
f Never allow persons to operate or service the mower or its attachments without correct instructions.
g Do not operate equipment while tired, sick or after you use alcohol or drugs.
3.1.2 PREPARATION
a When you operate the mower, wear correct clothing, slip resistant work shoes or boots, work gloves, hard hat,
safety glasses and hearing protection. Long hair, loose clothing or jewelry can be caught in moving parts.
b Do not operate the equipment with the Interlock System disconnected or the system does not operate correctly.
Do not disconnect or prevent the operation of any switch.
c Never operate equipment that is not in correct order or without decals, guards, shields, deflectors or other
protective devices fastened.
d Inspect the mower before you operate the mower. Check the tire pressure, the engine oil level, and the fuel level.
Fuel is flammable. Use caution when you add the fuel to the mower.
e Operate the mower in daylight or in good artificial light. Use caution when you operate the mower during bad
weather. Never operate the mower with lightning in the area.
f Inspect the area to select the accessories and attachments that are needed to correctly and safely do the job.
Only use parts, accessories and attachments approved by Dixie Chopper.
g Be careful of holes in the terrain and other hazards that are not visible.
h Inspect the area where the equipment is operated. Remove all objects you can find before you operate. Be
careful of obstructions above the ground (low tree limbs, electrical wires) and also underground obstacles
(sprinklers, pipes, tree roots). Enter a new area carefully. Look for possible hazards.
i Inspect the cutting system before you start the mower. Make sure the blades are free to rotate. When you rotate
one blade, other blades can rotate.
WARNING
EQUIPMENT OPERATED INCORRECTLY OR WITHOUT TRAINING CAN BE DANGEROUS.
Know the location and correct operation of controls. Operators without experience must receive instruction from
another person that knows the correct operation of the equipment before you operate the mower.
Only use parts, accessories and attachments approved by Dixie Chopper.
!

SAFETY 3
en-6
3.1.3 OPERATION
a Never operate the engine without enough ventilation or in an enclosed area. The carbon monoxide in the exhaust
fumes can increase to dangerous levels.
b Never carry passengers. Keep other persons or animals away from the mower.
c Disengage all drives and engage the parking brake before you start the engine. Only start the engine with the
operator in the seat. Never start the engine with persons near the mower.
d Keep your legs, arms and body inside the operator compartment while the mower is in operation. Keep your
hands and feet away from the cutting units.
e Do not use on the slopes greater than the safe slope limit for the equipment.
f To guard against over turning or loss of control:
– Operate the mower up and down on the face of slopes (vertically), but not across the face (horizontally).
– Do not start or stop suddenly on slopes.
– Decrease the speed when you operate on slopes or when you must turn. Use caution when you change
direction. Turf condition can change the mower stability.
– Use caution when you operate the mower near drop-offs, ditches or embankments.
– Be careful of holes in the terrain and other hazards that are not visible.
g When you drive in the reverse direction, look behind you and down to make sure the path is clear. Do not operate
the cutting unit when you drive in the reverse direction.
h Use caution when you go near corners, trees or other objects that can prevent a clear view.
i Equipment must meet the current regulations to be driven on the public roads.
j Before you move across or operate on the paths or roads, turn off the PTO switch, lift the cutting unit and travel at
decreased speed. Look for traffic.
k Stop the blades when the mower is on any surface that is not grass.
l Do not release the cut grass in the direction of persons or allow persons near the mower while in operation.
m Do not operate the mower with damaged guards or without safety devices in position.
n Do not change the engine governor setting or over-speed the engine. Never change or tamper with adjusters that
are closed with a seal for the engine speed control.
o Before you leave the operator compartment, for any reason:
– Disengage all the drives and lower the cutting unit to the ground.
– Engage the parking brake.
– Stop the engine and remove the key.
p When you hit an object or mower starts to cause the vibration that is not normal, inspect the mower for damage
and make repairs.
q Decrease the throttle setting before you stop the engine.
r Do not use this equipment for uses that the mower was not made for.

3 SAFETY
en-7
3.1.4 OPTIONAL ROPS ACCESSORY
a The ROPS is a safety device. Keep the ROPS in the vertical and locked position. Always use the seat belt when
you operate the mower. Make sure the seat belt can be released quickly in an emergency.
b Only operate the mower with the ROPS in the folded position on flat and level surfaces when necessary. Do not
operate the mower with the ROPS in the folded position on slopes, near sharp edges or near water. There is no
roll over protection with the ROPS in the folded position.
c Check for clearance before you drive below objects. Do not contact tree branches, electrical wires or other
objects with the ROPS.
d Do not use the seat belt with the ROPS in the folded position.
e Inspect the ROPS for damage. Keep the ROPS hardware fastened.
f Do not weld, drill, change or bend the ROPS. Replace a damaged ROPS. Do not try to correct a damaged
ROPS.
g Do not remove the ROPS from the mower.
h Dixie Chopper must approve any changes to the ROPS.
3.1.5 SAFE HANDLING OF FUELS
a The fuel and the fuel vapors are flammable. Use caution when you add the fuel to the mower. The fuel vapors
can cause an explosion.
b Never use the containers that are not approved to keep or transfer fuel.
c Never keep the mower or fuel containers near an open flame or any device that can cause the ignition of fuel or
fuel vapors.
d Never fill the fuel containers inside a vehicle or on a truck or trailer with a plastic liner. Always put the fuel
container on the ground away from your vehicle before you fill the container.
e Refuel the mower before you start the engine. When the engine is in operation or while the engine is hot, never
remove the fuel cap or add fuel to the mower.
f Refuel outdoors only and do not smoke when you add fuel. Extinguish all types of ignition.
g The fuel nozzle must touch the rim of the fuel tank when you add fuel to the mower. Do not use a device to lock
the fuel nozzle in the open position.
h Do not over fill the fuel tank. Leave at least 1 inch (2.5 cm) below the filler neck.
i Always tighten the fuel tank cap and container cap after you add fuel.
j If the fuel spills on your clothing, change your clothing immediately.
3.1.6 MAINTENANCE AND STORAGE
a Before you clean, adjust or repair this equipment, push PTO switch to the OFF position, lower the cutting unit to
the ground, engage the parking brake, stop the engine and remove the key.
b Make sure the mower is parked on a solid and level surface.
c Never work on a mower that is lifted only by the jack. Always use the jack stands.
d Never allow persons to service the mower or its attachments without correct instructions.
e When the mower is parked, put into storage or left without an operator, lower the cutting device unless a positive
mechanical lock is used.
f When you put the mower on a trailer or put the mower in storage, close the fuel valve. Do not keep fuel near
flames or drain the fuel inside a building.

SAFETY 3
en-8
g Disconnect the battery before you service the mower. Always disconnect the negative battery cable before the
positive battery cable. Always connect the positive battery cable before the negative battery cable.
h Charge the battery in an area with good airflow. The battery can release hydrogen gas that is explosive. To
prevent an explosion, keep any device that can cause sparks or flames away from the battery.
i Disconnect the battery charger from the power supply before you connect or disconnect the battery charger to
the battery. Wear protective clothing and use insulated tools when you service the battery.
j Be careful and wear gloves when you check or service the cutting unit blades. Replace any damaged blades, do
not try to correct a damaged blade.
k Keep your hands and feet away from parts that move. Do not adjust the mower with the engine in operation,
unless the adjustment needs the engine in operation.
l Carefully release the pressure from components with stored energy.
m To prevent injury from the hot, high pressure oil, never use your hands to check for oil leaks. Use the paper or
cardboard to find leaks.
n The hydraulic fluid pressure can have enough force to enter your skin. If hydraulic fluid has entered your skin, a
doctor must remove the hydraulic fluid surgically within a few hours or gangrene can occur.
o When you service the hydraulic system, make sure the hydraulic fittings, tubes and hoses are tightened to the
correct torque. Make sure the hydraulic system is in good condition before you start the engine.
p Keep the mower and the engine clean.
q Allow the engine to become cool before storage and always remove the ignition key.
r Keep all nuts, bolts and screws tight to make sure the equipment is in safe condition.
s Replace worn or damaged parts for safety. Replace damaged or worn decals. Only use parts, accessories and
attachments approved by Dixie Chopper.
t To decrease the fire hazard, remove materials that burn from the engine, muffler, battery tray and fuel tank area.
u Disconnect the battery and controller connectors before you weld on this mower.
3.1.7 WHEN YOU PUT THE MOWER ON A TRAILER
a Be careful when you load or unload the mower on a trailer. Trailer must be wider than the mower and can carry
the weight of the mower.
b Use a full-width ramp to load or unload the mower on a trailer.
c Use straps, chains, cables or ropes to fasten the mower to the trailer. Both front and rear straps must be sent
down and toward sides of trailer.
d Make sure that all latches are correctly fastened.

3 SAFETY
en-9
3.1.8 IMPORTANT SAFETY NOTES _______________________________________________
This safety alert symbol gives a warning of possible hazards.
DANGER - Indicates a dangerous condition that WILL cause death or injury unless it is prevented.
WARNING - Indicates a dangerous condition that CAN cause death or injury unless it is prevented.
CAUTION - Indicates a dangerous condition that can cause injury and property damage unless it is prevented. The
label can indicate work procedures that are not safe.
NOTICE - Indicates a condition that can cause damage to the property unless it is prevented. The label can indicate
work procedures that are not safe.
Some illustrations in this manual show the shields, guards or plates, removed. Do not operate this equipment without
these devices correctly fastened in position.
If additional information or service is needed, contact your Authorized Dixie Chopper Dealer. Your Dealer knows the
current methods to service this equipment.
WARNING
The Interlock System on this mower prevents the operation of the mower
unless a.) The parking brake is engaged. b.) The PTO switch is in the OFF
position and c.) The steering control levers are in the Neutral position. The
system will stop the engine if the operator leaves the operator position
without:
a.) The parking brake engaged
b.) The steering control levers in the Neutral position and
b.) the PTO switch in the OFF position.
NEVER operate the mower unless the Interlock System operates correctly.
WARNING
1. Before you leave the operator position, for any reason:
a. Return the steering control levers to Neutral.
b. Disengage all drives.
c. Lower the cutting unit to the ground.
d. Engage the parking brake.
e. Stop the engine and remove the ignition key.
2. Keep your hands, feet and clothing away from moving parts. Wait for all
movement to stop before you clean, adjust or service the mower.
3. Keep persons and animals away from the area of operation.
4. Never carry passengers.
5. Never operate the equipment without a correctly fastened grass
deflector in position.
!
!

SPECIFICATIONS 4
en-10
4Specifi cations
4.1 ENGINE SPECIFICATIONS __________________________________________________
ZEE 2 2348 / 2354 2348BR / 2354BR 2342KO / 2348KO / 2354KO
Make Kawasaki Briggs & Stratton Kohler
Model FR691V 44T777 KT730
Type Four cycle, air cooled, V-Twin,
OHV
Four cycle, air cooled, V-Twin,
OHV
Four cycle, air cooled, V-Twin,
OHV
Number of Cylinders 2 2 2
Bore and Stroke 3.07 x 2.99 in.
(7.8 x 7.6 cm)
3.12 x 2.89 in.
(7.92 x 7.34 cm)
3.27 x 2.64 in.
(8.3 x 6.7 cm)
Total Displacement 44.3 in3(0.726 l) 44.2 in3(0.724 l) 44.2 in3(0.725 l)
Intake System Naturally Aspirated Naturally Aspirated Naturally Aspirated
Gross Intermittent
Power
23.0 hp (17.2 kW) @ 3600
RPM
23.0 hp (17.2 kW) @ 3600
RPM
23 hp (17.2 kW) @ 3600 RPM
Compression Ratio 8.2:1 8.5:1 9.1:1
Maximum Speed 3600 ± 100 rpm (No Load) 3600 ± 100 rpm (No Load) 3600 ± 100 rpm (No Load)
Low Idle 1550 ± 100 rpm (No Load) 1750 ± 100 rpm (No Load) 1750 ± 100 rpm (No Load)
Rotation Clockwise viewed at flywheel Clockwise viewed at flywheel Clockwise viewed at flywheel
Fuel System Single Barrel Float Feed
Carburetor
Single Barrel Float Feed
Carburetor
Single Barrel Float Feed
Carburetor
Fuel 87 Octane Gasoline
Maximum 10% Ethanol
87 Octane Gasoline
Maximum 10% Ethanol
87 Octane Gasoline
Maximum 10% Ethanol
Ignition System Two magnetos triggered by
flywheel magnets
Two magnetos triggered by
flywheel magnets
Two magnetos triggered by
flywheel magnets
Spark Plug NGK BPR4ES B&S 491055 Kohler 12 132 02
Spark Plug Gap 0.030 Inch (0.76 mm) 0.030 Inch (0.76 mm) 0.030 Inch (0.76 mm)
Engine Oil (API
Class)
SF, SG, SH, SJ or SL SF, SG, SH, SJ or higher SJ or higher
Oil Pan Capacity 2.3 quarts (2.2 l) 2.0 quarts (1.9 l) 2.0 quarts (1.9 l)
Starter 12 Volt Electric Start 12 Volt Electric Start 12 Volt Electric Start
Alternator 12 Volt, 15 Amp 12 Volt, 15 Amp 12 Volt, 15 Amp
Dry Weight 88 lb. (39.9 kg) 84 lb. (38.1 kg) 85 lb. (38.6 kg)
Dimensions
(Length x Width x
Height)
19.6 x 17.99 x 15.08 in.
(49.8 x 45.7 x 38.3 cm)
19.3 x 19.4 x 15.7 in.
(49.0 x 49.2 x 39.9 cm)
18.7 x 17.5 x 13.9 in.
(47.5 x 44.45 x 35.31 cm)
Emission Regulation

4 SPECIFICATIONS
en-11
4.2 DIMENSIONS AND WEIGHTS________________________________________________
2342KO 2348 / 2348BR / 2348KO 2354 / 2354BR / 2354KO
A - Width of Cut 42 inch (106.7 cm) 48 inch (121.9 cm) 54 inch (137.2 cm)
B - Maximum
Width
51.5 inch (130.8 cm) 57.5 inch (146.0 cm) 64 inch (162.6 cm)
C - Height 47 inch (119.4 cm)
D - Total length 76 inch (193.0 cm)
E - Wheel Base 43.4 inch (110.2 cm)
F - Front Wheel
Track
31.63 inch 34.38 inch (87.6 cm)
G - Rear Wheel
Track
35.88 inch (91.1 cm)
Weight of unit 730 lb. (331.1 kg) 750 lb. (340.2 kg) 763 lb. (346.1 kg)
Tire Specifications
Front Wheel Rear Wheel
Tire Size Type Tire Pressure Tire Size Type Tire Pressure
13 x 6.5-6 N/A 42 in. Mower
20 x 8-10
48 and 54 in.
20 x 10-8
Grass
Master
8-10 psi (0.55-0.69 BAR)

SPECIFICATIONS 4
en-12
E
A
G
F
B
D
C

4 SPECIFICATIONS
en-13
4.3 MOWER SPECIFICATION ___________________________________________________
Battery: 12V, 300 CCA
Service Brake: Dynamic braking through the traction circuit
Parking Brake: Hand lever connected to brake in both drive axles
Fuel Tank: 4 U.S. Gallons (15.1 l)
Steering: Hand lever speed and direction controls for left and right rear wheel
Traction Drive: Belt driven dual hydrostatic Hydro-Gear ZT-2800 drive axle
Cutting Unit Drive: Belt drive with electric clutch
Ground Speed: 0-7 mph (0-11.27 kph)
42 in. Deck Cutting Performance: Up to 2.4 acres/hr. (1.64 hectares/hr) @7 mph (11.27 km/hr)
48 in. Deck Cutting Performance: Up to 2.7 acres/hr. (1.96 hectares/hr) @7 mph (11.27 km/hr)
54 in. Deck Cutting Performance: Up to 3.1 acres/hr. (2.35 hectares/hr) @7 mph (11.27 km/hr)
4.4 CUTTING UNIT SPECIFICATION _____________________________________________
4.5 BELT SPECIFICATION _____________________________________________________
Traction Belt Part Number 200572, A-Section, Raw, 64 in. EL Belt
42 in. Deck Belt Part Number 300996, A-Section, Wrapped, 133 in. EL Belt
48 in. Deck Belt Part Number 300995, B-Section, Wrapped, 146 in. EL Belt
54 in. Deck Belt Part Number 300997, B-Section, Wrapped, 159 in. EL Belt
2342KO 2348 / 2348BR / 2348KO 2354 / 2354BR / 2354KO
Blade Length 15-1/4 inch (38.7 cm) 17-1/4 inch (43.8 cm) 19-1/4 inch (48.9 cm)
Number of blades 3
Height of cut 1-1/2 to 4-1/2 in. (3.8 to 11.4 cm) in 1/2 in. (1.27 cm) increments
Height of cut
adjustment
A foot lever to lift or lower the cutting unit with a HOC pin installed in different holes for
specified HOC.
Blade Tip Speed
@ 3600 rpm engine
speed
290.5 feet/second (88.5
meters/second)
287.4 feet/second (87.6
meters/second)
269.4 feet/second (82.1
meters/second)

SPECIFICATIONS 4
en-14
4.6 RECOMMENDED LUBRICANTS ______________________________________________
Engine Oil:
Kawasaki Engine: API Classification grades SF, SG, SH, SJ or SL
Briggs & Stratton Engine: API Classification grades SF, SG, SH, SJ or higher
Kohler Engine: API Classification grades SJ or higher
Drive Axle Fluid:
The standard drive axle fluid is SAE 20W50 API Classification SL.
Grease:
Texaco Starplex 2EP Moly (NLGI Grade 2-EP Lithium Complex Grease containing Molybdenum Disulfide) or
equivalent.
4.7 ACCESSORIES____________________________________________________________
4.7.1 STRIPING KIT _____________________________________________________________
Kit Number 902773
4.7.2 ROLL BAR HARDWARE KIT _________________________________________________
Kit Number 902782
Temperature Viscosity
Above 95° F (35° C) SAE 40
68° to 95° F (20° to 35° C) SAE 30 or SAE 10W-30 or SAE 10W-40 or SAE 40
32° to 68° F (0° to 20° C) SAE 30 or SAE 10W-30 or SAE 10W-40
-4° to 32° F (-20° to 0° C) SAE 5W-20 or SAE 10W-30 or SAE 10W-20
Below -4° F (-20° C) SAE 5W-20
Temperature Viscosity
Above 95° F (35° C) SAE 30 or Synthetic SAE 5W-30
40° to 95° F (4° to 35° C) SAE 30 or SAE 10W-30 or Synthetic SAE 5W-30
-0° to 40° F (-18° to 4° C) SAE 5W30 or SAE 10W-30 or Synthetic SAE 5W-30
Below -0° F (-18° C) SAE 5W30 or Synthetic SAE 5W-30
Temperature Viscosity
Above 50° F (10° C) SAE 30 or SAE 10W-30
32° to 50° (0° to 10° C) SAE 10W-30
0° to 32° F (-18° to 0° C) SAE 5W-30 or SAE 10W-30
Below 0° F (-18° C) SAE 5W-30

4 SPECIFICATIONS
en-15
4.7.3 COMPLETE ROPS KIT _____________________________________________________
Kit Number 902676
4.7.4 SEAT BELT KIT ___________________________________________________________
Kit Number 902784
4.7.5 SEAT CABLE KIT _________________________________________________________
Kin Number 902827
4.7.6 QUICK LIFT KIT ___________________________________________________________
Kit Number 902935
4.7.7 REPLACMENT BLADES ____________________________________________________
Standard 15-1/4 inch (38.7 cm) High Lift Blade Part Number 301067E (For 42 inch (106.7 cm) cutting unit)
Standard 17-1/4 inch (43.8 cm) High Lift Blade Part Number 301068E (For 48 inch (121.9 cm) cutting unit)
Standard 19-1/4 inch (48.9 cm) High Lift Blade Part Number 301069E (For 54 inch (137.2 cm) cutting unit
4.7.8 COMPLETE DECK ASSEMBLY ______________________________________________
42 inch (106.7 cm) Kit Number 300945
48 inch (121.9 cm) Kit Number 300946
54 inch (137.2 cm) Kit Number 300947
4.7.9 MULCHER KIT ____________________________________________________________
42 inch (106.7 cm) Kit Number 903010
48 inch (121.9 cm) Kit Number 903011
54 inch (137.2 cm) Kit Number 903012
4.7.10 OCDC KIT _______________________________________________________________
42 inch (106.7 cm) Kit Number 301428
48 inch (121.9 cm) Kit Number 301429
54 inch (137.2 cm) Kit Number 301430
4.8 SUPPORT LITERATURE ____________________________________________________
Contact your Dixie Chopper Dealer for a complete listing of literature available for your mower.
Operator’s Manual: 700561
Mower Parts Manual: 700583

DECALS 5
en-16
5Decals
5.1 SAFETY DECALS__________________________________________________________
Understand the purpose of these decals. The decals are important to the safe operation of the mower. REPLACE THE
DAMAGED DECALS IMMEDIATELY.
30229
800817
Read the manual
before you operate the
mower
Pick up sticks, stones
and other debris that
can be thrown by the
mower.
Wear eye protection
when you operate the
mower.
Wear ear protection
when you operate the
mower.
Keep bystanders away
from the mower.
Be careful of debris
thrown by the mower.
Use caution when you
operate on slopes.
Only operate on slopes
with the ROPS in the
vertical position.
Do not carry
passengers.
Serious injury or death can result from blade contact or from contacting
the belts or pulleys with the engine running. Deck spindles may have a
fan installed above or below the pulleys.
Do not operate the mower with the discharge chute or belt guards
removed. Make sure the Interlock System is operates correctly.
800848
DO NOT OPERATE WITHOUT OPERATOR CONTROLLED
DISCHARGE CHUTE (OCDC), DISCHARGE DEFLECTOR,
ENTIRE GRASS COLLECTION SYSTEM, OR MULCHING
KIT IN PLACE. DO NOT REMOVE GRASS CATCHER
UNTIL BLADES HAVE STOPPED.
MAXIMUM TONGUE WEIGHT
100 lbs.
WARNING
800208
800818
MAX. FILL
Only fill the fuel tank to the
bottom of the fuel filler
neck. Do not overfill the
fuel tank.

5 DECALS
en-17
5.2 INSTRUCTION DECALS ____________________________________________________
WHEN ADDING OIL FOR TRANSAXLES,
USE MULTIVISCOSITY SAE 20W-50 OIL
DO NOT ADD AUTOMATIC TRANSMISSION FLUID
OR HYDRAULIC FLUID!
THIS WILL VOID WARRANTY
MAINTAIN OIL LEVEL TO THE COLD FILL
CHECK OIL WHEN COLD.
LINE ON THE DRIVE OIL EXPANSION TANK (APPROXIMATELY 1/4”
FROM BOTTOM) DO NOT TOP OFF !
OIL/FILTER CHANGE TO BE PERFORMED
BY AUTHORIZED DIXIE CHOPPER SERVICE DEALER ONLY!
DRIVE OIL EXPANSION TANK
CAUTION
800192
Transaxle service interval: Initial 75 hrs., every 400 hrs thereafter
800842
R
800843
L
Fast Reverse
Slow Reverse
Slow Forward
Fast Forward
Neutral Neutral Lock
Position
Neutral Lock
Position
Left Side
Steering Lever
Right Side
Steering Lever
Height of Cut

DECALS 5
en-18
800846
Engaged
Position
Disengaged
Position
Fast
Slow
Engine
Throttle
PARKING
BRAKE
800845
REAR
1.) Engine to Transmission Belt
2.) Engine to Deck Belt
FRONT800903
1
2
No Step

6 CONTROLS
en-19
6Controls
6.1 MOWER CONTROLS_______________________________________________________
6.4
6.5
6.6
6.3
6.2
